ZKETECH EBC-A05 User manual

http://www.zketech.com
EBC-A05 User Manual
Copyright (C) 2006-2015 ZKE Technology
Multifunction Electronic Load
EBC-A05）
UserManual

http://www.zketech.com
EBC-A05 User Manual
Copyright (C) 2006-2015 ZKE Technology
1.Features
1.1 BatteryCapacity Test
Thistester isdesignedforchargingand dischargingofawiderangeofbatteries,including
NiMH, NiCd, LiPo, LiFeand Pb, as well as thecapacitytest.
1.2 PortablePower Bank Test
This tester supports chargingand dischargingofportablepowerbanks, aswell as capacitytest.
1.3 Power PerformanceTest
This tester supports performance and agingtests ofvarious kinds ofDCpower supplies.
2. Specifications
1)Power Supply:DC12V/3.5Aorabove
2)VoltageRange:0-4.500V/4.50V-30.00V
3)CurrentRange:0.1-5.000A
4)ChargingFunction:(Thistester canchargesinglebatteryorbatterypacks up to10Vat
0.1-3.00A. Maxcharging current=Power current 0.5A)
²Standard Charging:SupportNiMH, NiCd, LiPo, LiFeand Pb batteries
²CVCharging:SupportcustomCC-CVcharging
²Fixed Output: 5V/2Aoutput, supportchargingportablepower banks and cell phones
5)Discharging:(0-30.00V, 0.1-5.00A, maxpower60Wand automaticcurrentlimitingabove)
²CC Discharging:Dischargingarelativelyuniformcurrent,supporttestingbatterycapacity
orcurrentofpowersupplies
²CPDischarging:Dischargingarelativelyuniformpower, forconstantpower
equipment-likeuseortestingpower
6)AutomaticCharging/Discharging:Thetester support “charging-discharging-charging”mode
in capacitytests.
7)LCDDisplay:voltage,current, time, capacity, power, energy, and etc
8)PC Connection:Thetester canbeconnectedtoacomputer throughadesignatedUSB-TTL
cableto havemore functions.

http://www.zketech.com
EBC-A05 User Manual
Copyright (C) 2006-2015 ZKE Technology
3. Connectingpattern
EBC-A05
A+ V+ V- A-
Battery
+-
COMM Power
3.1 TestingPorts
Thetester hasfourbananajacks whichconnectwithA+/V+/V-/A-.A+and A- portsare
connectedwiththepositiveand negativepolesofthetestobjects, workingasthecurrent
channelincharginganddischarging.V+and V-portsare connectedwiththepositiveand
negativepolesofthetestobjects, workingasthevoltagechannelinvoltagetests. Thiswayof
usingfourindividualcableswill helpeliminatetheeffectofwiresonthetestresult and
improvethetestprecision.
3.2 PC Connection
Thetester can beconnected with acomputer through adesignated USB-TTLcable.
3.3 InputPower:
Thetesterworks onapower supplyofaboveDC12V/3.5Aand interface specification of
5.5/2.1 (insidepositiveand outsidenegative).
4. Display and setting
4.1 Buttons
ON —— startand stop
SET —— setup and switch
INC—— pageup and increase
DEC —— pagedown and decrease
4.2 TestingInterface

