ZyXEL Communications LTE Series User manual

Default Login Details
User’s Guide
LTE7461-M602 & LTE7480-S905
Copyright © 2019 Zyxel Communications Corporation
LAN IP Address http://192.168.1.1
Login admin
Password See the Zyxel Device label
Version 2.00 Ed 2, 9/2019

LTE Series User’s Guide
2
IMPORTANT!
READ CAREFULLY BEFORE USE.
KEEP THIS GUIDE FOR FUTURE REFERENCE.
This is a series User’s Guide. Screenshots and graphics in this book may differ slightly from what you see
due to differences in your product firmware or your computer operating system. Every effort has been
made to ensure that the information in this manual is accurate.
Related Documentation
•QuickStartGuide
The Quick Start Guide shows how to connect the Zyxel Device.
•MoreInformation
Go to support.zyxel.com to find other information on the Zyxel Device.

LTE Series User’s Guide
3
Document Conventions
Warnings and Notes
These are how warnings and notes are shown in this guide.
Warnings tell you about things that could harm you or your Zyxel
Device.
Note: Notes tell you other important information (for example, other things you may need to
configure or helpful tips) or recommendations.
Syntax Conventions
• The LTE device in this user’s guide may be referred to as the “Zyxel Device” in this guide.
• Product labels, screen names, field labels and field choices are all in bold font.
• A right angle bracket ( > ) within a screen name denotes a mouse click. For example, Network Setting
> Routing > DNS Route means you first click Network Setting in the navigation panel, then the Routing
sub menu and finally the DNS Route tab to get to that screen.
Icons Used in Figures
Figures in this user guide may use the following generic icons. The Zyxel Device icon is not an exact
representation of your Zyxel Device.
Zyxel Device Generic Router Switch
Server Firewall USB Storage Device
Printer

Contents Overview
LTE Series User’s Guide
4
Contents Overview
User’s Guide ......................................................................................................................................11
Introduction ........................................................................................................................................... 12
The Web Configurator ......................................................................................................................... 17
Quick Start ............................................................................................................................................. 24
Technical Reference ........................................................................................................................26
Connection Status ................................................................................................................................ 27
Broadband ............................................................................................................................................ 34
Home Networking ................................................................................................................................. 43
Routing ................................................................................................................................................... 66
Network Address Translation (NAT) ..................................................................................................... 74
Dynamic DNS Setup ............................................................................................................................. 84
Firewall ................................................................................................................................................... 88
MAC Filter .............................................................................................................................................. 99
Certificates .......................................................................................................................................... 101
Log ........................................................................................................................................................ 110
Traffic Status ........................................................................................................................................ 113
ARP Table ............................................................................................................................................ 116
Routing Table ...................................................................................................................................... 118
Cellular WAN Status ............................................................................................................................ 121
System .................................................................................................................................................. 125
User Account ...................................................................................................................................... 126
Remote Management ....................................................................................................................... 129
Time Settings ........................................................................................................................................ 133
E-mail Notification .............................................................................................................................. 136
Log Setting ........................................................................................................................................... 139
Firmware Upgrade .............................................................................................................................. 142
Backup/Restore .................................................................................................................................. 144
Diagnostic ........................................................................................................................................... 147
Troubleshooting & Appendices .....................................................................................................149
Troubleshooting .................................................................................................................................. 150

