Aaeon PCM-QM77 User manual

Last Updated: March 16, 2016
PCM-QM77
Compact Board
User‟s Manual 3rd Ed

Preface II
Compact Board PCM-QM77
Copyright Notice
This document is copyrighted, 2016. All rights are reserved. The original manufacturer
reserves the right to make improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any
form or by any means without the prior written permission of the original manufacturer.
Information provided in this manual is intended to be accurate and reliable. However,
the original manufacturer assumes no responsibility for its use, or for any infringements
upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design without notice to its
users.

Preface III
Compact Board PCM-QM77
Acknowledgement
All other products‟ name or trademarks are properties of their respective owners.
Microsoft Windows is a registered trademark of Microsoft Corp.
Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel Corporation
Core, Atom are trademarks of Intel Corporation
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines
Corporation.
All other product names or trademarks are properties of their respective owners.

Preface IV
Compact Board PCM-QM77
Packing List
Before setting up your product, please make sure the following items have been
shipped:
Item
Quantity
PCM-QM77
1
17592QM772 Cooler
1
1702150155 SATA cable
1
1709070500 SATA Power cable
1
9657666600 Jumper Cap
1
Product DVD with User‟s Manual (in pdf) and drivers
1
If any of these items are missing or damaged, please contact your distributor or sales
representative immediately.

Preface V
Compact Board PCM-QM77
About this Document
This User‟s Manual contains all the essential information, such as detailed descriptions
and explanations on the product‟s hardware and software features (if any), its
specifications, dimensions, jumper/connector settings/definitions, and driver installation
instructions (if any), to facilitate users in setting up their product.
Users may refer to the AAEON.com for the latest version of this document.

Preface VI
Compact Board PCM-QM77
Safety Precautions
Please read the following safety instructions carefully. It is advised that you keep this
manual for future references
1. All cautions and warnings on the device should be noted.
2. Make sure the power source matches the power rating of the device.
3. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
4. Always completely disconnect the power before working on the system‟s
hardware.
5. No connections should be made when the system is powered as a sudden rush
of power may damage sensitive electronic components.
6. If the device is not to be used for a long time, disconnect it from the power
supply to avoid damage by transient over-voltage.
7. Always disconnect this device from any AC supply before cleaning.
8. While cleaning, use a damp cloth instead of liquid or spray detergents.
9. Make sure the device is installed near a power outlet and is easily accessible.
10. Keep this device away from humidity.
11. Place the device on a solid surface during installation to prevent falls
12. Do not cover the openings on the device to ensure optimal heat dissipation.
13. Watch out for high temperatures when the system is running.
14. Do not touch the heat sink or heat spreader when the system is running
15. Never pour any liquid into the openings. This could cause fire or electric shock.
16. As most electronic components are sensitive to static electrical charge, be sure to
ground yourself to prevent static charge when installing the internal components.
Use a grounding wrist strap and contain all electronic components in any
static-shielded containers.

Preface VII
Compact Board PCM-QM77
17. If any of the following situations arises, please the contact our service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described in
this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
18. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED ENVIRONMENT WITH
TEMPERATURES BEYOND THE DEVICE‟S PERMITTED STORAGE TEMPERATURES
(SEE CHAPTER 1) TO PREVENT DAMAGE.

Preface VIII
Compact Board PCM-QM77
FCC Statement
This device complies with Part 15 FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received including interference that may cause
undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer‟s instructions and your local government‟s
recycling or disposal directives.
Attention:
Il y a un risque d‟explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu‟avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et
les directives gouvernementales de recyclage.

