3M 3M-Matic 800r Datasheet

3M Packaging Systems Division
3M Center, Building 220-8W-01
St. Paul, MN 55144-1000
800r Type 29600
Random
Case Sealer
with
Taping Heads
3M-Matic
TM
Instructions and Parts List
"3M-Matic" and "AccuGlide" are Trademarks
of 3M, St. Paul, MN 55144-1000
Printed in U.S.A.
© 3M 1999 44-0009-1897-7(A59.0)
Serial No.
For Reference, record taping head(s) serial number(s) here.
Important
It is recommended you
immediately order the
spare parts listed on
page 35. These parts
are expected to wear
through normal use
and should be kept on
hand to minimize
production delays.
AccuGlide II
TM
Important
Safeguards
Read "Important Safeguards",
pages 3-6 and also operating
"Warnings", page 17
BEFORE INSTALLING OR
OPERATING THIS
EQUIPMENT.

Replacement Parts and Service Information
3M Packaging Systems Division
3M Center, Building 220-8W-01
St. Paul, MN 55144-1000
To Our Customers:
This is the 3M-Matic™/AccuGlide™/Scotch™ brand equipment you
ordered. It has been set up and tested in the factory with "Scotch" brand
tapes. If technical assistance or replacement parts are needed, call or Fax
the appropriate number listed below.
Included with each machine is an Instructions and Parts List manual.
Replacement Parts and Additional Manuals
Order parts by part number, part description and quantity required. Also,
when ordering parts and/or additional manuals, include machine name,
number and type. A parts order form is provided at the back of this manual.
3M/Tape Dispenser Parts
241 Venture Drive 1-800/344 9883
Amery, WI 54001-1325 FAX# [phone]
Technical Assistance:
3M-Matic™ Helpline – 1-800/328 1390. Please provide the customer support
coordinator with the machine number, machine type/model and serial number.
If you have a technical question that does not require an immediate response,
you may Fax it to 715/381 0248.
Minimum billing on parts orders will be $25.00. Replacement part prices available on request.
Note : Outside the U.S., contact the local 3M subsidiary for parts ordering information.
$10.00 restocking charge per invoice on returned parts.
"3M-Matic", "AccuGlide" and “Scotch” are trademarks
of 3M, St. Paul, Minnesota 55144-1000
Printed in U.S.A.
© 3M 1999 44-0009-1851-4(E79.0)

Replacement Parts And Service Information
To Our Customers:
This is the 3M-Matic™/AccuGlide™/Scotch™ brand equipment you
ordered. It has been set up and tested in the factory with "Scotch" brand
tapes. If any problems occur when operating this equipment, and you
desire a service call, or phone consultation, call, write or Fax the
appropriate number listed below.
Included with each machine is an Instructions and Parts List manual.
SERVICE, REPLACEMENT PARTS AND ADDITIONAL MANUALS
AVAILABLE DIRECT FROM:
Order parts by part number, part description and quantity required. Also, when
ordering parts and/or additional manuals, include machine name, number and
type.
1-800/328 1390
"3M-Matic", "AccuGlide" and “Scotch” are trademarks
of 3M, St. Paul, Minnesota 55144-1000
Printed in U.S.A.
© 3M 1999 44-0009-1852-2(D79.0)
3M Packaging Systems Division
3M Center, Building 220-8W-01
St. Paul, MN 55144-1000

i
This instruction manual is divided into two sections as follows:
Section IIncludes all information related to installation, operation and parts for the case sealer.
Section II Includes specific information regarding the AccuGlide™ II STD 2 Inch Taping Heads.
Table of Contents Page
Section I– 800r Random Case Sealer
Intended Use..................................................................................................................................... 1
Equipment Warranty and Limited Remedy....................................................................................... 2
800r Contents ................................................................................................................................... 2
Important Safeguards ....................................................................................................................... 3 - 6
Specifications.................................................................................................................................... 7 - 9
Installation and Set-Up ..................................................................................................................... 10 - 12
Receiving and Handling....................................................................................... 10
Machine Set-Up ................................................................................................... 10 - 12
Packaging and Separate Parts .................................................................. 10
Outboard Tape Roll Mounting.................................................................... 11
Taping Heads............................................................................................. 11
Box Size Capacity of Case Sealer............................................................. 11
Pneumatic Connection............................................................................... 12
Electrical Connection and Controls ........................................................... 12
Initial Start-Up of Case Sealer ................................................................... 12
Operation .......................................................................................................................................... 13 - 18
Controls, Valves and Switches............................................................................ 14 - 16
Tape Loading/Threading ..................................................................................... 17
Box Sealing.......................................................................................................... 18
Box Jam............................................................................................................... 18
Maintenance ..................................................................................................................................... 19 - 22
Cleaning............................................................................................................... 19
Lubrication ........................................................................................................... 19
Drive Belts ........................................................................................................... 20 - 21
Circuit Breaker ..................................................................................................... 22
Knife Replacement, Taping Head ....................................................................... 22
Adjustments ..................................................................................................................................... 23
Drive Belt Tension ............................................................................................... 23
Taping Head Adjustments ................................................................................... 23
(Table of Content continued on next page)
Instruction Manual
800r Random Case Sealer, Type 29600

ii
Table of Contents (Continued) Page
Special Set-Up Procedure ................................................................................................................ 24 - 25
Changing Tape Leg Length ................................................................................. 24
Box Height Range................................................................................................ 24 - 25
Troubleshooting ................................................................................................................................ 27 - 28
Operating Sequence......................................................................................................................... 29
Electrical Diagram............................................................................................................................. 30 - 31
Pneumatic Diagram .......................................................................................................................... 32 - 33
Parts and Service Information .......................................................................................................... 35
Options/Accessories ......................................................................................................................... 36
Replacement Parts Illustrations and Parts Lists.................................................. Yellow Section 37 - 67
Section II – AccuGlide™ II STD 2-Inch Taping Head
(See Section II for Table of Contents)
