2N 9160341 User manual



2N Access Unit Installation
Manual

v.2.16
www.2n.com





2N Access Unit Installation Manual
2 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Content:
1. Product Overview
1.1 Components and Associated Products
1.2 Terms and Symbols
2. Description and Installation
2.1 Before You Start
2.2 Mechanical Installation
2.2.1 One Module Box
2.2.2 Two Module Box
2.2.3 Module dimensions
2.3 Electric Installation
2.3.1 Overvoltage Protection
2.4 Extending Module Connection
2.5 Mounting Completion
3. Maintenance
4. Technical Parameters
4.1 General drawings
5. Supplementary Information
5.1 Troubleshooting
5.2 Directives, Laws and Regulations
5.3 Other Countries' Legislation
5.4 General Instructions and Cautions

2N Access Unit Installation Manual
3 / 107
•
•
•
•
•
•
•
1. Product Overview
Here is what you can find in this section:
1.1 Components and Associated Products
1.2 Terms and Symbols

Basic Properties
2NAccess Unitis an elegant and reliable access IP system equipped with a number of useful
functions, which are not always common in devices of this category.
2NAccess Unitis a modular access system that meets all individual user needs. Unlike other
access systems available on the market,2NAccess Unitis not a single-module system with a
fixed functionality, but a user friendly modular system, allowing the user to assemble required
modules and accessories on a “plug and play” basis. This approach provides individual
configuration options and increase in functionality as necessary.
Keypadis a numeric keypad module that allows you to use the device for code lock switch
activation.
Integrated card reader moduleprovides the RFID card access control functionality. With
additional software settings, you can control more functions than the door lock using the card.
Electric lock switch –this switch can be can be controlled via a numeric keypad or Automation
actions. The switch can be completed with additional output modules if necessary. A wide range
of the switch mode settings provide an infinite number of applications.
Resistance–2NAccess Unitis designed as a robust, mechanically resistant access system,
which withstands any weather conditions without requiring additional accessories.
Installation of2NAccess Unitis very easy. All you have to do is assemble the required modules
and connect the system to your LAN via a mains cable. Being of the “plug and play” type, the
modules need not be configured individually. Feed the intercom either from a 12 V power supply
or directly from your PoE-supporting LAN.
To configure 2NAccess Unit, you need a PC equipped with any Internet browser. To manage
extensive intercom installations easily, use the2NAccess Commander.

Advantages of Use
Elegant design
Weather resistance
Variable mounting options (brick/plasterboard flush mounting, wall mounting)
Optional numeric keypad with backlight
Use of multiple modules of the same type – e.g. building entrance/exit card reader

2N Access Unit Installation Manual
4 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
Integrated electronic lock switches with wide setting options
Integrated RFID card reader module, Bluetooth module, fingerprint reader module or
touch keypad module
LAN (PoE) or external 12 V power supply
Configuration via web interface
HTTP server for configuration
SNTP client for server time synchronisation
SMTP client for e-mail sending
TFTP/HTTP client for automatic configuration and firmware update
1.1 Components and Associated Products
Basic Units
2N Part No. 9160341
2N® Access Unit 2.0 125 kHz
The card reader provides you with access control via
contactless cards or keyfobs. The module supports the 125
kHz EM4xxx.
2N Part No. 9160341US
Axis Part No. 02137-001
2N® Access Unit 2.0 125 kHz
The card reader provides you with access control via
contactless cards or keyfobs. The module supports the 125
kHz EM4xxx.
Reads HID Proximity

2N Access Unit Installation Manual
5 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2N Part No. 9160342
Axis Part No. 02143-001
2N® Access Unit 2.0 13.56 MHz, NFC/HCE ready
The card reader module provides you with access control via
contactless cardsorkeyfobs. The module supports the
following 13.56 MHz cards or other carriers (only card serial
number is read):
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
2N Part No. 9160342-S
Axis Part No. 02142-001

2N® Access Unit 2.0 13.56 MHz, NFC/HCE ready
The card reader module provides you with access control via
contactless cardsorkeyfobs. The module supports the
following 13.56 MHz cards or other carriers (only card serial
number is read):
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
HID SE (Seos, iClass SE, Mifare SE)
2N Part No. 916013
Axis Part No. 01368-001
2N®Access Unit Bluetooth
The Bluetooth reader is used for reading users secure ID
numbers from the 2N®Mobile Key application of smart
phones Android and iOS.