Preface IX
Compact Board PCM-QM77
China RoHS Requirements (CN)
产品中有毒有害物质或元素名称及含量
AAEON Main Board/ Daughter Board/ Backplane
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
○
○
○
○
○
○
外部信号
连接器及线材
○
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：此产品所标示之环保使用期限，系指在一般正常使用状况下。

Preface X
Compact Board PCM-QM77
China RoHS Requirement (EN)
Poisonous or Hazardous Substances or Elements in Products
AAEON Main Board/ Daughter Board/ Backplane
Component
Poisonous or Hazardous Substances or Elements
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr(VI))
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
PCB & Other
Components
O
O
O
O
O
○
Wires &
Connectors
for External
Connections
O
O
O
O
O
O
O：The quantity of poisonous or hazardous substances or elements found in each of the
component's parts is below the SJ/T 11363-2006-stipulated requirement.
X: The quantity of poisonous or hazardous substances or elements found in at least one of the
component's parts is beyond the SJ/T 11363-2006-stipulated requirement.
Note: The Environment Friendly Use Period as labeled on this product is applicable under normal
usage only

Preface XI
Compact Board PCM-QM77
Table of Contents
Chapter 1 - Product Specifications........................................................................................ 1
1.1 Specifications............................................................................................................ 2
Chapter 2 –Hardware Information ....................................................................................... 5
2.1 Dimensions ............................................................................................................... 6
2.2 Jumpers and Connectors....................................................................................... 8
2.3 List of Jumpers .......................................................................................................10
2.3.1 LVDS Port 2 Operating VDD Selection (JP1)..................................11
2.3.2 LVDS Port 2 Backlight Inverter VCC Selection (JP1)......................11
2.3.3 LVDS Port 1 Backlight Lightness Control Mode Selection (JP2).11
2.3.4 LVDS Port 2 Backlight Lightness Control Mode Selection (JP3).11
2.3.5 LVDS Port 1 Operating VDD Selection (JP4)..................................12
2.3.6 LVDS Port 1 Backlight Inverter VCC Selection (JP4)......................12
2.3.7 COM6 Pin9 Function Selection (JP5) ...............................................12
2.3.8 COM2 Pin9 Function Selection (JP6) ...............................................12
2.3.9 AT/ATX Power Supply Mode Selection (JP8) ..................................13
2.3.10 Front Panel Connector (JP9)..............................................................13
2.3.10 Clear ME Jumper (JP10)......................................................................14
2.3.11 Clear CMOS Jumper (JP10) ...............................................................14
2.3.12 Touch Screen 4/5-Wire Mode Selection (JP11) (Optional)..........14
2.4 List of Connectors..................................................................................................15
2.4.1 DVI Connector (CN1)..........................................................................17
2.4.2 Stereo Audio Output Connector (CN2) ..........................................18
2.4.3 Ethernet#2 Connector (CN3) (Optional).........................................18
2.4.4 Ethernet#1 Connector (CN4) (Optional).........................................19
2.4.5 RJ-45 Ethernet#2 Connector (CN5).................................................20
2.4.6 RJ-45 Ethernet#1 Connector (CN6).................................................20

Preface XII
Compact Board PCM-QM77
2.4.7 ATX Power Connector (CN7).............................................................21
2.4.8 LVDS Port 2 Inverter / Backlight Connector (CN8).......................22
2.4.9 LVDS Port 1 Inverter / Backlight Connector (CN9).......................22
2.4.10 Audio In/Out/CD-in and MIC Connector (CN10).........................23
2.4.11 D-SUB CRT Connector (CN11) (Optional)......................................23
2.4.12 CRT Connector (CN12).......................................................................24
2.4.13 mSATA Slot (CN13) ..............................................................................25
2.4.14 Ethernet#1 LED Indicator (CN14).....................................................27
2.4.15 COM Port 2 (CN15).............................................................................28
2.4.16 COM Port 1 (CN16).............................................................................30
2.4.17 Ethernet#2 LED Indicator (CN17).....................................................30
2.4.18 LVDS Port 2 (CN18).............................................................................31
2.4.19 COM Port 4 (CN19).............................................................................32
2.4.20 COM Port 3 (CN20).............................................................................33
2.4.21 LVDS Port 1 (CN21).............................................................................34
2.4.22 LPC Port (CN22)...................................................................................35
2.4.23 COM Port 6 (CN23).............................................................................36
2.4.24 COM Port 5 (CN24).............................................................................38
2.4.25 PCI Slot (CN25).....................................................................................38
2.4.26 COM Port 8 (CN26).............................................................................39
2.4.27 COM Port 7 (CN27).............................................................................39
2.4.28 PCIe [x16] Slot (CN28) ........................................................................40
2.4.29 DDR3 SO-DIMM Channel B Slot (CN29) ........................................40
2.4.30 DDR3 SO-DIMM Channel A Slot (CN30)........................................40
2.4.31 COM Port 10 (CN31)...........................................................................40
2.4.32 COM Port 9 (CN32).............................................................................41
2.4.33 USB 3.0 Ports 1 and 2 (CN34)...........................................................42
2.4.34 USB 3.0 Ports 3 and 4 (CN35)...........................................................43

