2864 Series Modem
User’s Manual
Document No.: 8406, Rev. 1.0
ZyXEL COMMUNICATIONS CORPORATION

ii
Limited Warranty
ZyXEL Communications Corporation warrants to the original retail purchaser that
this product is free from defects in materials or workmanship for a period of two (2)
years from the date of purchase. If, during the warranty period, and upon proof of
purchase, the product should have indications of failure due to faulty workmanship
and/or materials, ZyXEL will, at its option, repair or replace the defective products
or components without charge for either parts or labor, and to whatever extent it
shall deem necessary to restore the product or component to proper operating con-
dition. Any replacement will be a new or remanufactured functionally equivalent
product of equal value, and will be solely at the option of ZyXEL.This warranty
shall not apply if the product is modified, misused, tampered with, damaged by
natural causes, or subjected to abnormal working conditions.
NOTE: REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS
THE EXCLUSIVE REMEDY OF THE PURCHASER. THIS WARRANTY IS IN LIEU OF
ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR USE OR
PURPOSE. ZYXEL COMMUNICATIONS CORPORATION SHALL IN NO EVENT BE
HELD LIABLE FOR INDIRECT OR CONSEQUENTIAL DAMAGES OF ANY KIND OR
CHARACTER TO THE PURCHASER.
To obtain the services of this warranty, please contact ZyXEL SERVICE CENTER
(refer to the separate WARRANTY CARD) for your Return Material Authoriza-
tion number (RMA). Products must be returned Postage Prepaid. It is recom-
mended that the unit be insured when shipped. Any returned products without
proof of purchase or those with an expired warranty will be repaired or replaced (at
the option of ZyXEL) and the customer will be billed for parts and labor. All
repaired or replaced products will be shipped by ZyXEL to the corresponding
return address, Postage Paid (USA and territories only). If the customer desires
some other return destination beyond the USA borders, the customer shall bear the
cost of the return shipment.This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state and from country to coun-
try.

iii
Notice: ZyXEL COMMUNICATIONS CORPORATION does not assume any liability
arising out of the application or use of any products, or software
described herein, neither does it convey any license under its patent
rights nor the patent rights of others. ZyXEL COMMUNICATIONS
CORPORATION further reserves the right to make changes in any
products described herein without notice. This document is subject to
change without notice.
PUBLISHED BY:
ZyXEL COMMUNICATIONS CORPORATION
2F., 58 Park Avenue II
Science-Based Industrial Park
Hsinchu,Taiwan 30077 R.O.C.
EDITED BY:
Computer Software Manuals, Christian Schmitz-Moormann
Wölfelstraße 4, 95444 Bayreuth, Germany
Turtle-Soft EDV-Beratung, D. Katzschke
Hufelandstraße 5, 30453 Hannover, Germany
1995 by ZyXEL Communications Corporation
All rights reserved.
No part of the contents of this publication may be reproduced or transmitted in
any form or by any means without the written permission of the publisher.

iv
Acknowledgments
Trademarks mentioned in this manual are used for plain informational purpose.
Trademarks are properties of their respective owners.
U-Modem, ZFAXand ZyXELare trademarks of ZyXEL Communications
Corporation.
Smartmodemis a registered trademark of Hayes Microcomputer Products, Inc.
MNPis a registered trademark of Microcom, Inc.
IBM PC, XT, AT and OS/2 are trademarks of International Business Machine Cor-
poration.
Touch-toneis a trademark of AmericanTelephone andTelegraph Corporation.
WINDOWSis a trademark of Microsoft Corporation.
ATARI, ST, STE, MEGA STE, TT, and Falcon030 are trademarks or registered
trademarks of Atari Corporation.
Apple, Macintosh, and Lisaare registered trademarks of Apple Computer Inc.
NeXT, NeXT Cube, and NeXT Station are registered trademarks of NeXT, Inc.
Amigais a registered trademark of Commodore Business Machines.
.