Table of Contents
LTE Series User’s Guide
5
Table of Contents
Document Conventions ......................................................................................................................3
Contents Overview .............................................................................................................................4
Table of Contents.................................................................................................................................5
Part I: User’s Guide..........................................................................................11
Chapter 1
Introduction ........................................................................................................................................12
1.1 Overview ......................................................................................................................................... 12
1.2 Application for the Zyxel Device .................................................................................................. 13
1.3 Manage the Zyxel Device ............................................................................................................. 13
1.4 Good Habits for Managing the Zyxel Device ............................................................................. 14
1.5 Front and Bottom Panels ............................................................................................................... 14
1.5.1 LEDs (Lights) ........................................................................................................................... 14
1.5.2 Bottom Panels ........................................................................................................................ 14
1.6 Using the WiFi Button ...................................................................................................................... 15
1.7 The RESET Button ............................................................................................................................. 16
Chapter 2
The Web Configurator........................................................................................................................17
2.1 Overview ......................................................................................................................................... 17
2.1.1 Access the Web Configurator ............................................................................................. 17
2.2 Web Configurator Layout .............................................................................................................. 19
2.2.1 Settings Icon .......................................................................................................................... 19
2.2.2 Widget Icon ........................................................................................................................... 23
Chapter 3
Quick Start..........................................................................................................................................24
3.1 Overview ......................................................................................................................................... 24
3.2 Quick Start Setup ............................................................................................................................ 24
3.3 Time Zone ........................................................................................................................................ 24
3.4 WiFi Setup ........................................................................................................................................ 25
3.5 Quick Start Setup-Finish .................................................................................................................. 25
Part II: Technical Reference...........................................................................26

Table of Contents
LTE Series User’s Guide
6
Chapter 4
Connection Status..............................................................................................................................27
4.1 Connection Status Overview ........................................................................................................ 27
4.1.1 Connectivity .......................................................................................................................... 27
4.1.2 System Info ............................................................................................................................. 28
4.1.3 WiFi Settings ........................................................................................................................... 30
4.1.4 LAN ......................................................................................................................................... 32
Chapter 5
Broadband..........................................................................................................................................34
5.1 Overview ......................................................................................................................................... 34
5.1.1 What You Can Do in this Chapter ....................................................................................... 34
5.1.2 What You Need to Know ..................................................................................................... 34
5.1.3 Before You Begin ................................................................................................................... 35
5.2 Cellular WAN ................................................................................................................................... 35
5.3 Cellular SIM Configuration ............................................................................................................. 37
5.4 Cellular Band Configuration .......................................................................................................... 38
5.5 PLMN Configuration ....................................................................................................................... 39
5.6 IP Passthrough ................................................................................................................................. 41
Chapter 6
Home Networking..............................................................................................................................43
6.1 Overview ......................................................................................................................................... 43
6.1.1 What You Can Do in this Chapter ....................................................................................... 43
6.1.2 What You Need To Know ..................................................................................................... 43
6.2 LAN Setup ........................................................................................................................................ 44
6.3 Static DHCP ..................................................................................................................................... 48
6.3.1 Before You Begin ................................................................................................................... 48
6.4 UPnP ................................................................................................................................................. 50
6.5 Technical Reference ...................................................................................................................... 51
6.6 Turn on UPnP in Windows 7 Example ............................................................................................ 52
6.6.1 Auto-discover Your UPnP-enabled Network Device ........................................................ 53
6.7 Turn on UPnP in Windows 10 Example .......................................................................................... 56
6.7.1 Auto-discover Your UPnP-enabled Network Device ........................................................ 58
6.8 Web Configurator Easy Access in Windows 7 ............................................................................. 61
6.9 Web Configurator Easy Access in Windows 10 ........................................................................... 63
Chapter 7
Routing................................................................................................................................................66
7.1 Overview ......................................................................................................................................... 66
7.2 Configure Static Route .................................................................................................................. 66
7.2.1 Add/Edit Static Route ........................................................................................................... 67
7.3 DNS Route ........................................................................................................................................ 69

