Design
Twin DECT Phone
MEDION® LIFE® S63012 (MD82269)
Instruction manual

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 3
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Contents
Introduction ................................................................................... 6
Safety instructions .......................................................................... 7
Keeping electrical equipment out of reach of children................. 7
Potentially explosive areas........................................................... 7
Mains adapters............................................................................ 8
Setting the appliance up safely.................................................... 8
Accessibility of mains power socket ............................................. 9
Thunder storms/Non-use ............................................................ 9
Handling the rechargeable batteries safely ................................ 10
Correct repair procedure........................................................... 11
Package contents.......................................................................... 12
ECO function................................................................................ 13
Control......................................................................................... 14
Handset..................................................................................... 14
Basestation................................................................................ 15
Preparation................................................................................... 16
Setting the appliance up safely.................................................. 16
Insert rechargeable batteries into the handset ........................... 16
Connecting the base station to the mains.................................. 17
Connecting the charging station to the mains ........................... 18
Charging the rechargeable batteries.......................................... 19
Connecting the base station to the telephone network.............. 21
The display ................................................................................... 22
Basic display.............................................................................. 22
Other indicators on the display.................................................. 23
Telephone Calls ............................................................................ 25
Basic functions .......................................................................... 25
Additional functions .................................................................. 28

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 4
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Making calls with several callers ................................................ 34
Setting the telephone via the menu .............................................. 36
Navigating in the menu............................................................. 36
Menu Call List............................................................................... 37
STORE ....................................................................................... 37
DELETE...................................................................................... 37
DELETE ALL................................................................................ 37
DETAILS .................................................................................... 38
Menu Phonebook ......................................................................... 38
Add entry .................................................................................. 38
VIEW ......................................................................................... 39
EDIT .......................................................................................... 40
DELETE...................................................................................... 40
DELETE ALL................................................................................ 40
PB STATUS ................................................................................ 40
Menu Base-Settings ...................................................................... 40
BS RINGER................................................................................. 40
RING VOLUME........................................................................... 40
DELETE HS................................................................................. 41
FLASH TIME............................................................................... 41
CHANGE PIN ............................................................................. 42
HS Settings ................................................................................... 43
ALARM ...................................................................................... 43
RING SETUP............................................................................... 44
TONE SETUP.............................................................................. 44
LANGUAGE ............................................................................... 45
RENAME HS............................................................................... 45
HS DISPLAY ............................................................................... 45
AUTO ANSWER.......................................................................... 45
DATE & TIME ............................................................................ 46

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 5
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
SELECT BASE ............................................................................. 46
REGISTRATION.............................................................................. 47
DEFAULT....................................................................................... 47
Answering machine (Menu ANS. MACHINE)................................. 48
MSG PLAYBACK......................................................................... 48
DELETE ALL................................................................................ 49
MEMO ...................................................................................... 49
TAM (Answering machine) ON/OFF .......................................... 50
TAM (Answering machine) SETTINGS........................................ 50
Using the answering machine at the base station......................... 54
Switching on and off................................................................. 54
Displays on the base station ...................................................... 55
Playing back messages .............................................................. 56
Deleting messages .................................................................... 59
Troubleshooting ........................................................................... 60
Factory settings............................................................................. 63
Factory settings on the handset................................................. 63
Factory settings on the base station........................................... 64
Further factory settings.............................................................. 64
Repairs ...................................................................................... 65
Cleaning....................................................................................... 65
Disposal........................................................................................ 66
Technical Data .............................................................................. 67
Declaration of conformity ............................................................. 68

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 6
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Introduction
Congratulations on choosing to buy a MEDION® product. By doing
so you now have the assurance and peace of mind that comes with
purchasing a product made by one of the leading manufacturers.
All products brought to you by MEDION® are manufactured to the
highest standards of performance and safety, and, as part of our
philosophy of customer service and satisfaction, are backed by our
comprehensive 3 Year Warranty.
In case of warranty claim, please fill in and return the Warranty Card
to the address provided.
We hope you will enjoy using your purchase for many years to
come.

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 7
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Safety instructions
Please read these operating instructions thoroughly and
follow the safety notes in particular before using the
appliance for the first time.
Anything done to or with this appliance should be
undertaken as described in the operating instructions.
Keep these instructions in a safe place for further use. If you
pass on this appliance to a third party, please include these
instructions.
Keeping electrical equipment out of reach of
children
Children are not aware of the dangers associated with using
electrical equipment. Children should therefore always be
supervised when using electrical equipment.
Rechargeable batteries can be fatal if swallowed. For this reason,
keep the handset and the batteries out of reach of small children. If a
rechargeable battery is swallowed, please obtain immediate medical
assistance.
Keep plastic packaging out of reach of children. It may cause
suffocation.
Potentially explosive areas
Never use the handset in a potentially hazardous environment, e. g.
in a paint shop or in the vicinity of a gas leak.

