Operation
The fur to be cut must be dry and clean. Brush the
fur through to remove any knots.
•
Remove the blade guard from the cutting
head 1.
•Place the required trimming guide ( - )
with the prongs facing upwards on the cutting
head 1and thereby press the flap of the trim-
ming guide down firmly onto the lower metal
edge of the cutting head (see illustration).
• Ensure that the trimming guide has properly
engaged and is secured before starting to cut/
trim the fur.
Note:
It is advisable to first trim a small area so as to test
the individual comb attachments. Start with a comb
attachment for long hair (1/2“ or 3/8“ )
and, if necessary, use a shorter one. The comb
attachments permit cutting lengths from 3 to 13 mm.
•
Switch the appliance on by sliding the On/Off
switch 3to the position „ON“.
• Slowly run the appliance through the fur against
the direction of hair growth. Hold the appliance
so that the trimming guide is as flat as possible
against the animal.
•
In addition, with the adjustment switch 4the
cutting length of the cutter head 1can be
adjusted in steps(up to 2 mm) without having
to exchange the comb attachment. To do this,
slide the adjustment switch 4 backwards to
increase the cutting length in steps. With this the
cutting length of the respectively attached comb
attachment is also increased by up to 2 mm.
Slide the adjustment switch 4forward again to
reduce the cutting length or to bring the comb
attachment back into its original position.
•
Through removal of the individual trimming
guide, i.e. using only the cutting head 1itself,
you can cut clean contours.
•
After use, switch the appliance off by sliding the
On/Off switch 3to the position „OFF“.
Cleaning and Care
Risk of electric shock!
Before cleaning, remove the plug from the mains
power socket.
NEVER submerse the appliance in water or other
liquids.
• Take the respective trimming guide, if fitted, off.
•
Using exclusively the cleaning brush , remove
the hairs from the cutting head 1. Wipe off the
cutting head 1with a damp cloth. After this,
dry the cutting head 1 off with a dry cloth.
We recommend that you occasionally clean the
cutting head 1with medicinal alcohol.
•
If in regular use, the cutting head 1should be
oiled occasionally. For this, use the supplied
blade oil .
• Remove excess oil with a dry cloth.
• Clean the housing with a soft, dry lint-free cloth.
In cases of stubborn soiling, clean the housing
using a damp cloth and then dry it off with a
dry cloth.
•
Store the appliance in a dry and dust free
location. When it is in storage, place the blade
guard on the cutting head 1.
