ZyXEL
Firmware Release Note
Prestige 662HW-61
Standard Version
Release 3.40(QR.5)C1
Date: Feb 15, 2005
Author: Keil Chu

ZyXEL Confidential
340QR5C1.doc 2/38
ZyXEL Prestige 662HW-61 Standard Version
Release 3.40(QR.5)C1
Release Note
Date: Feb 15, 2005
Supported Platforms:
ZyXEL Prestige 662HW-61
Versions:
ZyNOS Version : V3.40(QR.5) | 12/2/2004 19:16:06
Bootbase Version : V1.10t | 1/17/2005 15:54:30
Notes:
The Prestige 662HW-61, is 4th generation of ZyXEL ADSL product family. It is a high
performance ADSL/ADSL2/ADSL2+ router for small/medium office to have Internet
access and LAN-to-LAN application over the existing copper line. P662HW-61 takes
advantage of much higher data rate than ADSL, speed up to 12Mbps (ADSL2) or 26Mbps
(ADSL2+), greater reach, faster start-up, advanced diagnostics and better power
management. This high performance ADSL router is a high integrated advanced Firewall,
Bandwidth Management and IEEE 802.11g wireless features to meet the demand of
high-end market.
P662HW-61 provides an embedded mini-PCI module for 802.11g Wireless LAN
connectivity, four single auto-sensing, auto-detection 10/100BASE-T Ethernet ports for
connection to the user’s local network, and a single RJ-11/RJ-45 port for connection to
ADSL/ADSL2/ADSL2+ line.
Internal Information:
Modifications in V 3.40(QR.2)b2 | 06/28/2004
1. [FEATURE ENHANCE]
Symptom: Support multicast firmware upgrade tools on PC, please refer to related
document for details.
Condition: N/A
1.Known Issues:
1. US Robotics modem is not supported for dial backup
2. If user wants to register to extend expired date, packet-Scan engine won’t send out
expired date request until 6th checking with Packet-Scanning server.

ZyXEL Confidential
340QR5C1.doc 3/38
3. If device LAN is connected with a switch, and device reboots, then the PC with Any-IP
can't connect with device until ARP entry is cleared by PC.
4. WLAN has Beacon failure problem when the channel is in very busy/dirty condition
5. In Web/GUI, the MBM wizard successful page is English only.
2.Features:
Modifications in V 3.40(QR.5)C1 | 02/15/2005
1. update bootbase to change MAC OUI from 00A0C5 to 001349(short term solution)
Modifications in V 3.40(QR.5)C0 | 12/2/2004
1. [FEATURE CHANGE]
Change to FCS version.
Modifications in V 3.40(QR.5)b2 | 11/29/2004
1. [BUG FIX]
Symptom: In “VC auto hunt failed” page, if we change the HTTP port number in
smt24.11, and then the “here” hyperlink can’t connect to eWC.
Condition: N/A
2. [BUG FIX]
Symptom: If the Web site is blocked by CAC Web control function, then the
centralized logs can’t display correct username and URL address in logs.
Condition: N/A
3. [FEATURE CHANGE]
Symptom: The default ESSID of wireless is changed to “ZyXEL”
Condition: N/A
4. [BUG FIX]
Symptom: In PPPoE mode, if uses the CI command “device drop channel all”, the
PPPoE can’t dial up any more.
Condition: N/A
5. [BUG FIX]
Symptom: Turn on Anti-Virus to scan HTTP packets, and go to the Web site
“http://www.alltime.ru/watch.shtml”, device will get exceptions.
Condition: N/A
Solution: Update the AV engine to 0.18 can fix this bug.
6. [BUG FIX]
Symptom: In eWC, the F/W upload page doesn’t have password protection.
Condition: N/A
7. [BUG FIX]
Symptom: For SIP pass-through feature, if the SIP client uses an account with IP
address like [email protected] , then our router will modify the IP address field, and
causes the SIP connection failed.
Condition: N/A
Solution: It is not necessary to modify the SIP tag “from”, and “to” field at any time.
Modifications in V 3.40(QR.5)b1 | 11/18/2004
1. [BUG FIX]