Preface XIII
Compact Board PCM-QM77
2.4.35 USB 2.0 Ports 5 and 6 (CN36)...........................................................44
2.4.36 USB 2.0 Ports 7 and 8 (CN37)...........................................................44
2.4.37 PS/2 Keyboard/Mouse Combo Port (CN38)..................................45
2.4.38 IrDA Connector (CN39) (Optional)...................................................45
2.4.39 SATA Port 2 Connector (CN40).........................................................46
2.4.40 SATA Port 1 Connector (CN41).........................................................46
2.4.41 +5V Output for SATA HDD (CN43)..................................................47
2.4.42 LPT Connector (CN44)........................................................................47
2.4.43 System Fan Connector (CN45)..........................................................49
2.4.44 Digital IO Port 1 Connector (CN46).................................................49
2.4.45 Digital IO Port 2 Connector (CN47).................................................50
2.4.46 Touch Screen Connector (CN48) (Optional) ..................................50
2.4.47 CPU FAN Connector (CN49)..............................................................52
2.4.48 UIM Card Connector (CN50).............................................................52
2.4.49 MiniCard Slot (CN51) ..........................................................................52
2.4.50 CFast Slot (CN52).................................................................................55
Chapter 3 - BIOS Setup ........................................................................................................ 56
3.1 System Test and Initialization ..............................................................................57
3.2 AMI BIOS Setup .....................................................................................................58
3.3 Setup submenu: Main ..........................................................................................59
3.4 Setup submenu: Advanced .................................................................................60
3.4.1 Advanced: ACPI Management..........................................................62
3.4.2 Advanced: RTC Wake Settings ..........................................................63
3.4.3 Advanced: Trusted Computing .........................................................65
3.4.4 Advanced: CPU Configuration..........................................................66
3.4.5 Advanced: Dynamic Digital IO Configuration................................67
3.4.6 Advanced: SATA Configuration.........................................................68
3.4.7 Advanced: Intel TXT (LT) Configuration ..........................................70

Preface XIV
Compact Board PCM-QM77
3.4.8 Advanced: AMT Configuration .........................................................71
3.4.9 Advanced: USB Configuration ..........................................................72
3.4.10 Advanced: F81216 Second Super IO Configuration ....................74
3.4.11 Advanced: Super IO Configuration..................................................75
3.4.11.1 Super IO Configuration: Serial Port X Configuration .....76
3.4.12 Advanced: Parallel Port Configuration ............................................78
3.4.13 Advanced: F81866 H/W Monitor .....................................................80
3.4.14 Advanced: Smart Fan Configuration ...............................................81
3.4.15 Advanced: CPU PPM Configuration ................................................83
3.5 Setup submenu: Chipset......................................................................................84
3.5.1 Chipset: PCH-IO Configuration ........................................................85
3.5.2 Chipset: System Agent (SA) Configuration.....................................87
3.5.2.1 System Agent (SA) Configuration: Graphics Configuration
88
3.5.2.2 Graphics Configuration: LCD Control..................................90
3.6 Setup submenu: Boot...........................................................................................93
3.6.1 Boot: BBS Priorities ..............................................................................94
3.7 Setup submenu: Security .....................................................................................95
3.8 Setup submenu: Save & Exit ...............................................................................97
Chapter 4 –Drivers Installation............................................................................................ 98
4.1 Product CD/DVD ...................................................................................................99
Appendix A - Watchdog Timer Programming................................................................. 105
A.1 Watchdog Timer Registers ................................................................................106
A.2 F81866 Watchdog Timer Initial Program .......................................................109
Appendix B - I/O Information ............................................................................................ 111
B.1 I/O Address Map .................................................................................................112
B.2 Memory Address Map .......................................................................................114
B.3 IRQ Mapping Chart.............................................................................................115

