Zonet ZEW1642 Operation manual

300
Mbps
WIRELESS
2T/2R
WEP
WPA
PRODUCT DATA
802.11n Wireless PCI Adapter
ZEW1642
Features:
High-speed Wireless-N Networking
For your computer
MIMO Smart Antenna Technology
Compatible with 802.11b/g devices
Advanced wireless encryption:
WEP, WPA, WPA2
Supports Windows 2000, XP, Vista, 7
The Zonet ZEW1642 - 802.11n Wireless PCI Adapter delivers an
incredible speed to your desktop PC without running wires. It complies with the
IEEE 802.11n standard, making it backward compatible with 802.11b/g networks for
assured compatibility. Advanced 128-bit WEP encryption is supported to provide
secure access for your data. Once you're connected, you can stay in touch with your
email, access to the internet and send large files across the network.

WIRELESS
Specification
*Maximum wireless signalrate derived fromIEEE 802.11b/g/n specifications.Actual data throughput will
vary from volume ofnetwork traffic, buildingmaterials and construction,and network overhead,
lower actual datathroughput rate.
Zonet is a registered trademark.Other Brands and product namesare trademarks of their respectiveholders. Information provided in thisdocument pertains to
Zonet products and issubject to change atany time, without notice.For the most recentproduct information please visit
http://www.zonetusa.com
Copyright© Zonet. All Rights Reserved.
Contact Us:
1.888.883.8880
[email protected]
www.zonetusa.com
Related Products:
ZEW1542 11n Wireless Cardbus
ZEW2546 11n Wireless USB Aapter
ZSR4154WE 11n Wireless Broadband Router
One ZEW1642
One Quick InstallationGuide
One Installation CD
Two Antennas
Package content:
802.11n Wireless PCI Adapter
ZEW1642
Zonet USA Corporation
18513 East Gale Ave. City of Industry, CA 91748
Tel: [phone] Fax: [phone]
Standards
Interface
Antenna
Frequency Range
Signal Rates
Transmit Power
Channels
Modulation
Security
Chipset
LED Indicators
Media Access Protocol
OS Support
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
IEEE 802.11n, IEEE802.11b, IEEE 802.11g
32bit PCI
2 x 2.2dBi detachable Antennas
2.4GHz-2.4835GHz
11n: 270/243/216/162/108/81/54/27Mbps
135/121.5/108/81/54/40.5/27/13.5Mbps
150/130/117/104/78/52/39/26/13Mbps
65/58.5/52/39/26/19.5/13/6.5Mbps
11g:54/48/36/24/18/12/9/6Mbps
11b: 11/9/6/5.5/2/1Mbps
11n 20MHz/40MHz: -70dBm
54Mbps: -72dBm
11Mbps: -87dBm
1~ 11 (US), 1~13 (EU)
OFDM, CCK, BPSK, QPSK
WPA/ WPA2; 64/128-bit WEP; TKIP/AES
Ralink RT3062
Status / Activity
WMM
Windows 2000/XP/Vista/7, Linux, Mac OS 10.3 or above
0 C ~ 40 C
-40 C~70 C
10%~ 90% RH Non-condensing
5% ~ 90% RH Non-condensing