ZyXEL Confidential
340QR5C1.doc 4/38
Symptom: The Web redirect function can’t work if HTTP port number is changed by
remote management function.
Condition: N/A
2. [BUG FIX]
Symptom: Device will crash when doing PAP with INode PPPoE server
Condition: If PPPoE server uses PAP and then our device receive a packet PAP ACK
or PAP NAK, but it only happens in Inode server.
3. [BUG FIX]
Symptom: When delete SMT4 and the ADSL mode changes to multi mode
automatically even we configure it as G.DMT
Condition: N/A
4. [BUG FIX]
Symptom: IPSec Transport mode will be treated as Tunnel mode
Condition: N/A
5. [BUG FIX]
Symptom: The IP Alias is active in rom-t, but it is actually inactive in SMT
Condition: N/A
6. [BUG FIX]
Symptom: DNS server can't work after configuring DNS server in smt3.2 or web LAN
page, it need reboot system to let DNS server work.
Condition: N/A
7. [BUG FIX]
Symptom: Routing table doesn't update when change different remote IP in SMT4 and
encapsulation is ENET ENCAP.
Condition: N/A
8. [BUG FIX]
Symptom: In Web/GUI firewall rule summary page there is no LAN to WAN ACL set
Condition: N/A
9. [BUG FIX]
Symptom: In Web/GUI, changing the setting of Windows Networking (NetBIOS over
TCP/IP) in DMZ setting page will cause system reboot
Condition: N/A
10. [BUG FIX]
Symptom: Customers report that can’t build VPN tunnel between 2 devices when using
DES/3DES encryption, but after we changing the AES encryption the tunnel is built
OK.
Condition: N/A
11. [BUG FIX]
Symptom: In smt3 2, we change nothing but it still save to ROM file
Condition: N/A
12. [BUG FIX]
Symptom: Use ENET ENCAP mode, traffic redirect/Dial backup function can't work
fine if the destination IP is in the same subnet with WAN IP address.
Condition: N/A

ZyXEL Confidential
340QR5C1.doc 5/38
Modifications in V 3.40(QR.4)C0 | 10/01/2004
1. [FEATURE CHANGE]
Symptom: Change to FCS version
Condition: N/A
Modifications in V 3.40(QR.4)b2 | 09/30/2004
1. [BUG FIX]
Symptom: The router gets exception when a client PC runs a port scan tool “bonk”.
Condition: N/A
2. [BUG FIX]
Symptom: User can’t login to embedded Web/GUI, if PC uses windows XP and
installed service pack 2, and the system UPnP is enabled.
Condition: Only happens when UPnP function is enabled.
Modifications in V 3.40(QR.4)b1 | 09/22/2004
1. [BUG FIX]
Symptom: Enable email Anti-Virus packet scanning function, then system gets
exception when doing email stress test.
Condition: N/A
2. [BUG FIX]
Symptom: For Zero-Configuration feature, when VC auto hunt successfully, and the
display PPPoE username/password page, but input wrong value, the Web page will be
always in testing state.
Condition: N/A
Modifications in V 3.40(QR.2)b6 | 09/16/2004
1. [BUG FIX]
Symptom: Configuring the bandwidth of MBM class by command “bm
defaultClassBw 20 (kbps)”, but it doesn’t work.
Condition: N/A
2. [BUG FIX]
Symptom: Register and Activate CAC but disable it, and configure some Web
categories to block web sites and then uses browser to get on Internet, the system will
get exception.
Condition: N/A
3. [BUG FIX]
Symptom: Using Web/GUI to update firmware, the Web page will display error
message.
Condition: N/A
4. [BUG FIX]
Symptom: Reset to default ROM file, and after Anti-Virus activated, the first time to
update AV engine will get failed, but it only found in PQA’s environment.
Condition: N/A
5. [BUG FIX]

ZyXEL Confidential
340QR5C1.doc 6/38
Symptom: The Zero-configuration(VC auto-hunting) is not turned on by default.
Condition: N/A
6. [BUG FIX]
Symptom: Configuring ATUR two remote nodes with PPPoE mode, after two PVC
are connected, change the DSLAM first PVC setting with a wrong VPI/VCI. Drop the
first PVC in ATUR, and dial it again, the first PVC (PPPoE) still can dial up
successfully.
Condition: N/A
7. [BUG FIX]
Symptom: DNS resolving wrong, if the ping an address from console like
“www.123.com”, system resolves as 0.123.0.0.
Condition: N/A
8. [BUG FIX]
Symptom: NetMeeting can’t be connected when the connection is from WAN to LAN
Condition: N/A
9. [BUG FIX]
Symptom: Configure a MAC address and IP address in static DHCP pool, if a PC is
requesting IP by DHCP but it is not in the static DHCP pool, the system will assign the
IP address which is belong to static DHCP pool.
Condition: N/A
10. [FEATURE CHANGE]
Symptom: In CAC feature, configure 4 groups name “GROUP1” to “GROUP4” by
default.
Condition: N/A
11. [BUG FIX]
Symptom: In AV feature, the E-Mail scanning will cause our CPU loading to reach to
100% and SMT will hang up for a few seconds.
Condition: Only happens when receiving E-Mail attachments and E-Mail AV scanning
is enabled.
12. [FEATURE ENHANCE]
Symptom: Enhance CI command under “lan” to support DMZ interface, please refer to
appendix – CI command list for details.
Condition: N/A
13. [FEATURE ENHANCE]
Symptom: If WLAN card is not existed, system will change product name
automatically to “P662H-61”.
Condition: N/A
14. [BUG FIX]
Symptom: In Web/GUI, change PPPoE pass-through from “No” to “Yes” but the
function can’t work immediately, but after reboot it can work fine.
Condition: N/A
15. [BUG FIX]
Symptom: The string “Enter Menu selection number:" display two times in SMT 15.1
Condition: N/A
16. [FEATURE CHANGE]
Symptom: In Web/GUI, content filter keyword blocking page if we key in capital letter

