Zte Blade L2 User manual

ZTE Blade L2
WCDMA/GSM
Mobile Phone
Quick Start Guide
5
Power Key
●
Press and hold to turn on your phone.
● Press and hold to reset the phone, turn
on or off Silent or vibrate or Airplane
mode, or to power off or Reboot Device.
● Press to switch your phone to Sleep
mode.
● Press to wake up your phone.
Home Key
●
Press to return to the Home Screen from
any application or screen.
● Hold to see Google search.
4
Getting to Know Your
Phone
3
Keep away from pacemakers
and other personal medical
devices.
Avoid any contact with liquid,
keep it dry.
Switch off when instructed in
hospitals and medical facilities.
Do not attempt to disassemble.
Switch off when instructed in
aircrafts and airports.
Do not rely on this device for
emergency communications.
Switch off in explosive
environments.
Only use approved accessories.
2
Product Safety
Information
Do not use while re-fuelling.
Do not use hand-held while
driving.
This device may produce a
bright or flashing light.
For body-worn operation
maintain a separation of 15 mm.
Do not dispose of it in a fire.
Small parts may cause a choking
hazard.
Avoid contact with magnetic
media.
This device may produce a loud
sound.
To prevent possible hearing
damage, do not listen at high
volume levels for long periods.
Avoid Extreme Temperatures.
1
LEGAL INFORMATION
Copyright © 2013ZTE
CORPORATION.
All rights reserved.
No part of this publication may be
quoted, reproduced, translated or used in
any form or by any means, electronic or
mechanical, including photocopying and
microfil m, without the prior written
permission of ZTE Corporation.
ZTE Corporation reserves the right to make
modifications on print errors or update
specifications in this guide without prior
notice.
Version No.: R1.0
Edition Time: 2014.04.23
We offer self-service for our smart terminal
device users. Please visit ZTE official website
(www.ztedevice.com)for more information
on self-service and supported product
models. Information subject to the website.
For more information, visit
www.ztedevice.com and download the user
manual.
6
Menu Key
●
Press to get the options on the current
screen.
● Hold to see recently used applications.
Back Key
Press to go to the previous screen.
Volume Key
Press or hold to turn the volume up or down.
Before Getting Started
1. Remo ving the back cover.
2. Inserting the SIM card.

7
NOTES:
● SIM card 1 (the figure to the left of the
main card) support WCDMA and GSM
networks; SIM card 2 only supports GSM
networks.
● Switch off your phone before installing
or replacing the SIM card.
● Please buy standardization SIM
dedicated card sets from the formal
channels，otherwise the slot shrapnel
may be pulled off when taking cards.
CAUTION: Use of Micro/Nano SIM with
/without adapter is not supported. Warranty
will be voided.
3. Inserting the memory card.
NOTE:Some applications may require a
microSD card to work normally or may store
certain data on it. Therefore, it is
recommended that you keep a microSD card
installed and not remove or replace it
r a n do m l y.
12
Requirement
Standard Report No.
EN 50332-1-2000
EN 50332-2-2003
ECIT-2012-
0103-A
Health and
safety
EN609501:2006+
A11:2009+A1:201
0+A12:2011
IEC 62471:2006
EN 62209-1:2006
EN 50360:2001
EN 62311-2008
EN 62479:2010
ECIT-2012-
0103
-
Safety
3125677.
50A
ECIT-2012-
0103
-
SAR
EMC
EN 301 489-1
V1.9.2:2011
EN 301 489-3
V1.4.1:2002
EN 301 489-7
V1.3.1: 2005
EN 301 489-17
V2.1.1: 2009
EN 301 489-24
V1.5.1: 2010
ECIT-2012-
0103
-EMC
Radio
Spectrum
EN 300 440-1
V1.6.1
EN 300 440-2
V1.4.1
EN 301 511
V9.0.2 :(2003-03)
EN 301 908-1/-2
V5.2.1
EN 300 328
V1.7.1:2006
ECIT-2012-
0103-GPS
ECIT-0103-
RF-G
ECIT-0103-
RF-W
ECIT-2012-
0103-RF
-BT
ECIT-2012-
0103-RF
-WLAN
RoHS IEC 62321:2008 RLSHE001
227150001
ErP
(EC) No 278/2009
TRS
11120039
11
Complies with the essential protection
requirements of Directives on Radio and
Telecommunication Terminal Equipment
(Directive 1999/5/EC)，Restriction of the
Certain Hazardous Substances in
electrical and electronic
equipment(Directive 2011/65/EU),
Eco-design Requirements for
Energy-Related Products(Directive
2009/125/EC) and their
amendments.This declaration applies to
all specimens manufactured identical to
the samples submitted for
testing/evaluation.
Assessment of compliance of the product
with the requirements relating to Directive
1999/5/EC was performed by PHOENIX
(Notified Body No.0700) and assessment of
compliance of the product with the
requirements relating to Directive
2011/65/EU and Directive 2009/125/EC was
performed by ZTE Corporation Reliability
Testing Centre. The assessments were
based on the following regulations and
standards:
10
Waking Up Your Phone
Your phone automatically goes into sleep
mode when it is not in use for some time.
The display is turned off to save power and
the keys are locked to prevent accidental
operations.
You can wake up phone by turning on the
display and unlocking the keys.
1. Press the Power Key to turn the screen
on.
2. Touch and hold at the center of
the screen.
NOTE:
If you have set an ‘unlock pattern’, or a
PIN/password for your phone, you’ll need to
draw the pattern or enter the PIN/password
to unlock your screen.
EC Declaration of
Conformity
It is hereby declared that following
designated product:
Product Type: WCDMA / GSM (GPRS)
Dual-Mode Digital Mobile Phone
Model No: ZTE Blade L2
Product Description:WCDMA / GSM
(GPRS) Dual-Mode Digital Mobile Phone
9
NOTES:
● If excessive discharge of the battery, the
charging icon will display delay.
● If the battery is extremely low, you may
be unable to power on the phone even
when it is being charged. In this case,
try again after charging the phone for at
least 10 minutes. Contact customer
service if you still cannot power on the
phone after prolonged charging.
CAUTION:Do not change the built-in
rechargeable battery in your phone by
yourself. The battery can only be changed
by ZTE or ZTE authorised service provider.
Powering On/Off Your
Phone
Make sure the SIM card is in your phone and
the battery is charged.
● Press and hold the Power Key to turn
on your phone.
● To turn it off, press and hold the Power
Key to open the options menu. Touch
Power off and then touch OK.
Restarting the Phone
If you ever encounter any problem while
using the phone, try pressing and holding
the Power Key for about 15 seconds to
restart the phone，or Press the power key
to select Reboot Device.
8
Charging the battery
When you first get your new phone you’ll
need to charge the battery like this:
1. Connect the adapter to the charger
jack.
2. Connect the charger to a standard AC
wall outlet.
3. Disconnect the charger when the
battery is fully charged.
13
This declaration is the responsibility of the
manufacturer:
ZTE Corporation
ZTE Plaza, Keji Road South, Hi-Tech,
Industrial Park, Nanshan District, Shenzhen,
Guangdong, 518057, P.R.China
Authorised person signing for the company:
Xu Feng Quality Director Of ZTE
Corporation
Name in block letters & position in the
company
Shenzhen, February 18, 2014
Place & date Legally valid signature
This equipment may
be operated in: HR
AT
BE
CY CZ DK EE FI FR
DE GR HU IE IT LV
LT LU MT NL PL PT
SK SI ES SE GB IS
LI NO CH BG RO TR
