3One data NP5100 Series User manual

NP5100 Series
Safe Serial Server
Quick Installation Guide
3onedata Co., Ltd.
Address: 3/B, Zone 1, Baiwangxin High Technology
Industrial Park, Xili, Nanshan District, Shenzhen
Website: www.3onedata.com
Tel: [phone]
Fax: [phone]
【Package Checklist】
Please check whether the package and accessories are
intact while using the serial server for the first time.
1. Serial server
2. Quick installation guide
3. Power line x2
4. Network cable
5. Rack-mounting lug x2
6. Foot pad x4
7. Software installation CD
8. Warranty card
9. Certification
If any of these items are damaged or lost, please contact our
company or dealers, we will solve it ASAP.
【Product Overview】
The series products are managed rack-mounted industrial
safe serial servers, including the following models:
Model I. NP5100-2T-32DI(3IN1)-RJ-OLED (2
10/100Base-T(X) copper ports + 32
RS-232/485/422 serial ports +1 OLED display)
Model II. NP5100-2T-32DI(3IN1)-RJ (2 10/100Base-T(X)
copper ports + 32 RS-232/485/422 serial ports)
Model III. NP5100-2T-16DI(3IN1)-RJ-OLED (2
10/100Base-T(X) copper ports + 16
RS-232/485/422 serial ports + 1 OLED display)
Model IV. NP5100-2T-16DI(3IN1)-RJ (2 10/100Base-T(X)
copper ports + 16 RS-232/485/422 serial ports)
【Panel Design】
Front View
Model I, Model II
Model III, Model IV
Rear View
Model I
Model II
Model III
Model IV
Top view
Left view and right view
1. RS-232/485/422 serial port
2. 100M Copper Port
3. Console port
4. DIP switch
5. Grounding screw
6. TF card slot
7. AC power input
8. Lugs
9. Serial port transmitting indicator
10. Serial port receiving indicator
11. Running indicator
12. Power indicator
13. Copper port connection indicator
14. OLED display
15. Menu/Exit button
16. Page UP
17. Page Down

18. Select/confirm button
【Mounting Dimension】
Unit: mm
Note before mounting:
Don't place or install the device in area near water or
moist, keep the relative humidity of the device surrounding
between 5%~95% without condensation.
Before power on, first confirm the supported power
supply specification to avoid over-voltage damaging the
device.
The device surface temperature is high after running;
please don't directly contact to avoid scalding.
【Rack-mounted】
This product adopts rack-mounting, mounting steps as
below:
Step 1 Select the device mounting location to ensure
enough size.
Step 2 Adopt 4 bolts to install the mounting lugs in the
device position as figure below.
Step 3 Place the device in the rack; adopt 4 bolts to fix
two sides mounting lugs in the rack.
Step 4 Check and confirm the product is mounted firmly
on the rack, mounting ends.
【Disassembling Device】
Step 1 Device power off.
Step 2 Adopt screw driver to loosen the 4 bolts fixed on
the mounting lugs in the rack.
Step 3 Shift out the device from rack, disassembling
ends.
Note before powering on:
Power ON operation: First insert the power supply
terminal block into the device power supply interface, and
then plug the power supply plug contact and power on.
Power switch “—” means power ON, “O” means
power OFF.
Power OFF operation: First, put the powers switch to
the "O" side and then disconnect the power supply. Finally
disconnect the connector between the device and the power
cord. Please notice the operation order above.
【Power Supply Connection】
AC power supply
This device provides 2 AC power supply access interfaces
which come with a switch.
Voltage range: 85~265VAC.
【Serial Port Connection】
This device provides 3IN1 serial port, which
supports RS232, RS485 and RS422 at the same
time. The interface type is RJ45 and its pin
definitions are as follows:
PIN
1
2
3
4
5
6
7
8
RS-232
DSR
RTS
GND
TXD
RXD
DCD
CTS
DTR
RS-485
—
—
GND
—
—
D-
—
D+
RS-422
—
R-
GND
R+
—
T-
—
T+
【DIP Switch Settings】
Provide 4 pins DIP switch for function settings, where "ON"
is enable valid terminal. The device needs to be powered on
again to change the status of DIP switch.
DIP switches definition as follows:
DIP
Definition
Operation
1
Reserved
-
2
Restore
factory
defaults
Set the DIP switch to ON, the
device will root automatically
and restore to factory settings,
then turn off the DIP switch.
3
Reserved
-
4
Reserved
-
【Console Port Connection】
The series products provide 1 program debugging port
based on RS-232 serial port which can conduct device CLI
command management after connecting to PC. The
interface adopts RJ45 port, the RJ45 pin definition as
follows:
Pin No.
2
3
5
Definition
TXD
RXD
GND

