Aaeon EMB-H61B User manual

I n du s t ri a l M o t he r bo a r d EM B- H6 1B
EMB-H61B
Manual 1
st
Ed.
December 2012

Industrial Motherboard
EMB-H61B
i
Copyright Notice
This document is copyrighted, 2012. All rights are reserved. The original
manufacturer reserves the right to make improvements to the products
described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any infringements
upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject
to change without notice. While reasonable efforts have been made in the
preparation of this document to assure its accuracy, the original
manufacturer assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
The original manufacturer reserves the right to make changes in the
product design without notice to its users.

Industrial Motherboard
EMB-H61B
ii
Acknowledgments
All other products’name or trademarks are properties of their respective
owners.
AMI is a trademark of American Megatrends Inc.
CompactFlash™is a trademark of the Compact Flash Association.
Intel®is a trademark of Intel®Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International Business
Machines Corporation.
SoundBlaster is a trademark of Creative Labs, Inc.
All other product names or trademarks are properties of their respective
owners.

Industrial Motherboard
EMB-H61B
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
1 Industrial Motherboard
1 SATA Cable
1 SATA Power Cable
1 Metal I/O Bracket
1 DVD-ROM for Manual (in PDF Format) and
Drivers
If any of these items should be missing or damaged, please contact
your distributor or sales representative immediately.

Industrial Motherboard
EMB-H61B
iv
Contents
Chapter 1 General Information
1.1 Features ....................................................................1-2
1.2 Specifications ............................................................1-3
Chapter 2 Quick Installation Guide
2.1 Safety Precautions....................................................2-2
2.2 Location of Connectors and Jumpers .......................2-3
2.3 Mechanical Drawing.................................................. 2-5
2.4 List of Jumpers..........................................................2-7
2.5 List of Connectors .....................................................2-7
2.6 Setting Jumpers ........................................................2-9
2.7 Clear CMOS (CLRTC)...............................................2-10
2.8 LVDS Panel Voltage Selection (J1) ..........................2-10
2.9 Inverter Voltage Selection (J2)..................................2-10
2.10 Mode Selection for Back Light Control of Inverter (J3)
.........................................................................................2-10
2.11 AT/ATX Mode Selection (J4)...................................2-10
2.12 COM1 Ring/+5V/+12V Selection (J5) ..................... 2-11
2.13 Internal COM Serial Port Connector (COM2 ~ COM6)
.........................................................................................2-11
2.14 PS/2 Keyboard/Mouse Connector with Dock USB 2.0
Connector (KBMS_USB56).............................................2-11
2.15 1000Base-T Ethernet Connector with Dock USB 2.0
Connector (LAN1_ USB12 / LAN2_ USB34) .................. 2-12

Industrial Motherboard
EMB-H61B
v
2.16 Digital I/O Connector (DIO).....................................2-12
2.17 Front Panel Connector (F_PANEL)......................... 2-13
2.18 Inverter Connector (INV).........................................2-13
2.19 LVDS Panel Signal Connector (LVDS)...................2-13
2.20 SATA Power Connector (PWR1)............................2-15
2.21 FAN Connector (S_FAN1 / S_FAN2)...................... 2-15
2.22 Internal USB 2.0 Connector (USB910) ...................2-15
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization. .................................. 3-2
3.2 AMI BIOS Setup........................................................3-3
Chapter 4 Driver Installation
4.1 Installation ................................................................. 4-3
Appendix A Programming The Watchdog Timer
A.1 Watchdog Timer Initial Program ........................A-2
Appendix B Mating Connector
B.1 List of Mating Connectors and Cables...................B-2
Appendix C Digital Input & Output
C.1 DIO Programming................................................. C-2
C.2 Digital I/O Register................................................ C-3
C.3 Digital I/O Sample Program.................................. C-4

I n du s t ri a l M o t he r bo a r d EM B-H 6 1B
Chapter 1 General Information 1- 1
General
Information
Chapter
1

