3One data NP318T-8DI User manual

NP Series
Serial Device Server
User Manual
Document Version: 02
Publication Date: Oct. 2017
Industrial Ethernet communication solutions experts 3onedata Co., Ltd.

Copyright © 2018 3onedata Co., Ltd. All rights reserved.
For this manual, all rights reserved by 3onedata Co., Ltd. No company or individual is allowed to
duplicate or translate this manual in any forms without written permission issued by 3onedata
Technology Co., Ltd.
Trademark statement
, and is the registered trademark owned by
Shenzhen 3onedata Technology Co., Ltd. And other trademarks mentioned in this manual belong to
their corresponding companies.
Conventions Used in the Manual
Technical or printing errors might exist in the product or the instruction manual; therefore, Shenzhen
3onedata Technology Co., Ltd. reserves the right to change the manual entirely or partially with no
advance notice required. 3onedata provides this document as is, without warranty of any kind, either
expressed or implied, including, but not limited to, its particular purpose. Due to the improvement of the
management software, the version of software that you are using might not be the latest or the perfect
version. The manual is only for your reference, and please contact us if you have any questions.

3onedata Co., Ltd.
Headquarter address:
3/B, Zone 1, Baiwangxin High Technology Industrial park, Nanshan District, Shenzhen,
518108 China
Technology support: [e-mail]
Tel: [phone]
E-mail: [e-mail]
Fax: [phone]
Website: http://www.3onedata.com

User Manual
3onedata proprietary and confidential 1
Copyright © 3onedata Co., Ltd.
Preface
NP series serial device server user manual has introduced:
Product features
Network management method
Network management relative principle overview
The description of this manual is from the NP318T-8DI (3IN1). Other types of products in
addition to the support of the serial port type (RS-232, RS-422, RS-485), the number of
serial ports and the number of network ports are different, the interface functions and
operations are the same.
Audience
This manual applies to the following engineers:
Network administrators
Technical support engineers
Hardware engineers
Conventions
Format Description
“ ”
Words with the symbol “” mean that those are interface
words. Fox example “Port number”.
> Multiple paths are separated by the symbol ‘>’.
Light blue Font Click light blue font to hyperlink The font color is as follows:
‘Light Blue’.
About This Chapter
The section ‘about this chapter’ provide links to various
sections of this cha
pter, as well as links to the Principles
Operations Section of this chapter.
Symbols
Format Description

User Manual
3onedata proprietary and confidential 2
Copyright © 3onedata Co., Ltd.
Format Description
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to personal
injury.
Ndicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Calls attention to important information, best practices and
tips.
NOTE is used to address information not related to personal
injury, equipment damage, and environment deterioration.
The tips of configuration and operation.
Pay attention to the operation or information to ensure
success device configuration or normal working.
Revision History
Version No. Date Revision note
01 2017-05-25 Layout Adjustment
02 2017-10-10 Add Password Verification Funciton

User Manual
3onedata proprietary and confidential I
Copyright © 3onedata Co., Ltd.
Contents
PREFACE.......................................................................................................................................1
CONTENTS.....................................................................................................................................I
PART ONE: OPERATION ..............................................................................................................1
1LOGIN THE WEB INTERFACE ............................................................................................1
1.1 SYSTEM REQUIREMENTS..............................................................................................1
1.2 SET THE IP ADDRESS OF THE COMPUTER........................................................................1
1.3 LOGIN THE WEB CONFIGURATION INTERFACE ...............................................................3
1.4 WEB TIMEOUT PROCESSING ........................................................................................4
2DEVICE INFORMATION ......................................................................................................5
3SETTING NETWORK ...........................................................................................................7
4SERIAL SERVER .................................................................................................................10
ABOUT THIS CHAPTER...........................................................................................................10
4.1 COM SETTINGS ........................................................................................................10
4.2 CHECKING COM INFORMATION ..................................................................................13
4.3 COM MODE SETTINGS ..............................................................................................14
4.3.1 RealCom Mode ..........................................................................................................15
4.3.2 TCP Server Mode .......................................................................................................18
4.3.3 TCP Client Mode........................................................................................................22
4.3.4 UDP Server Mode.......................................................................................................26
4.3.5 UDP Client Mode .......................................................................................................29
4.3.6 Pair Slave & Master Mode...........................................................................................31
4.3.7 UDP Rang Mode ........................................................................................................33
4.3.8 UDP Multicast Mode ..................................................................................................35
4.4 COM MODE INFORMATION ........................................................................................37
4.5 REBOOT PORT ...........................................................................................................37
5MONITORING STATE.........................................................................................................39
ABOUT THIS CHAPTER...........................................................................................................39
5.1 CONNECT STAT E ........................................................................................................39
5.2 COM STAT E ..............................................................................................................40
5.3 COM PARAMETER.....................................................................................................41
6CONTROLING ACCESS......................................................................................................43
ABOUT THIS CHAPTER...........................................................................................................43

