Aaeon GENE-CV05 User manual

SubCompact Board GENE-CV05
GENE-CV05
Intel
®AtomTM D2550/N2800/N2600
Processor
With LVDS
10/100/1000Base-TXEthernet
1 Mini Card, LPC
6USB2.0,6COM
2CH HD Audio + 2W Amplifier
GENE-CV05 Manual Rev. A 7th Ed.
January 16th, 2014

SubCompact Board
G E N E - C V 0 5
i
Copyright Notice
This document is copyrighted, 2014. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

SubCompact Board
G E N E - C V 0 5
ii
Acknowledgments
All other products’name or trademarks are properties of their
respective owners.
AMI is a trademark of American Megatrends Inc.
CFast™is a trademark of the Compact Flash Association.
Intel®, Atom™are trademarks of Intel®Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
SoundBlaster is a trademark of Creative Labs, Inc.
Please be notified that all other products’name or trademarks not be
mentioned above are properties of their respective owners.

SubCompact Board
G E N E - C V 0 5
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
GENE-CV05 CPU Card with Active Cooler (Intel®
Atom™D2550 version) or Passive Heatsink (Intel®
Atom™N2800/N2600 version)
DVD-ROM for manual (in PDF format) and drivers
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.

SubCompact Board
G E N E - C V 0 5
iv
Contents
Chapter 1 General Information
1.1 Introduction................................................................ 1-2
1.2 Features .................................................................... 1-3
1.3 Specifications ............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions....................................................2-2
2.2 Location of Connectors and Jumpers .......................2-3
2.3 Mechanical Drawing..................................................2-5
2.4 List of Jumpers.......................................................... 2-7
2.5 List of Connectors .....................................................2-8
2.6 Setting Jumpers ........................................................ 2-10
2.7 Auto Power Button Selection (JP1)...........................2-11
2.8 Clear CMOS (JP2) ....................................................2-11
2.9 COM2 RI/+5V/+12V Selection (JP3).........................2-11
2.10 Touch Screen 4/5/8-wire Mode Selection (JP4) .....2-11
2.11 Brightness Control for 2nd LVDS (JP5) .................. 2-11
2.12 2nd LVDS Backlight Bias/PWM Mode Selection (JP6)
......................................................................................... 2-12
2.13 2nd LVDS Operating Voltage Selection (JP7) ........ 2-12
2.14 2nd LVDS Inverter Voltage Selection (JP8)............2-12
2.15 1st LVDS Inverter Voltage Selection (JP9).............2-12
2.16 1st LVDS Backlight Bias/PWM Mode Selection (JP10)
......................................................................................... 2-12

SubCompact Board
G E N E - C V 0 5
v
2.17 1st LVDS Operating Voltage Selection (JP11) ....... 2-13
2.18 Front Panel (CN1) ...................................................2-13
2.19 External +5VSB Input (CN2)...................................2-13
2.20 CPU Fan Connector (CN3) ..................................... 2-13
2.21 +5VSB Output w/SMBUS (CN4).............................2-14
2.22 SATA Port (CN5).....................................................2-14
2.23 External 12V Input (CN6)........................................2-14
2.24 Digital I/O Connector (CN7) ....................................2-15
2.25 Parallel Port Connector (CN8) (Optional)................ 2-15
2.26 +5V Output for SATA HDD Usage (CN9) ............... 2-16
2.27 USB Port #6 (CN10)................................................2-16
2.28 COM Port #6 (CN11)...............................................2-16
2.29 USB Port #5 (CN12)................................................2-17
2.30 COM Port #5 (CN13)...............................................2-17
2.31 USB Port #4 (CN14)................................................2-17
2.32 USB Port #3 (CN15)................................................2-18
2.33 COM Port #4 (CN16)...............................................2-18
2.34 LPC Expansion I/F (CN17)......................................2-18
2.35 COM Port #3 (CN18)...............................................2-19
2.36 COM Port #2 (CN19)............................................... 2-19
2.37 Touch Screen (CN20) ............................................. 2-20
2.38 Stereo-R Channel (CN21).......................................2-20
2.39 2nd LVDS Output Dual Channel 18/24-bit (CN22) . 2-20
2.40 PS/2 Keyboard and Mouse Connector (CN23).......2-21
2.41 2nd LVDS Inverter (CN24)......................................2-21