ZyXEL Confidential
340QR5C1.doc 7/38
then the content filter function can't work.
Condition: N/A
Solution: Use case-insensitive type instead of case-sensitive for keyword search.
17. [BUG FIX]
Symptom: When multiple stations connected to AP, once the previous one leave, the
other stations also disappeared.
Condition: N/A
18. [BUG FIX]
Symptom: Use CI command ”wlan association” to show association list will cause
system reboot.
Condition: When 3 stations connect to device if user uses CI command ”wlan
association” to show association list will cause system reboot
19. [BUG FIX]
Symptom: When Cerberian server stop the service, our request to Cerberian will get
“request error”, at that time, uses CAC will cause system exception.
Condition: Happens only when Cerberian server stop service, and our reqest will get
“request error”.
20. [BUG FIX]
Symptom: In AV feature, the message “scanned by GGreat” message will appear in
Email when virus detected
Condition: N/A
Modifications in V 3.40(QR.2)b5 | 08/11/2004
1. [BUG FIX]
Symptom: In Web/GUI, firewall page, the help about the customized services is
updated
Condition: N/A
2. [FEATURE CHANGE]
Symptom: In Web/GUI, CAC time scheduling should be "from Midnight to 24:00PM”
by default.
Condition: N/A
3. [BUG FIX]
Symptom: In Web/GUI CAC/Web category page, if user clicks "more…" to extend the
categories, and then click "basic…", the Web page swapping is very slow.
Condition: N/A
4. [BUG FIX]
Symptom: Enable the CAC, and then reboot device, and then PPPoE connection can’t
be dialed up by packets.
Condition: N/A
5. [BUG FIX]
Symptom: In CAC feature, when time budget is used up, it should not show "Idle Time
out" in small logout windows.
Condition: N/A
6. [BUG FIX]

ZyXEL Confidential
340QR5C1.doc 8/38
Symptom: In content filter, the schedule function and trusted user IP don’t work
Condition: N/A
7. [BUG FIX]
Symptom: WEB translation and characters of DHCP relay page has error in French
language.
Condition: N/A
8. [BUG FIX]
Symptom: The French login page is Germany, and the Germany login page is French
Condition: N/A
9. [BUG FIX]
Symptom: In French windows OS, the CAC budget left timer do not run
Condition: N/A
10. [BUG FIX]
Symptom: In eWC, the DMZ page, RIP version default should be N/A
Condition: N/A
11. [BUG FIX]
Symptom: When click "Activation" and "update now" of the anti-virus, system needs
to display a warning message that is to warn device needing reboot
Condition: N/A
12. [BUG FIX]
Symptom: When CAC turn on, the NAT server set (port forwarding) can’t work
Condition: N/A
Solution: If CAC is turn on, and LAN server should accept incoming request from
external side, if LAN PC is configured in NAT server set.
13. [BUG FIX]
Symptom: System is configured as PPPoE, after PPPoE is idle timeout, and then start
IE to trigger PPPoE, but it will redirect to "enter the username and password" page. It
problem also happens when the WAN link switch from dial backup to DSL link.
Condition: N/A
14. [BUG FIX]
Symptom: Using dial backup, the Web dynamic category block function of CAC do
not work, and device sometimes reboot when using IE to get web page
Condition: N/A
15. [BUG FIX]
Symptom: Reset to default configuration, using Web/GUI connection wizard to setting
connection to be PPPoE, after diagnostic is successful, and then starting the IE, it can
not get on Internet.
Condition: N/A
16. [FEATURE ENHANCE]
Symptom: In Web/GUI Anti-Virus, the item “Default action when session overflow”
supports multi language.
Condition: N/A
17. [FEATURE ENHANCE]
Symptom: In Web/GUI BW-Mgnt, the help page is updated for dynamic service H.323
and FTP
Condition: N/A

