3Q MG-F910 User manual

Model Number: MG-F910
3Q lnternational, Inc.
6910 Salashan Parkway, Suite B6
Ferndale,WA 98248
United States
Tel: [phone]
Fax: [phone]
http://www.3QInternational.com
Instruction Manual
with waist air compression massage and infrared heat
Luxury Foot and Calf Massager

Contents:
♦Air pressure/scrap/shiatsu/heat massages, full massage functions
♦3-level air pressure massage makes you more relaxed
♦8 pcs of massage knobs in different shape and height rolling and
cover reflexology points on the sole of feet.
♦4 pcs of knobs massage the sides of ankles.
♦8pcs of air bags for soles, ankles and insteps hold the feet firmly
for an enhanced massage experience.
♦Detachable air pressure massage bag for calf, waist and belly
♦Feet scrap and infrared heating function
♦Factory default automatic massage programs included
♦Automatic shut off after 15 minutes
.
Features of the product
Power button: turn on/off the massager
“P” button: factory default automatic massage program
Kneading massage button: When the appliance is in manual mode
press this button to toggle the kneading function. This function
cannot be used when in "P" factory default mode.
Air pressure massage button: Switch between the three levels
of air massage intensity
Heating button: turn on/off heating function
Product features 2
Item description and accessories 3
Control panel – functions 3
Operating instruction 3
Product maintenance and warnings 4
Trouble shooting 6
Specifications 6
Thank you for choosing MG-F910 Luxury Foot and
Calf Massager with waist air compression and infrared
heat massageBefore using this appliance, please read
this manual carefully. Always keep this user manual for
later use.
21
7
One year limited warranty
Luxury Foot and Calf Massager
Control panel - functions
Item description and accessory
with waist air compression and infrared heat massage
Figure 1
Figure 2

Plug in the output jack of the adapter into the power cord jack of
the foot massager on the side of the unit, and then plug in the
adapter into an AC power socket. The buzzer will make a beep
sound and the LED power indicator will start flashing. The foot
massager is now ready for operation.
If you are using the air bag massager for calf and waist, please
plug the input jack of the air bag massager into the output socket
of the foot massager. Then wrap the air bag massager on both
left and right calves, or waist. (As shown in Figure 3)
Operating instructions
1. Turn on the massager by pressing the power button.
The "P" button will start the massager in the factory
default mode (kneading/heating functions are active
and air massage intensity is at the lowest level).
Each time you press a button the buzzer will beep once.
2. In “P” mode: press the air pressure button to choose the next
level of pressure intensity (if the button color is green,
it means first level, if it is yellow, it means second level,
and if it is red, it means third level.) At the same time by pushing
the air pressure button, the buzzer gives as many beeps
3. In manual working mode, press the air pressure button to choose
the next level of pressure intensity (if the button color is green,
it means first level, if it is yellow, it means second level, and if it is
red, it means third level.) Press kneading massage button to
turn the kneading function on and off.
4. Press “heating” button to turn on/off heating function.
5. The massager's auto turn off feature will automatically shut down
the massager after fifteen minutes have passed.
To keep the massager in optimal condition, please follow the correct
usage and pay attention to the following points:
1.Please do not massage area's of the foot where there is trauma or
ulceration.
2.To prevent damage of the massager unit do not apply excessive
force to the top of the unit.
3.People unaccustomed to the massager should avoid prolonged
periods of use until they are more familiar with it.
4.Duration of a single use should not exceed 30 minutes.
5.During operation, if any abnormal event occurs, such as overheating
or strange odors being released, please stop using the unit immediately
and turn off the massager.
6.After each use, please switch off the power by pressing “Power”
button on the control panel first, and then disconnecting the power plug
from AC outlet. To prevent damage disconnect the massager by pulling
on the plug and not the power cord.
7.Please always unplug the adapter from the AC power jacket before
cleaning the product.
8.Please use wet and soft cotton sheet and neutral detergent to clean
the massager.
9.Please don't drag or pull the power cord of the massager.
10.Please don't use the massager in water or in a humid environment.
If the massager falls in water accidentally, please unplug the power
plug from the socket immediately, before taking it out from the water.
11.To prevent overheating please don't cover the product with a
pillow or blanket, when you are using it.
12.Please do not use anything to cover the massager, when using it,
because it can cause malfunction or damage.
13.Please don't use the massager near stoves or any other heat sources.
14.Only use original accessories or parts from the manufacturer of
this massager.
15.Avoid detaching or dismantling of the massager for self repair.
Doing so can be dangerous and will void the guarantee and warranty
for the after sales service.
16.For your personal safety and the proper operation of this massager,
please do not open the zipper. We will be not responsible for any
consequences caused by such interaction.
17.If you are receiving medical treatment or you are having any of the
following diagnoses below, please consult your physician and use the
appliance in accordance with your doctor's orders.
Product maintenance and warnings
43
1
2 3
45
Figure 3