v
FCC Part 15 Information
This device complies with Part 15 of FCC rules. Operation is subject to the follow-
ing two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including
interference that may cause undesired operations.
This equipment has been tested and found to comply with the limits for a CLASS
B digital device pursuant to Part 15 of the FCC Rules.These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion.This equipment generates, uses, and can radiate radio frequency energy, and if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation.
If this equipment does cause harmful interference to radio/television reception,
which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for com-
pliance could void the user's authority to operate the equipment. Shielded RS-232
cables are required to be used to ensure compliance with FCC Part 15, and it is the
responsibility of the user to provide and use shielded RS-232 cables.
FCC REQUIREMENTS
This equipment complies with Part 68 of the FCC Rules. On the base unit of this
equipment is a label that contains, among other information, the FCC Registration
Number and the Ringer Equivalence Number (REN) for this equipment. IF
REQUESTED,THIS INFORMATION MUST BE GIVENTOTHETELE-
PHONE COMPANY.
The REN is useful to determine the quantity of the devices you may connect to
your telephone line and still have all of those devices ring when your telephone
number is called. In most, but not all areas, the sum of the REN's of all devices
connected to one line should not exceed five (5.0).To be certain of the number of
devices you may connect to your line, as determined by the total RENs, you should

vi
contact your local telephone company to determine the maximum REN for your
calling area.
If your equipment causes harm to the telephone network, the telephone company
may discontinue your service temporarily. If possible, they will notify you in
advance. But if advance notice isn't practical, you will be notified as soon as possi-
ble. You will be informed of your right to file a complaint with the FCC.
Your telephone company may make changes in its facilities, equipment, operations,
or procedures that could affect the proper functioning of your equipment. If they
do, you will be notified in advance to give you an opportunity to maintain uninter-
rupted telephone service.
Ifyou experience trouble with thistelephoneequipment,please contact the Address
and Phone number listed in the warranty card for information on obtaining service
or repairs.
The telephone company may ask that you disconnect this equipment from the net-
work until the problem has been corrected or until you are sure the equipment is
not malfunctioning.
The user is not authorized to repair or modify the equipment beyond replacing the
EPROMs containing the firmware or uploading firmware into the flash EPROM.
This equipment may not be used on coin service provided by the telephone com-
pany. Connection to party lines is subject to state tariffs.
TELEPHONE COMPANY REQUIREMENTS
It is not necessary to notify your telephone company before installing the modem,
but your telephone company may request the following information:
•Telephone number to which the modem is connected.
•Manufacturer and Model Number:
ZyXEL Communications Corporation
Model Name FCC Part 68 Approval Number REN#
You will find this information on the sticker label on the bottom case.
The modem is connected to a public switched line using a USOC (Universal Serv-
ice Order Code) RJ11C modular jack, and to a leased line using a JM8 jack.

vii
Information for Canadian Users
The Industry Canada (IC, formerly DOC) label identifies certified equipment.
This certification means that the equipment meets certain telecommunications net-
work protective, operational, and safety requirements. IC does not guarantee that
the equipment will operate to a user’s satisfaction.
Before installing this equipment, users should ensure that it is permissible to be
connected to the facilities of the local telecommunications company.The equip-
ment must also be installed using an acceptable method of connection. In some
cases, the company's inside wiring associated with a single line individual service
may be extended by means of a certified connector assembly (telephone extension
card).Thecustomer should be aware that the compliance withtheaboveconditions
may not prevent degradation of service in some situations.
Repairs to certified equipment should be made by an authorized Canadian mainte-
nance facility designated by the supplier. Any repairs or alterations made by the user
to this equipment, or equipment malfunctions, may give the telecommunications
company cause to request the user to disconnect the equipment.
Fortheir ownprotection,users should ensurethat the electrical ground connections
of the power utility, telephone lines, and internal metallic water pipe system, if
present, are connected together.Tthis precaution may be particularly important in
rural areas.
Caution: Users should not attempt to make such connections themselves, but
should contact the appropriate electrical inspection authority, or electrician, as
appropriate.
The Load Number (LN) assigned to each terminal device denotes the percentage of
the total load to be connected to the telephone loop used by the device without
overloading.The termination on a loop may consist of any combination of devices,
subject only to the requirement that the total of the Load Numbers of all the
devices not exceed 100.
This digital apparatus does not exceed the class B limits for radio noise emissions
from digital apparatus set out in the radio interference regulations of Industry Can-
ada (formerly Canadian DOC).