Table of Contents
LTE Series User’s Guide
7
7.3.1 Add/Edit DNS Route ............................................................................................................. 69
7.4 Policy Route .................................................................................................................................... 70
7.4.1 Add/Edit Policy Route .......................................................................................................... 72
7.5 RIP Overview ................................................................................................................................... 73
7.5.1 RIP ........................................................................................................................................... 73
Chapter 8
Network Address Translation (NAT)..................................................................................................74
8.1 Overview ......................................................................................................................................... 74
8.1.1 What You Can Do in this Chapter ....................................................................................... 74
8.1.2 What You Need To Know ..................................................................................................... 74
8.2 Port Forwarding Overview ............................................................................................................. 75
8.2.1 Port Forwarding ..................................................................................................................... 76
8.2.2 Add/Edit Port Forwarding ..................................................................................................... 77
8.3 Port Triggering ................................................................................................................................. 78
8.3.1 Add/Edit Port Triggering Rule ............................................................................................... 80
8.4 DMZ .................................................................................................................................................. 81
8.5 ALG ................................................................................................................................................... 82
Chapter 9
Dynamic DNS Setup...........................................................................................................................84
9.1 DNS Overview ................................................................................................................................. 84
9.1.1 What You Can Do in this Chapter ....................................................................................... 84
9.1.2 What You Need To Know ..................................................................................................... 84
9.2 DNS Entry ......................................................................................................................................... 85
9.2.1 Add/Edit DNS Entry ............................................................................................................... 85
9.3 Dynamic DNS .................................................................................................................................. 86
Chapter 10
Firewall................................................................................................................................................88
10.1 Overview ....................................................................................................................................... 88
10.1.1 What You Need to Know About Firewall .......................................................................... 88
10.2 Firewall ........................................................................................................................................... 89
10.2.1 What You Can Do in this Chapter ..................................................................................... 89
10.3 Firewall General Settings .............................................................................................................. 89
10.4 Protocol (Customized Services) .................................................................................................. 91
10.4.1 Add Customized Service .................................................................................................... 91
10.5 Access Control (Rules) ................................................................................................................. 92
10.5.1 Access Control Add New ACL Rule .................................................................................. 93
10.6 DoS ................................................................................................................................................. 95
10.7 Firewall Technical Reference ...................................................................................................... 96
10.7.1 Firewall Rules Overview ...................................................................................................... 96
10.7.2 Guidelines For Security Enhancement With Your Firewall .............................................. 97

Table of Contents
LTE Series User’s Guide
8
10.7.3 Security Considerations ...................................................................................................... 97
Chapter 11
MAC Filter ...........................................................................................................................................99
11.1 MAC Filter Overview ..................................................................................................................... 99
11.2 MAC Filter ...................................................................................................................................... 99
Chapter 12
Certificates .......................................................................................................................................101
12.1 Overview ..................................................................................................................................... 101
12.1.1 What You Can Do in this Chapter ................................................................................... 101
12.2 Local Certificates ....................................................................................................................... 101
12.2.1 Create Certificate Request ............................................................................................. 102
12.2.2 View Certificate Request ................................................................................................. 103
12.3 Trusted CA ................................................................................................................................... 105
12.4 Import Trusted CA Certificate ................................................................................................... 106
12.5 View Trusted CA Certificate ...................................................................................................... 106
12.6 Certificates Technical Reference ............................................................................................. 107
12.6.1 Verify a Certificate ............................................................................................................ 108
Chapter 13
Log ....................................................................................................................................................110
13.1 Log Overview .............................................................................................................................. 110
13.1.1 What You Can Do in this Chapter ................................................................................... 110
13.1.2 What You Need To Know ................................................................................................. 110
13.2 System Log .................................................................................................................................. 111
13.3 Security Log ................................................................................................................................. 111
Chapter 14
Traffic Status .....................................................................................................................................113
14.1 Traffic Status Overview ............................................................................................................... 113
14.1.1 What You Can Do in this Chapter ................................................................................... 113
14.2 WAN Status .................................................................................................................................. 113
14.3 LAN Status .................................................................................................................................... 114
Chapter 15
ARP Table..........................................................................................................................................116
15.1 ARP Table Overview ................................................................................................................... 116
15.1.1 How ARP Works .................................................................................................................. 116
15.2 ARP Table .................................................................................................................................... 117
Chapter 16
Routing Table....................................................................................................................................118

