3M Aqua-Pure AP110 Series User manual

At a Glance:
• New and Improved*
• Up to 30% Longer Lasting*
• 47% More Surface Area*
• 50% More Efficient*
Applications:
• Pre-Filtration
• Sediment/Rust
Product Benefits:
• Patent pending technology provides fine sediment filtration down to 5 micron**
• Grooved cartridge increases surface area for longer cartridge life, by 132% over
non-grooved and 47% over the previous design
• Rigid construction helps to eliminate sediment “unloading” due to variances in
water pressure
Models:
AP110 Series / AP124 Series
Whole House Water Filters
Product Specifications:
Model No.
(Part No.)
Dimensions
Flow Rate Max. Water Temp. Degree of Filtration
Height Diameter
AP1110
(56204-04)
(56204-06)
9-3/4” (24.8 cm) 2-1/2” (6.4 cm) 8 gpm (30.3 lpm) 170°F (76.7°C) 5 micron nominal
AP110-2
(56204-05) 19-1/2” (49.5 cm) 2-1/2” (6.4 cm) 16 gpm (60.6 lpm) 170°F (76.7°C) 5 micron nominal
AP124
(56206-01)
(56206-05)
9-3/4” (24.8 cm) 2-1/2” (6.4 cm) 8 gpm (30.3 lpm) 170°F (76.7°C) 50 micron nominal
AP124-2
(56206-03) 19-1/2” (49.5 cm) 2-1/2” (6.4 cm) 16 gpm (60.6 lpm) 170°F (76.7°C) 50 micron nominal
Spec #
Quantity
AP110 / AP124
* as compared to original AP110 design
** depends on model selected
AP110-2 / AP124-2

a 3M company
CUNO Incorporated
400 Research Parkway
Meriden, CT 06450 U.S.A.
Toll Free: 1.800.222.7880
Worldwide: 203.237.5541
Fax: [phone]
www.aquapure.com • www.cuno.com
CUNO and Aqua-Pure are trademarks of 3M Company used under license.
© 2007 3M Company. All rights reserved.
LITAP929 0607
Physical Specifications:
• Cartridge is manufactured from FDA CFR-21 compliant materials
• Cartridge has a maximum operating temperature of 170°F (76.7°C)
• Cartridge to be installed at point of entry
WARNING: Do not use with water that is microbiologically unsafe
or of unknown quality without adequate disinfection before or
after the system.
CUNO Incorporated recommends regularly scheduled maintenance
and replacement of the filter cartridge(s) in order for the product to
perform as advertised/sold. Change the filter cartridge at least ev-
ery 6 months. Improper installation and maintenance may result
in property damage due to water leakage.
Spec #
Quantity
Model Number
Part Number
Easy Installation:
Limited Warranty:
CUNO Incorporated warrants that this product is free from defects in materials and workmanship. This limited warranty,
together with any and all warranties implied by law, shall be limited to a period of one (1) year from the date of original
purchase. This limited warranty does not apply to failures that result from abuse, misuse, alteration or damage not caused
by CUNO or failure to properly comply with these installation or cartridge change-out instructions. This limited warranty is
subject to exclusions and limitations. Please refer to the Warranty Card provided with the product for details.
Distributed by:
Fits all CUNO and most competitive filter housings
AP110 AP110-2 AP124 AP124-2
AP11T AP12T AP11T AP12T
AP101T AP102T AP101T AP102T
AP1610SS AP2610SS AP1610SS AP2610SS
SST1HA SST2HB SST1HA SST2HB
SS4 EPE-316L
(4 carts)
SS4 EPE-316L
(4 carts)
SS8 EPE-316L
(8 carts - 2 high)
SS8 EPE-316L
(8 carts - 2 high)
SS12 EPE-316L
(12 carts - 3 high)
SS12 EPE-316L
(12 carts - 3 high)
SS20 EPE-316L
(20 carts - 4 high)
SS20 EPE-316L
(20 carts - 4 high)
SS24 EPE-316L
(24 carts - 2 high)
SS24 EPE-316L
(24 carts - 2 high)
SS36 EPE-316L
(36 carts - 3 high)
SS36 EPE-316L
(36 carts - 3 high)
AP110 / AP124
2-1/2”
(6.4 cm)
19-1/2”
(49.5 cm)
CAUTION: Diagram shown is for reference purposes
only. Read installation and operation manual prior to
installing the unit.
Visit www.nsf.org for
the claims associated
with products that
are NSF listed.
AP110-2 / AP124-2
9-3/4”
(24.8 cm)
2-1/2”
(6.4 cm)
nehctiKmoorhtaB
Utility Room
Water Meter
Cold Water
Supply
Public
Water
Supply
Well
Water
Supply
AP100
Series
Pressure Tank
Well
Supply
Only
Pump