viii

TOC-1
TABLE OF CONTENTS
FCC Part 15 Information . . . . . . . . . . . . . . . . . . . . . . . . . . v
FCC REQUIREMENTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . v
TELEPHONE COMPANY REQUIREMENTS. . . . . . . . . . . . . . . . . . .vi
Information for Canadian Users . . . . . . . . . . . . . . . . . . . . . . vii
BASIC OVERVIEW
INTRODUCTION 1-1
How To Use This Manual. . . . . . . . . . . . . . . . . . . . . . . . .1-2
Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
The 2864 Series Standard Features . . . . . . . . . . . . . . . . . . . .1-4
Additional specific features . . . . . . . . . . . . . . . . . . . . . . . .1-6
ISDN Ready or Upgradeable . . . . . . . . . . . . . . . . . . . . . . .1-6
Voice Playback and Recording . . . . . . . . . . . . . . . . . . . . . .1-6
Telephony Capability. . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
Parallel and Serial Port Interface . . . . . . . . . . . . . . . . . . . . .1-7
DRAM Expandability . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7
Flash EPROM for Easy Firmware Update. . . . . . . . . . . . . . . . . .1-7
Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7
How To Become A Registered Owner . . . . . . . . . . . . . . . . . . .1-8
What You Need To Have . . . . . . . . . . . . . . . . . . . . . . . . .1-8
Communication Software. . . . . . . . . . . . . . . . . . . . . . . . .1-8
Connecting To Your Phone . . . . . . . . . . . . . . . . . . . . . . . .1-9
Dial-Up Or Leased Line. . . . . . . . . . . . . . . . . . . . . . . . . .1-9
MODEM AND FAX BASICS 2-1
Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
DTE and DCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
RS-232C or EIA-232D/E . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Serial Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Serial RS-232C Cable . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Synchronous and Asynchronous Communication. . . . . . . . . . . . . .2-2
UART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Modem Standards and Speeds . . . . . . . . . . . . . . . . . . . . . .2-3
Type of Telephone Line. . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Intelligent Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
ISDN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
AT Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
V.25bis Command Set . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
Error Correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
Data Compression . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6

TOC-2
MNPProtocols . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
V.42bis and V.42 . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Xmodem, Ymodem, and Zmodem. . . . . . . . . . . . . . . . . . . . 2-7
Fax and Facsimile . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Fax Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Modem as a Fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
EIA Class 1 and Class 2/2.0 Fax Commands . . . . . . . . . . . . . . . 2-8
Autodetection of Fax or Data Call . . . . . . . . . . . . . . . . . . . . 2-8
Caller ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Distinctive Ring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Digitized Voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Cellular Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Automatic Redial / Call Hunting . . . . . . . . . . . . . . . . . . . . . 2-9
Modem Approval and Legal Matters . . . . . . . . . . . . . . . . . . .2-10
MODEM INSTALLATION 3-1
External Modems. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Elite 2864 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Elite 2864 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Elite 2864 Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Connecting the Elite 2864 . . . . . . . . . . . . . . . . . . . . . . . 3-5
Turning on the Elite 2864. . . . . . . . . . . . . . . . . . . . . . . . 3-6
Elite 2864L . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Elite 2864L Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Elite 2864L Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Connecting the Elite 2864L . . . . . . . . . . . . . . . . . . . . . . . 3-7
Turning on the Elite 2864L . . . . . . . . . . . . . . . . . . . . . . . 3-7
Elite 2864I and Elite 2864IU . . . . . . . . . . . . . . . . . . . . . . 3-7
Supreme 2864L . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Supreme 2864L Front Panel . . . . . . . . . . . . . . . . . . . . . . 3-8
Supreme 2864L Rear Panel. . . . . . . . . . . . . . . . . . . . . . . 3-8
Connecting the Supreme 2864L. . . . . . . . . . . . . . . . . . . . . 3-9
Turning on the Supreme 2864L . . . . . . . . . . . . . . . . . . . . . 3-9
Supreme 2864I and 2864IU . . . . . . . . . . . . . . . . . . . . . . 3-9
Omni 288P and Omni 288S . . . . . . . . . . . . . . . . . . . . . .3-10
Omni 288P Front Panel. . . . . . . . . . . . . . . . . . . . . . . . .3-10
Omni 288S Front Panel. . . . . . . . . . . . . . . . . . . . . . . . .3-10
Omni 288P Rear Panel. . . . . . . . . . . . . . . . . . . . . . . . .3-11
Omni 288S Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . .3-12
Connecting the Omni 288P . . . . . . . . . . . . . . . . . . . . . . .3-12
Connecting the Omni 288S . . . . . . . . . . . . . . . . . . . . . . .3-13
Turning on the Omni 288P or Omni 288S . . . . . . . . . . . . . . . .3-13