SubCompact Board
G E N E - C V 0 5
vi
2.42 Stereo-L Channel (CN25) .......................................2-22
2.43 1st LVDS Inverter (CN26) ....................................... 2-22
2.44 1st LVDS Output-Single Channel 18/24-bit (CN27) 2-22
2.45 2nd RJ-45 Ethernet Connector (CN28)...................2-23
2.46 1st RJ-45 Ethernet Connector (CN29)....................2-23
2.47 USB Port #1 and #2 (CN30).................................... 2-23
2.48 Audio Line In/Out and MIC (CN31).........................2-24
2.49 DVI/CRT Display Connector (CN32) Configured by
manufacturing.................................................................. 2-24
2.50 COM Port #1 (CN33)............................................... 2-25
2.51 SIM Card Socket (CN34) ........................................ 2-26
2.52 CFast™ Disk (CFD1) ..............................................2-26
2.53 Mini Card/ mSATA (PCIE1)..................................... 2-27
2.54 DDR3 SODIMM Slot (DIMM 1) ...............................2-28
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization. .................................. 3-2
3.2 AMI BIOS Setup........................................................3-3
Chapter 4 Driver Installation
4.1 Installation .................................................................4-3
Appendix A Programming The Watchdog Timer
A.1 Programming .........................................................A-2
A.2 ITE8783 Watchdog Timer Initial Program..............A-6

SubCompact Board
G E N E - C V 0 5
vii
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 1st MB Memory Address Map ................................B-4
B.3 IRQ Mapping Chart................................................B-5
B.4 DMA Channel Assignments...................................B-6
Appendix C Mating Connector
C.1 List of Mating Connectors and Cables.................. C-2
Appendix D AHCI Setting
D.1 Setting AHCI......................................................... D-2
Appendix E Digital I/O
E.1 Digital I/O ...............................................................E-2

SubCompact Board GENE-CV05
Chapter 1 General Information 1- 1
General
Chapter
1
Information

SubCompact Board GENE-CV05
1.1 Introduction
AAEON, a leading embedded boards manufacturer, is pleased to
announce the debut of their new generation 3.5” SubCompact
Board —GENE-CV05.
GENE-CV05 adopts Intel® AtomTM D2550/N2800/N2600
Processor. The system memory is deployed with 204-pin
SODIMM DDR3 800/1066 up to 4 GB for Intel® AtomTM D2550
/N2800 processor and up to 2 GB for Intel® AtomTM N2600
Processor. In addition, Realtek RTL8111E supports two
10/100/1000Base-TX that allows a faster network connections.
The display of GENE-CV05 supports CRT/LCD, DVI/LCD
simultaneous and dual view displays. This model applies one Mini
Card and LPC bus for flexible expansions. Moreover, one SATA
3.0Gb/s and one CFastTM provide a better storage. Six USB2.0,
six COM Ports (five RS-232, one RS-232/422/485) and 8-bit digital
I/O are configured on the GENE-CV05 as well. Full functions make
GENE-CV05 user friendly. This brand new SubCompact board is
developed to cater to the requirements of Automation, Medical,
ticket machine, transportation, gaming, KIOSK, and POS/POI
applications.
Chapter 1 General Information 1- 2

SubCompact Board GENE-CV05
1.2 Features
Onboard Intel®Atom™ D2550/N2800/N2600 Processor
Intel®NM10
DDR3 800/1066 SODIMM , Max. 4 GB for Intel®Atom™
D2550/N2800 Processor, and Max. 2 GB for Intel®Atom™
N2600 Processor
Gigabit Ethernet x 2
CRT, 24-bit Single Channel LVDS LCD +18/24-bit Dual
Channel LVDS LCD for Intel®Atom™ D2550 Processor;
18-bit Single Channel LVDS LCD+ 18/24-bit Dual Channel
LVDS LCD for Intel®Atom™ N2800/N2600 Processor
2CH HD Audio + 2W Amplifier
SATA 3.0Gb/s x 1, CFast™ x 1
USB2.0 x 6, COM x 6 , 8-bit Digital I/O, Parallel x 1
(Optional)
Onboard 4/5/8-wire Resistive Touch Screen Controller
Mini Card x 1
+12V Only Operation
Onboard Trusted Platform Module (Optional)
mSATA x 1 (Optional, if you choose mSATA, the functions
of Mini Card & CFAST™ will be disabled.)
Chapter 1 General Information 1 - 3