Preface XV
Compact Board PCM-QM77
B.4 DMA Channel Assignments ..............................................................................118
Appendix C –Mating Connectors ..................................................................................... 119
C.1 List of Mating Connectors and Cables............................................................120
Appendix D –RAID & AHCI Settings................................................................................. 123
D.1 Setting RAID .........................................................................................................124
D.2 Setting AHCI .........................................................................................................131
Appendix E –Electrical Specifications for I/O Ports......................................................... 135
E.1 Electrical Specifications for I/O Ports...............................................................136
Appendix F –Digital I/O Ports ........................................................................................... 138
F.1 Digital I/O Ports ...................................................................................................139

Compact Board PCM-QM77
Chapter 1
Chapter 1 - Product Specifications

Chapter 1 –Product Specifications 2
Compact Board PCM-QM77
1.1 Specifications
System
Form Factor
5.25” Compact Board (203 mm x 146 mm)
Processor
Intel®3rd Generation Intel®Core™
i7/i5/i3/Celeron®processor
System Memory
204-pin DDR3 SODIMM x 2, DDR3/L
1333/1600, up to 16GB
Chipset
Intel®QM77/HM76
I/O Chipset
Fintek 81866
Ethernet
Intel 82579LM Gigabit PHY x1 & Intel 82583V
Gigabit x 1, RJ-45 x 2 co-lay with pin header
Intel 82583V shared with Intel 82574L Support
IEEE1588
BIOS
Plug & Play BIOS –16MB flash
Wake On LAN
Yes
Watchdog Timer
Generates a time-out system reset
H/W Status Monitoring
Supports power supply voltages and
temperature monitoring
Expansion Interface
Mini Card x1, mSATAx1, PCI x1 and PCI
Express [x16] x1
Battery
Lithium Battery
Power Requirement
ATX/AT

Chapter 1 –Product Specifications 3
Compact Board PCM-QM77
(AT mode to control by jumper, and BIOS
need to be set ACPI disabled)
Board Size
8”(L) x5.75” (W) (203mm x 146mm)
Gross Weight
0.88 lb (0.4 Kg)
Operating Temperature
32°F~140°F (0°C~60°C)
Storage Temperature
-40°F~176°F (-40°C~80°C)
Operation Humidity
0% ~ 90% relative humidity, non-condensing
Display
Chipset
Intel®QM77/HM76 integrated
Memory
Shared system memory up to 512MB
Resolution
Up to 2048 x 1536 for VGA
Up to 1920 x 1200 for LVDS LCD, DVI
Display Combination
VGA/LCD, DVI/LCD simultaneous / dual view
displays
I/O
Storage
SATA 6.0Gb/s x 2
CFast™ x 1
mSATA x 1
USB
USB 3.0 x 4
USB 2.0 x 4
Serial Port
10 COM ports:
- Six 5x2 box header on internal (COM1~6)
from Fintek 81866

Chapter 1 –Product Specifications 4
Compact Board PCM-QM77
- COM2/6: RS-232/422/RS485
- Four 5x2 box header on internal(COM7~10)
- COM 7 ~10: RS-232 from F81216D(Optional)
DI/O
16-bit Programmable
Audio
Line-in, Line-out, Mic-in
PS/2 Port
Keyboard x 1
Mouse x 1
*Note on OS
For Linux, AAEON suggests the following:
- Kernel 2.6.39 version or later: Set default BIOS/SATA operating mode to IDE
- Use Ubuntu 12.04 version or later for better display performance

Compact Board PCM-QM77
Chapter 2
Chapter 2 –Hardware Information