TOC-3
MODEM OPERATION
MODEM OPERATION 4-1
Parallel or Serial Port Operation. . . . . . . . . . . . . . . . . . . . . .4-1
PC Parallel Port Operation . . . . . . . . . . . . . . . . . . . . . . . .4-2
Parallel Port under Windows . . . . . . . . . . . . . . . . . . . . . . .4-2
Parallel Port under DOS . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Parallel Port Speed Limit . . . . . . . . . . . . . . . . . . . . . . . . .4-2
ZyXEL Parallel Port Adapter. . . . . . . . . . . . . . . . . . . . . . . .4-3
Using the Microphone and Speaker Jacks . . . . . . . . . . . . . . . . .4-3
Non-volatile Memory. . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Firmware Update/Upgrade . . . . . . . . . . . . . . . . . . . . . . . .4-3
DRAM Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Resetting The Modem . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
2864 QUICK START 5-1
LCD Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Panel Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Menu Tree. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
LED Status Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Double Arrows on The Screen. . . . . . . . . . . . . . . . . . . . . . .5-3
Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
Dial Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4
Storing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4
Dial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5
Manual Dial and the DATA/VOICE Switches . . . . . . . . . . . . . . . .5-5
Repeat Last Dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
Auto Answer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
Dialing Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7
Panel Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-9
MODEM PARAMETER SETTINGS 6-1
Parameter Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Parameter Selection . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
Status Register Content Modification. . . . . . . . . . . . . . . . . . . .6-2
Menu Tree Elements . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
TERMINAL OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3
MODEM OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-6
ERROR CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
AUDIO OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12

TOC-4
SETTINGS AND COMMANDS
PROFILES 7-1
Resetting from Profile . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Saving to Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Profile Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Resetting Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
STATUS REGISTERS 8-1
Reading and Setting S-Registers . . . . . . . . . . . . . . . . . . . . . 8-1
S-Register Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
ZyXEL-specific Registers. . . . . . . . . . . . . . . . . . . . . . . . . 8-5
AT COMMAND SET SUMMARY 9-1
Basic AT Command Set. . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Extended AT& Command Set . . . . . . . . . . . . . . . . . . . . . . 9-6
Extended AT* Command Set . . . . . . . . . . . . . . . . . . . . . .9-10
SPECIAL FUNCTIONS
ERROR CONTROL AND DATA COMPRESSION 10-1
Error Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-1
Data Compression . . . . . . . . . . . . . . . . . . . . . . . . . . .10-2
Run-length Encoding . . . . . . . . . . . . . . . . . . . . . . . . . .10-3
Adaptive Frequency Encoding . . . . . . . . . . . . . . . . . . . . . .10-3
String Coding . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-3
Bidirectional Compression. . . . . . . . . . . . . . . . . . . . . . . .10-4
Negotiation Fail Fall-Back. . . . . . . . . . . . . . . . . . . . . . . .10-4
DTE to DCE Connection. . . . . . . . . . . . . . . . . . . . . . . . .10-4
Averaging Throughput . . . . . . . . . . . . . . . . . . . . . . . . .10-4
Hints for High-speed Operation . . . . . . . . . . . . . . . . . . . . .10-5
Flow Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-5
Hardware CTS/RTS Flow Control. . . . . . . . . . . . . . . . . . . . .10-5
Software XON/XOFF Flow Control . . . . . . . . . . . . . . . . . . . .10-5
SYNCHRONOUS OPERATION 11-1
Clock Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-1
RTS Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-1
Half-Duplex Operation . . . . . . . . . . . . . . . . . . . . . . . . .11-2
Mode Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-2
Dial from Synchronous Mode . . . . . . . . . . . . . . . . . . . . . .11-2
Auto-answer from Synchronous Mode . . . . . . . . . . . . . . . . . .11-3
Manual Answer from Synchronous Mode. . . . . . . . . . . . . . . . .11-3
Change from Synchronous Mode into Asynchronous Mode . . . . . . . .11-3
Setting up a ZyXEL Modem with the AS-400 . . . . . . . . . . . . . . .11-3