2N Access Unit Installation Manual
6 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2N Part No. 916031
Axis Part No. 02263-001
2N®Access Unit 2.0 Fingerprint reader
The Fingerprint reader is used for verification of human
fingers for access control and intercom control.
2N Part No. 916032
Axis Part No. 02262-001
2N®Access Unit 2.0 Touch keypad
The numeric touch keypad module helps you control the
lock and use other code-accessible functions. The keypad
digits and symbols are backlit.
2N Part No. 9160344
Axis Part No. 02138-001
2N®Access Unit 2.0 RFID – 125 kHz, 13.56 MHz, NFC/HCE
The card reader provides you with access control via
contactless cards or keyfobs. The module supports the 125
kHz EM-41xx.
The card reader module provides you with access control via
contactless cardsorkeyfobs. The module supports the
following 13.56 MHz cards or other carriers (only card serial
number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key

2N Access Unit Installation Manual
7 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2N Part No. 9160344-S
Axis Part No. 02146-001
2N®Access Unit 2.0 RFID – 125 kHz, secured 13.56 MHz,
NFC/HCE
The card reader provides you with access control via
contactless cards or keyfobs. The module supports the 125
kHz EM-41xx.
The card reader module provides you with access control via
contactless cardsorkeyfobs. The module supports the
following 13.56 MHz cards or other carriers (only card serial
number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
HID SE (Seos, iClass SE, Mifare SE)
2N Part No. 9160335
Axis Part No. 02545-001
2N®Access Unit 2.0 Bluetooth & RFID – 125 kHz, 13.56
MHz, NFC/HCE
The bluetooth card reader module provides you with access
control via contactless cards or keyfobs. The module
supports the following125 kHz and13.56 MHz cards or other
carriers (only card serial number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key

2N Access Unit Installation Manual
8 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2N Part No. 9160335-S
Axis Part No. 01851-001
2N®Access Unit 2.0 Bluetooth & RFID – 125 kHz, secured
13.56 MHz, NFC/HCE
The bluetooth card reader module provides you with access
control via contactless cards or keyfobs. The module
supports the following125 kHz and13.56 MHz cards or other
carriers (only card serial number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
HID SE (Seos, iClass SE, Mifare SE)
2N Part No. 9160336
Axis Part No. 02546-001
2N®Access Unit 2.0 Touch keypad & RFID – 125 kHz, 13.56
MHz, NFC/HCE
The touch keypad and card reader module provides you
with access control via contactless cards or keyfobs. The
module supports the following125 kHz and13.56 MHz cards
or other carriers (only card serial number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key

2N Access Unit Installation Manual
9 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
2N Part No. 9160336-S
Axis Part No. 01852-001
2N®Access Unit 2.0 Touch keypad & RFID – 125 kHz,
secured 13.56 MHz, NFC/HCE
The touch keypad and card reader module provides you
with access control via contactless cards or keyfobs. The
module supports the following125 kHz and13.56 MHz cards
or other carriers (only card serial number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
HID SE (Seos, iClass SE, Mifare SE)
License
2N Part No. 916012
Axis Part No.
01369-001
2NAccess Unit license
2N Part No. 9160401
2N Access Unit Lift module license
•
Tip
Supported auxiliary modules: 2N®IP Verso modules are supported – RFID card
reader (125 kHz; 13.56 MHz), keypad, 5-button module, Wiegand, etc.


