4EVAC IMPACT User manual

Hacousto Holland bv
Industrieweg 87
2651BC Berkel & Rodenrijs
4E-IMPACT reference manual
Author:
DD
Page 1of 8
SUMMARY
This document describes specifications, functions, configuration settings and interfaces of the 4EVAC
IMPACT Voice Evacuation System.
REVISION AND APPROVAL
Rev.
Date
Nature of Changes
Approved By
01
05-07-2018
Original draft
DD
02
11-06-2020
Corrections
TvdH

Hacousto Holland bv
Industrieweg 87
2651BC Berkel & Rodenrijs
4E-IMPACT reference manual
Author:
DD
Page 2of 8
Table of Contents
1. What is the 4E-FSC? ............................................................................................................................................................... 3
2. Installation................................................................................................................. Fout! Bladwijzer niet gedefinieerd.
3. Connection diagram............................................................................................................................................................... 4
4. Network cabling....................................................................................................................................................................... 4
5. Technical specifications......................................................................................................................................................... 6

Hacousto Holland bv
Industrieweg 87
2651BC Berkel & Rodenrijs
4E-IMPACT reference manual
Author:
DD
Page 3of 8
1. What is IMPACT?
4EVAC IMPACT is a scalable, networkable Voice
Evacuation System suitable for installations which
require centralized power amplification of large
capacity.
It is dedicated to centralized installations, yet fully
capable of distributed operation.
4E-FSC is a DIN-rail mounted, optical multimode fiber signal adapter dedicated for the 4EVAC Voice
Evacuation Systems. 4E-FSC is dedicated only to the G-Net (Global Network) of the 4EVAC system,
interconnecting main units of the system. It extends single link range up to 2 km.
The fiber adapter is powered directly over the G-Net port.
4E-FSC features a standard SC connector for the fiber cable, providing easy click-in connection.
2. System components
Core components
2.1.1. CONTROLLER
2.1.2. DCA2.500 charging amplifier
2.1.3. 4E-SW6 zone switching module
Peripherals
IMPACT is fully compatible with all L-Net devices as well as the Compact 500 system.
Impact and Compact systems both can work in one network, sharing the same configuration data.

Hacousto Holland bv
Industrieweg 87
2651BC Berkel & Rodenrijs
4E-IMPACT reference manual
Author:
DD
Page 4of 8
3. Connection diagram
4. Network cabling
The 4EVAC network features a full duplex RS-422 data link and 24V DC power to remote devices.
If you’re building a distributed system using the 4EVAC network, you should make physical links between
devices using the right cables. The cabling should meet the following requirements:
1. Crossover twisted-pair cable (compatible with Ethernet crossover)
2. CAT5e or higher for maximum distance of 250m.
3. Non-CAT / lower than CAT5e: 250m not guaranteed.
pin number pin number
GND shield shield GND
RX+ 1 1 RX+
RX- 2 2 RX-
TX+ 3 3 TX+
power + 4 4 power +
power - 5 5 power -
TX- 6 6 TX-
power + 7 7 power +
power - 8 8 power -
pin number pin number
GND shield shield GND
RX+ 1 1 RX+
RX- 2 2 RX-
TX+ 3 3 TX+
power + 4 4 power +
power - 5 5 power -
TX- 6 6 TX-
power + 7 7 power +
power - 8 8 power -
xover type A cable
xover type B cable

Hacousto Holland bv
Industrieweg 87
2651BC Berkel & Rodenrijs
4E-IMPACT reference manual
Author:
DD
Page 5of 8
4. Shield required (at least FTP)
NOTE: If you use a straight cable, the device will power up but the Tx/Rx data terminals will not be properly
connected. This will result in a communication fault.
Caution! Use only crossover cables and keep the correct pinout! Connecting power pins to data pins will
damage the network port.

Hacousto Holland bv
Industrieweg 87
2651BC Berkel & Rodenrijs
4E-IMPACT reference manual
Author:
DD
Page 6of 8
5. Technical specifications
CONTROLLER
Maximum number of zones
Standalone
96 (16 x 4E-SW6)
Network
255 (max. system capacity)
Inputs
Outputs
Network interface
Maximum range (optical)
2000 m
Optical interface
Wavelength
820 nm
Compatible fiber type
multimode Plastic-Clad Silica (PCS):
50/125 μm
62.5/125 μm (recommended)
100/140 μm
200 μm
Connector
SC
Cable type
Double fiber (full duplex)
Transceiver details
Avago (Broadcom) Tx: HFBR-14E4Z Rx: HFBR-24E2Z
manufacturer’s datasheet: docs.broadcom.com/docs/AV02-0176EN
Mechanical
Dimensions HxWxD)
9 x 3.6 x 6.2 cm
Weight
70 g
Housing material
ABS
IP rating
IP 30
Mounting
DIN rail
Operating conditions
Temperature
10–40°C
Relative humidity
max. 90% (non condensing)
Storage temperature
-40–70°C
DCA 2.500
General
20 mA
Power consumption
Inrush current
Audio
Frequency response
SNR

Hacousto Holland bv
Industrieweg 87
2651BC Berkel & Rodenrijs
4E-IMPACT reference manual
Author:
DD
Page 7of 8
Inputs
Outputs
Charger
Type
Autonomous EN54-4 compliant charger with thermal correction
Parallel operation
Max. 3 x DCA2.500 (1 x master + 2 x slave)
Max. charging current
Battery type
24V (2x12V) maintenance-free, lead-acid, sealed, for stationary buffer operation.
Max. battery capacity
Float voltage (full capacity)
Mechanical
Dimensions HxWxD)
9 x 3.6 x 6.2 cm
Weight
Housing material
Steel
IP rating
IP 30
Mounting
19” rack frame
Operating conditions
Temperature
10–40°C
Relative humidity
max. 90% (non condensing)
Storage temperature
-40–70°C

Hacousto Holland bv
Industrieweg 87
2651BC Berkel & Rodenrijs
4E-IMPACT reference manual
Author:
DD
Page 8of 8
MADE IN THE NETHERLANDS