TOC-5
LEASED-LINE OPERATION 12-1
Connecting to a Leased Line . . . . . . . . . . . . . . . . . . . . . . 12-1
Line Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-1
Power Level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-2
Handshake Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-2
Manual Connection . . . . . . . . . . . . . . . . . . . . . . . . . . 12-2
Auto-handshake . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-2
Leased-Line Dial Backup. . . . . . . . . . . . . . . . . . . . . . . . 12-3
Dial Backup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-3
Aborting from Leased-Line Operation . . . . . . . . . . . . . . . . . . 12-4
Disconnecting a Leased-Line Connection . . . . . . . . . . . . . . . . 12-4
SPECIAL FUNCTIONS 13-1
Security Function . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-1
Remote Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 13-2
Caller Number Delivery(CND). . . . . . . . . . . . . . . . . . . . . . 13-4
Distinctive Ring . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-5
Extended Distinctive Ring. . . . . . . . . . . . . . . . . . . . . . . . 13-6
Setting Up The EDR . . . . . . . . . . . . . . . . . . . . . . . . . . 13-7
Application Example . . . . . . . . . . . . . . . . . . . . . . . . . . 13-9
V.25bis Command Set . . . . . . . . . . . . . . . . . . . . . . . . . 13-9
CELLULAR MODE OPERATION 14-1
Cellular Phone Systems . . . . . . . . . . . . . . . . . . . . . . . . 14-1
Cellular Impairments. . . . . . . . . . . . . . . . . . . . . . . . . . 14-1
Cellular Modems and ZyCellular Technology. . . . . . . . . . . . . . . 14-2
ZyXEL ZyCellular Modes . . . . . . . . . . . . . . . . . . . . . . . . 14-3
Cellular Mode Usage. . . . . . . . . . . . . . . . . . . . . . . . . . 14-3
Cellular Modem Installation. . . . . . . . . . . . . . . . . . . . . . . 14-4
FAX OPERATION 15-1
ITU-T T.30 Fax Protocol . . . . . . . . . . . . . . . . . . . . . . . . 15-1
Fax Command Sets . . . . . . . . . . . . . . . . . . . . . . . . . . 15-2
Class 1 Command Set . . . . . . . . . . . . . . . . . . . . . . . . . 15-2
Class 2 Command Set . . . . . . . . . . . . . . . . . . . . . . . . . 15-3
Extended Fax AT Commands . . . . . . . . . . . . . . . . . . . . . 15-13
Flow Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-16
Parallel Receiving with the Fax Machine. . . . . . . . . . . . . . . . 15-17
Fax reception from within a BBS System. . . . . . . . . . . . . . . . 15-17
Direct FAX Reception and Printing. . . . . . . . . . . . . . . . . . . 15-18
Stand-alone FAX Reception and Storing . . . . . . . . . . . . . . . . 15-20