User Manual
3onedata proprietary and confidential II
Copyright © 3onedata Co., Ltd.
6.1 DEVICE SECURITY .....................................................................................................43
6.2 IP FILTER..................................................................................................................44
6.3 MAC FILTER.............................................................................................................46
6.4 USER MANAGE .........................................................................................................47
7REMOTE MONITOR...........................................................................................................49
ABOUT THIS CHAPTER...........................................................................................................49
7.1 SNMP SETTINGS .......................................................................................................49
7.1.1 Introduction of SNMP.................................................................................................49
7.1.2 Work Mechanism of SNMP .........................................................................................49
7.1.3 SNMP Version............................................................................................................50
8SYSTEM MANAGE .............................................................................................................52
ABOUT THIS CHAPTER...........................................................................................................52
8.1 IP MAP.....................................................................................................................52
8.2 SYSTEM INFORMATION ..............................................................................................53
8.3 SYSTEM FILE ............................................................................................................55
8.4 LOGOUT &REBOOT...................................................................................................56
9WORKING MODE CONFIGURATION EXAMPLE ............................................................58
ABOUT THIS CHAPTER...........................................................................................................58
9.1 REALCOM MODE ......................................................................................................58
9.2 TCP SERVER MODE ...................................................................................................64
9.3 TCP CLIENT MODE....................................................................................................69
9.4 UDP SERVER MODE ..................................................................................................74
9.5 UDP CLIENT MODE ...................................................................................................79
9.6 PAIR SLAVE &MASTER MODE....................................................................................83
9.7 UDP RANG MODE .....................................................................................................85
9.8 UDP MULTICAST MODE.............................................................................................91
PART TWO: FREQUENTLY ASKED QUESTIONS .....................................................................97
10 FAQ ......................................................................................................................................97
ABOUT THIS CHAPTER...........................................................................................................97
10.1 LOGIN PROBLEM .......................................................................................................97
10.2 CONFIGURATION PROBLEM ........................................................................................98

User Manual
3onedata proprietary and confidential 1
Copyright © 3onedata Co., Ltd.
Part One: Operation
1Login the WEB Interface
1.1 System Requirements
Using the serial device server, the system should meet the following conditions.
Hardware and software System requirements
CPU Pentium 586 or above
Memory 128MB or more
Resolution 1024x768 or above
Color 256 color or above
Browser Internet Explorer 8.0 or above
Operating system Windows XP
Windows 7
1.2 Set the IP address of the Computer
The default management of the serial device server is as follows:
IP Settings Default Values
IP address 192.168.1.254
Subnet mask 255.255.255.0
When configuring a serial server through the Web:

User Manual
3onedata proprietary and confidential 2
Copyright © 3onedata Co., Ltd.
Before making remote configuration, make sure that the route between the
computer and the switch is reachable.
Before making a local configuration, make sure that the IP address of the
computer and the serial server are on the same subnet.
Note:
When the serial server is first configured. If it is configured locally, make sure the current
computer network segment is 1.
For example, suppose that the IP address of the computer is 192.168.5.60, need to
change the IP address of the network segment "5" to "1"
Operation steps
The steps are as follows:
Step 1 Open “Control panel > Network connection > Local area connection > Properties >
Internet protocol version (TCP/IPv4) Properties”.
Step 2 Change the "5" selected by the red frame in the figure to "1".
Step 3 Click "OK".
Step 4 End.

