PRODUCT DATA
802.11n High Gain PCI Adapter
ZEW1690
Features:
The Zonet ZEW1690 - 802.11n High Gain PCI Adapter delivers an
incredible speed to your desktop/laptop PC without running wires. It complies with
IEEE802.11n standards, making it backward compatible with IEEE802.11b/g fro assured
compatibility. ZEW1690 adopts the advanced signal-amplification technology and is
equipped with a Dual 7dBi Omni-Directional Antenna. Therefore wireless reception
increases 6 times range of 802.11g standard and reduce "dead spots" in the wireless
coverage area. Advanced 64/128-bit WEP, WPA/WPA2 encryption is supported to provide
secure access for your data. Once you're connected, you can stay in touch with your email,
access to the internet and send large files across the network at greater distances than
ever before. ZEW1690 also comes with a low-profile bracket. Simply replace the
regular bracket with the low-profile bracket to install ZEW1690 into any low-profile PC.
High-Speed Wireless-N Networking
for your computer
Signal-amplification technology
Compatible with 802.11g/b devices
Supplies with Extended Dual 7dBi
Omni-Directional Antenna
WIRELESS WIR ELE S S
High GainH i g h G a i n
6x
of normal
USB Adapter
Range
WIRELESS
7dBi x 2
Antenna

Specification
*Maximum wireless signalrate derived fromIEEE 802.11b/g/n specifications.Actual data throughput will
vary from volume ofnetwork traffic, buildingmaterials and construction,and network overhead,
lower actual datathroughput rate.
Zonet is a registered trademark.Other Brands and product namesare trademarks of their respectiveholders. Information provided in thisdocument pertains to
Zonet products and issubject to change atany time, without notice.For the most recentproduct information please visit
http://www.zonetusa.com
Copyright© Zonet. All Rights Reserved.
Contact Us:
1.888.883.8880
[email protected]
www.zonetusa.com
Related Products:
ZSR9104WE High Gain Wireless N Router
ZEW2590 High Gain 11N USB Adapter
One ZEW1690
Two 7dBi Antennas
One Antenna Base
One Installation CD
One Quick Installation Guide
One Wall Mount Kit
Package content:
Zonet USA Corporation
18513 East Gale Ave. City of Industry, CA 91748
Tel: [phone] Fax: [phone]
WIRELESS WIR ELE S S
High GainH i g h G a i n
802.11n High Gain PCI Adapter
ZEW1690
WIRELESS
Standards
Interface
Chipset
OS
User interface
roaming
LED
Antenna type
Frequency range
Radio data rate
Modulation
Spectrum Spread Technology
Sensitivity
Antenna Gain
Channels
Media Access Protocol
Data security
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b standards
One 32-bit PCI interface
Ralink RT3062
Windows 2000 / XP / Vista / 7
Easy to use user configuration software
Support multipoint auto roaming and configuration;
Support wireless network environments auto detect.
Status / Activity
Extended dual Omni-Directional Antenna (Detachable)
2.4~2.4835GHz
11n: 270/243/216/162/108/81/54/27Mbps
135/121.5/108/81/54/40.5/27/13.5Mbps
150/130/117/104/78/52/39/26/13Mbps
65/58.5/52/39/26/19.5/13/6.5Mbps
11g: 54/48/36/24/18/12/9/6Mbps
11b:11/5.5/2/1Mbps
OFDM, CCK, BPSK, QPSK
DSSS
11n 20MHx/40MHz:-70dBm
54Mbps:-72dBm
11Mbps:-87dBm
2 x 7dBi
11 Channels (USA, Canada) ; 13 Channels (Europe)
WMM
WPA/WPA2; 64/128-bit WEP; TKIP/AES
0 C ~ 40 C
-40 C ~ 70 C
10%~ 90% RH Non-condensing
5% ~ 90% RH Non-condensing