ZyXEL Confidential
340QR5C1.doc 9/38
18. [FEATURE ENHANCE]
Symptom: In Web/GUI MBM Wizard, the help and multi language is supported.
Cndition: N/A
19. [FEATURE ENHANCE]
Symptom: The redirected Web pages of Zero-Configuration support multi language
Condition: N/A
20. [FEATURE ENHANCE]
Symptom: In Web/GUI, CAC page supports help and support multi language.
Condition: N/A
21. [FEATURE ENHANCE]
Symptom: In Web/GUI, firewall page, the help in customized services support multi-
language
Condition: N/A
22. [BUG FIX]
Symptom: In MBM advance, add a class and budget is over than root budget, system
will save it anyway with a warning message, if you go to Wizard system will return an
error also.
Condition: N/A
23. [BUG FIX]
Symptom: In eWC CAC feature, if admin is login-in, system will allow the PC to
connect Internet but if admin is timeout from eWC, the PC still can connect Internet
Condition: N/A
Solution: If Admin is timeout or logout, the PC should redirect to login page.
24. [BUG FIX]
Symptom: The throughput from LAN to WLAN is only 10Mb around when tested by
Chariot tool.
Condition: N/A
25. [FEATURE ENHANCE]
Symptom: The AV engine is updated to version 0.13.
Condition: N/A
26. [FEATURE ENHANCE]
Symptom: In logs page, add alert for Anti-Virus feature, that means if virus is detected
system can send an email to Admin immediately.
Condition: N/A
27. [FEATURE ENHANCE]
Symptom: Add a command “bm defaultClassBw” to adjust the default bandwidth of
class for MBM.
Condition: N/A
28. [BUG FIX]
Symptom: When system receive OAM AIS packet, the data channel will be corrupted
and can’t be recovered until ADSL drop and connected again.
Condition: N/A
Modifications in V 3.40(QR.2)b4 | 07/16/2004
1. [FEATURE ENHANCE]

ZyXEL Confidential
340QR5C1.doc 10/38
Symptom: Support CAC (Content Access Control) feature, please refer to external
specification or appendix for details.
Condition: N/A
2. [FEATURE ENHANCE]
Symptom: Support Vantage CNM
Condition: N/A
3. [BUG FIX]
Symptom: If WAN (ISP) provides static IP address, and the VC auto-hunt is active,
then the hunting will fail always.
Condition: N/A
Solution: If WAN (ISP) provides static IP address, the VC auto-hunt feature should be
turn off in SMT4, SMT11, and connection Wizard.
4. [FEATURE CHANGE]
Symptom: The default ROM file setting of DMZ- RIP should be turned off
Condition: N/A
5. [BUG FIX]
Symptom: In Web/GUI, spelling error in firewall customized port hyperlink, and
change to multi language the customized port link will display error.
Condition: N/A
6. [BUG FIX]
Symptom: In Web/GUI, NAT page, click edit details, and change NAT setting to full
feature and don’t apply it, but it always configured as full feature.
Condition: N/A
7. [BUG FIX]
Symptom: In Anti-Virus page, the activating and update function display successfully
but the expire date is still old (1970/01/01).
Condition: N/A
8. [BUG FIX]
Symptom: Turning on Anti-Virus debug flag will cause update function failed
Condition: N/A
Modifications in V 3.40(QR.2)b3 | 07/08/2004
1. [BUG FIX]
Symptom: DMZ can’t work fine when promiscuous mode is enabled.
Condition: N/A
2. [BUG FIX]
Symptom: In MBM Wizard, disable active button then go next the device will get
exception
Condition: N/A
3. [BUG FIX]
Symptom: In MBM Web/GUI, change the FTP priority in advance setup, and then goes
to Wizard, and the priority item doesn’t go to “others”.
Condition: N/A
4. [BUG FIX]
Symptom: In MBM Web/GUI, add a class (for example port 80) in advance and then

