Zero Z06 Quick guide

zero
HOME AUTOMATION
Z06 - SWING GATE
PG1
USER MANUAL AND CONFIGURATION
Z06.REV01.2018
IT | EN | FR
zero
HOME AUTOMATION Z06 - SWING GATE MOTOR
SUPPLY 230-24V

zero
HOME AUTOMATION Z06 - SWING GATE
PG2
zero
HOME AUTOMATION

zero
HOME AUTOMATION
Z06 - SWING GATE
PG3
INDEX
01. SAFETY INSTRUCTIONS
02. OPERATOR
TECHNICAL SPECIFICATIONS
DIMENSIONS
03. INSTALLATION
INSTALLATION STEPS
04. MAINTENANCE
MANUEL RELEASE
05. TROUBLESHOOTING
01. SAFETY INSTRUCTIONS
ATTENTION:
•To ensure the safety of people, it is important that you read all the following instrucons.
Incorrect installaon or incorrect use of the product can cause physical injury and material
damage.
•Keep these instrucons in a safe place for future reference.
•This product was designed and produced strictly for the use indicated in this manual. Any
other use, not expressly indicated here, could compromise the good condion/ operaon of
the product and/or be a source of danger.
•ZERO SRLS. is not responsible for the improper use of the product, or other use than that
for which it was designed.
•ZERO SRLS. is not responsible if safety standards were not taken into account when instal-
ling the equipment, or for any deformaon that may occur to it.
•ZERO SRLS. is not responsible for the safety and proper operaon when using components
not sold by them.
•Do not make any modicaons to the operator components and / or their accessories.
•Before installaon unplug the automasm from the source of power.
•The installer must inform the client how to handle the product in case of emergency and
provide this manual to user.
•Keep remote controls away from children, to prevent the automated system from being
acvated involuntarily.
•The customer shall not, under any circumstances, aempt to repair or tune the operator
.Must call qualied technician only.
•Connect the automasm to a 230V plug with ground wire.
•Operator for outdoor and indoor use.

zero
HOME AUTOMATION Z06 - SWING GATE
PG4
02. OPERATOR
TECHNICAL SPECIFIATIONS
Z02 specicaons are as follow:
DIMENSIONS
Z06 dimensions are the following:
Z06 Z06.24
Power Supply 230Vac 50/60Hz 24Vdc
Power 280W 50W
Current 1,4 A 3 A
Capacitor 12.5µF -
RPM 1400 1800
Maximum gate weight/leaf 500 kg
Torque 250 Nm
Operang temperatures -25°C to 65°C
Thermal protecon 120°C -
Protecon class IP67
Working frequence 25% INTENSIVE
Opening me 16 seconds

zero
HOME AUTOMATION
Z06 - SWING GATE
PG5
03. INSTALLATION
INSTALLATION STEPS
GATE LEAF OPENING ANGLE: Establish the required opening angle.
1. Dig a hole big enough to hold the box contai-
ning the operator (C1).
2. Insert the tube for water drainage in the
prepared hole (F1). Insert the sheath for laying
the power cables (F2).
3. Cement so that the box cannot be moved,
wait for it to dry and then assemble the opera-
tor and levers.
Note: while posioning the box, keep in mind
the minimum distance there must be between
the pillar and the centre of rotaon of the gate
hinge.
It is important to respect this instal-
laon order!
Otherwise, it is not possible to ensu-
re correct installaon and operators
may not work properly!

zero
HOME AUTOMATION Z06 - SWING GATE
PG6
It is very important that these dimen-
sions are respected! Only this way
can be as- sured the correct funco-
ning and durability of the operators!
It is also very important to have a
levelled ground/terrain!
1. Insert the motor into the foundaon case
and xit with nuts and washers supplied.
2. Insert the ball in the pin located on the box
and t the gate anchorage lever (L1).
3. Put the connecon lever(L2) between the le-
vers (L3) and (L1) and block it with screws and
washers supplied.
4. Insert the cover and fasten it with the screws
provided posion
5. Posion the gate wing and the lever (L1) so
that they are perfectly aligned and fasten them
by welding or similar.

zero
HOME AUTOMATION
Z06 - SWING GATE
PG7
LIMIT SWITCHES ASSEMBLY (OPTIONAL)
Insert, regulate and block the mechanical limit switches in the desired posion.
OPENING CLOSING
It is important to use mechanical stoppers in the opening and closing posion of
the gate. If not respected, components of the automaon may suer eorts for
which they were not prepared, and as a result will be damaged.
It is important to use juncon boxes for connecons between motors, components
and control unit. All cables must enter and exit on the boom of the juncon and
control board box.
04. MAINTENANCE
Check motor supports: Make sure that supports remain well xed on the pillars and
gate to ensure proper funconing of the equipment.
These maintenance measures must be applied every year in order to insure proper
funconing of the automated system.
MANUAL RELEASE
To open manually the gate in case of electric
power failure or in case of damage, follow
the below steps:
Insert the key C provided into the appropria-
te hole on the lever L1 and turn the key.