I n du s t ri a l M o t he r bo a r d EM B- H6 1B
Chapter 1 General Information 1-2
1.1 Features
Intel
®
Socket 1155 for 3
rd
/2
nd
Generation Core™ i7/ i5/ i3/
Pentium® / Celeron® Processors
(Supports Intel® 22/32 nm CPU up to 65W)
2 x 204-pin Dual-Channel DDR3 1333/1066MHz SO-DIMM
Up to 16GB
Intel
®
integrated Graphics Engine Supports Dual View by VGA,
HDMI x 2, LVDS
Realtek PCI-Express Gigabit Ethernet x 2
SATA 3.0Gb/s x 2 & CF Socket x 1 (Supports Both CF-SATA
Card and CF Type 1
USB 2.0 x 8 & COM x 6
PCI-Express 2.0 [x4] x 1 & Full-size Mini Card(PCIe +USB) +
SIM Card x 1
EuP/ErP Compliance
12V DC-in Support
TPM Module Support

I n du s t ri a l M o t he r bo a r d EM B- H6 1B
Chapter 1 General Information
1-3
1.2 Specifications
System
 Processor Intel
®
2
nd
/3
rd
generation Core™
i7/i5/i3 Processor, up to 65W
 System Memory 204-pin dual-channel DDR3
1333/1066 SODIMM x 2, Max. 16
GB
 Chipset Intel
®
H61 (B3)
 I/O Chipset Fintek F81866D-I
 Ethernet Realtek 8111F for
10/100/1000Base-T, RJ-45 x 2
 BIOS
AMI BIOS, 64Mb ROM
 Wake On LAN Yes
 Watchdog Timer System reset: 1~255 steps
programmable
 TPM Infineon SLB9635 TT 1.2
 H/W Status Monitoring Monitoring System Temperature,
Voltage, and Cooling Fan status
 Expansion Interface PCI-Express 2.0 [x4] x 1,
Full-size Mini Card(PCIe +USB) +
SIM Card x1
 Battery Lithium battery
 Power Requirement 4-
pin connector for DC12V input x 1;
CPU fan x 1, System fan with 4-pin
wafer x 1;
SATA power with 4-pin wafer x 1
 Power Compliance Compliant with EuP/ErP
 Board Size 6.7”(L) x 6.7”(W) (170 mm x 170
mm)

I n du s t ri a l M o t he r bo a r d EM B- H6 1B
Chapter 1 General Information 1-4
 Gross Weight 1.1 lb (0.5 Kg)
 Operating Temperature 32°F ~ 131°F (0°C ~ 55°C)
 Storage Temperature -40°F ~ 185°F (-40°C ~ 85°C)
 Operating Humidity 0% ~ 90% relative humidity,
non-condensing
 EMI CE/FCC Class A
Display
 Chipset Intel® Graphics Media Accelerator
 Resolution Up to 2048x1536 @ 75Hz for
VGA;
Up to 1920x1200 @ 60Hz for
HDMI;
 LCD Interface Dual 24-bit for LVDS
Up to 1920 x 1200 @ 60 Hz
 Output Interface Multi-VGA output support:
HDMI/ VGA/ LCD
I/O
 Storage SATA 3.0 Gb/s x 2,
CF Socket x 1 (Supports Both
CF-SATA Card and CF Type 1
 Serial Port RS-232 x 5 (COM2~COM6),
RS-232/422/485 x 1 (COM1)
supports 5V/12V/RI option
 USB USB2.0 x 8 (2 ports at mid-board,
6 ports at back panel)
 Digital I/O Supports 8-bit (4-in/ 4-out)
 PS/2 Port Keyboard/ Mouse x 1
 Audio Audio jack with BTX type x 3
(Mic-in, Line-out, Line-in)

Industrial Motherboard
EMB-H61B
Chapter 2 Quick Installation Guide 2 - 1
Quick
Installation
Guide
Chapter
2

Industrial Motherboard
EMB-H61B
Chapter 2 Quick Installation Guide 2 - 2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

