Zotac ZBOX-AD02-B User manual

Raise your performance expectations for energy-efficient computing with the digital media
friendly ZOTAC ZBOX AD02 mini-PC powered by the AMD E-350 APU platform. Paired with
AMD Radeon™ Discrete-Class Graphics, the ZOTAC ZBOX AD02 delivers the perfect synergy
of GPU and CPU performance for a rich multimedia computing experience with flawless high-
definition video playback capabilities and ultra-fast responsiveness for regular day-to-day
computing tasks.
High performance energy-efficient computing is only two thumb screws away with the ZOTAC
ZBOX AD02 mini-PC thanks to a user friendly design that makes mastering the mini-PC quick
and easy. Space for a 2.5-inch hard drive and 2 204-pin DDR3-1066 SO-DIMM slots enables
users to customize the internals of the ZOTAC ZBOX AD02 to their own needs while USB 3.0
and USB 2.0 ports, a 6-in-1 memory card reader (SD/SDHC/MS/MS Pro/xD/MMC) and eSATA
port provide greater external expansion capabilities for perfect energy-efficient computing.
Specifications
• AMD Radeon™ HD 6310 GPU
• AMD Dual-Core Processor E-350 (1.6 GHz)
• AMD M1 Chipset
Inside the box
• ZOTAC ZBOX AD02
• Power brick & cable
• VESA monitor mount (w/4 screws)
• Stand
• DVI-to-VGA adapter
WWW.ZOTAC.COM
SKU: ZBOX-AD02-B/E/J/U
Internal Expansion
• 1 2.5-inch SATA 6.0 Gb/s hard drive
• 2 204-pin DDR3-1066 SO-DIMM
Display Outputs
• HDMI (1080p w/8-channel audio)
• DVI-I
• HDCP compliant
• VGA (with DVI-to-VGA adapter)
• Dual simultaneous displays
Front Ports
• Headphone/Audio out jack
• Microphone jack
• 6-in-1 Memory card reader
• (MMC/SD/SDHC/MS/MS Pro/xD)
• 1 USB 2.0 port
• WiFi LED
• Hard drive LED
• Power button
Features
• ATI Avivo™ HD technology
• ATI Stream™ technology
• Adobe® Flash® Player 10.1 acceleration
• Microsoft® DirectX® 11 compatible
• Microsoft® DirectCompute ready
• OpenGL® 3.2 compatible
• OpenCL compatible
• Integrated 802.11n WiFi
Dimensions
• Length: 7.40in - 188mm
• Width: 7.40in - 188mm
• Depth: 1.73in - 44mm
Rear Ports
• eSATA
• 2 USB 3.0 ports
• 2 USB 2.0 ports
• 10/100/1000 Ethernet (RJ45)
• Digital S/PDIF output
• Power connector
Top Ports
• 1 USB 2.0 port
© 2011 ZOTAC International (MCO) Limited