ZyXEL Confidential
340QR5C1.doc 11/38
goes to Wizard, then you can see the XBOX is selected.
Condition: N/A
5. [BUG FIX]
Symptom: In MBM Web/GUI, add a FTP class in advance setting and delete it then the
FTP connection will get problem.
Condition: N/A
6. [FEATURE ENHANCE]
Symptom: In MBM Wizard finish page, add a button to return to main page.
Condition: N/A
7. [BUG FIX]
Symptom: Leave the device with default setting for over night and no traffics, the
system will get memory leakage
Condition: The default WLAN channel is very busy, and cause Beacon failure
Solution: When WLAN restart, system should use the same memory block that is
already allocated.
8. [BUG FIX]
Symptom: Change MBM bandwidth in advance summary page and then the device
gets reboot.
Condition: N/A
9. [BUG FIX]
Symptom: In MBM advance setting, disable filter in class setting but doesn’t work, the
traffics are still limited.
Condition: N/A
10. [BUG FIX]
Symptom: The redirect page of Zero-Configuration has Java script error problem.
Condition: N/A
11. [FEATURE CHANGE]
Symptom: Change ADSL modem code version to 3.0.9.0
Condition: N/A
12. [FEATURE CHANGE]
Symptom: In MBM feature, limit the depth to be 1, it means all the class must be just
under root.
Condition: N/A
Modifications in V 3.40(QR.2)b2 | 06/28/2004
1. [BUG FIX]
Symptom: In SMT4, and SMT11 the system will limit the usage when VPI is 0 and
VCI is 32 or under.
Condition: N/A
2. [BUG FIX]
Symptom: Static route doesn’t work fine when turning on Any-IP feature
Condition: N/A
3. [BUG FIX]
Symptom: In Web/GUI, if ping an address like "192.168.1.1 a" the device will ping it

ZyXEL Confidential
340QR5C1.doc 12/38
for a loop and the Web GUI can't get response and just like locked.
Condition: N/A
4. [BUG FIX]
Symptom: Multiple remote nodes are configured with different QoS (CBR/VBR/UBR)
types, but the traffic transmitting rates are all the same. The schedule priority should be
CBR > VBR > UBR
Condition: N/A
5. [BUG FIX]
Symptom: Any-IP doesn’t work fine when Any-IP PC uses Windows XP as OS.
Condition: N/A
6. [BUG FIX]
Symptom: Enable Anti-Virus to scan HTTP packets, and access Web GUI from WAN
side, some pages can’t display correctly.
Condition: N/A
7. [BUG FIX]
Symptom: Enable Anti-Virus to scan email, and system will cause exception if the
length of filename is over then 64.
Condition: N/A
Solution: Extend the max length of filename to be 255 for Anti-Virus.
8. [BUG FIX]
Symptom: In Anti-Virus, system will only notify user one time if there are many
viruses found on different attachments.
Condition: N/A
9. [BUG FIX]
Symptom: If SMT4 ISP node is cleared, and doing VC auto-hunt system will get
exception
Condition: N/A
10. [BUG FIX]
Symptom: Device will reply wrong packet when system is configured as ENET
ENCAP
Condition: Use IES-1000 as ATUC, and CPE device uses ENET ENCAP and NAT is
turn off.
Solution: Only receive packets that destination MAC are to device or it’s broadcast/
multicast packets
11. [FEATURE ENHANCE]
Symptom: Support one CLI command to enable/disable SIP ALG. This value will be
saved in ROM file
Condition: N/A
12. [FEATURE ENHANCE]
Symptom: Support Anti-Virus in Web logs page.
Condition: N/A
13. [FEATURE ENHANCE]
Symptom: Support Media Bandwidth Management Wizard, and also add dynamic
service for FTP, and H.323 in Bandwidth Management.
Condition: N/A

ZyXEL Confidential
340QR5C1.doc 13/38
14. [FEATURE ENHANCE]
Symptom: In Web/GUI, add Anti-Virus hyperlink in panel and first page when multi
language is chose.
Condition: N/A
15. [FEATURE ENHANCE]
Symptom: In Web/GUI, support multi language help for Zero-Configuration and
PPPoE pass-through
Condition: N/A
16. [FEATURE ENHANCE]
Symptom: In Web/GUI, support multi language help for Any-IP item.
Condition: N/A
17. [FEATURE ENHANCE]
Symptom: In Web/GUI Anti-Virus, after “activate” is pressed, device will activate
Anti-Virus service and also update expire date automatically.
Condition: N/A
18. [FEATURE CHANGE]
Symptom: VC auto-hunt feature will be turn off after VC/Encapsulation is hunted
successfully.
Condition: N/A
Modifications in V 3.40(QR.2)b1 | 06/02/2004
1. [FEATURE ENHANCE]
Symptom: Support DMZ interface, and port based-VLAN
Condition: N/A
2. [FEATURE ENHANCE]
Symptom: NAT traversal for IPSec feature
Condition: N/A
3. [FEATURE ENHANCE]
Symptom: Support Packet Scanning (Anti-Virus) feature, but system only can support
FTP, HTTP, E-mail application so far, please refer to external specification for details.
Condition: N/A
Modifications in V 3.40(QR.3)C0 | 06/17/2004
1. [FEATURE CHANGE]
Change to FCS version.
Modifications in V 3.40(QR.3)b1 | 06/16/2004
1. [FEATURE CHANGE]
Symptom: Wireless AP F/W 5.0.8 has bad throughput, change back to AP F/W 5.0.7
Condition: N/A
Modifications in V 3.40(QR.1)C0 | 06/02/2004
[FEATURE CHANGE]
1. Change to FCS version