Table of Contents
LTE Series User’s Guide
9
16.1 Routing Table Overview ............................................................................................................ 118
16.2 Routing Table .............................................................................................................................. 118
Chapter 17
Cellular WAN Status ........................................................................................................................121
17.1 Cellular WAN Status Overview .................................................................................................. 121
17.2 Cellular WAN Status .................................................................................................................... 121
Chapter 18
System...............................................................................................................................................125
18.1 System Overview ........................................................................................................................ 125
18.2 System .......................................................................................................................................... 125
Chapter 19
User Account....................................................................................................................................126
19.1 User Account Overview ............................................................................................................. 126
19.2 User Account .............................................................................................................................. 126
19.2.1 User Account Add/Edit .................................................................................................... 127
Chapter 20
Remote Management.....................................................................................................................129
20.1 Overview ..................................................................................................................................... 129
20.2 MGMT Services ............................................................................................................................ 129
20.3 MGMT Services for IP Passthrough ............................................................................................ 130
20.4 Trust Domain ................................................................................................................................ 131
20.5 Add Trust Domain ....................................................................................................................... 131
Chapter 21
Time Settings.....................................................................................................................................133
21.1 Time Settings Overview .............................................................................................................. 133
21.2 Time .............................................................................................................................................. 133
Chapter 22
E-mail Notification ...........................................................................................................................136
22.1 E-mail Notification Overview ..................................................................................................... 136
22.2 E-mail Notification ...................................................................................................................... 136
22.2.1 E-mail Notification Edit ...................................................................................................... 137
Chapter 23
Log Setting .......................................................................................................................................139
23.1 Log Setting Overview ................................................................................................................. 139
23.2 Log Setting ................................................................................................................................... 139

Table of Contents
LTE Series User’s Guide
10
Chapter 24
Firmware Upgrade...........................................................................................................................142
24.1 Overview ..................................................................................................................................... 142
24.2 Firmware Upgrade ...................................................................................................................... 142
Chapter 25
Backup/Restore ...............................................................................................................................144
25.1 Backup/Restore Overview ........................................................................................................ 144
25.2 Backup/Restore .......................................................................................................................... 144
25.3 Reboot ......................................................................................................................................... 145
Chapter 26
Diagnostic.........................................................................................................................................147
26.1 Diagnostic Overview .................................................................................................................. 147
26.2 Ping/TraceRoute/Nslookup Test ................................................................................................ 147
Part III: Troubleshooting & Appendices ......................................................149
Chapter 27
Troubleshooting................................................................................................................................150
27.1 Overview ..................................................................................................................................... 150
27.2 Power and Hardware Connections ......................................................................................... 150
27.3 Zyxel Device Access and Login ................................................................................................ 150
27.4 Internet Access ........................................................................................................................... 152
27.5 UPnP ............................................................................................................................................. 153
27.6 SIM Card ...................................................................................................................................... 154
27.7 Cellular Signal ............................................................................................................................. 154
Appendix A Customer Support ..................................................................................................... 156
Appendix B IPv6............................................................................................................................... 162
Appendix C Legal Information ...................................................................................................... 168
Index.................................................................................................................................................175

11
PART I
User’s Guide

LTE Series User’s Guide
12
CHAPTER 1
Introduction
1.1 Overview
Zyxel Device refers to these models as outlined below.
The following table describes the feature differences of the Zyxel Device by model.
The Zyxel Device is an outdoor LTE (Long Term Evolution) router that supports (but not limited to) the
following:
• Gigabit Ethernet connection
• DHCP (Dynamic Host Configuration Protocol) server
• NAT (Network Address Translation)
• DMZ (Demilitarized Zone)
• Port Forwarding/Triggering
• ALG (Application Layer Gateway)
• Embedded Bridge/Router mode
• Dynamic DNS (Domain Name System) for the first APN (Access Point Name)
• Static/Dynamic Route setting for RIP (Routing Information Protocol)
• Remote Management under Bridge mode
• LTE7461-M602
• LTE7480-S905
Table 1 Zyxel Device Comparison Table
LTE7461-M602 LTE7480-S905
Gigabit Ethernet Port V V
2.4G WLAN - -
LTE Speed FDD-LTE
• Downlink: 400 Mbps
(Optional: 256QAM support)
• Uplink: 50 Mbps
TDD-LTE config. #2
• Downlink: 573 Mbps
• Uplink: 15.1 Mbps
Note: These are the theoretical downlink and uplink rates. LTE speed is
affected by strength of signal, network congestion, LTE band(s) or
frequency(-ies) to which your Zyxel Device is connected, and so forth.
LTE Band B2/4/5/7/12/13/25/26/29/66 B48
WCDMA B2/4/5 -
Wall Mount V V
Pole Mount V V