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 8
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Mains adapters
Use only the mains adapters supplied.
Setting the appliance up safely
Place the base station on a stable, level surface.
Make sure to set up the base station so that it is protected from
falling down.
Do not place the base station and handset near heat sources
(e. g. radiators) that could affect the base station and handset.
Do not expose the appliances to direct sunlight.
Contact with moisture, water and splashes must be avoided.
The appliance is not suitable for use in rooms that are very humid
(e. g. bathroom).
Do not place the base station or the charging station close to
other electrical equipment (e. g. television or microwave oven).
Do not place the base station or the charging station close to
open sources of fire (e. g. burning candles).
Do not connect the device immediately to the power supply if
the unit has been moved from a cold to a warm room. The
ensuing condensation could damage the device. The device can
be operated as soon as it reaches room temperature.

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 9
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Accessibility of mains power socket
Connect the base station to an easily accessible power outlet
(240 V ~ 50 Hz) that is close to where you have set up the
appliance. Keep the power outlet free of obstructions so that the
plug can be pulled out easily.
To disconnect the appliance from the mains, always pull on the
plug rather than on the cable.
Do not kink or crush the mains cable.
Never put the handsets back in the base station and charging
station without the battery cover.
Warning!
This equipment will be inoperable when main power
fails.
Thunder storms/Non-use
Pull the mains plug and telephone cable from the base station and
the charging station if you will be away for a long period of time or
if there is a thunder storm.
For non-use, always remove the rechargeable batteries from the
handsets to prevent leakage. Leaked batteries can damage the
handsets.

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 10
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Handling the rechargeable batteries safely
You will need a rechargeable batteries for the handset. Please note
the following:
Keep children away from the rechargeable batteries.
Do not throw rechargeable batteries into a fire, do not short-
circuit them and do not dismantle them.
Only use rechargeable batteries of the same type. Do not use
different types.
Please note the polarity (+/-) when inserting the rechargeable
battery block.
Remove the rechargeable battery block if the unit will not be
used for long periods.
Remove exhausted rechargeable batteries from the appliance
immediately! There is an increased risk of leakage.
Do not expose rechargeable batteries to extreme conditions; for
example, do not place the appliance on top of radiators! There is
an increased risk of leakage.
In the event of leakage, remove the rechargeable batteries from
the appliance immediately. Clean the contacts before inserting
new rechargeable batteries. There is a risk of skin irritations from
battery acid!
If battery acid leaks out it is essential to avoid contact with the
skin, eyes and mucous membranes! Leaked battery fluid can
cause skin rash. If the acid does come into contact with skin,
immediately rinse the affected areas with plenty of clear water
and consult a doctor immediately.

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 11
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
If you suspect a battery has been swallowed, please seek
immediate medical advice.
Correct repair procedure
If the mains adapter, cable, charging adapter or base
station is damaged, detach the plug from the power
supply immediately.
Never try to open and/or repair the appliances yourself. There is
a risk of electric shock. In the event of a fault please contact the
Medion Service Centre or an approved repair specialist.
If the mains cable is damaged, it must be replaced by the
manufacturer or the manufacturer’s customer service
department or a similarly qualified person in order to prevent
exposure to danger.

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 12
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Package contents
Warning!
Do not let children play with the plastic film. It may
cause suffocation.
Remove all packaging materials including the film on the displays of
the base station an the handsets.
Unpack the unit and ensure that the following parts are included:
2 Handsets
Base station
Charging station with mains adaptor
Mains adaptor for base station
Telephone cable
4 rechargeable batteries type NiMH, size AAA
Operating instructions and warranty documents

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 13
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
ECO function
The ECO Mode setting enables low emission operation while
operation a call. The reduction of the radiation depends on the
distance of the handset to the base station.

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 14
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Control
Handset
1Loudspeaker
2Display
3Control keys right and left
4Call key: End the call; pressing longer
will switch the handset on/off
5Alphanumeric keys 0 to 9:
To enter numbers and letters
6Hash key: To enter the #-symbol,
pressing longer while idle will switch
ring tone on or off.
7R-key: Recall key
8Microphone
9Contacts: To charge the batteries
10 : Open the phonebook
11 : Handsfree button
12 Asterisk key: To enter the *-symbol
Pressing longer while idle will active
the keypad lock
13 Talk key: Accept the call; dial the selected number
14 Arrow keys 
In the menus: Select entries/options;
When idle: Open redial; open Call list, message list;
During a call: Adjust the earpiece/loudspeaker volume

