10-8 Video Digital Evidence Solutions 10-8 Body Camera User manual

2014r1
User Manual
10-8 Body Camera

2 3
Warranty & Return Information
Warranty Details
• One(1)yearfreereplacementofanyfailedcomponent.
How to Get Support
1. VisittheWarrantyPartsReplacementformonourwebsite:
hp://www.10-8video.com/support/warranty-form/
2. Filloutandsubmittheform.
Shipping Address
10-8VideoDigitalEvidenceSolutions
1423Huntsville,Hwy.
Fayeeville,TN37334
Phone Numbers
(888)788-1048•(931)262-2221
(931)233-1263(FAX)
Copyright © 2011-2014 10-8 Video Digital Evidence Solutions. • All rights reserved.
Disclaimer: 10-8VideoDigitalEvidenceSolutionsreservestherighttomakechangesin
specicationsatanytimeandwithoutnotice.Theinformationprovidedbythisdocument
isbelievedtobeaccurateandreliable.However,noresponsibilityisassumedby10-8Video
DigitalEvidenceSolutionsforitsuse;noranyinfringementsofpatentsorotherrightsof
thirdpartiesresultingfromitsuse.Nolicenseisgrantedunderanypatentsorpatentrights
of10-8VideoDigitalEvidenceSolutions.
Othercompanyandproductnamesmentionedhereinmaybetrademarksoftheirrespective
companies.
10-8 Digital Video Evidence Solutions
1423 Huntsville Hwy.
Fayeeville, TN 37334
Tel: [phone] • [phone]
Fax: [phone]
World Wide Web: www.10-8Video.com

4 5
Contents
Introduction 6
Overview 6
Package Contents 6
First-Time Usage 8
Body Camera Setup 8
BC-1 Body Camera Diagram 10
Operation 11
Power On/Off 11
Power On: 11
Power Off: 11
Video Recording & Playback 12
Recording Video 12
Stop Recording Video 12
Video Playback 12
Stop Video Playback 12
Recording and Playing Audio 14
Recording Audio 14
Stop Recording Audio 14
Audio Playback 14
Stop Audio Playback 14
Taking a Photo 15
View Photos 15
Exit Playback Mode 15
Charging the Battery 16
Charging Battery with USB Cable 16
Battery Status Icons 16
Factory Reset 17
Changing BC-1 Body Camera Password 17
Software 18
Using the Software 18
Managing Files 19
Viewing a File 19
Deleting a File 19
Copying a File to Your Computer 20
Changing Your Software Password 20
Administrating Software User Accounts 20
Creating a New Software User Account 20
Editing a Software User Account 21
User Account Permissions 21
Deleting a Software User Account 22
Setting the BC-1 Body Camera Device ID 22
Setting the BC-1 Body Camera Ofcer ID 22
Backing Up Files 23
System Messages 24
LED Status Indicator Lights 24
Audio Indicators 24
Specifications 25

6 7
Introduction
Overview
ThisdigitalpoliceenforcementDVRprovidestheocerwithstateofthe
artcapabilitiessuchashigh-denitiondigitalvideorecording,stillimage
capturecapabilities,high-speedUSBdatatransmissionandUSBcharging.
Package Contents
Your10-8BC-1BodyCamerawillhaveshippedwiththefollowingitems,
pleasetakethetimetoconrmyouhavethefollowingitems:
• 1-BodyCamera
• 1-InstructionManual
• 1-12VCarCharger
• 1-120VCharger
• 1-USBCable
• 1-MicCable(Optional)
Thankyouforpurchasingthe10-8BC-1BodyCamera.Topreventany
damagetotheunitcausingareductionofitslifespan,werecommend
readingthisUserManualcarefullybeforeusingthedevice.
This page left intentionally blank.
Introduction

8 9
IMPORTANT!
READ THIS FIRST
BeforeusingyournewBC-1BodyCameraforthersttime,we
recommendperformingthefollowingstepstomaximizetheusabilityof
yournewBC-1BodyCamera.
Body Camera Setup
1. ChargetheBC-1BodyCamerausingthe120Volt,12VoltorUSB
cable.
SeeCharging the Baerysectionfordetails.
2. DownloadandinstalltheBC-1BodyCamerasoftwarefromthe10-8
VideoWebsite:hp://www.10-8video.com/support/downloads/
3. Ifthesoftwareisnotalreadyrunning,launchtheBC-1BodyCamera
software.
4. Entertheusernameandpasswordtologintothesoftware.