zero
HOME AUTOMATION Z06 - SWING GATE
PG8
Problem Procedure Behavior Procedure II
Door doesn’t
work
Make sure you have 230V
power supply connected
to control board and if it
is working properly.
Sll not working. Consult a qualied ZERO
technician.
Motor doesn’t
move but makes
noise
Unlock motor and move
the gate by hand to check
for mechani cal problems
on the movement
Encountered problems? Consult an experienced
gate expert.
The gate moves easily? Consult a qualied ZERO
technician.
Motor opens
but doesn’t
close
Unlock motor and move
the gate by hand to closed
posion.
Lock motor again and turn
o power supply for 5 se-
conds. Reconnect it and
send start signal using
transmier.
Gate opened but didn’t clo-
se again.
Check if there is any obsta-
cle in front of the photo-
cells;
Check if any of the control-
devices (key selector, push
buon, video intercom,
etc.) of the gate are jam-
med and sending perma-
nent signal to control unit;
Consult a qualied ZERO
technician.
Gate doesn’t
make complete
route
Unlock motor and move
ate by hand to check for
mechanical problems on
the gate
Encountered problems? Consult an experienced
gate expert.
The gate moves easily? Consult a qualied ZERO
technician.
05. TROUBLESHOOTING

zero
HOME AUTOMATION
Z06 - SWING GATE
PG9
Discovering the origin of the problem
1. Open control board
and check if it has
230V power supply
2. Check input fuses
3. Disconnect the motor
from control board and
test them by connecng
directly to power supply
in order to nd out if they
have problems.
4. If the motor works,
the problem is on the
control board. Pull it out
and send it to our ZERO
technical services for
diagnosis.
5. If the motor doesn’t
work, remove them
from installaon site
and send to our ZERO
technical services for
diagnosis.
Check all moon axis and associated moon systems related with the motor and the gate to nd out
what is the problem.
1. Check capacitors,
tesng operator with
new capacitors;
2. If capacitors are not the
problem, disconnect mo-
tors from control board
and test them by con-
necng directly to power
supply in order to nd out
if they have problems.
3. If the motors work,
the problem is from
control board. Pull it out
and send it to our ZERO
technical services for
diagnosis;
4. If the motors don’t
work, remove them
from installaon site
and send to our ZERO
technical services for
diagnosis
All ZERO control boards have LEDs that indicate the funconing of connecons to allow easy diagnosis
of faults. All safety devices LEDs (DS) in normal situaons remain On. All “START” circuits LEDs in normal
situaons remain O.
If LEDs devices are not all On, there is some security systems malfuncon (photocells, safety edges),
etc.
1 • Close with a shunt all safety systems on the control board (check manual of the control board in
queson). If the automated system starts working normally check for the problemac device.
2 • Remove one shunt at a me unl you nd the malfuncon device .
3 • Replace it for a funconal device and check if the motor works correctly with all the other devices. If
you nd another one defecve, follow the same steps unl you nd all the problems.
1. Check capacitors,
tesng with new ca-
pacitors;
2. If capacitors are not
the problem, discon-
nect motor from con-
trol board and test it
by connecng directly
to power supply in or-
der to nd out if it is
broken;
3. If the motor doesn’t
work, remove it from in-
stallaon site and send to
our ZERO technical servi-
ces for diagnosis.
4. If motor work well
and move gate at full
force during the enre
course, the problem is
from controller. Set force
using P1 buon on the
board. Make a new wor-
king me programming,
giving sufcent me for
opening and closing with
appropriate force.
5. If this doesn’t work,
remove control unit and
send it to ZERO techni-
cal services services.
Check all moon axis and associated moon systems related with the motor and the gate to nd out
what is the problem.
NOTE: Seng force of the controller should be sufcient to make the gate open and close without stop-
ping, but should stop and invert with a lile eort from a person. In case of safety systems failure, the gate
shall never cause physical damaged to obstacles (vehicles, people, etc.).

zero
HOME AUTOMATION Z06 - SWING GATE
PG10
NOTE:
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________

zero
HOME AUTOMATION
Z06 - SWING GATE
PG11
zero
HOME AUTOMATION

zero
HOME AUTOMATION Z06 - SWING GATE
PG12
zero
HOME AUTOMATION
ZERO SRLS
Via ROMA 25/A ALTAVILLA VIC.
ITALIA
info@miozero.it - www.miozero.it
