ZKTeco FaceDepot-7A User manual

Quick Start Guide
Version: 1.0
Date: Nov. 2018
FaceDepot-7A

1
Distance sensor
Overview
7 inch screen
Camera
Flash
Device Installation
USB port
Method 1: Installation on the floor
Please route the wire through the bracket 1
and connect it before installation.
1. Fix the device on the bracket 1.
2. Insert the bracket 1 into the bracket 2 and
fix it with screws. The height of camera from
the ground is recommended to be 1.55m.
3. Fix the bracket to the ground with 4 screws.
Bracket 1
Bracket 2
Sun canopy
Please install the sun canopy
above of terminal once strong
light environment.

2
Device Connection
RS485 communication/Wiegand
TCP/IP
12V 3A Power
Please route the wire through
the bracket before installation.
1. Fix the device on the bracket.
2. Drill a hole on the barrier
gate. Insert the bracket into
the hole and fix it with a nut.
Method 2: Install on barrier gate
Barrier Barrier
In
FaceDepot-7A
ZKBioSecurity

3
1. Connect a mouse to the device, click [System Settings] > [Network Settings] > [TCP/IP
Settings] > [DHCP], input the IP address and click [OK].
2. Then click [Cloud Service Settings], set cloud service server address on the device.
+12V
GND
WD0
WD1
IWD0
IWD1
+12V
GND
485A
485B
NO
COM
NC
NO
COM
NC
SEN
GND
BUT
NO
COM
NC
TX+
TX-
RX+
RX-
TXD1
GND
RXD1
TXD2
GND
RXD2
TXD3
GND
RXD3




Ethernet port
R 232 ort1SP
R 232 ort2SP

R2SP32 ort3
Exit Button
Sensor
Left
Open

Lock
+12V
GND
485B
485A
Wiegand Reader
RS485 Reader
Diagram
GND
Right
Open
Barrier
+12V
GND
WD1
WD0
USB
Update
Access
Settings
Employee Attendance
Data
Manage
USB disk
Manage
Record Alarm
System
Settings
Network Settings
Date and Time
ATT Parameters
Cloud Service Settings
Wiegand Settings
Display Settings
Sound Settings
Biometric Parameters
Advanced Settings
Auto-testing
About Device
System Settings
Ethernet Settings
State
DHCP
IP Address
Subnet Mask
Gateway Address
DNS
TCP COMM. Port
114.114.114.114
4370
192.168.54.1
System Settings
Automatic
192.168.54.190
255.255.255.0
Note: IP addresses of the server (PC) and the device must be in the same network segment
when connecting to the software.
Connect to the software
Server
Server type
Enable Domain Mode
Server Address
Server Port
Enable Proxy
Cloud Service Settings
0.0.0.0
8081

4
Verification is successful
The device ll automatically switch to the standby page f t doesn't detect any personwi i i
within 5 seconds.
The icons or in the standby interface indicates that the network connection or the
server is abnormal. Please check the network cable and network connection.
4 Quick Start
User registration
User authentication Door openVerified
User registration
Step 1
²Login onto http://X.X.X.X:XX/app/v1/adreg with mobile phone to register users.
²Click [Personnel] > [Person] > [New] to register users in ZKB Software.iosecurity
²Register users on the device.
Step 2 Click [Access Device] > [Device] > [New] to add the device to the software..
Step 3. Add users to access levels.
For more details, please refer to the ZKBiosecurity User Manual.
User authentication
When the distance between the person
and the machine is 1.5m, the device will
automatically switch to the face
verification interface. The verification
result is as shown on the right:
1.5m
1.55m
Cloud server IP address Server port

ZK Building, Wuhe Road, Gangtou,
Bantian, Buji Town, Longgang
District, Shenzhen China 518129