Chapter 1 Introduction
LTE Series User’s Guide
13
• Address Resolution Protocol (ARP)
• Firewall that uses Stateful Packet Inspection (SPI) technology
• Protects against Denial of Service (DoS) attacks
• Filter of LAN MAC address, LAN IP address and URLs
• Local and remote device management
• Firmware upgrade via Web Configurator
The embedded Web-based Configurator enables straightforward management and maintenance. Just
insert the SIM card (with an active data plan) and make the hardware connections. See the Quick Start
Guide for how to do the hardware installation, wall mounting, Internet setup and turning on/off WiFi
(optional).
1.2 Application for the Zyxel Device
Wireless WAN
TheZyxel Device can connect to the Internet through a 2G/3G/4G LTE SIM card to access a wireless
WAN connection. Just insert a SIM card into the SIM card slot at the bottom of the Zyxel Device.
Note: You must insert the SIM card into the card slot before turning on the Zyxel Device.
Internet Access
Your Zyxel Device provides shared Internet access by connecting to an LTE network. A computer can
connect to the Zyxel Device’s PoE injector for configuration via the Web Configurator.
Figure 1 Zyxel Device’s Internet Access Application
1.3 Manage the Zyxel Device
Use the Web Configurator for management of the Zyxel Device using a (supported) web browser.
LTE (4G)/3G/2G
WiFi

Chapter 1 Introduction
LTE Series User’s Guide
14
1.4 Good Habits for Managing the Zyxel Device
Do the following things regularly to make the Zyxel Device more secure and to manage the Zyxel
Device more effectively.
• Change the password. Use a password that’s not easy to guess and that consists of different types of
characters, such as numbers and letters.
• Write down the password and put it in a safe place.
• Back up the configuration (and make sure you know how to restore it). Refer to Section 25.2 on page
144. Restoring an earlier working configuration may be useful if the Zyxel Device becomes unstable or
even crashes. If you forget your password to access the Web Configurator, you will have to reset the
Zyxel Device to its factory default settings. If you backed up an earlier configuration file, you would
not have to totally re-configure the Zyxel Device. You could simply restore your last configuration.
Write down any information your ISP provides you.
1.5 Front and Bottom Panels
The LED indicators are located on bottom panel.
Figure 2 Bottom Panel
1.5.1 LEDs (Lights)
None of the LEDs are on if the Zyxel Device is not receiving power.
1.5.2 Bottom Panels
The connection ports are located on the bottom panel.
LED Descriptions
COLOR STATUS DESCRIPTION
Red Blinking The Zyxel Device is booting or self-testing.
On The Zyxel Device encountered an error.
Green Blinking The Zyxel Device is trying to connect to the Internet.
On The Zyxel Device is connected to the Internet.
Amber Blinking The Zyxel Device WiFi is on.

Chapter 1 Introduction
LTE Series User’s Guide
15
The following table describes the items on the bottom panel.
1.6 Using the WiFi Button
The wireless network is turned off by default.
You can use the wireless function for 30 minutes by default after the Zyxel Device finishes rebooting or
when the wireless function is turned on.
Figure 3 WiFi Button
To turn on WiFi:
1Make sure the POWER LED is on and not blinking.
2Press the WiFi button for more than 5 seconds and release it.
Once WiFi is turned on, the LED blinks amber.
To activate WPS (WiFi must be already on):
1Press the WiFi button for more than 1 second but less than 5 seconds and release it (pressing more than
5 seconds will turn off WiFi).
2Press the WPS button on another WPS-enabled device within range of the Zyxel Device.
To turn off the wireless network, press the WiFi button for more than 5 seconds.
The amber LED turns off.
Table 2 Panel Ports and Buttons
LABEL DESCRIPTION
LAN Connect a computer via the PoE injector for configuration.
Connect the PoE injector to a power outlet to start the device.
WiFi Press the WLAN button for more than five seconds to enable the wireless function.
WPS After the wireless function is enabled, press the WLAN button for more than one second but less
than five seconds to quickly set up a secure wireless connection between the device and a WPS-
compatible client.
Reset Press the button for more than five seconds to return the Zyxel Device to the factory defaults.
Reboot Press the RESET button for more than 2 seconds but less than 5 seconds, it will cause the system to
reboot.
SIM card Insert a micro-SIM card into the slot with the chip facing down and the beveled corner in the top
left corner.

