ZOLL M Series User manual

M Series
XL Battery
ZOLL XL Smart Battery
9650-0221-01 Rev. B

The issue date or revision level for this operation guide is shown on the front cover.
ZOLL, XL Battery, Smart Battery, Base PowerCharger4x4, Base Powercharger1x1, and M Series are
trademarks of ZOLL Medical Corporation.
 2002 by ZOLL Medical Corporation. All rights reserved.

ZOLL M Series XL Battery 1
Product Description
The ZOLL XL Battery is a 4.5 AH lead acid battery pack intended for use in appropriately
configured M Series and M Series CCT defibrillators. It is available as a Smart Battery or Smart
Ready Battery. Please see the Smart Battery Operator’s Guide for additional information on Smart
Battery functionality.
NOTE: The XL battery is NOT intended for use in ZOLL 900/1200/1400/1600/1700/2000 series
units. See the "Defibrillator Compatibility" section below for information on M Series use.
Warnings!
• Follow all recommended maintenance and operating instructions for the XL Battery and associated
ZOLL charging/testing systems. If a problem or question arises, contact Technical Service. Do not
use the XL Battery until it has been inspected, tested, and recalibrated by the appropriate personnel
and you have been adequately trained in the proper use of the XL Battery.
• Locate the XL Battery and ZOLL resuscitation devices where they cannot harm the patient or user
if they fall.
• Under certain conditions, it is possible for small amounts of hydrogen gas to be released during
charging of the battery pack. This may present a hazard.
• Do not immerse or set the XL Battery in fluid.
• Do not use alcohol or ketones (MEK, acetone, etc.) on the XL Battery. Do not autoclave the XL
Battery.
• The XL Battery is protected against interference from radio frequency emissions typical of two way
radios and cellular phones (digital and analog) used in emergency service/public safety activities.
Users of the XL Battery should assess the device's performance in their typical environment of use
for the possibility of radio frequency interference from high power sources.
• Keep a fully charged spare battery pack available at all times with the Monitor/Defibrillator.
Replace the battery immediately upon low battery message.
• Do not install batteries into Monitor/Defibrillators when storage may exceed 90 days. Battery
damage may occur.
• Do not use the XL Battery if the case is cracked or broken.
• When charging a XL Battery pack in a Base PowerCharger4x4 or Base PowerCharger1x1 unit, ensure
unit is labeled “XL Battery Ready” otherwise the battery cannot be charged to full capacity and
operating life may be reduced.
• ZOLL charging/testing systems used with the XL Battery should be calibrated or tested
periodically using the appropriate Service Manual Test Check Out procedures.
• To dispose of the battery properly, place it in an acid resistant container. Dispose of the battery in
accordance with federal, state, and local regulations. Do not incinerate batteries. Ship the batteries
to a reclaimation facility for the recovery of metal and plastic compounds as the proper method of
waste management.
General Information
Defibrillator Compatibility
M Series units must have software version 30.00 or higher and be outfitted with the appropriate
handle assembly. New M Series units may be ordered with the XL Battery option. Older M Series
units may be upgraded if the current software version is 20.00 or higher. All M Series CCT units are
XL Battery-ready.
The XL Battery is not intended for use in ZOLL 900/1200/1400/1600/1700/2000 series units.

2 ZOLL M Series XL Battery
Charger Compatibility
The XL Battery is only compatible with ZOLL Base PowerCharger4x4 or Base PowerCharger1x1 units
labeled “XL Battery Ready.”
Older ZOLL Base PowerCharger4x4 or Base PowerCharger1x1 units may be upgraded.
All XL Battery ready chargers are backward compatible with the PD4410 battery pack.
Battery Maintenance
Test batteries regularly. At a minimum, ZOLL recommends testing batteries every three months. For
additional information on battery maintenance, refer to the ZOLL document, Battery Management
Program (#9650-0019).
Environmental Specifications
Operating Note
The XL Battery may feel warm to the touch following an excessive number of defibrillation
discharges at maximum energy.
Charge Time
The XL battery charge times are as follows:
Cleaning
Clean the ZOLL XL Battery with a soft damp cloth and mild soap.
CAUTION! Do not immerse or set battery in fluids; do not use alcohol, ketones
(MEK, acetone, etc.); and do not autoclave.
Upgrade Kits
M Series units with software version 20.00 and higher may be upgraded for use with the XL Battery.
If the unit is equipped with an Extreme Pack II, an upgrade will be required for the Extreme Pack as
well.
All M Series CCT units are compatible with the XL Battery.
Base PowerCharger4x4 and Base PowerCharger1x1 units not labeled “XL Battery Ready” must be
upgraded for use with the XL Battery.
Temperature 0°C to 50°C (operating)
15°C to 35°C (optimal battery charging)
-40°C to 70°C (storage)
Humidity 5% to 95% (relative humidity, non-condensing)
Charging Device Maximum Charge Time
M Series - unit plugged in and OFF 7.2 hours
M Series - unit plugged in and in use 43 hours
Base PowerCharger4x4/1x1 Quick Charge 6 hours
Base PowerCharger4x4/1x1 Auto Test 12 hours
Device to Upgrade Upgrade P/N
M Series (requires software version 20.00 or higher) 7777-0261
Extreme Pack II Call your sales representative

ZOLL M Series XL Battery 3
Service
U.S.A. Customers
Should the ZOLL XL Battery require service, contact ZOLL Medical Corporation Technical Service
Department at 1-800-348-9011 (in Massachusetts: 1-781-229-0020)
International Customers
Should the ZOLL XL Battery require service, contact the nearest authorized ZOLL Medical
Corporation service center.
Base PowerCharger4x4 7777-0262
Base PowerCharger1x1 7777-0263
Device to Upgrade Upgrade P/N

4 ZOLL M Series XL Battery