ZyXEL Confidential
340QR5C1.doc 14/38
Modifications in V 3.40(QR.1)b1 | 05/28/2004
1. [BUG FIX]
Symptom: TI WLAN has connection problem after a period of time (after 6 hrs to 3
days).
Condition: N/A
Solution: Add a watchdog mechanism to constantly monitor WLAN activity in AP, if
anomaly is detected, the watchdog will restart WLAN TNETW1130 module to avoid
AP dead.
2. [BUG FIX]
Symptom: In Web/GUI, time and date page, after successfully get time from time
server, and then manually change the time and save, but the actually time displayed
will reduce one hour.
Condition: Happens on Web GUI only.
3. [BUG FIX]
Symptom: If you set right accounting server, password and enable it, and then turn
on/off authentication server or accounting server then system possible occurs reset.
Condition: N/A
4. [FEATURE ENHANCE]
Symptom: VC auto-hunt can’t hunt “Enet-encap” service
Condition: Only happens on some DHCP server, that the DHCP server will check the
MAC address in UDP layer.
5. [FEATURE ENHANCE]
Symptom:
1. Can’t enable alert function for Firewall, IPSec, IKE in Centralized log of Web/GUI.
2. Can’t enable Centralized logs 802.1x function in centralized log of Web/GUI
Condition: N/A
Solution: Add Web/GUI in Centralized log page.
6. [FEATURE ENHANCE]
Symptom: Change WLAN AP code to 5.0.8, it’s for supporting power tuning function,
the CI command is “wlan power <1-5>”.
Condition: N/A
7. [BUG FIX]
Symptom: VBR can’t work fine
Condition: N/A
Modifications in V 3.40(QR.0)C0 | 05/7/2004
1. Change to FCS version
Modifications in V 3.40(QR.0)b6 | 05/6/2004
1. [BUG FIX]
Symptom: In Web GUI, choose French or German language, the Web help of Any-IP is
not ready in LAN setup and Any IP table.
Condition: N/A
Solution: If user chose French or German language system will still display English

ZyXEL Confidential
340QR5C1.doc 15/38
help as well.
2. [BUG FIX]
Symptom: In Web GUI, chose French or German language, and the any IP can’t be
displayed in logs setting page.
3. [BUG FIX]
Symptom: Configure more than 5 entries in VC hunt table, Restart device. VC auto
hunt will start. Start the IE, and will see the "Wait..." information. Wait a moment, the
IE will show "hunt successfully page"(error) Restart IE, page will show PPPoE
need username and password page. Enter the user name and password and click
"Apply". IE will re-display the setup page for username and password. SMT shows
“dial fail, no interface available”
Condition: N/A
Solution: After hunting is successful, system should see the hunted encapsulation but
not the ISP remote node’s encapsulation for further reference.
4. [FEATURE ENHANCE]
Symptom: VC auto-hunting doesn’t support static IP address, if ISP provides static IP
address, system hunting will fail and browser will get fail page
Condition: N/A
Solution:
1. In Web GUI, add a hyperlink in failed page of Zero-Configuration that’s to prompt
user to login Web Configurator if they have static IP address from ISP
2. In Web GUI Wizard, if the configuration is saved with static IP address, then system
will turn off Zero-Configuration (VC auto-hunting) automatically, and if dynamic IP
address is chose then system will turn on Zero-Configuration as well
3. In Web GUI, WAN setting page, add an item for Zero-Configuration to turn on/off.
4. In SMT4, SMT11, if user saves remote node as static IP address, system will turn off
Zero-Configuration, and vice versa.
Modifications in V 3.40(QR.0)b5 | 05/3/2004
1. [BUG FIX]
Symptom: When change to France or German, the string of media bandwidth
management display is EMPTY on Web GUI
Condition: N/A
2. [FEATURE ENHANCE]
Symptom: In Zero-Configuration, when DSL is down, user click home page will get
Web redirect to fail page, and after connection is up, click home page again will not
work, but open another IE is OK
Condition: N/A
Solution: Add a close button in successful page, this IE will be closed automatically.
3. [BUG FIX]
Symptom: Throughput is only 12M with G100
Condition: Bandwidth management will impact WLAN throughput even bandwidth
management is not active.
4. [BUG FIX]