TOC-6
ADVANCED VOICE CAPABILITY 16-1
Voice Data Compression . . . . . . . . . . . . . . . . . . . . . . . .16-1
Automatic Detection of Voice, Fax and Data . . . . . . . . . . . . . . .16-2
Voice States and Operation Modes. . . . . . . . . . . . . . . . . . . .16-2
Voice Command State . . . . . . . . . . . . . . . . . . . . . . . . .16-3
Voice Data State . . . . . . . . . . . . . . . . . . . . . . . . . . . .16-4
Voice Data Transmission State. . . . . . . . . . . . . . . . . . . . . .16-4
Voice Data Receival State . . . . . . . . . . . . . . . . . . . . . . . .16-4
Events and Actions with Shielded Code. . . . . . . . . . . . . . . . . .16-5
Event Detection and Reporting. . . . . . . . . . . . . . . . . . . . . .16-5
Action Commands in Voice Data State . . . . . . . . . . . . . . . . . .16-7
Voice AT Commands . . . . . . . . . . . . . . . . . . . . . . . . . .16-8
Supported Commands For Voice Mode Operation . . . . . . . . . . . . .16-9
Action Voice Commands for Voice Mode Operation . . . . . . . . . . . 16-12
Configuration Commands for Voice Mode Operation. . . . . . . . . . . 16-14
Examples of Voice Mode Operation . . . . . . . . . . . . . . . . . . 16-20
Connecting a Telephone Set to the Modem's PHONE Jack . . . . . . . . . 16-27
NETWORK MANAGEMENT CAPABILITY 17-1
ZyXEL Modem Network Management System . . . . . . . . . . . . . . .17-1
Hierarchical Modem Network . . . . . . . . . . . . . . . . . . . . . .17-1
Distributed Management . . . . . . . . . . . . . . . . . . . . . . . .17-1
NMS Capable Models. . . . . . . . . . . . . . . . . . . . . . . . . .17-2
DIAGNOSTICS 18-1
Power-on Self-test . . . . . . . . . . . . . . . . . . . . . . . . . . .18-1
Analog Loopback Test (AT&T1) . . . . . . . . . . . . . . . . . . . . .18-2
Analog Loopback with Self-test (AT&T8) . . . . . . . . . . . . . . . . .18-3
Local Digital Loopback Test (AT&T3) . . . . . . . . . . . . . . . . . .18-3
Remote Digital Loopback Test (AT&T6) . . . . . . . . . . . . . . . . .18-4
Remote Digital Loopback with Self-test (AT&T7) . . . . . . . . . . . . .18-4
Line Condition Status Display . . . . . . . . . . . . . . . . . . . . . .18-5
Link Status Report (ATI2) . . . . . . . . . . . . . . . . . . . . . . . .18-7
Throughput Display. . . . . . . . . . . . . . . . . . . . . . . . . . 18-10
Retransmission Indicator . . . . . . . . . . . . . . . . . . . . . . . 18-10
Dialing Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-10
Handshaking And Retrain Indicator . . . . . . . . . . . . . . . . . . 18-10
Firmware Update . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-10

TOC-7
HINTS AND TIPS
GENERAL HINTS AND TIPS 19-1
Activating Saved Settings upon Turning-on. . . . . . . . . . . . . . . . 19-1
Avoiding Low Throughput and Loss of Data . . . . . . . . . . . . . . . 19-1
Disabling Compression May Yield Faster Transfers . . . . . . . . . . . . 19-1
Avoiding Disconnections during a Handshake on a Leased Line . . . . . . . 19-1
Avoiding Disconnections when Making a Data Call. . . . . . . . . . . . 19-1
Calling from an Extension / Blind Dial. . . . . . . . . . . . . . . . . . 19-2
THE FIRST CONNECTION 20-1
ZyXEL MODEMS AND A PC 21-1
Serial Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-1
Parallel Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-2
Using the Windows 3.1 Terminal Program. . . . . . . . . . . . . . . . 21-2
Hardware Hints . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-2
ZyXEL Serial/Parallel I/O Adapter Card. . . . . . . . . . . . . . . . . . 21-3
ZyXEL MODEMS AND UNIX 22-1
Hints for Unix Setups. . . . . . . . . . . . . . . . . . . . . . . . . . 22-1
Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-1
Software Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-2
ZyXEL MODEMS AND APPLE MACINTOSH 23-1
Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-1
Apple Macintosh Particularities . . . . . . . . . . . . . . . . . . . . . 23-1
Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-2
Software for the Apple Macintosh . . . . . . . . . . . . . . . . . . . . 23-3
ZyXEL MODEMS AND ATARIS 24-1
Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-1
Hardware Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-2
Software Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-2
ZyXEL MODEMS AND AMIGA 25-1
Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-1
Software Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-2
Hardware Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-2

TOC-8
APPENDICES
GLOSSARY GLO-1
EIA-232D INTERFACE A-1
PHONE JACK PIN ASSIGNMENTS B-1
ZyXEL PARALLEL PORT INTERFACE C-1
V.25bis COMMAND SET D-1
STANDARDS E-1
ASCII Control Characters . . . . . . . . . . . . . . . . . . . . . . . . E-1
Selection of ITU-T standards. . . . . . . . . . . . . . . . . . . . . . . E-2
Data transmission through telephone networks (V.1 -V.110). . . . . . . . E-3
INDEX Index-1

