ZyXEL Communications ISG50 Installation and operating instructions

ISG50
Application Note
Version 1.0
June, 2011

Scenario 1 - ISG50 is placed behind an existing ZyWALL
1.1 Application Scenario
For companies with existing network infrastructures and demanding
VoIP requirements, you can connect the ISG50 to the LAN or DMZ of
the ZyWALL. The USG provides security services and the ISG50 acts as
a pure IP PBX to provide VoIP services.
Goal to Achieve
IP phones from the Internet can register to ISG50 through USG’s
WAN IP and can talk to another IP phone which is connected under
ISG50’s LAN zone.

1.2 Configuration Guide
Network Conditions
USG 20W:
-WAN IP: 59.124.163.156
-SIP server IP (ISG50): 172.16.1.10
ISG50:
-WAN IP: 172.16.1.10
USG 20W:
Step 1. Click CONFIGURATION > Network > Interface > Ethernet to assign USG 20W a WAN IP.

Step 2. Assume ISG50’s WAN port is connected to LAN2 (port 4) of USG 20W.
Configure an IP for this interface.

Step 3. For NAT setting, the user needs to configure the following:
-Rule’s name.
-Set Virtual Server type to let USG 20W do packet forwarding.
-Fill in the Original IP (WAN IP) address.
-Fill in the Mapped IP (ISG’s IP) address.
-Configure the Original Port and the Mapped Port; here we set the SIP signaling port 5060 and RTP port range 10000-20000.
Make sure these ports setting are the same as those set in ISG50.

Step 4. The user can create an address object for ISG50 for further configuration usage. Click Create new object for this function.

Step 5. Click CONFIGURATION > Network >Firewall to open the firewall configuration screen.
Click on the Add button to create a firewall rule to enable the VoIP service to pass from the WAN to LAN2.

Step 6. Disable SIP ALG.

ISG50:
Step 1. Set the WAN IP of USG 20W in the Fake IP field.

Step 2. Make sure the SIP signaling port and the RTP port range are the same as those you configured in the port forwarding in USG 20W.

Step 3. Disable the firewall in ISG50 since USG 20W acts as firewall.

Scenario 2 –Secure site-to-site connections using IPSec VPN/ Secure client-to-site connections using IPSec VPN
2.1 Application Scenario
The ISG50 can provide secure site-to-site access between remote
locations and corporate resources through the Internet. Using IPSec
VPN, companies can secure connections to branch offices, partners
and headquarters.
Besides, road warriors and telecommuters can access the company’s
network by installing the ZyXEL IPSec VPN client software.
Goal to Achieve
1. Build an IPSec VPN tunnel between ISG50 and USG 20W.
2. Build an IPSec VPN tunnel for PC/laptop user’s dynamic access to
ISG50.

2.2 Configuration Guide
2.2.1 Secure site-to-site connections using IPSec VPN
Network Conditions
ISG50:
-WAN IP: 59.124.163.156
-Local subnet: 10.5.5.0/24
USG 20W:
-WAN IP: 59.124.163.151
-Local subnet: 192.168.2.0/24
IPSec VPN Conditions
Phase 1:
-Authentication: 1234567890
-Negotiation mode: Main
-Encryption Algorithm: 3DES
-Authentication Algorirhm: MD5
-Key Group: DH1
Phase 2:
-Active Protocol: ESP
-Encapsulation Mode: Tunnel
-Encryption Algorithm: DES
-Authentication Algorithm: SHA1
-Perfect Forward Secrecy (PFS): None

ISG50:
Step 1. Click on the Add button to add a VPN gateway rule.

Step 2.
To configure the VPN gateway rule, the user needs to fill in the
following:
- VPN gateway name.
- Gateway address: My Address (ISG50’s IP) and Peer Gateway
Address (USG’s IP).
- Authentication setting.
-Shared Key.
ID Type setting (Local and Peer side).

- Phase-1 setting
Negotiation mode
Encryption algorithm
Authentication algorithm
Key Group
Step 3. Click CONFIGURATION > VPN > IPSec VPN > VPN Connection to configure the phase-2 rule.

Step 4.
To configure the phase 2 rule, the user needs to fill in the
following:
- VPN connection name
- VPN gateway selection

- Policy for
Local network side
Remote network side
- Phase 2 Settings
Active protocol
Encapsulation mode
Encryption algorithm
Authentication algorithm
Perfect Forward Secrecy
Step 5. Click the Connect button to establish the VPN link. Once the tunnel is established, a connected icon will be displayed in front of the
rule.

USG 20W:
Step 1. Add a VPN gateway rule.
Step 2.
To configure the VPN gateway rule, user needs to fill in:
- VPN gateway name
- Gateway address: My Address (USG’s IP) and Peer Gateway
Address (ISG50’s IP)
- Authentication setting
-Shared Key
ID Type setting (Local and Peer side)

- Phase-1 setting
Negotiation mode
Encryption algorithm
Authentication algorithm
Key Group
Step 3. Configure the phase-2 rule.