User Manual
3onedata proprietary and confidential 3
Copyright © 3onedata Co., Ltd.
1.3 Login the WEB Configuration Interface
Operation steps
Log in to the WEB configuration interface as follows:
Step 1 Run the computer browser.
Step 2 Enter the address of the serial server "http://192.168.1.254" in the address bar of the
browser.
Step 3 Click the Enter key.
Step 4 Pop-up dialog box as shown below, enter the user name and password in the login
window.
Note:
The default username and password for the serial server are "admin", which is strictly
case-sensitive when typing.
The default user password is with administrator privileges.
WebServer will provide three opportunities to enter the user name and password. If you
enter the error 3 times in succession, the browser will display "Access denied" to deny
access to the information. Please refresh the page and try again.
Step 5 Click “OK”.
Step 6 End.
After successful login, you can configure the relevant parameters and information of
the WEB interface as needed.
Note:
After logging in to the device, you can modify the IP address of the serial server for ease of
use.

User Manual
3onedata proprietary and confidential 4
Copyright © 3onedata Co., Ltd.
1.4 WEB Timeout Processing
When the user does not operate for more than 300 seconds in the Web interface, the
system will do the timeout processing:
Keep the configuration of this login;
Logout this login
Note:
After the system times out, if you need to continue operate in the WEB interface, please
re-login.

User Manual
3onedata proprietary and confidential 5
Copyright © 3onedata Co., Ltd.
2Device Information
Function Description
On the “Device Information” page, you can view information such as device name,
device model, device description, device number, hardware version, and software
version.
Operation Path
Device information> basic information
Interface description
Basic information interface screenshot
The main element configuration instructions in the basic information interface
Interface Elements Description
Name Display device name.
Module Display device module.
Description Displays the number of network ports
Serial NO. Display device serial number.
Default LAN Display the default network port.
Hardware Ver. Display device hardware version.

User Manual
3onedata proprietary and confidential 6
Copyright © 3onedata Co., Ltd.
Network information interface screenshot
The main element configuration instructions in the network information interface
Interface Elements Description
Gets IP mode Shows how the device gets the IP address.
Subnet mask Display device subnet mask.
Gets DNS mode Display device gets the way for DNS.
MAC address Display device MAC address.
IP address Display deivce IP address information.
Gateway Display device gateway address.
DNS server Display device DNS server address.

User Manual
3onedata proprietary and confidential 7
Copyright © 3onedata Co., Ltd.
3Setting Network
Function Description
On the "Network Settings" page, you can configure the way to obtain the IP address
or DNS server address, manually configure the device IP address, network mask,
gateway address and DNS server address and other information.
Operation Path
Open “Network Settings> Network Settings” in sequence.
Interface description
Network settings interface screenshot
The dual-port device displays the "Lan1" and "Lan2" columns. The single-port device
displays only the "Lan1" column.

User Manual
3onedata proprietary and confidential 8
Copyright © 3onedata Co., Ltd.
Network settings interface main element configuration instructions
Interface Elements Description
Default LAN Enable the data from the different network segment of the
device to transmit from the default network port.
Note：
Single-port devices do not support this function。
Lan1 Network port 1 network configuration column.
Note：
The default IP for Lan1 is 192.168.1.254.
The way
to get the
Use the following IP addresses: Manually configure the

User Manual
3onedata proprietary and confidential 9
Copyright © 3onedata Co., Ltd.
Interface Elements Description
IP address IP address, subnet mask, and default gateway address.
Obtain an IP address automatically: Obtain an IP
address, subnet mask, and default gateway address
automatically.
IP address Configure the IP address manually in the “IP Address” text
box.
Subnet mask Configure the subnet mask manually in the “Subnet mask”
text box.
Gateway Configure the gateway address manually in the “Gateway
Address” text box.
The way
to get the
DNS server address
Use the following DNS server address: Manually
configure the DNS server address information.
Automatically obtain DNS server address:
Automatically obtain DNS server address information.
Lan2 Network port 2 network configuration column.
Note：
The default IP for Lan1 is 192.168.8.254.
Refer to the corresponding section of Lan1 in this table for
the description of interface elements.
IP Report IP Report configuration column.
Note：
When the serial server adopts the "automatic IP address", it
reports the IP address of the user by intermittently, so that the user
knows the new IP address of the serial server in time.
Sever Address The server that receives the IP address report.
Sever Port The port that sends the IP address report.
Repeat Time The sending frequency of IP report.
When the DHCP server assigns a new IP address to the serial server, the host needs to
detect the new IP address of the serial server when the serial server is in a network
environment that dynamically assigns an IP address. When the dynamic IP address
changes, the serial server reports its own IP address to the user by intermittently, so that the
user knows the new IP address of the serial server in time.

