ZOSI V6.W.0 User manual

WiFi Camera
Quick Start Guide
For more information of your new system, please refer to
www.zositech.com
V6.W.02.Z

1. What’s in the box
Quick Start Guide
Quick Start Guide
Mounting Screw Bag 12V 1A Power Adapter
Camera
Warning StickerMounting Hole Template
2. Introduce the Cameras
Dome Camera
NOTE: Products and accessories vary by product models, please refer to
the actual product.
Reminder：
You have entered the
monitoring area
Speaker
IR-LEDs
Spotlight
Antenna
Lens
Microphone
or
1 English 1 English

3. Connection Diagram
Bullet Camera
1. Power on the IP camera and WiFi NVR.
2. The NVR will auto-pair with the camera after the devices are powered on
and then enjoy live viewing.
NOTE: If you buy a new add on camera, you need to re-pair to the system
manually, please refer to the following link for detailed operation.
Spotlight
Speaker
Microphone
CDS
IR-LEDs
IR-LEDs
Antenna
Antenna
Lens Lens
CDS Sensor
Network Port
Power Port
English 2English 2
Scan UID CodeWired Connection

4. Install the Camera
2. Mount the camera on the wall
NOTE: Dome camera and bullet camera are installed in the same way, the
following is the example of the bullet camera. Please refer to the actual
product and install the camera according to the corresponding instructions.
Drill holes on the wall according to the position of mounting hole
template and insert the plastic wall plugs.
Install Steps：
1
3 English
1. Installation Precautions
٬Avoid directing the camera towards strong light or reflective objects,
including sunlight, light glass, mirrors and other areas with strong
refraction of light sources.
٬Do not install at location with objects covering or obscuring the camera.
٬Avoid mounting the camera in places too dim. Point the camera towards
a well-lit area. For better image quality, make sure the camera and the
captured subject are at the same lighting conditions.
٬It is recommended to clean the lens with a soft cloth from time to time.
٬Do not expose the power port to water or moisture. Make sure it is not
blocked by dirt or other things.
٬Do not install the camera where rain and snow may hit the lens directly.
٬Camera may work in extremely cold conditions as low as -10˳ because
it will produce heat when powered on. You may power the camera
indoors for a few minutes before installing it outdoors. (Only for outdoor
cameras).

Align the camera base with the mounting hole template and use the screws
to fix the base. (please place the camera's wires to the notch.)
Loosen the adjustment knob of the bracket and adjust the camera to a right
angle.
2
3
English 4

3. Installation Distance, Height and Angle
Distance: Best accuracy for object within 5-50ft (1.5-15m).
Angle: Tilt the camera down about 30°-60° from the horizontal position.
Height: Install the camera 8-16ft (2.5-5m) above the ground.
NOTE: The accuracy of human detection will be affected by various factors,
such as the distance between the person and the camera, the height of the
person, the height and angle of the camera, etc. The accuracy and distance
of detection will also be affected in the night vision environment.
4
Install the camera 8-16ft (2.5-5m)
above the ground.
Best accuracy for object within
5-50ft (1.5-15m).
Tighten the adjustment knob of the bracket to fix the camera.
Note: The dome cameras can ignore steps 3 and 4.
5 English

5. Terms of Use
English 6
٬Use the camera only with compatible ZOSI NVRs.
٬Please read this guide carefully and keep it for future reference.
٬Follow all instructions for safe use of the product and handle with
care.
٬Use the camera within given temperature, humidity, voltage level noted in
the specifications.
٬Do not disassemble the camera.
٬Avoid facing the camera directly to sunlight or strong light sources.
٬Use only a regulated power supply (optional). Use of a non regulated,
non-conforming power supply can damage the product and void the
warranty.
٬Periodic cleaning may be required. Use a damp cloth only. Do not use
any harsh chemical cleaners.
٬Do not open the case while power is on.

3. Correct Dispose of this product
This marking indicates that this product should not be disposed with other
household waste throughout the EU. To prevent harm to the environment or
human health from uncontrolled waste disposal and promote the sustainable
reuse of material resources, please recycle it responsibly. To return your used
device, please use the return and collection system or contact the retailer
from whom the product was purchased. They can take this product for
environmentally safe recycling.
2. CE Simplified EU Declaration of Conformity
ZOSI declares that product is in compliance with the essential requirements
and other relevant provisions of Directive 2014/53/EU.
6. Notification of Compliance
7 English
1. FCC Compliance Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
٬This device may not cause harmful interference,
٬This device must accept any interference received, including interfer
ence that may cause undesired operation.

Copyright © 2022 ZOSI Technology Co., Ltd.
No part of this publication may be reproduced in any way without the written
permission of ZOSI. The information in this publication is believed to be accurate in
all respects. ZOSI assumes no responsibility for any consequences resulting from
their use. As our products require continuous improvement, ZOSI reserves the
right to modify product designs, specifications and prices without notice and
without any obligation. All rights reserved,and ZOSI reserves the final interpretation
right of this manual.