1–1
Chapter 1
INTRODUCTION
The2864 series ofV.34 modems includes three sub-series of models, namelytheSu-
preme, Elite and Omni series.The Supreme and Elite series models have ISDN ca-
pabilityorcanbeupgradedtohave ISDN capability.TheOmni series doesnothave
ISDN capability.The Supreme series provides an LCD display panel while the Elite
series has a front panel with LED indicators only. Many features are common to all
threeseries. If not noted otherwise,afeatureillustrated with oneseries model in this
manual applies to the other models and series as well.
The Elite 2864 series of high-speed modems features four base 10models.They dif-
fer only in the implemented line interface module, everything else is equivalent ex-
cept for the panel LED indicator designations.
The models are
The Elite 2864 has a 2-wire dial-up line DAA (Direct Access Arrangement) module
for connection to a normal PSTN (Public SwitchedTelephone Network) 2-wire
dial-up phone line.The Elite 2864L has a DAA with both a dial-up and leased line
interface. A 2 or a 4-wire leased line can also be used besides the normal 2-wire dial-
up line. Dial back-up capability is provided while using leased line.The Elite 2864I
has an ISDN S-interface module that will connect to an ISDN S-interface line. It
will connect to an ISDN call or a modem/fax call from PSTN made to this ISDN
line.AU-interfaceISDNmodule isavailablefortheUSAmarket.TheElite2864IU
is the ISDN model with the U-interface module.
By changing the line interface module, one Elite model will essentially become an-
otherElitemodel. Each Elite model has different markings on its front and rear pan-
els.Thus, in addition to the line interface module the front and rear panel also need
to be changed in order to transform one Elite model into a different Elite model.
Note that each Elite model has its own telecommunication authority approval
Model Name Line Interface Module Phone Line Used
Elite 2864 Dial-up line DAA Dial-up analog PSTN line
Elite 2864L Dial-upand leased line
DAA Dial-up and/or 2/4-wire leased ana- log line
Elite 2864I ISDN S-interface ISDN line, S-interface
Elite 2864IU ISDN U-interface ISDN line, U-interface

1–2
number.Whenthe modelischanged,theapprovalnumber isalso changed.Findthe
new approval number and check whether it is appropriate for the user to do the
model transformation before you start the transformation process.
Like the Elite series, the Supreme series includes different models which differ only
in the line interface module.There are three models in the Supreme series -The Su-
preme2864L,2864I,and2864IU.TheSupreme2864Lhasa DAAwithbothadial-
up and leased-line interface; the Supreme 2864I has an ISDN S-interface module;
the Supreme 2864IU has an ISDN U-interface module.
TheOmniseriesmodelshaveonlymodem/fax/voicecapability.Theydonotprovide
ISDNcapabilitynoraretheyISDNupgradeable.TheOmni288Pisthemodelwith
aparallelportDTEinterfaceandtheOmni288SiswithaserialportDTEinterface.
The Supreme and Elite models have both a parallel port and a serial port DTE in-
terface.
How To Use This Manual
This manual describes the use of all models in the 2864 series and gives instruction
for their installation and operation.The 2864I and 2864IU ISDN models come
with a separate manual describing their ISDN operation.
The manual is divided into five sections.
Basic Overview - The first section is comprised of chapter 1 (INTRODUCTION)
through chapter 3 (MODEM INSTALLATION). It gives a basic overview of the
2864 series modems' features, introduces some basics of modem operation for nov-
ice users, and explains the installation of the different models of the 2864 series.
Modem Operation-Thesecondsectionintroducesyoutosome skillsyou willneed
tomake the best use of yourmodem.Inchapter 4(MODEMOPERATION)you are
introduced to the use of the different modem ports and you will find information
on how to return the modem to standard settings (reset) and how to upgrade your
modem in the future.The panel operation of the Supreme models is described in
chapter 5 (2864 QUICK START) and chapter 6 (MODEM PARAMETER SET-
TINGS).Usersofthenon-LCDmodelsshouldconsulttheequivalentATcommand
sections listed for each of the panel operations.
Settings and Commands -The third section, chapter 7 (PROFILES) through
chapter 9 (AT COMMAND SET SUMMARY), provides an overview of the settings
and commands which are available in the 2864 series.
Special Functions - Section four is comprised of chapter 10 (ERROR CONTROL
ANDDATACOMPRESSION)through chapter 18(DIAGNOSTICS)anddescribes
manyspecial functions of the 2864 series modems in detail, including data compres-
sion, synchronous and leased-line operation, remote configuration, caller ID, cellu-