Chapter 1 Introduction
LTE Series User’s Guide
16
Note: Use the WiFi function of the Zyxel Device for configuration (for example, connect to the
LTE Ally app of your mobile device to find the optimal LTE signal strength and manage
your Zyxel Device).
1.7 The RESET Button
If you forget your password or cannot access the Web Configurator, you will need to use the RESET
button of the Zyxel Device as shown in the following figure to reload the factory-default configuration
file. This means that you will lose all configurations that you had previously saved, the password will be
reset to the default password shown on the device label and the IP address will be reset to 192.168.1.1.
Figure 4 Reset Button
1Make sure the Zyxel Device is connected to power and POWER LED is on.
2To set the Zyxel Device back to the factory default settings, press the RESET button for 5 seconds.
Note: If you press the RESET button for more than 2 seconds but less than 5 seconds, it will
cause the system to reboot.

LTE Series User’s Guide
17
CHAPTER 2
The Web Configurator
2.1 Overview
The Web Configurator is an HTML-based management interface that allows easy Zyxel Device setup
and management via Internet browser. Use Internet Explorer 8.0 and later versions or Mozilla Firefox 3
and later versions or Safari 2.0 and later versions. The recommended screen resolution is 1024 by 768
pixels.
In order to use the Web Configurator you need to allow:
• Web browser pop-up windows from your Zyxel Device. Web pop-up blocking is enabled by default in
Windows 10.
• JavaScript (enabled by default).
• Java permissions (enabled by default).
2.1.1 Access the Web Configurator
1Make sure your Zyxel Device hardware is properly connected (refer to the Quick Start Guide).
2Launch your web browser. If the Zyxel Device does not automatically re-direct you to the login screen,
go to http://192.168.1.1.
3A password screen displays. Select the language you prefer (upper right).
4To access the Web Configurator and manage the Zyxel Device, type the default username admin and
the randomly assigned default password (see the Zyxel Device label) in the Login screen and click Login.
If you have changed the password, enter your password and click Login.
Figure 5 Password Screen

Chapter 2 The Web Configurator
LTE Series User’s Guide
18
Note: The first time you enter the password, you will be asked to change it. Make sure the new
password must contain at least one uppercase letter, one lowercase letter and one
number.
5The Connection Status screen appears. Use this screen to configure basic Internet access, wireless
settings, and parental control settings.
Figure 6 Connection Status

Chapter 2 The Web Configurator
LTE Series User’s Guide
19
2.2 Web Configurator Layout
Figure 7 Screen Layout
As illustrated above, the main screen is divided into these parts:
•A- Settings Icon (Navigation Panel & Side Bar)
•B- Widget Icon
•C- Main Window
2.2.1 Settings Icon
Click this icon ( ) to see the side bar and navigation panel.
C
A
B

Chapter 2 The Web Configurator
LTE Series User’s Guide
20
2.2.1.1 Side Bar
The side bar provides some icons on the right hand side.
The icons provide the following functions.
Table 3 Web Configurator Icons in the Title Bar
ICON DESCRIPTION
Wizard: Click this icon to open screens where you can configure the Zyxel Device’s time zone
and wireless settings. See Chapter 3 on page 24 for more information about the Wizard screens.
Theme: Click this icon to select a color that you prefer and apply it to the Web Configurator.
Language: Select the language you prefer.
Restart: Click this icon to reboot the Zyxel Device without turning the power off.
Logout: Click this icon to log out of the Web Configurator.