【TF Card Slot】
This device provides 1 TF card slot. Using a screwdriver to
unscrew the screw behind the TF card slot with slight
strength and the card slot would pop up, then put TF card in
the slot in the right way. TF card could be used for device
upgrade. Before using it, please format the TF card into
FAT32 format.
Note:
In case of damaging TF card, user needs to power off
the device first to change the TF card.
【Set OLED Display】
Model I and model III of the device provide liquid crystal
display screens. Under normal working conditions, the liquid
crystal display is dark and shows the IP address of LAN1.
User can press the button to change the settings and query
accordingly:
Key
Name
Command
MENU
Menu/Exit
Enter Main Menu/Back
︿
Page UP
Select the last target
﹀
Page Down
Select the next target
SEL
Select/confirm
Select selected item
Display resolution is 128*16, support numbers, English case,
". ", "-", "_", "↑", "↓" and other characters, support single line
left and right scroll. Supports cursor blinking to determine
the current cursor position. Trigger the button, the screen
light is on. If there is no new operation for 30s, the screen
would go into sleep state.
Detailed operation steps of OLED display screen are as
follows:
Step 1 Start up, the first line shows the device name, the
second line shows the LAN1 IP address.
Step 2 Trigger the menu key to enter the menu interface,
options:
-Server setting: basic information of the
device, please skip to step 3 and step 6 for
this setting;
-Network setting: network configuration,
please skip to step 5 and step 6 for this
setting;
-Save/Restart: Save Settings /Restart the
device, skip to step 6 for this setting.
Step 3 Select Server setting on the Menu interface,
trigger SEL key, enter the configuration interface
of Server setting, options:
-Serial number (read only);
-Server name (read only);
-Firmware ver (read only);
-Model name (read only);
Step 4 Select Network setting on the Menu interface,
trigger SEL key, enter the configuration interface
of Network setting, options:
-LAN 1: network card 1 configuration;
-LAN 2: network card 2 configuration.
Step 5 Select LAN 1(LAN 2) on the Network setting
interface, trigger SEL key, enter the configuration
interface of LAN 1(LAN 2), options:
-Ethernet status: network card state (read
only);
-MAC address: MAC address (read only);
-IP config: IP configuration method (trigger
SEL key configuration)
Options: Static, DHCP;
-IP address (read-write);
-Netmask (read-write);
-Gateway: default gateway (read-write).
Note:
When the configuration needs to be modified, it can
be triggered by ∧and ∨keys to change the value.
Step 6 Select Save/Restart on the Menu interface,
trigger SEL key, enter the configuration interface
of Save/Restart, options:
-Save: save configuration;
-Restart: reboot the device.
Note:
Select Save or Restart, the interface shows the Disable
option (to prevent over-long key-press time and
misoperation) first, it can trigger ﹀button, select the
Enable option, and then trigger the SEL button, Save
the configuration or Restart the device.
【Checking LED Indicator】
The series products provide LED indicators to monitor the

device working status with a comprehensive simplified
troubleshooting; the function of each LED is described in the
table as below:
LED
Indicate
Description
POWER
(1-2)
ON
PWR is connected and running
normally
OFF
PWR is disconnected and
running abnormally
RUN
Blinking
System runs normally
OFF
The system is not running or
running abnormally
ON
System is running abnormally
Link(1-2)
ON
Port has established valid
network connection
Blinking
Port is in a network
communication status
OFF
Port hasn’t established valid
network connection.
TX(1-32)
OFF
No data or abnormal data is
being transmitted through serial
port.
Blinking
Serial port is transmitting data.
RX(1-32)
OFF
Serial port is not receiving data
or receiving data abnormally
Blinking
Serial port is receiving data.
【Logging in to WEB Interface】
This device supports WEB management and configuration.
Computer can access the device via Ethernet interface. The
way of logging in to device’s configuration interface via IE
browser is shown as below:
Step 1 Configure the IP addresses of computer and the
device to the same network segment(The
network segment of Network Port 1 is 1, and the
network segment of network port 2 is 8), and the
network between them can be mutually
accessed.
Step 2 Enter device’s IP address in the address bar of
the computer browser.
Network Port 1:
Network Port 2：
Step 3 Enter device’s username and password in the
login window as shown below.
Step 4 Click “OK” button to login to the WEB interface of
the device.
Note:
The default IP address of the device Network port 1 is
“192.168.1.254”, the default IP address of the network port
2 is “192.168.8.254”.
The default user name and password of the device are
“admin”.
If the username or password is lost, user can restore it
to factory settings via device DIP switch or management
software; all modified configurations will be cleared after
restoring to factory settings, so please backup configuration
file in advance.
Please refer to user manual for specific configuration
method of logging in to WEB interface and other
configurations about network management function.
【Specification】
Panel
100M Copper Port
10/100Base-T(X)
self-adapting RJ45 port,
half/full duplex self-adapting or
forced working mode, support
MDI/MDI-X self-adapting
Serial Port
3IN1 serial port, adopts RJ45,
supports 15KV ESD protection
Console port
CLI command management
port (RS-232), RJ45
Indicator
Power indicator, running
status indicator, copper port
connection status indicator,
serial port receiving indicator,
serial port transmission
indicator
OLED display
Menu/Exit, page up, page
down, select/confirm
Power Supply
Input power supply
85~265VAC
Access terminal block
Support single-phase socket
with rocker switch
Power Consumption
No-load
5.6W@220VAC
Full-load
13.2W@220VAC
Working Environment
Working temperature
-40～75℃
Storage temperature
-40～85℃
Working humidity
5%～95% (no condensation)
Protection grade
IP40 (metal shell)
