Zte CDMA2000 1X EVDO User manual

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
CDMA2000 1X EV-DO
Wireless Data Terminal
User Guide
This User Guide applies to Wireless Data Terminal of MG478 and AC8700.

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
Copyright Statement
Copyright © 2006 by ZTE Corporation
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by
any means, electronic or mechanical, including photocopying and microfilm, without the prior
written permission of ZTE Corporation.
ZTE Corporation reserves the right to make modifications on print errors or update specifications
in this manual without prior notice.
V1.0, August, 2006

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
Table of Contents
1. Introduction.............................................................................................................................1
2. Specification ...........................................................................................................................1
3. Precautions..............................................................................................................................1
4. Appearance .............................................................................................................................2
4.1 Introduction.........................................................................................................................2
4.2 Insert R-UIM Card ..............................................................................................................3
5. Install and Uninstall................................................................................................................4
5.1Windows 2000 ...................................................................................................................5
5.1.1 Install........................................................................................................................5
5.1.2 Uninstall ...................................................................................................................9
5.2Windows XP ....................................................................................................................10
5.2.1 Install......................................................................................................................10
5.2.2 Uninstall .................................................................................................................14
6. Run the Application ..............................................................................................................15
7. Connect/Disconnect..............................................................................................................16
8. Connection Records..............................................................................................................17
9. Setting...................................................................................................................................18
10. Help ......................................................................................................................................20
11. Connect to the Website .........................................................................................................20
12. Trouble-shooting...................................................................................................................21

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
1. Introduction
Thank you for choosing MG478/AC8700 CDMA2000 1X EV-DO Wireless Data Terminal
(hereinafter referred to as Data Terminal) of ZTE Corporation.
The Data Terminal equips with a standard USB interface and supports both CDMA2000 1X
EV-DO and CDMA2000 1X network. In the area where there is signal, it allows you to go surfing
on the Internet, browse the web pages, and send & receive Emails
2. Specification
Model
Parameter
MG478 AC8700
Transmitting Frequency
452.625-456.850MHz 824-849MHz
Receiving Frequency
462.625-466.850MHz 869-894MHz
Stability Fc±300Hz
Dimensions ( L × W ×H)
80 mm ×36 mm×12.8mm
Weight 38.7g
Data Rate Max. down-link transmission rate: 2.4Mbps,
Max. up-link transmission rate: 153Kbps
Current 5V˄using USB interface supply˅
Current Consumption Sleep: 5mA Max.: 480mA
Transmitting Power
224mW
3. Precautions
¾Please don’t use the product near flammable or explosive materials because it might cause
failure or fire.
¾Keep the product away from high temperature, humidity, or dust because it might cause
failure.
¾Avoid shock, cast or impact. Please keep the product well when you don’t use it.
¾Do not dismantle or disassemble the product at will or revolve the antenna frequently. Our
company will not provide warranty service for the damage caused by abnormal operations.
¾Don’t use the product near the place where is weak signal or high-precision electronic device
because the magnetic interference might cause the misoperation of electronic device or other
problems.
¾Please don’t insert or pull out the card with great force to avoid damaging the interface.

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
4. Appearance
4.1 Introduction
Top View Rear View
LED status descriptions:
Network Registered There is service or
searching the networkLED Insert the data terminal
EV-DO 1X EV-DO 1X
Yellow ON OFF Slow Flash OFF Quick Flash
Green ON Slow Flash OFF Quick Flash OFF
USB Interface
Host
Tap
Antenna
LED
R-UIM Card Cover

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
4.2 Insert R-UIM Card
Note: If your data terminal doesn’t need R-UIM card, please skip this section.

1. Pull out the tap
2. Take out the R-UIM card cover in the
direction indicated by the arrow 3. Insert R-UIM card as below figure
4. Push back R-UIM card cover in the direction indicated by the arrow

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
5. Install and Uninstall
System Requirements:
The Data Terminal supports the following operating system:
¾Windows 2000
¾Windows XP
PC minimum configurations:
CPU Pentium-II/233MHz
USB interface 2.0 (USB1.0 and 1.1 compatible

Optical Drive CD-ROM (for installation only)
Memory 64 MB
Disk Space 30 MB (used for installation of application)

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
5.1

Windows 2000
5.1.1 Install
Note:
Do not insert the Data Terminal before installation.
1ǃFind “Setup.exe” firstly in Data Terminal CD-ROM, double-click it to display the Welcome
picture, and then click “Next”;
2ǃSelect the location where you want the program to be installed, and then click “Next”;

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
3ǃSelect Start Menu folder, and then click “Next”;
4ǃWhen you see the window below, please click “Install”;
5ǃPlease wait for installation.