User Manual
3onedata proprietary and confidential 10
Copyright © 3onedata Co., Ltd.
4Serial Server
About This Chapter
Content Hyperlink
This chapter 4.1 COM Settings
4.2 Checking COM Information
4.3 COM Mode Settings
4.4 COM Mode Information
4.5 Reboot Port
4.1 COM Settings
Function Description
On the “COM settings” page, you can configure basic parameters such as baud rate,
data bit, stop bit and parity bit corresponding to the serial port number. You can also
configure whether the corresponding serial number is enabled for FIFO function, RTS
control, DTR control and Packing length and other advanced parameter information.
Operation Path
Open “serial server > COM settings” in sequence.
Interface Description
COM settings interface screenshot

User Manual
3onedata proprietary and confidential 11
Copyright © 3onedata Co., Ltd.
The main elements configuration instructions in COM settings
Interface Elements Description
Port Select the serial number of the device.
Alias Enter the alias for the corresponding serial number in the
“Alias” text box.
BaudRate Select the baud rate for the corresponding serial number.
The options are:
300/600/1200/2400/4800/9600/19200/38400/57600/115200
DataBits Select the data bit for the corresponding serial number. The
options are:
5 bits
6 bits
7 bits
8 bits
StopBits Select the stop bit for the corresponding serial number. The
options are:
1 bits
2 bits

User Manual
3onedata proprietary and confidential 12
Copyright © 3onedata Co., Ltd.
Interface Elements Description
ParityBits Select the parity bit
for the corresponding serial number.
The options are:
None
Odd
Even
Mark

Space
Flow Control Flow control is used in two data transmis
sion speed of
different devices in the control of data flow technology to
ensure that two devices communicate with each other to
avoid data loss. Click the "flow control" drop-down list box,
select the flow control parameters, the options are:
No
RTS/CTS
XON/XOFF
DTR/DSR
Work mode It’s jointly determined by software and hardware, 3IN1
products RS232 and RS485/RS422 optional, RS485/RS422
and RS232 can be automatically identified by the hardware.
FIFOEnable Enable or disable the FIFO function, if the serial device does
not support data transceiver cache FIFO, FIFO function can
be disabled to avoid data transmission errors.
RTSCtrl RTS pin can be controlled, the options are:
AUTO
Force ON

Force OFF
DTRCtrl DTR pin can be controlled, the options are:
AUTO
Force ON
Force OFF
Pack Length Serial data to Ethernet data frame length, in the set time
range, the data is greater than or equal to set the frame
length will be forwarded, the value range of 0 ~ 1460. When
the frame length is 0, it indicates that the data transmission
length is not limited.
Note:
Actual pack length exists a small amount of deviation to the

User Manual
3onedata proprietary and confidential 13
Copyright © 3onedata Co., Ltd.
Interface Elements Description
setting value.
Delimiter If the packet length or forced transmission time is 0 and the
number of delimited characters is greater than 0, the system
will receive the serial data and perform delimiter detection.
Whenever a matching delimited character (or combination
of characters) is received, the system immediately sends all
the cached data to the serial port over the network.
Character Handing Select the character handling method. The options are:
Retain: The system sends the received delimited
characters along with other data over the network.
Delete: The matching delimited character (or character
combination) will be deleted and the system will only
transfer data other than delimiters.
Transmit time If the forced transmission time is greater than 0, the system
sends the serial data received within the specified time
through a packet, in the range of 0 to 65535 ms. When the
transfer time is 0, it means
that the data transmission
interval is not restricted.
Apply to all Port Check the “Apply to all port” check box to apply the current
settings to all serial ports.
"Work mode" and model corresponds to RS232, RS485 and RS422 option.
If there is no matching characters, the data will be sent when the serial data cache is
full of 1460 bytes.
4.2 Checking COM Information
Function Description
On the "COM Information" page, you can view parameter information such as serial
number, alias, baud rate, data bit, stop bit, parity bit and flow control.
Operation Path
Open "Serial server> COM Information" in sequence.