SubCompact Board GENE-CV05
1.3 Specifications
System
Processor Intel®Atom™
D2550/N2800/N2600 Processor
System Memory 204-pin DDR3 SODIMM x 1,
Max. 4 GB (DDR3 800/1066) for
Intel®Atom™D2550/N2800;
Max. 2 GB (DDR3 800/1066) for
Intel®Atom™N2600
Chipset Intel
®NM10
I/O Chipset ITE 8783
Ethernet Realtek RTL8111E,
10/100/1000Base-TX, RJ-45 x 2
BIOS AMI BIOS SPI type, 4MB ROM
Wake On LAN Yes
Watchdog Timer Generates a time-out system
reset
H/W Status Monitoring Supports power supply
voltages and temperature
monitoring
Expansion Interface Mini Card x 1, LPC bus
Power Requirement +12V, AT/ATX
Trusted Platform Infineon SLB 9635 TT 1.2
Module (TPM) (Optional)
Chapter 1 General Information 1- 4

SubCompact Board GENE-CV05
Battery Lithium battery
Board Size 5.75”(L) x 4”(W) (146mm x
101.6mm)
Gross Weight 0.88 lb (0.4 Kg)
Operating Temperature 32˚F~140˚F (0˚C ~ 60˚C)
WiTAS2: -40°F~185°F (-40°C ~
85°C) (GENE-CV05W2-A10-13)
Storage Temperature -40˚F~ 176˚F (-40˚C ~ 80˚C)
Operating Humidity 0%~90% relative humidity,
non-condensing
Display: Supports CRT/LCD, DVI/LCD, simultaneous and dual
view displays
Chipset Intel®Atom™D2550/ N2800/
N2600 integrated
Memory Shared system memory up to
256 MB
LCD Interface LCD Interface Dual LVDS
LCDs: 24-bit Single Channel
LVDS LCD + 18/24-bit Dual
channel LVDS LCD for Intel®
Atom™D2550; 18-bit Single
Channel LVDS LCD + 18/24-bit
Dual Channel LVDS LCD for
Intel®Atom™N2800/N2600
Chapter 1 General Information 1 - 5

SubCompact Board GENE-CV05
Resolution Up to 1920 x 1200 for CRT;
Up to 1366 x 768 for LCD;
Up to 1920 x 1200 for LCD
(TF-GENE-CV05-A10-14 Only)
I/O
Storage SATA 3.0Gb/s x 1, CFast™ x 1
Serial Port RS-232 x 5, RS-232/422/485
(auto flow) x 1 (the baud rate of
the serial port should be 9600
during high temperature
operation)
Parallel Port SPP/EPP/ECP x 1 (Optional)
USB Port USB2.0 x 6
PS/2 Port Keyboard x 1, Mouse x 1
Digital I/O Supports 8-bit (Programmable)
Audio MIC-in, Line-in, Line-out
Touch Screen Supports 4/5/8-wire resistive
touch screen
Note: (1) If you choose Parallel Port, the COM6 will be removed
from the GENE-CV05.
(2) Dose not support RC-D (2Rx16 dual die), and
RC-E(2Rx16) DDR3 SODIMM momery.
(3) Max memory size by sku: N2600 series 2GB; N2800,
Chapter 1 General Information 1- 6

SubCompact Board GENE-CV05
Chapter 1 General Information 1 - 7
D2550 series 4GB.

SubCompact Board GENE-CV05
Chapter2QuickInstallationGuide2-1
Quick
Installation
Chapter
2
Guide

SubCompact Board GENE-CV05
Chapter 2 Quick Installation Guide 2-2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

SubCompact Board GENE-CV05
Chapter2QuickInstallationGuide2-3
2.2 Location of Connectors and Jumpers
Component Side

SubCompact Board GENE-CV05
Chapter 2 Quick Installation Guide 2-4
Solder Side

SubCompact Board GENE-CV05
Chapter2QuickInstallationGuide2-5
2.3 Mechanical Drawing
Component Side