5. PlugtheincludedUSBcableintoyourcomputer,thenplugtheother
endofthecableintotheBC-1BodyCamera.
6. TheBC-1BodyCamerawillautomaticallysynchronizeitsinternal
clocktothedateandtimeonthecomputertowhichitisconnected.
7. TheLCDDisplayontheBC-1BodyCamerawilldisplayfour(4)
asterisks(*)indicatingitiswaitingforyoutoenterthepassword
toaccesstheinternalsofthedevice.The default password for the
camera is 0000-fourzeros.
8. UsetheBC-1BodyCameratosettheproperbadgenumberforthe
ocerwhoistousethecamera.TheBC-1Softwareallowsyoutoset
boththeunitanduserIDforeachunitused.Thisinformationwill
displayoneveryvideoalongwiththedateandtime.
9. Wealsorecommendchangingthepasswordatthispoint.
If you connect the BC-1 Body Camera to a computer and do not
enter the proper password, it will only charge its battery and you
cannot access the camera’s internal les.
For maximum security of your les, we recommend changing the
default password after setting up the BC-1 Body Camera for the
rst time.
Default Login:
User: 0000
Password: 000
Note: You can also press the Play button four (4) times to
advance through the password screen without having to
change the password.
First-Time Usage
First-Time Usage

10 11
BC-1 Body Camera Diagram
IR LEDS
Lens
Recording
Microphone
Speaker
Microphone
USB
LED Status Indicator
Clamp
1.5” LCD Screen
Earphone
Water Tight
Seal
REC/Down
USB Port
Earphone Jack
Talk
Selection
PlayPower
Walkie
Cable
FIG. 1
Body Camera Diagram
Power On/Off
Power On:
1. Pressandholdthe“Power” buonuntilthedevicebeeps.
2. TheLED Status IndicatorwilllightupgreenandtheLCD screenwill
displaythe10-8Videologo.
3. Afterafewminutesofinactivity,thesystemwillthenenterinto
recording standby modeandtheLED Status Indicatorwillremainlit
green.
4. TheLCD screenwilldisplaythecurrentlyrecordinginterfaceand
yourbodycameraisreadytouse.

Power Off:
1. Pressandholdthe“Power”buonforatleastthreeseconds.
2. Thecurrentlewillbesavedtotheinternalstorageandthedevice
willpowerdown.
When the recorder is in standby mode if there is no interaction
with it for more than thirty (30) seconds the LCD screen will turn
off.
The recorder will automatically power off when the battery is low.
Operation

12 13
Operation
Video Recording & Playback
Recording Video
1. Brieypressthe“REC” buonuntiltheLED Status Indicatorlights
upred.TheBC=1BodyCamerawillbeepaudibly.
2. TheBC-1BodyCamerawillenterintoVideo Recording Mode(FIG.2)
andbegintorecord.Itwillsavealeevery10minutes.






Stop Recording Video
1. Pressthe“REC” buonuntiltheLED Status Indicatorlightsup
green.
2. TheBC-1BodyCamerawillenterRecording Standby Mode.(FIG.3)
Video Playback
1. Pressthe“Play” buonuntiltheBC-1BodyCameraentersinto
Playback Mode.(FIG.4)
2. Toplaythecurrentlyrecordingle,pressthe“Play” buonagain.
3. Toplayanotherle,usethe“Selection” buontocyclethroughthe
les.Pressthe“Play” buonwhenyou’vefoundtheletoplayit.
Stop Video Playback
1. Pressthe“Play” buontostopthecurrentlyplayingleandenter
intoPlayback Standby Mode.(FIG.5)
FIG. 2
Video Recording Mode
FIG. 4
Playback Mode
FIG. 3
Video Standby Mode
FIG. 5
Playback Standby Mode
Battery Status Icon
Recording Time
Playback Mode Icon
Play Status
Playing Time
Current Playback Time
Video File Icon
Focus Area Current Date & Time
Current File Number
Recording Status Icon
Remaining Recording Time
Operation
If lighting is insufcient, the recorder will automatically enable
Night Mode and the IR LED. It will automatically return to the
normal recording mode when lighting conditions improve.