2N Access Unit Installation Manual
10 / 107
•
•
•
•
•
•
Frames
2N Part No. 9155011
Axis Part No. 01278-001
Flush mounting frame, 1-module
Covering frame for the 1-module brick/plasterboard
flush mounting box. This 1-module frame is used for
connection of an OUT card reader or keypad, for
example. Remember to order the frame when you
order a 1-module flush mounting box, Part No.
9155014.
2N Part No.9155011B
Axis Part No. 01279-001
Flush mounting frame, 1-module
Covering frame for the 1-module brick/plasterboard
flush mounting box. This 1-module frame is used for
connection of an OUT card reader or keypad, for
example. Remember to order the frame when you
order a 1-module flush mounting box, Part No.
9155014.
2N Part No. 9155012
Axis Part No. 01281-001
Flush mounting frame, 2-module
Covering frame for the 2-module brick/plasterboard
flush mounting box. Remember to order the frame
when you order a 2-module flush mounting box, Part
No. 9155015.

2N Access Unit Installation Manual
11 / 107
•
•
•
•
2N Part No.9155012B
Axis Part No. 01282-001
Flush mounting frame, 2-module
Covering frame for the 2-module brick/plasterboard
flush mounting box. Remember to order the frame
when you order a 2-module flush mounting box, Part
No. 9155015.
2N Part No. 9155021
Axis Part No. 01287-001
Wall mounting frame, 1-module
Covering frame for wall (surface) mounting.This 1-
module frame is used for connection of an OUT card
reader or keypad, for example.

2N Access Unit Installation Manual
12 / 107
•
•
2N Part No.9155021B
Axis Part No. 01288-001
Wall mounting frame, 1-module
Covering frame for wall (surface) mounting.This 1-
module frame is used for connection of an OUT card
reader or keypad, for example.

2N Access Unit Installation Manual
13 / 107
•
•
•
•
2N Part No. 9155022
Axis Part No. 01289-001
Wall mounting frame, 2-module
Covering frame for wall (surface) mounting.
2N Part No.9155022B
Axis Part No. 01290-001
Wall mounting frame, 2-module
Covering frame for wall (surface) mounting.

2N Access Unit Installation Manual
14 / 107
•
•
•
Extending Modules
2N Part No. 916020
Axis Part No. 01371-001
RJ-45 adapter
2N Part No.9155032
Axis Part No. 01255-001
2N®IP Verso – RFID Reader, 125 kHz
The card reader module works with 2NAccess Unitas
an OUT card reader. The module supports cards, key
fobs and/or other 125 kHz standard carriers: EM4xxx.
•
Tip
The 1-module frame is used when an auxiliary module from 2N® IP Verso is
mounted onto an extended interconnecting cable, for an OUT card reader or
keypad, for example.

•
•
•
Tip
Remember to order the flush mounting frame when you order a brick/plasterboard
flush mounting box:
1-module frame, Part No. 9155011 – 1-module flush mounting box, Part No.
9155014.
2-module frame, Part No. 9155012 –2-module flush mounting box, Part No.
9155015.


2N Access Unit Installation Manual
15 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2N Part No. 9155040
Axis Part No. 01262-001
2N®IP Verso– RFID Reader NFC/HCE support, 13.56
MHz
The card reader module works with 2NAccess Unit as
an OUT card reader. The module supports cards, key
fobs and/or other 13.56 MHz standard carriers (only
card serial number is read):
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
Part No. 9155082
2N®IP Verso – Bluetooth & RFID reader 125 kHz,
13.56 MHz, NFC/HCE
The bluetooth and card reader module works with
2NAccess Unit as an OUT card reader. The module
supports cards, key fobs and/or other 125 kHz and
13.56 MHz standard carriers (only card serial number
is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key

