101VOICE IP1060G Instruction manual

Quick User Guide
Voice Mail
Function Codes
For support, please contact us at 408-739-1000 between 8a - 5p PST.
Please email us at [email protected] if you know someone that can take
advantage of our service. We'll make sure to provide them the best service possible,
and send you a small token of appreciation for your referral.
Dial the voicemail access code ( ∗
1 by default) or press the Voicemail Function Key. If
your telephone forwards to a mailbox, you'll be logged in automatically. If not, you'll be
asked for a mailbox and password.
Alternatively, dial ∗ 2 to access the voicemail portal. Or call your telephone line from an
outside telephone, such as a mobile phone.
When you hear your voicemail greeting prompt, dial ∗ and you will access the voicemail
portal. Enter your mailbox and password, then follow the prompts to navigate the menus.
Dial * to return to the main menu
∗67, followed by phone number : Hide Caller ID
∗72 , followed by phone number : Set Call Forward
∗8 , followed by phone number : Transfer to Voicemail
∗ 68 : Play Last Caller ID
∗ 73 : Cancel Call Forward
∗ 66 : Dial by Name Menu
Dialpad Headset
Phonebook
Redial
Indicator
Light
Soft-keys
Navigation keys
+OK+Return
Volume
Microphone
Mute
For getting your Voicemail:
1. Lift the Handset or alternatively press Headset or Speaker button
Press MWI/Voicemail key to get your voice mail
2.
•
•
•
Tips:
•
If you are using a headset that is wired or a wireless without the EHS cable, press the
headset button to make or answer calls.
Headset/EHS Support
If you are using the wireless headset with the EHS cable you just needs to press the
button on the headset to make or dial a call.
1.
2.
Transfer
Hold
Page Keys
Voicemail
Programmable
Function Keys
IP1060G Enterprise IP Phone
Copyright © 101VOICE. All rights reserved.
101VOICE IP1060G
Hands-free
Speaker
Programmable
Function Keys

Key
OK
Key Pad
Color LCD Screen
Making Calls
Pick-Up
1. If a phone is ringing, users of other phones in the same pickup group may press pick up function
key to intercept the call and bring it to their phone.
Conference Calls — 3-Party Audio Conferencing
1. While the 1st party is on the phone, press the Conf soft key at the bottom of the
LCD display or Conference button.
2. Dial the 2nd party phone number (internal or external phone number), then press
the Dial soft key.
3. Press the Conf soft key again - to join the conference, use Navigation Keys (up or
down) to select the caller on-hold and press OK.
4. You may press the End soft key to end the conference, or Split to split the callers.
Transferring Calls — Announced/Attended Transfer
1. While the 1st party is on the phone, press the Transfer button or XFER soft key,
dial the number to transfer (internal or external), then press the Dial soft key.
2. Announce/notify the receiving party about the transfer.
3. Press the XFER soft key to complete the transfer, or press End, then Resume to
return to the 1st party.
Transferring Calls — Unannounced/Blind Transfer
1. While the 1st party is on the phone, press the Transfer button or XFER soft key,
dial the number to transfer to (internal or external), then press XFER again to
complete the transfer.
Transferring Calls — Direct Voicemail Transfer
(This function allows users to transfer directly to an extension's voicemail without
ringing the phone).
1. Press the OK navigation key, or the Menu soft key, to access the phone's menu.
2. Select Basic, then Ring. Then select Ring Type or Ring Volume.
IP1060G IP Phone User Guide - Powered by 101 VOICE
Telephone Lines
Function
Access phone's menu / select sub-menu .
Select a line to make or ans wer a call, or place a call on hold.
When PFK is flashing, press to retrieve a call on hold.
Use to dial a number, or enter a name.
Displays menu, date/time, phone number/name, call status
and soft keys.
1. Enter the phone number on telephone dialpad.
2.
3.
Either pickup the handset, press the Headset button (if a headset's connected),
press the Speaker button, or press the Dial softkey on the bottom of the LCD
display.
To end the call, either hang up the handset, press End soft key, or press the Speaker
button.
Tips:
•No need to dial 9 to make external system calls (outside line).
•No need to dial the Area Code if the destination number has the same Area Code
as your phone's caller ID.
•No need to dial 1 before any phone numbers.
•No need to place an existing call on hold to take another call. You can simply
switch calls by pressing the phone line Function Keys.
Accepting Calls
1. Either pick up the handset, press the Headset button (if a headset's connected),
press the Speaker button, or press the Answer soft key on the LCD display.
Call Park/Orbit (System-Wide Hold)
(This function allows users to place an incoming call on system-wide hold, so the call can
be retrieved from any phone within the location).
1. Press the Transfer button or XFER soft key, dial ∗ 8 followed by the destination
mailbox number,then press XFER again.
4.
1. With the caller on the line, press the Call Park Function Key or dial # ∗ 7 # .
2. Wait for about (2) seconds to hear the "Call Park extension number" (i.e. 701 or 702).
3. Then press the End soft key or hang up the handset (you must do this for the call to
be in Park mode).
The Parked call can be retrieved via any phone by dialing the "Call Park extension
number" within (2.5) minutes.
Tip:
•You should announce "You've got a call on 701" or "There's a call waiting for you
on 702", etc.
Ring Type/Volume Selection
Copyright © 101VOICE. All rights reserved.
1. Press the Menu soft key to access the phone's menu.
2. Select Basic, then Bluetooth.
Pair Bluetooth Headset
3.Use right and left keys to enable . Select paired device or if no paired is displayed
press Scan to search, long press your bluetooth pairing button until you hear
pairing, then select the scanned device to connect.

IP1060G IP Phone User Guide - Powered by 101 VOICE
Copyright © 101VOICE. All rights reserved.
Speed Dial Configuration on Phone
1. Long press the Dss key, on the Main display, you will see the Dss key number, Type and
Dss theme.
2. Use down arrow button and select type. Then, select Memory Key type, then,
select Speed dial as subtype, then enter the name and number and press Ok.
3. After saving, you should be able to see the name next to Dss key.
Speed Dial Configuration on the Web Interface
1. Press the down arrow button on your phone and check the IPv4 address (e.g. 192.168.19.15)
2.Open your web browser and enter the IP address. You should be able to see your phone
web interface
3.
4.
5.
•
•
•
Speed Dial Configuration on the Web Interface (continued)
Select Dss Key page, then select Dss key you want to program, then choose
Memory Key type, then, select Speed dial as subtype, and click on apply.
The name will be shown next to the Dss key.
You have the option to configure the main display side keys. By default,
they are configured to be line keys. If you would like to program them,
select Function Key on the left navigation bar, then, select Side key from
the top navigation bar and repeat step 4 (Expcept selecting Dss key page)
and click on apply.
On the left navigation bar, select Function Key
Please note that
Names with more than 12 characters won't be shown completely.
You can change the color of handset icon next to the name by selecting color
in Icon Color.
The Speed dial LED will be off.
Username is user and password is voip101.
Version 3.1
