Zline Bliss bls-shs Assembly instructions

SHOWER SYSTEMS

Installation Guide and User Manual

1.0.1

REGISTERING YOUR PRODUCT

Please register your ZLINE appliance. Begin the simple registration process by

scanning the QR code.

By registering your appliance, you will have easy and accurate access to:

• Technical Support

• Warranty Service

• Tracking your support inquiries

WARNING: This product can expose you to chemicals including nickel, which is known to the

State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.

SCAN ME

ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams

is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to

providing you an elevated experience in the heart of your home. With an endless selection of

features and ﬁnishes, our inspiration is your reality.

ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end

luxury designs and professional features into everyone’s homes. Because we continually strive

to improve our products, we may change speciﬁcations and designs without prior notice.

WARRANTY

COVERAGE

ZLINE Kitchen and Bath shower systems have a limited lifetime warranty from the

original purchase date for the original purchaser of the product.

TERMS

This warranty applies only to the original purchaser of a shower system installed for

normal residential use. This is deﬁned as a single-family, residential dwelling in a

non-commercial setting. Commercial settings include but are not limited to: schools,

churches, hotels, restaurants, vacation rentals such as Airbnb, day care centers,

private clubs, ﬁre stations, common areas in multi-family dwellings, nursing homes,

food service locations, and institutional food service locations such as hospitals or

correction facilities. This warranty is non-transferable and will not be extended based

on the date of installation. The warranty applies only to products installed in the

continental United States and the District of Columbia.

Warranty shall not apply and ZLINE Kitchen and Bath is not responsible for damage

resulting from negligence, improper maintenance, misuse, abuse, alteration of or

tampering with the appliance, accident, natural disaster, improper installation, or

installation not in accordance with the instructions contained in the manual, or the

local codes.

WHAT IS NOT COVERED

1. Installation or start-up, damages, or problems caused by improper installation or

use.

2. Installation in any commercial or non-residential application.

3. Removal or re-installation cost.

4. Aesthetic damage, scratches, or natural wear caused by normal use.

5. Second-hand, open box products or products purchased from an unauthorized

retailer.

TABLE OF CONTENTS

SAFETY INSTRUCTIONS 1

BLISS SHOWER SYSTEM (BLS-SHS) 2

ZLINE SHOWER FAUCET 22

BLISS SHOWER FAUCET (BLS-SHF) 27

EL DORADO SHOWER SYSTEM (ELD-SHS) 41

EL DORADO SHOWER FAUCET (ELD-SHF) 61

TROUBLESHOOTING 75

PRIOR TO INSTALLATION

• Make sure that the cold and hot water lines are turned off.

• Wrap all threaded connections with Teﬂon tape. Always wrap in a clockwise

direction.

• Cover your drain to avoid losing parts.

• Do not disassemble the main system body, as it has been installed and

commissioned correctly and precisely before delivery to the factory.

• To keep the system from jamming, ﬂush the water pipe before installation.

Operating conditions: Working pressure at 0.05-1.0 MPa (including cold and hot

water pressure) with applicable water temperature: 39.2°F - 194°F.

CARE AND MAINTENANCE

To keep the product clean and shining, follow the steps below:

1. Rinse clean with water and dry with a soft cloth.

2. Do not clean with soaps, acid, polish, abrasives, or harsh cleaners.

3. Do not use cloth with a coarse surface.

4. Unscrew the aerator and clean when necessary.

• If soldering the water connections when installing the system, remove the

O-rings, cartridges, and washers before applying any heat.

• Protect your eyes when cutting or soldering.

• Do not over tighten screws/nuts. Finger tighten, then use a wrench/screwdriver

to tighten the ﬁxing screw/nut until snug.

SAFETY INSTRUCTIONS

General Safety

BLISS SHOWER SYSTEM (BLS-SHS)

Bliss Shower System Product Speciﬁcations

1. Flange cover

2. Shower arm

3. Top spray shower

4. Wall valve body

5. Faceplate

6. Sleeve

7. Washer

8. Water control handle

9. Switch handle

10. Cap

11 . Sleeve

12. Flange cover

13. Angle valve

14. Shower rail

15. Shower handle

16. Hose

BLISS SHOWER SYSTEM (BLS-SHS)

Bliss Shower System Product Speciﬁcations

BLISS SHOWER SYSTEM (BLS-SHS)

Bliss Shower System Tools

needed:

Slide the sleeves onto the pipes and then insert pipes into the wall valve. Tighten the

ring around the pipes with the wrench. NOTE: If brazing is involved, you must remove

the internal valve components prior to the brazing. Please note the original position of

the cartridge.

BLISS SHOWER SYSTEM (BLS-SHS)