14 15
Operation
Operation
Recording and Playing Audio
Recording Audio
1. Pressandholdthe“REC” buonforabout2seconds.
2. TheBC-1BodyCamerawillbeep,andtheLED Status Indicatorwill
lightupyellowindicatingithasbegunrecordingaudioonly.
3. TheLCD ScreenwillshowtheAudio Recording Mode Screen(FIG.6)
Stop Recording Audio
1. Pressthe“REC” buonuntiltheLED Status Indicatorlightsup
green.
2. TheBC-1BodyCamerawillenterRecording Standby Mode.(FIG.3)
Audio Playback
1. Pressandholdthe“Playback” buonuntiltheBC-1BodyCamera
entersintoPlayback Mode.(FIG.4)
2. Usethe“Selection” buontocyclethroughtheles.
3. Toplaythecurrentlyselectedle,pressthe“Play” buon.When
playinganaudiole,theAudio Playback Screenwilldisplay.(FIG.7)
Stop Audio Playback
1. Pressthe“Play” buontostopthecurrentlyplayingleandenter
intoPlayback Standby Mode.(FIG.5)
Taking a Photo
1. MakesuretheBC-1BodyCameraisinRecording Standby Modeby
exitinganycurrentlyactivemode.
2. Pressthe“Selection” buontotakeapictureandtheLED Status
Indicatorwillashred.
View Photos
1. Pressandholdthe“Playback” buonuntiltheBC-1BodyCamera
entersintoPlayback Mode.(FIG.4)
2. Usethe“Selection” buontocyclethroughtheles.
Exit Playback Mode
1. ToexitthePlayback Standby Mode,pressthePowerBuononce.
2. TheBC-1BodyCamerawillreturntotheRecording Standby Mode.
FIG. 6
Audio Recording Mode
FIG. 7
Audio Playback Mode

16 17
Operation
Charging the Battery
Therearethreewaystochargeyour10-8BC-1BodyCamera:
• 120VoltCharger(FastestChargeRate)
• 12Voltcarcharger(Fast)
• USBcableconnectedtoapoweredUSBcomputerport(Slow)





Charging Battery with USB Cable
1. ConnectaUSBcablewithacompatibleconnectortoacomputer.
2. ConnecttheUSBcabletotheUSBportonthebodycamera.
Battery Status Icons
Factory Reset
Pressandholdboththe“Power”and“REC”buonstoresettheBC-1
BodyCameratoitsfactorydefaults.
Changing BC-1 Body Camera Password
TheBC-1BodyCamerahasitsowninternalpassword,orPIN,that
protectsitslesfrombeingaccessedbyacomputerwithoutpermission.
Changing BC-1 Body Camera PIN
1. ConnecttheBC-1BodyCameratoacomputerusingtheUSBcable.
2. Createale“UK.txt”onyourcomputerwithatexteditorsuchas
Notepad.DonotuseawordprocessorsuchasMicrosoftWord.Itwill
introducedatathatwillcorruptthele.
3. Addthefollowinglinetotherstlineofthele:

UK 0000 1111

InthisexamplewehavesetthePINto“1111”,feelfreetosetittoany
four(4)digitnumber.
4. SavetheletotherootfolderoftheBC-1BodyCamera.
5. DisconnectandrestarttheBC-1BodyCamera.
DuringchargingtheLED Status Indicatorwilllightupred,theLCD
screenwilldisplay“MSDC”andthebaeryicon.After10secondstheBC-1
BodyCamerawillenablethescreensaverfortheLCD.Pressanybuonon
theBC-1BodyCameratoexitthescreensaver.
Whenthebaeryisfullycharged,theredLED Status Indicatorwillturn
oandthebaerystatusiconwilldisplaythe“FullyCharged”icon.
Low Power Not Fully Charged Fully Charged
A new, or completely drained BC-1 Body Camera battery can
take 6-8 hours to charge fully.
Operation
Caution: Do not perform a Factory Reset while recording or while
the device is connected to a computer. Doing so may cause le
corruption and/or damage the internal memory.

18 19
Software
Using the Software
It’sadvisabletoalwaysstartthesoftwarebeforepluggingtheBC-1Body
Cameraintoyourcomputer.
1. StarttheBC-1BodyCamerasoftware.
2. Enteryoursoftwareuseridandsoftwarepasswordtologin.





