ZyXEL Communications P-660HW-Tx v3 Series User manual

www.zyxel.com
802.11g Wireless ADSL2+ 4-port
Gateway
Firmware v3.70
Edition 2, 5/2009
P-660HW-Tx v3
DEFAULT LOGIN DETAILS
IP Address: http://192.168.1.1
Admin Password: 1234
User Password: user
Copyright 2009
ZyXEL Communications Corporation

2
Device Panels
INTERNET
LED
LAN
LED 1-4 WPS/WLAN
LED DSL
LED
POWER
LED
ON/OFF RESETPOWER LAN
PORT 1-4 DSL
PORT
WPS
WLAN
BUTTON

P-660HW-Tx v3
3
Overview
The P-660HW-Tx v3 is an ADSL router with a four-port built-in Ethernet
switch and IEEE 802.11b/g wireless capability. The P-660HW-Tx v3
allows wired and wireless clients to safely access the Internet.
See your User’s Guide for background information on all features.
The included CD provides multi-media animations that help you set up
your P-660HW-Tx v3.
Hardware Connections
If you prefer to see a multi-media animation of how to make hardware
connections, see the installation tutorial on the included CD.

4
1. DSL: Use a telephone wire to connect your P-660HW-Tx v3’s DSL
port to a telephone jack (or to a splitter, if one is already installed).
2. LAN: Use an Ethernet cable to connect a computer to a LAN port for
initial configuration and/or Internet access.
3. POWER: Use the power adaptor provided with your P-660HW-Tx v3
to connect an appropriate power source to the POWER socket. Make
sure the power source is on.
4. Push in the POWER button. Look at the lights on the front panel.
• The POWER light blinks while your P-660HW-Tx v3 starts up and
stays on once it is ready. The DSL light is on when the P-660HW-Tx
v3 has a DSL connection, and the WLAN light is on when the
wireless LAN is ready. The INTERNET light is on when you are
able to access the Internet and blinks when the P-660HW-Tx v3 is
sending or receiving data.
• Each LAN light stays on if the corresponding LAN port is properly
connected and blinks when there is traffic.
If any of these lights are not on, check your connections, and inspect
your cables for damage. If the lights are still off, contact your local
vendor.
Status Page
1. In your browser, go to http://192.168.1.1.

P-660HW-Tx v3
5
2. Enter the default password user to go directly to the Status screen.
3. See the User’s Guide for field descriptions of the Status screen.
Internet and Wireless Setup
1. Open your web browser, and go to http://www.zyxel.com.

6
Your P-660HW-Tx v3 tries to detect your Internet connection. Wait for
the P-660HW-Tx v3 to finish detection. If any other screens appear,
follow the directions in the screen.
If the web page opens correctly, your P-660HW-Tx v3 is ready for you to
use. If the web page does not open, follow the rest of the steps. You
should have the information provided by your ISP.
2. In your browser, go to http://192.168.1.1.
3. Enter the admin password 1234 to set up your internet and wireless
connections and security settings. Click Login. Follow the directions
in the screens.
4. Click Go to Wizard setup. Then, click Apply.

P-660HW-Tx v3
7
5. Click INTERNET/WIRELESS SETUP. Wait while your P-660HW-Tx
v3 tries to detect your DSL connection.
6. Follow the directions in the wizard. Do not change default settings if
your ISP did not provide information.
Troubleshooting
1. If you cannot access the web configurator using Internet Explorer in
Windows XP or Windows Server 2003, make sure you allow pop-up
windows, JavaScripts and Java permissions or set the Internet
security level lower than High in Internet Explorer (in Internet
Explorer, click Tools > Internet Options > Security > Custom
Level...). See the appendix in the User’s Guide for more information.
2. If you cannot access the Internet when your computer is connected to
the LAN port, follow these steps.
a. Check the lights on the front panel. If they are different from what is
described in section , make sure the P-660HW-Tx v3 is correctly

8
connected. If the lights are still different, turn off the device, wait a
few seconds, and turn it on again.
b. Follow the steps in section again. Make sure you enter the correct
information. For example, if your account has a user name and
password, make sure you type it correctly. In addition, if you are not
sure which encapsulation your ISP uses, contact your ISP.
c. If you are using a new Internet account, contact your ISP to make
sure it is active.
d. If you still have problems, see Troubleshooting in the User’s
Guide.
3. If you cannot access the Internet using the wireless network, follow
these steps.
a. On a computer in the wireless network, open your browser, and go
to http://192.168.1.1. If you see the screen in step 3of section ,
follow suggestions a- dabove. If you do not, go to the next step.
b. Make sure your P-660HW-Tx v3 and your computer are using the
same wireless and wireless security settings. Follow the steps in
section .
Viewing Certification(s)
• Go to www.zyxel.com.
• Select your product from the drop-down list box on the ZyXEL home
page to go to that product's page.
• Select the certification you wish to view from this page.