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
6ǃPlease insert the Data Terminal into USB interface if the system prompts you to insert the
hardware (If it has been inserted, please unplug it and insert again.)
7ǃThe system shall find the new hardware and install the driver automatically. Just wait a minute;

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
8ǃThe driver is installed successfully. Pleas click “OK”;
9ǃClick “Finish” to close the last screen of the wizard. Now you can start the application for Data
Terminal.


CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
5.1.2 Uninstall
1ǃSelect Start -> Programs -> ZTE EV-DO -> Uninstall ZTE EV-DO. Click “Uninstall ZTE
EV-DO”, and you will be asked if you want to remove the program. Click “Yes”;
2ǃPlease wait;
3ǃClick “OK” when un-installation is completed; 

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
5.2

Windows XP
5.2.1 Install
Note:
Do not insert the Data Terminal before installation.
1ǃFind “Setup.exe” firstly in the Data Terminal CD-ROM, double-click it to display the Welcome
picture, and then click “Next”;
2ǃSelect the location where you want the program to be installed, and then click “Next”;

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
3ǃSelect Start Menu folder, and then click “Next”;
4ǃWhen you see the window below, please click “Install”;
5ǃPlease wait for installation. This process will take a few minute;

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
6ǃPlease insert the Data Terminal into USB interface if the system prompts you to insert the
hardware (If it has been inserted, please unplug it and insert again.)
7ǃThe system shall find the new hardware and install the driver automatically. Just wait a
minute.(Please ignore the prompt during the installation, such as “USB device not recognized” or
“Your hardware might not be able to work normally because there is an error during the hardware
installation.”)

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
8ǃThe driver is installed successfully. Pleas click “OK”;
9ǃClick “Finish” to close the last screen of the wizard. Now you can start the application for data
terminal


CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
5.2.2 Uninstall
1ǃSelect Start -> Programs -> ZTE EV-DO -> Uninstall ZTE EV-DO. Click “Uninstall ZTE
EV-DO”, and you will be asked if you want to remove the program. Click “Yes”;

2ǃPlease wait;
3ǃClick “OK” when un-installation is completed. 

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
6. Run the Application
After the application is installed successfully, the application icon will appear on your
desktop. Double-click this icon or select from Start -> Programs -> ZTE EV-DO -> ZTE EV-DO.
Run the application to display the following user interface.
The icons on the interface are used to access the function, which indicate as below:
Connect/Disconnect Open URL
Connection Records Setting
Help
Status Bar:
EV-DO Indication
1X Indication
Signal strength indication. The more bars,
the stronger signals
CDMA network unavailable
Network Connection
Sleep mode
In Roaming
No R-UIM card inserted
R-UIM card inserted

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
7. Connect/Disconnect
Connect
Click icon to set the relevant parameters. For details, please refer to Chapter 9
“Setting” for details;
Click icon at the left-up corner of the interface;
After connecting to Internet, the current network information will appear on the
interface. Double-click any place in the display area to view the connection records.
Disconnect
After connecting to Internet, click the rotating icon at the left-up corner of the interface.

CDMA2000 1X EV-DO Wireless Data Terminal User Guide
ZTE Corporation http//wwwztecomcn
8. Connection Records
Click icon to view connection records. Connection records save the previous relevant
information including Start at, Duration and Transmit bytes, which help you know the status
easily.
By switching among “List”, “Monthly” and “Statistic”, you could inquire the records every time,
by month or by time.
Note:
The relevant information contained in connection records are just for user’s reference rather than
the charging basis.
Delete Connection Records
Click “Delete” button to delete the records you have selected on the interface.
Clear Connection Records
Click “Clear” button to delete all the records.