3. PlugtheBC-1BodyCameraintoyourcomputerusingthesupplied
USBcable.





4. OncethecomputerdetectsthattheBC-1BodyCamerahasbeen
connectedtoit,theBC-1BodyCameraLCDscreenwilldisplaya
screenpromptingyoutoenterthesecuritypin.




5. Usethe“Selection” buonontheBC-1BodyCameratocyclethrough
thenumberszerothroughnine(0-9)intherstcolumn.
6. OnceyouhavecycledthroughtotheproperrstnumberinthePIN,
usethe“Play” buontomovetothenextdigit.
7. AfteryouhavesetthelastnumberinthePIN,clickingthe“Play”
buontoselectthatdigitwillsubmitthePINforverication.
8. IfyouhaveenteredtheproperPINontheBC-1BodyCamera,the
LCDscreenwilldisplay“MSDC”forafewsecondsthenturno.
9. Thesoftwarewillthendisplaythefoldersandleslocatedonthe
BC-1BodyCamera.
Managing Files
TheleftcolumnoftheBC-1BodyCamerasoftwaredisplaysthefolders
andlescontainedonthedevice.Usetheuppersectionoftheleftcolumn
tonavigatethroughthevariousfoldersontheBC-1BodyCamerastorage
media.
Viewing a File
1. Clickonceonthelenameoftheleyouwishtoview.
2. Clickthe“Open” buonattheboomoftheleftcolumn.
3. Onceloaded,thelewilldisplayinthebigwindowontheright.
Deleting a File
You must have administrative privileges to delete les.
1. Clickonceontheleyouwishtodelete.
2. Clickthe“Delete” buonattheboomoftheleftcolumn.
3. Conrmthedeletionwithinthepopupwindow.
Default Administrator Login:
User: 0000
Password: 000
Default BC-1 Body Camera PIN: 0000
If this is the rst time you have connected the BC-1 Body
Camera to this computer, you may have to wait for your
computer to automatically install the proper drivers.
You can also double-click any lename to load that le in the
viewer.
Software

20 21
Copying a File to Your Computer
1. Clickonceontheleyouwishtocopy.
2. Clickthe“Copy” buonattheboomoftheleftcolumn.
3. Apopupwindowwillappear.Selectthelocationwhereyouwishto
savethele.
4. Clickthe“Save” buon.
Changing Your Software Password
1. Clickonthe“Change Password” iconatthetopofthewindow.
2. Enteryourcurrentor“old”password.
3. Enteryourdesirednewpassword-twice.
4. Clickthe“Ok” buon.
Administrating Software User Accounts
Thefollowingfeaturesareonlyavailabletoanuseraccountpossessingan
Administratoraccountlevel.
Creating a New Software User Account
1. Clickonthe“User Management” iconlocatedatthetopofthe
window.
2. Clickonthe“New” buonintheusermanagementpopupwindow.
3. EntertheAccount#/OcerID.
4. Fillouttheuser’sname,passwordandselectwhichaccountlevelthey
shouldhaveassignedtothem.
5. Unlessyouhaveareasontodisabletheaccountyoushouldleavethe
accountenabled.
6. Clickthe“Ok” buon tosavethenewuser’saccount.
Editing a Software User Account
1. Clickonthe“User Management” iconlocatedatthetopofthe
window.
2. Clickonthenameoftheaccountyouwishtoedit.
3. Clickonthe“Edit” buon.
4. Updateinformationasdesired.
5. Clickon“Ok” buontosavethechanges.
User Account Permissions
TherearetwolevelsofaccesstotheBC-1BodyCamerasoftware-
“Normal”and“Administrator”.
Administrators can:
• View,copyanddeletelesanddirectories.
• Manageaccounts-create,edit&delete.
• SetOcerIDandDeviceIDforthecurrentlyconnectedBC-1Body
Camera.
Normal Users Can:
• Viewles
• Changetheirsoftwareaccountpassword.
Software
Software