●In case of any health related question, please consult your
physician before start using the device.
●Do not let children use the device, and do not switch on the massage
function, when somebody is asleep or unconscious! In cases of
myocardial infarction, somnolence, incapacitated by illness or
problems of sensitivity on the skin or from movement, do not use
the device.
●Do not use the device: if the skin is swollen,sore or injured, if you
have a skin rash, on sensitive areas of your body (eyes, face, etc.)
or if you are injured.
●This device is to use only by healthy adults.
People with any of the diagnoses listed below should consult a
physician before using the product:
●Pregnancy
●Patients with pacemaker
●Phlebitis
●Thrombosis (Deep Vein Thrombosis)
●Severe heart disease
●Tumor malignant
●Problems with the spine, scoliosis, lordosis
●Osteoporosis or other bone diseases
●Ovarian or similar illnesses or discomfort
●If you feel discomfort during the massage, immediately discontinue
using it and consult your physician.This is a product for domestic use
only; it was not designed for professional use of therapeutic purposes.
Specification
Product Name:
Luxury Foot and Calf Massager with waist air
compression massage and infrared heat
Model No.: MG-F910
Operating Voltage: DC 12 V 3 A
Power: 30 W
Phenomenon Possible cause How to deal with it
Does not work? 1. The power supply is not
connected
2. Power plug has poor
contact
3. “Power” button has not
been pressed
1.Connect power supply
2.Check the plug
3.Press “power” button
Stop working? 1. Massager is powered
off.
2. Massager has
automatically turned off
after 15 minutes.
1.Check whether the
power supply interface is
connected properly
2. Press the power button
to turn on the machine
again.
Important
65
Trouble shooting
1、This appliance does not intend to provide to the people who are physical
disability,sensory or nerve defect or lack of experience and common sense
to use,unless they got the supervision and guildance about how to use this
equipment from the people who take responsibility to their safety.
2. Children must be supervised to ensure that they will not take instruments to play .

The massager comes with one-year factory limited warranty.
We warrant that for a period of one year from the date of
purchase, this product will be free from defects in material and
workmanship. We will repair or replace this product or any
component of the product found to be defective during the
warranty period. Replacement will be made with a new or
remanufactured product or component. This is your exclusive
warranty.
●This warranty is valid for the original retail purchase from the
date of initial retail purchase and it’s not transferable. Keep
the original sales receipt. Proof of purchase is required to
obtain warranty performance. 3Q dealers, service centers,
or retail stores selling 3Q products do not have the right to
alter, modify or any way change the terms and conditions
of this warranty.
●This warranty does not cover normal wear-and-tear on upholstery
or damaged resulting from any of following: negligent use or
misuse of the product, use on improper voltage or current, use
contrary to the operating instructions, disassembly, repair or
alteration by anyone other than 3Q or an authorized 3Q service
center.
●Further, the warranty does not cover: Acts of God, such as fire,
flood, hurricanes and tornadoes.
●For purchasing thru internet, buyer is responsible for both-way
shipping costs (returning and resending).
●How to Obtain Warranty Service
● If you have any questions regarding this warranty or would like to
obtain warranty service, please contact our Service Department or
authorized 3Q dealers.
●
One year limited warranty
87
Heat insensitive users should pay attention to the
surface of the application.