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 15
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Basestation
1Connection for telephone cable (RJ11 jack)
2Connection for mains adapter lead
3Cable holder for mains adapter lead
4Charging cradle with contacts: To charge the handset
5Paging key: Triggers ringing on handset
6On/Off switch: Answering machine on or off
7Delete key: Deletes messages on the answering machine
8Flashes when the telephone rings
9Glows when the handset is set into the charging cradle
10 Display: Shows information on the answering machine
11 Play: Begins playback of messages, pause playback
12 Raise the volume for the base station
13 Keys backward/forward: Jumps to the previous/next message
14 Speaker

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 16
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Preparation
Setting the appliance up safely
Place the base station on a sturdy, level surface.
Some aggressive furniture paints can weaken the appliance's
rubber feet. If necessary, place the base station on a pad.
Set up the base station at a practical working height and secure it
from falling down.
Set up the base station close to a power outlet and a telephone
socket. Place the charging station close to a power socket.
Prevent the appliances from coming into contact with moisture or
liquids.
Do not place the base station close to other electrical equipment
(e. g. televisions).
Insert rechargeable batteries into the handset
4 rechargeable batteries 1,2 V/600 mAh Type NiMH, Size AAA have
been supplied for the handsets.
Warning!
Only use nickel metal hydride rechargeable batteries of
the supplied type (NiMH) in the handset.
The appliance warranty will expire if you insert any other
type of rechargeable battery. The handset could be
damaged.

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 17
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Slide down the battery cover on the back of the handset.
Correctly insert 2 rechargeable batteries in the battery
compartment of each handset, observing the correct polarity, and
close the battery compartment.
Place the battery cover back on the battery compartment and
slide it shut.
Connecting the base station to the mains
Attention!
Only use the power supply unit for the base station to
connect the base station: Model No.: S005CB0600060. A
rating label with the corresponding information will be
located on the power supply unit.
Connect the plug of the mains adapter lead to the rightmost
connection of the base station.
Secure the plug from falling out by routing the cable behind the
cable clamp.

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 18
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Plug the mains plug of the mains adapter into a mains socket.
Connecting the charging station to the mains
Attention!
Only use the power supply unit for the charging station
to connect the charging station: Model No.:
S002CB0600030. A rating label with the
corresponding information will be located on the power
supply unit.
Connect the plug of the mains adapter lead to the charging
station.
Plug the mains plug of the mains adapter into a mains socket.
Model: S005CB06000

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 19
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Charging the rechargeable batteries
Warning!
Only connect the base station to the telephone network
after the handset has been completely charged.
Otherwise the rechargeable batteries will not achieve
their full capacity.
The charging time is 14 hours.
Do not interrupt the charging process, otherwise the
capacity of the rechargeable batteries can be
permanently reduced.
Never put the handset back in the base station or
charging station without the battery cover.
Note
You can leave the handset in the base station. This
ensures a maximum charging condition.
The capacity of the rechargeable battery will last for 10
hours of calls, or 100 standby hours.
The rechargeable battery will then have to be recharged
after that time.

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 20
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
Charging the rechargeable batteries of the handset in
the base station
Note
You cannot make calls with the handset while the
rechargeable batteries are being charged. For that reason,
only connect the base station to the telephone network
after the handset has been completely charged.
Place the handset in the charging cradle of the base station and
charge the rechargeable battery.
A beep indicates that the handset has been correctly placed in the
cradle.
The battery symbol in the top right of the display indicates that
the rechargeable battery is being charged.
Charging the rechargeable batteries of the handset in
the charging station
Note
You cannot make calls with the handset while the
rechargeable batteries are being charged.
Place the handset in the charging cradle of the charging station
and charge the rechargeable battery.
A beep indicates that the handset has been correctly placed in the
cradle.
The battery symbol in the top right of the display indicates that
the rechargeable battery is being charged.

Helpline No. UK/ North Ireland 0871 37 61 020 (calls are charged at 7p/min from 21
a standard landline; calls from mobiles could be higher)
Rep. Ireland 1-800-992 508 (free call)
Web Support www.medion.co.uk; Model Number: MD 82269
After the charging process has finished, the base station detects
the handset.
You will even be able to register the base station if it has not
recognised the handset automatically; see "REGISTRATION" on page
47.
Connecting the base station to the telephone
network
Warning!
Only connect the base station to the telephone network
after the handset has been completely charged.
Otherwise the rechargeable batteries will not achieve
their full capacity.
Insert the phone cable jack
(RJ11) of the supplied telephone
cable in the leftmost jack at the
back of the base station.
Insert the other plug on the
telephone cable to the
telephone wall socket.