ZyXEL Confidential
340QR5C1.doc 16/38
Symptom: Configure more than 5 entries in VC hunt table, Restart device. VC auto
hunt will start. Start the IE, and will see the "Wait..." information. Wait a moment, the
IE will show "hunt successfully page"(error) Restart IE, page will show PPPoE
need username and password page. Enter the user name and password and click
"Apply". IE will re-display the setup page for username and password. SMT shows
“dial fail, no interface available”.
Condition: N/A
5. [BUG FIX]
Symptom: When we turn on debug flag of zero configuration “wan zero debug 1” and
DSL link down, system will get exception
Condition: N/A
Solution: Remove the logs in DSL down.
6. [BUG FIX]
Symptom: Using Apple computer (PowerBook G4) can’t get IP address from router by
DHCP, disable Any-IP can fix this problem
Condition: It’s caused by Any-IP function
7. [BUG FIX]
Symptom: Configured as 802.1x Dynamic WEP key, re-authentication timer is 60sec,
after 60 sec, the client can’t ping out
Condition: N/A
8. [BUG FIX]
Symptom: Configured as WPA Mixed mode enabled, the client connect with 802.1x
Dynamic WEP first, and then switching to WPA client will fail
Condition: N/A
9. [FEATURE ENHANCE]
Symptom: The Web help of Any-IP is ready
Condition: N/A
10. [FEATURE ENHANCE]
Symptom: Boot module is upgraded to 1.06 version, it’s to support 32M DRAM
Condition: N/A
11. [FEATURE CHANGE]
Symptom: In centralized log, the schedule to send log is “when log is full”.
Condition: N/A
Solution: Change the schedule of send log to be “none”.
12. [BUG FIX]
Symptom: In SMT, configured as WPA-PSK, and radius server is not active, then
system will return error message.
Condition: N/A
Solution: System should not return error message because WPA-PSK doesn’t need
Radius server.
13. [BUG FIX]
Symptom: When firewall is turn on, SIP can’t pass through
Condition: N/A
Modifications in V 3.40(QR.0)b4 | 04/06/2004
1. [BUG FIX]

ZyXEL Confidential
340QR5C1.doc 17/38
Symptom: ADSL is down, LAN PC keeps doing ping to WAN side, and configure
Web GUI dial backup page, then system will get exception
Condition: N/A
2. [BUG FIX]
Symptom: In Web GUI, click content filter device will get exception.
Condition: Only happens with corrupted ROM file in content filter.
3. [BUG FIX]
Symptom: In Web GUI static WEP key is enabled, and configure 802.1x Dynamic
WEP key, the Wireless client doesn't work, and it can't connect to AP.
Condition: N/A
4. [BUG FIX]
Symptom: Configure PC as Any-IP, when router is doing Auto-Hunting, open IE
continuously, system will get exception.
Condition: N/A
5.[BUG FIX]
Symptom: In Zero-Configuration, when DSL is down, user click home page will get
Web redirect to fail page , and after connection is up, click home page again will not
work, but open another IE is OK.
Condition:N/A
Modifications in V 3.40(QR.0)b3 | 03/31/2004
1. [BUG FIX]
Symptom: Create VPN second rule and dial it will cause exception.
Condition: First rule is working, and create and dial second.
2. [BUG FIX]
Symptom: Run eMule will cause crash after a period time.
Condition: Running eMule over than one night causes exception.
3. [BUG FIX]
Symptom: System is configured as PPPoA and use IE to get Internet will cause
exception
Condition: N/A
4. [BUG FIX]
Symptom: In Web/GUI, select another language will cause exception
Condition: N/A
5. [BUG FIX]
Symptom: WLAN hide ESS ID function doesn’t work
Condition: N/A
6. [BUG FIX]
Symptom: Device connected with a power on analog modem, and then power on
device will cause PPPoE can’t dial successfully any more.
Condition: The analog modem must power on first, and then power on device.
7. [BUG FIX]
Symptom: The dial backup feature will let analog modem dial and drop over and over,
and can’t be dialed successfully.

