Operation
The fur to be cut must be dry and clean. Brush the
fur through to remove any knots.
1) Remove the blade guard 7from the cutting
head 1.
2) Place the required trimming guide (1 - 6)
with the prongs facing upwards on the cutting
head 1and thereby press the flap of the trimming
guide down firmly onto the lower metal edge
of the cutting head (see illustration).
■ Ensure that the trimming guide has properly
engaged and is secured before starting to cut/
trim the fur.
NOTE
► It is advisable to first trim a small area so as
to test the individual comb attachments. Start
with a comb attachment for long hair (1/2“ 4
or 3/8“ 3) and, if necessary, use a shorter
one. The comb attachments permit cutting
lengths from 3 to 13 mm.
3) Switch the appliance on by sliding the On/Off
switch 3to the position “ON“.
4) Slowly run the appliance through the fur
against the direction of hair growth. Hold the
appliance so that the trimming guide is as flat
as possible against the animal.
–––In addition, with the adjustment switch 4
the cutting length of the cutter head 1can
be adjusted in steps(up to 2 mm) without
having to exchange the comb attachment.
To do this, slide the adjustment switch 4–
backwards to increase the cutting length
in steps. With this the cutting length of the
respectively attached comb attachment is
also increased by up to 2 mm.
Slide the adjustment switch 4forward
again to reduce the cutting length or to bring
the comb attachment back into its original
position.
–––Through removal of the individual trimming
guide, i.e. using only the cutting head 1
itself, you can cut clean contours.
5) After use, switch the appliance off by sliding
the On/Off switch 3to the position “OFF“.
Cleaning and Care
DANGER – ELECTRIC SHOCK!
► Before cleaning, remove the plug from the
mains power socket.
CAUTION! PROPERTY DAMAGE!
► NEVER submerse the appliance in water or
other liquids.
■ Take the respective trimming guide, if fitted, off.
■ Using exclusively the cleaning brush 8, remove
the hairs from the cutting head 1. Wipe off the
cutting head 1with a damp cloth. After this,
dry the cutting head 1–off with a dry cloth.
We recommend that you occasionally clean the
cutting head 1with medicinal alcohol.
■ If in regular use, the cutting head 1should be
oiled occasionally. For this, use the supplied
blade oil 9.
■ Remove excess oil with a dry cloth.
■ Clean the housing with a soft, dry lint-free cloth.
In cases of stubborn soiling, clean the housing
using a damp cloth and then dry it off with a
dry cloth.
■ Clean the trimming guides (1 - 6) in warm
water. Add a little mild detergent. Dry all parts
well before re-use.
■ Store the appliance in a dry and dust free
location. When it is in storage, place the blade
guard 7–on the cutting head 1.