2N Access Unit Installation Manual
16 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Part No. 9155084
2N®IP Verso – Bluetooth & RFID reader 125 kHz,
secured 13.56 MHz, NFC/HCE
The bluetooth and secured card reader module works
with 2NAccess Unit as an OUT card reader. The
module supports cards, key fobs and/or other 125 kHz
and 13.56 MHz standard carriers (only card serial
number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
HID SE (Seos, iClass SE, Mifare SE)
Part No. 9155081
2N®IP Verso – Touch keypad & RFID reader 125 kHz,
13.56 MHz, NFC/HCE
The touch keypad and card reader module works with
2NAccess Unit as an OUT card reader. The module
supports cards, key fobs and/or other 125 kHz and
13.56 MHz standard carriers (only card serial number
is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key

2N Access Unit Installation Manual
17 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
Part No. 9155083
2N®IP Verso – Touch keypad & RFID reader 125 kHz,
secured 13.56 MHz, NFC/HCE
The touch keypad and secured card reader module
works with 2NAccess Unit as an OUT card reader.
The module supports cards, key fobs and/or other 125
kHz and 13.56 MHz standard carriers (only card serial
number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
HID SE (Seos, iClass SE, Mifare SE)
2N Part No. 9155031
Axis Part No. 01253-001
2N®IP Verso– Keypad
The numeric keypad module helps enter a numeric
entrance code. Use the keypad for departures or
double entrance authentication. The keypad digits
and symbols are backlit.

2N Access Unit Installation Manual
18 / 107
•
•
•
•
•
•
2N Part No.9155031B
Axis Part No. 01254-001
2N®IP Verso– Keypad
The numeric keypad module helps enter a numeric
entrance code. Use the keypad for departures or
double entrance authentication. The keypad digits
and symbols are backlit.
2N Part No.9155047
Axis Part No. 01277-001
2N®IP Verso– Touch keypad
The numeric keypad module helps you dial users via
their phonebook positions or phone numbers, control
the lock and use other code-accessible functions. The
keypad digits and symbols are backlit.
2N Part No.9155036
Axis Part No. 01275-001

2N®IP Verso – Touch Display
Touchscreen module allowing visitors to dial users in
a smartphone-like way. In addition to a structured
phonebook it also features a keypad.
•
Caution
This module is only supported by 2N Access
Unit 2.0.


2N Access Unit Installation Manual
19 / 107
•
•
•
•
•
•
•
2N Part No. 9155037
Axis Part No. 01259-001
2N®IP Verso– Wiegand
The Wiegand module helps you interconnect your
system with other systems (security) via the Wiegand
interface. The module is installed under another
module, i.e. cannot be installed directly into the2N
Access Unit(must be mounted outside).
2N Part No. 91550371
Axis Part No. 02577-001
2N®IPVerso– OSDP module
The OSDP moduleprovides communication between
a connected device (control panel, door controller)
and2N®IP Versovia the OSDP. The module is
installed under another module, i.e. needs no
separate position.
Compatible with Access Unit 2.0models only
2N Part No. 9155034
Axis Part No. 01257-001
2N®IP Verso – I/O
The logic input/output module helps you integrate
various sensors and control doors or other
equipment. The module is installed under another
module, i.e. cannot be installed directly into
the2NAccess Unit (must be mounted outside).

2N Access Unit Installation Manual
20 / 107
•
•
•
•
•
•
•
2N Part No.9155030
Axis Part No. 01252-001
2N®IP Verso – Info panel
The Infopanel module helps you add your company
logo, opening hours and similar information to the
access unit. The Infopanel has software-controlled
backlight.
Part Numbers:
9155050, 01267-001
9155054, 01268-001
9155055, 01269-001
1 m Interconnecting cable
3 m Interconnecting cable
5 m Interconnecting cable
Mounting Accessories
2N Part
No.9155014
Axis Part No.
01284-001
Flush mounting box, 1-module
The box is designed for brick/plasterboard flush mounting of a 1-
module installation. Supplied including accessories for multiple box
assemblies.