ZyXEL Confidential
340QR5C1.doc 18/38
Condition: In SMT2, check mechanism is “ICMP”, and input ping address with an
un-existed address.
8. [BUG FIX]
Symptom: Use SNMP browser to set system parameter will cause watchdog timeout.
Condition: N/A
9. [BUG FIX]
Symptom: Configured as WPA-PSK with mix mode enabled and select RADIUS only,
then save, re-enter into SMT 23.4 the authentication database will become "local
database only".
Condition: N/A
10. [BUG FIX]
Symptom: SMT 3.5 static WEP key is enabled, and SMT 23.4 select 802.1x Dynamic
WEP key, the Wireless client doesn't work, it can't connect to AP.
Condition: N/A
11. [BUG FIX]
Symptom: In firewall, LAN to LAN /Router interface doesn't work
Condition: N/A
12. [BUG FIX]
Symptom: In VPN function, if encryption method selects AES, the rule can’t dial
successfully.
Condition: N/A
13. [BUG FIX]
Symptom: In Web GUI, display DMZ in firewall default policy, but system doesn’t
include DMZ feature
Condition: N/A
14. [BUG FIX]
Symptom: In Web GUI, dial backup phone number field can't input pause character “,”.
Condition: N/A
15. [BUG FIX]
Symptom: In Web GUI, when system asks to change password and user presses
"apply" directly, system password will be changed to NULL.
Condition: N/A
16. [BUG FIX]
Symptom: In Zero-Configuration, ADSL is down, and dial backup is up, but Web GUI
is still displayed “failed page”
Condition: ADSL is down, but Dial backup is working
17. [FEATURE ENHANCE]
Symptom: In Web/GUI firewall, the customized port GUI is enhanced.
Condition: N/A
18. [FEATURE ENHANCE]
Symptom: In Web/GUI, add Any-IP centralized logs, switch on/off in LAN page, and
current status in maintenance.
Condition: N/A
19. [FEATURE ENHANCE]
Symptom: Support Bandwidth Management in Wireless LAN interface.

ZyXEL Confidential
340QR5C1.doc 19/38
Condition: N/A
Modifications in V 3.40(QR.0)b2 | 03/10/2004
1. [FEATURE ENHANCE]
Symptom: Support dial backup
Condition: N/A
2. [FEATURE ENHANCE]
Symptom: Support Zero-Configuration, please refer to ES for details
Condition:
3. [FEATURE ENHANCE]
Symptom: Support Any IP address, please refer to ES for details
Condition:
4. [FEATURE ENHANCE]
Symptom: Support maximum to 20 VPN rules
Condition: N/A
5. [BUG FIX]
Symptom: In debug mode, type “atba5” baud rate doesn’t be changed
Condition: N/A
6. [BUG FIX]
Symptom: In eWC/Dial backup, it needs to input at least one IP address even the check
mode is “DSL link”, but SMT doesn’t
Condition: N/A
7. [BUG FIX]
Symptom: In Zero-Configuration feature, the Web GUI display “connection test in
progress” page always, and won’t change to PPPoE setup page.
Condition: Only happens in PQA’s Red back server
.

ZyXEL Confidential
340QR5C1.doc 20/38
Annex A CI Command List
Command Class List Table
System Related Command Exit Command Ethernet Related Command
WAN Related Command WLAN_Related_Command IP Related Command
PPP Related Command Bridge Related Command Radius Related Command
8021x Related Command Firewall Related Command Configuration Related Command
SMT Related Command
System Related Command Home
Command Description
sys
adjtime retrive date and time from Internet
cbuf
display [a|f|u] display cbuf a: all f: free u: used
cnt cbuf static
display display cbuf static
clear clear cbuf static
baud <1..5> change console speed
callhist
display display call history
remove <index> remove entry from call history
clear clear the counters in GUI status menu
countrycode [countrycode] set country code
date [year month date] set/display date
domainname display domain name
edit <filename> edit a text file
enhanced return OK if commands are supported for PWC
purposes
errctl [level] set the error control level
0:crash no save,not in debug mode (default)
1:crash no save,in debug mode
2:crash save,not in debug mode
3:crash save,in debug mode
event
display display tag flags information
trace display system event information
display display trace event
clear <num> clear trace event
extraphnum maintain extra phone numbers for outcalls
add <set 1-3> <1st phone num> [2nd phone
num]
add extra phone numbers
display display extra phone numbers
node <num> set all extend phone number to remote node
<num>
remove <set 1-3> remove extra phone numbers
reset reset flag and mask
feature display feature bit
fid
display display function id list
firmware display ISDN firmware type
hostname [hostname] display system hostname