22 23
Software
Software
Deleting a Software User Account
1. Clickonthe“User Management” iconlocatedatthetopofthe
window.
2. Clickonthenameoftheaccountyouwishtodelete.
3. Clickonthe“Delete” buon.
4. Conrmaccountdeletionorcanceltherequest.
Setting the BC-1 Body Camera Device ID
1. EnsuretheBC-1BodyCameraisconnectedtoacomputerrunningthe
BC-1BodyCamerasoftwareandthesoftwarecanseetheBC-1Body
Camera.
2. Clickonthe“DeviceID”iconatthetopofthesoftwarewindow.
3. Enterthenewnumberdesired.Note:theDeviceIDmustbeve(5)
digitslong.
4. Clickthe“Ok” buontosavethenewID.
Setting the BC-1 Body Camera Ofcer ID
1. EnsuretheBC-1BodyCameraisconnectedtoacomputerrunningthe
BC-1BodyCamerasoftwareandthesoftwarecanseetheBC-1Body
Camera.
2. Clickonthe“OcerID”iconatthetopofthesoftwarewindow.
3. Enterthenewnumberdesired.Note:theOcerIDmustbesix(6)
digitslong.Useprecedingzerosifneeded:000123.
4. Clickthe“Ok” buontosavethenewID.
Backing Up Files
TheBC-1BodyCamerasoftwareallowsyoutoeasilycopyalltheles
currentlystoredonittoyourcomputer.
1. EnsuretheBC-1BodyCameraisconnectedtoacomputerrunningthe
BC-1BodyCamerasoftwareandthesoftwarecanseetheBC-1Body
Camera.
2. Clickonthe“Backup” icon.
3. Conrmthefolderonyourcomputertobackthelesuptoorusethe
“Browse” buontoselecttheproperfolder.
4. Selectwhethertooverwriteorskipcopyingaleifanexisting
lenamealreadyexistsinyourcurrentlyselectedfolder.
5. Clickthe“Backup” buontobeginthebackupprocess.
6. Fileswillbesavedtoyourcomputerandfolderswillautomaticallybe
createdforeachdaymediawastaken.
7. Typesofmediawillbefurthersortedintosub-foldersundereachdate
designatingthemediatypecontainedwithin.
8. Whenthebackupprocessiscomplete,clickthe“Close” buonoruse
the“View Backup Directory” linktoimmediatelyviewthelesjust
createdonyourcomputer.

24 25
Brand Name: 10-8
Model Name: 10-8 BC-1
Specications: • Loop Recording
• Industrial grade for extreme conditions & reliability
• Can replace existing mic for most major brand walkies
• Drop/shock & water resistant
• Same size as most existing walkie mics
• 8x Digital zoom
• IR with automatic switching in low/no light conditions
• 360° rotatable buckle
• Password protected les
• Includes 32GB memory
• Up to 6 hours continuous recording (48 hrs standby)
Camera Sensor: 5.0 mega pixels CMOS
Video Format: AVI
Video Resolution: 720x480 pixels, 30fps
Picture Format: JPEG
Picture Resolution: 12 mega pixels
Field of View: 120°
Text Overlay: Off / Date / Date & Time / Ofcer ID
Languages: English / French / German / Italian / Spanish / Chinese / Russian /
Turkish / Korean
Memory: 32GB
Battery: 2800mA, Rechargeable Lithium-ion Battery
Color: Black
Dimensions: 96 x 64 x 33 (mm)
Net Weight: 141g
Includes: • 2 - USB cables
• 1 - AC Adapter (110-240V)
• 1 - 12v Adapter
• 1 - User Manual
Optional Accessories: • Connector cable with intercom
Specications
System Messages
The10-8BC-1BodyCamerautilizesbothaudible(“beeps”)andvisual
(LEDlightsandLCDscreen)indicatorstoinformyouofthestatusand
healthofthedevice.Refertothechartsbelowformoreinformation.
LED Status Indicator Lights
LED Color LED Duration Explanation
Green On/Solid Power is on. System normal. In Recording Standby Mode.
Yellow On/Solid Recording audio in progress.
Red On/Solid Recording video in progress.
Red Blink/Flash In photograph mode indicates photo being taken.
Red On/Solid When charging indicated device is being charged. LED goes out
when fully charged.
Audio Indicators
“Beeps” Explanation
SIngle Beep Photo taken.
Four (4) beeps Memory card is full.
The LCD screen will also display “Memory Card Full”.
Five (5) beeps every three (3) minutes Battery low.
The camera will begin to shutdown within 20 minutes of this
warning.
If the BC-1 Body Camera has to stop recording due to a full
storage card or low battery, it will automatically stop recording,
save and close the le to ensure the integrity of the data.