1–3
lar mode, fax sending and receiving, voice mail, network management, and
diagnostic features.
HintsandTips-Sectionfiveisthetrouble-shootingandspecialadvicesection.Here
you will find additional information on how to use a 2864 series modem with your
computer, and some hints and tipsrelatingtoa number of communication software
applications.
Appendices - An extensive glossary, several appendices with technical details, infor-
mation on standards, and a thorough index complete this manual.
Those who need more detailed technical information may contact ZyXEL Commu-
nicationsCorporation directly.The addresscan befoundin thedisclaimersection at
the beginning of this manual.
Compatibility
ZyXEL 2864 series modems are high performance universal modems capable of
transmission speeds up to 28.8 Kbps full-duplex on a 2-wire dial-up line. Universal
compatibilitycoversabroadrangeofITU-TandBELLstandards,andprovidesdata
compression.
Various operation modes that can be achieved are as follows:
Standard Bit rate
(+/-0,01%)
[bps]
Baud rate
(+/-0,01%)
[baud]
Modulation Carrier
frequency
[Hz]
V.34 28 800 - 2 400 multiple multiple multiple
ZyXEL 19 200 2 743
ZyXEL 16 800 2 400
V.33*14 400 2 400 128-TCM 1800
V.33*12 000 2 400 64-TCM 1800
V.32bis 14 400 2 400 128-TCM 1800
V.32bis 12 000 2 400 64-TCM 1800
V.32bis 7 200 2 400 16-TCM 1800
V.32 9 600 2 400 32-TCM 1800
V.32 uncoded 9 600 2 400 16-QAM 1800
V.32 4 800 2 400 4-DPSK 1800
V.29*9 600 2 400 16-QAM 1700
V.29*7 200 2 400 8-QAM 1700
V.29*4 800 2 400 4-DPSK 1700
V.27bis*4 800 1 600 8-PSK 1800

1–4
The 2864 Series Standard Features
•Synchronous/Asynchronous operations for external stand alone models and
rack mount models. (Parallel port interface is for asynchronous transmission
only)
•Asynchronous operations for PC internal card model.
•MNP class 4/5 error correction/data compression.
•V.42/V.42bis error correction/data compression. V.42 with selective reject.
•Extended AT command set.
•V.25bis async/sync command set.
•Operation on 2-wire dial-up line or 2/4-wire leased line. (4-wire leased line on
2864L only.)
•Auto-dial/answer and manual originate/answer.
•Tone/Pulse dialing.
•Dial tone, busy signal, and ringback detection.
•Programmable speaker volume control.
*. V33, V.29, V.27bis and V.26bis are only available in model 2864L for 4-wire
leased-line operation. The other operation modes are common to all models.
V.26bis works in half-duplex mode on 2-wire dial-up line.
†. 1800 Hz guard tone for V.22bis/V.22 answer mode, 6 dB below data signal level.
V.27bis*2 400 1 200 4-DPSK 1800
V.26bis*2 400 1 200 4-DPSK 1800
V.23 1200 / 75 1200 / 75 FSK
V.23 600 / 75 600 / 75 FSK
V.22bis†2 400 600 16-QAM 1200 Orig.
2400 Ans.
V.22†
(BELL 212A) 1 200 600 4-DPSK 1200 Orig. 2400 Ans.
V.21 300 300 FSK
BELL 103 300 300 FSK
G3 FAX implemented according to T.30, V.17,V.29 and V.27ter.
Cellular Modes ZyXEL proprietary cellular modes; 14400 bps to 4800 bps.
Standard Bit rate
(+/-0,01%)
[bps]
Baud rate
(+/-0,01%)
[baud]
Modulation Carrier
frequency
[Hz]
