Improving Wireless Network Performance
with Wider Coverage and High Speed
Wireless N Access Point/Bridge
NWA570N
Benefits
Improved Network Speed and Coverage
The ZyXEL NWA570N is a Four-in-one 802.11n Draft 2.0 Wireless Access Point,can be
operated in one of the following 4 modes, including AP, client, repeater and point to
point bridge. Unlike ordinary wireless networking technologies, draft 802.11n uses the
reflections to increase the range and reduce“dead zone”in the wireless coverage area.
The NWA570N provides wireless delivery rates of up to 300 Mbps and 4x farther
coverage than 802.11g connection.It is designed for users that demand high speed
data and multimedia delivery in order to get a better Internet experience with a faster
wireless connection to enjoy downloading, video streaming and gaming.It can be also
backward compatible with 802.11g and 802.11b wireless networks.
Enhanced Wireless Security and Privacy
In addition to the basic 64/128/152-bit WEP encryption, the NWA570N features the
latest wireless security mechanisms to protect your network with 802.1x
authentication and Wi-Fi Protected Access Pre-Shared Key (WPA-PSK/WPA2-PSK). These
enhanced security functions allow only authorized users to access the network, thus
further protecting your data from being tapped during wireless transmission.
Simplify Network Security Setup with One-Touch
The NWA570N supports Wi-Fi Protected Setup (WPS) to simplify network security
setup.Users no longer have to define a network identifier (SSID) and pass phrase to
enable WPA security; instead, the NWA570N will automatically generate SSIDs and PIN
codes. In place of entering a pass phrase, users can authenticate a new device on the
network by pressing a button or by entering an automatically generated 4-digit or 8-
digit PIN code.With the button option, users only need to press a button on the device
and on the AP simultaneously in order to complete the authentication.
Three External Detachable Antennas
The detachable antenna allows you to replace the standard antenna with a reverse
SMA connector antenna. It also has the flexibility to meet user demands if high-gain
antenna replacements are required.
Ł
Delivers Data Rates of up to 300 Mbps in 802.11n
Draft Mode
Ł
Four Operation Modes: AP, Repeater, Bridge and
Wireless Client
Ł
MAC Address Filtering to Limit Access to the
Wireless Network
Ł
Supports Wi-Fi Protected Access (WPA/WPA2) and
64/128/152-bit WEP Encryption
WIRELE
SS

Wireless N Access Point/Bridge
NWA570N
System Specifications
•
Four 10/100 Mbps Ether
45
erne
rnet RJ-45
connectors (Auto MDI/
DI/MD
DIX)
•
ole
Three external deta
ole
etachable 2
ol
e 2 dBi dipo
a
n
t
enn
as
•
•
IEEE 802.11g
1g wireless
ard
ess LAN standar
•
EEE 802.11
1b wire
IE
d
reless LAN standard
•
(draft
EE 802.11n
nw
IEEE
d
n
wireless LAN standard (d
Short G
2.0)(Sh
rt Guar
ard Interval/Force
ega
Aggreg
gation/RIFS
FS TX)
•
ifferent modes
an be op
Can
perated in
n one of 4 dif
AP Client and
including AP
i
AP, Repeate
er and A
ulti-point bridges
Point to Point/
t/Point to M
Mul
•
upport
64/128/152-bits W
s WEP sup
•
EAP-TLS, EAP-TTLS,
IEEE 802.1x security (E
ty (EA
pport in AP mode
EAP-PEAP) only supp
•
y exchange
Dynamic WEP key
•
W
PA
/
WPA2 suppor
t
•
W
MM (Wi-Fi Multi-Media) suppor
t
•
W
PS (Wi-Fi Protecte
d
Setup) support (PIN &
PBC methods
)
•
IEEE 80211i standard support (including AES
su
pp
ort
)
•
M
AC address
f
iltering through WLA
N
(
su
pp
ort 32 users
)
•
S
upport both Auto and Manual MAC clone
•
Limitation setting o
f
client connections
•
Block Intra-BSS traffic support
•
4
WDS (Wire
l
ess Distri
b
ution S
y
stem) Lin
k
s
i
n Brid
g
e mode or AP + Repeater mode
(Loop-Prevention Algorithm
)
•
DHCP c
l
ien
t
•
W
EB/TFTP
f
irmware upgrade and
con
f
iguration backup and restor
e
Hardware Specifications
•
Power Ratin
g
: 12 V DC,1.0
A
•
Re
s
e
t
B
utto
n
•
WPS Button
•
LAN: Four 10/100Base-T Ethernet,
f
ull duplex
RJ-45 connector wit
h
auto MDI/MDIX su
pp
or
t
Physical Specifications
•
Dimensions: 190
(
W
)
x 128
(
D
)
x 33
(
H
)
m
m
•
Weig
h
t: 370 g
Environmental Specifications
•
O
peratin
g
Temperature: 0
°
C
~ 50
°
C
•
O
perating Humidit
y
: 20% ~ 95% RH
•
S
tora
g
e Temperature: -2
0
°
C
~ 6
0
°
C
•
Storage Humidit
y
: 20% ~ 95% R
H
Certification
•
FCC/CE/C-Tic
k
/IC/NCC
Specifications
Application Diagram
NW
D
210
N
W
ire
l
ess USB A
d
apte
r
NWD-17
0N
W
ireless Cardbus Card
NWA570N
Gaming
Console
NAS
PC
AP Mode
Repeater Mode
Client Mode
N
W
D
310N
ter
Wireless PCI Adapte
NWA570N
Remote
Network
NWA570N
Wired
Network
Ethernet
Cable
Ethernet
Cable
Bridge Mode
NWA570N
NWD210N
Wireless USB Adapter
For more product information, visit us on the web at www.ZyXEL.com
65-100-057004B 01/08