Industrial Motherboard
EMB-H61B
Chapter 2 Quick Installation Guide 2 - 3
2.2 Location of Connectors and Jumpers
Component Side

Industrial Motherboard
EMB-H61B
Chapter 2 Quick Installation Guide 2 - 4
Solder Side

Industrial Motherboard
EMB-H61B
Chapter 2 Quick Installation Guide 2 - 5
2.3 Mechanical Drawing
Component Side

Industrial Motherboard
EMB-H61B
Chapter 2 Quick Installation Guide 2 - 6
Solder Side

Industrial Motherboard
EMB-H61B
Chapter 2 Quick Installation Guide 2 - 7
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure your system
to suit your application.
The table below shows the function of each of the board's jumpers:
Label
Function
CLRTC
Clear CMOS
J1
LVDS Panel Voltage Selection
J2
Inverter Voltage Selection
J3
Mode Selection for Back Light Control of Inverter
J4
AT/ATX mode Selection
J5
COM1 Ring/+5V/+12V Selection
2.5 List of Connectors
The board has a number of connectors that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's connectors:
Label
Function
ATX12V
ATX 4P Power Connector
AUDIO
Audio jack Connector
BATTERY
RTC - Coin Battery Holder
CF-PATA_CF-SATA
CF Socket (Supports Both CF-SATA Card
and CF Type 1)
COM1
COM1 Connector
COM2
COM2 Connector
COM3
COM3 Connector
COM4
COM4 Connector

Industrial Motherboard
EMB-H61B
Chapter 2 Quick Installation Guide 2 - 8
COM5
COM5 Connector
COM6
COM6 Connector
DEBUG
Debug Connector
DIMM_A1
DIMM1 Slot
DIMM_B1
DIMM2 Slot
DIO
Digital I/O Connector
F_PANEL
Front Panel Connector
HDMI1
HDMI Connector
HDMI2
HDMI Connector
INV
Inverter Connector
KBMS_USB56
PS/2 KB&MS and USB5/6 Connector
LAN1_ USB12
LAN1 & USB1/2 Connector
LAN2_ USB34
LAN2 & USB3/4 Connector
LGA1
CPU Socket - LGA-1155P
LVDS
LVDS Panel Signal Connector
MINICARD
Mini Card socket
PCIEX4
PCI Express x4 Slot
PWR1
SATA Power Connector
S_FAN1
System FAN Connector
S_FAN2
System FAN Connector
SATA3G_1
SATA II Connector
SATA3G_2
SATA II Connector
SIM
SIM Card Socket
USB910
Int. USB 2.0 Connector
VGA
D-Sub15_VGA Connector

Industrial Motherboard
EMB-H61B
Chapter 2 Quick Installation Guide 2 - 9
2.6 Setting Jumpers
You configure your card to match the needs of your application by setting
jumpers. A jumper is the simplest kind of electric switch. It consists of two
metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the
pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three
pins, labeled 1, 2 and 3. In this case you would connect either pins 1 and 2 or
2 and 3.
123
Open Closed Closed 2-3
A pair of needle-nose pliers may be helpful when working with jumpers.
If you have any doubts about the best hardware configuration for your
application, contact your local distributor or sales representative before you
make any change.
Generally, you simply need a standard cable to make most connections.

Industrial Motherboard
EMB-H61B
Chapter 2 Quick Installation Guide 2 - 10
2.7 Clear CMOS (CLRTC)
CLRTC
Function
1-2
RTC Batt.
2-3
Clear CMOS
2.8 LVDS Panel Voltage Selection (J1)
J1
Function
1-2
+5V
2-3
+3.3V (Default)
2.9 Inverter Voltage Selection (J2)
J2
Function
1-2
+12V
2-3
+5V (Default)
2.10 Mode Selection for Back Light Control of Inverter (J3)
J3
Function
1-2
DC Voltage Control (Default)
2-3
PWM Control
2.11 AT/ATX Mode Selection (J4)
J4
Function
1-2
AT Mode (Default)
Empty
ATX Mode