http://www.zketech.com
EBC-A05 User Manual
Copyright (C) 2006-2015 ZKE Technology
Thefirstlineshows testingmode, voltageand current.Testingmodes include:
²CC constantcurrentdischarging
²CP constantpower discharging
²NiNiMH/NiCd charging
²LiLiPo/LiFecharging
²Pbplumbicacid batterycharging
²CV customconstantvoltagecharging
²PW fixed voltageoutput(5V/2A)
Thesecondlineshowsworking process, workingtime(inminute) andcapacity(automatic
switch between 0000mAh and 00.00Ah).
Workingprocess reads OFF whentheteststopsand DSCorCHG intesting.ItshowsAT1 if
you chooseautomaticcharging/dischargingand 1 means thestep 1 ofcurrenttesting.
Ashortpress on the “SET”button and thedisplaychanges to power and energy.
Inautomatic “charging-discharging-charging”test,you canchecktestresultsofeachstepbya
shortpress on “INC”or “DEC”buttons.
Press the “ON”button to starttestingand onemorepress to stop.
You canopensettinginterface bypress on the “SET”button for2seconds inthestop state
(This function is invalid when thetester beingconnected with thePC software).
4.3 SettingInterface
Thecursordefault ison modesetting.Press the “SET”button tomoveit tothevalueyouwant
tosetup. Onepress on “SET”and thecursormovesonedigitaltowardright.Press the “INC”
and “DEC”buttons tomodifythevalue.Press the “ON”button themovetothenextitem.It
will go back to thelimit valueifyoursettingexceeds theallowed range.
1)CC discharging
Firstline:modeand dischargingcurrentsetting.
Second line:cut-offvoltage(testingautomaticallystops whenvoltagereachesbelowthisvalue)
and themaximumtestingtimesetting(no timelimit ifbeingset0).
2)CPdischarging

http://www.zketech.com
EBC-A05 User Manual
Copyright (C) 2006-2015 ZKE Technology
Firstline:modeand dischargingpowersetting
Second line:cut-offvoltage(testingautomaticallystops whenvoltagereachesbelowthisvalue)
themaximumtestingtimesetting(no timelimit ifbeingset0).
3)Standard charging
Firstline:modeand chargingcurrentsetting. Modes include:NiMH, NiCd, LiPo, LiFe, Pb
Second line:batteriesnumbers(plumbicacid:2Vforeachbattery),chargingtime(no time
limit ifbeingset0)and auto modesetting:
²NOR normalmode, chargingwill finish soon.
²AUTO automaticallyfinish the “charging-discharging-charging”process.
Whencursorison AUTO,along press on “ON”and you will movetothesecond stepofauto
dischargingsetting.
Thefirstparameter:dischargingcurrent; thesecond parameter:cut-offvoltage;thethird
parameter:intervalbetweenstepswitches(a 5-10minutewaitingtimeissuggestedinaswitch
betweenchargingand dischargingto coolthebattery).
4)Customcharging
Firstline:modeand chargingcurrentsetting
Second line:CVvoltage,cut-offcurrent(testing stops whenthevoltagereachesbelowthis
value, can besetabove0.06A) and automaticmodesetting(samesettingasstandard charging).
5)Fixed voltageoutput
Select “CHG-PWR”forfixedvoltageoutputanddon’tneedtosetanyother parameter.The
modeturns offifthecurrentbecomes 0 within 10 seconds oftesting.
In settingmode,alongpress on “SET”button to savedataand return to testinginterface.
When settingcompletes, press “ON”button on thetestinginterface and testingstarts.
4.4 Settingexamples

http://www.zketech.com
EBC-A05 User Manual
Copyright (C) 2006-2015 ZKE Technology
1)CC dischargingsettings (3.7VLiPo to 2.8Vat2A)
2)CC dischargingsettings (12Vpower/60-minutedischargingat1.5A)
3)Standard chargingsettings (3.7VLiPo, chargingto 4.2Vat1A)
4)Customchargingsettings (3.7VLiPo, charging to 4.2Vat1A, cut-offcurrentsetat0.08A)
5)Autotest(3.7 LiPo, chargingat1Aand dischargingat2A,seta5-minuteintervalbetween
chargingand discharging)
5. Precautions
1)Positiveand negativeconnections should notbereversed.
2)Always usethetester within theallowed range.
3)Themaximumchargingcurrentshould besetbelowpower current 0.5A.
4)This manualis applicableto firmware 08-24. Pleasedownload thelatestsoftware fora
upgradeifyourversion is releasedearlier than thedate.
5)PC software:http://zke2006.blog.163.com/blog/static/199527095201111284512232/
6)Technicalsupport:
QQ 2353976901
E-Mail [e-mail]
Wealwaysfocus on innovation and improvementand will keepupgradingthesoftware.Please
frequentlyvisit ourofficialblog:zke2006.blog.163.comto download thelatestmanuals.
