Aaeon HSB-835P User manual

Half-size CPU Card HSB-835P
HSB-835P
Intel
®Pentium®4 Processor
PICMG/PCI Half-size CPU Card
With DDR, Ethernet,
CompactFlash
™& SATA
HSB-835P Rev. A Manual 1st Ed.
Mar. 2005

Half-size CPU Card HSB-835P
i
Copyright Notice
This document is copyrighted, 2005. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Half-size CPU Card HSB-835P
ii
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
 Award is a trademark of Award Software International, Inc.
 CompactFlash™is a trademark of the Compact Flash
Association.
 Intel®, Pentium®M, and Celeron®M are trademarks of Intel®
Corporation.
 Microsoft Windows®is a registered trademark of Microsoft Corp.
 ITE is a trademark of Integrated Technology Express, Inc.
 IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
 SoundBlaster is a trademark of Creative Labs, Inc.

Half-size CPU Card HSB-835P
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 HSB-835P CPU Card
• 1 Floppy Cable
• 1 ATA-100 Cable
• 1 USB Cable
• 1 Keyboard Cable
• 1 Serial + Parallel Cable
• 1 Serial Cable
• 1 ATX Cable
• 1 Quick Installation Guide
• 1 CD-ROM for manual (in PDF format) and drivers
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.

Half-size CPU Card HSB-835P
iv
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Feature......................................................................1-4
1.3 Specification..............................................................1-5
Chapter 2 Quick Installation Guide
2.1 Safety Precaution......................................................2-2
2.2 Location of Connectors and Jumpers .......................2-3
2.3 Mechanical Drawing..................................................2-4
2.4 List of Jumpers..........................................................2-5
2.5 List of Connectors .....................................................2-6
2.6 Setting Jumpers ........................................................2-7
2.7 Clear CMOS (JP1) ....................................................2-8
2.8 Front panel Connector (FP1) ....................................2-8
2.9 Front panel Connector (FP2) ....................................2-8
2.10 RS-232 Serial Port Connector (COM1)................... 2-9
2.11 RS-232/422/485 Serial Port Connector (COM2).....2-9
2.12 IrDA Connector (IR1)...............................................2-9
2.13 LPT Port Connector (LPT1) ....................................2-10
2.14 USB Connector (USB1~2) ......................................2-10
2.15 Fan Connector (FAN1)............................................2-11
2.16 ATX Power Control Connector (CN1).....................2-11
2.17 LAN LED Connector (CN2).....................................2-11

Half-size CPU Card HSB-835P
v
2.18 AC97 Connector (CN3)...........................................2-11
2.19 PS/2 Keyboard & Mouse Connector (CN4) ............2-12
2.20 Internal Keyboard Connector (CN5)........................ 2-12
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization. ..................................3-2
3.2 Award BIOS Setup.................................................... 3-3
Chapter 4 Driver Installation
4.1 Installations ...............................................................4-3
Appendix A I/O Information
A.1 I/O Address Map....................................................A-2
A.2 1st MB Memory Address Map ................................A-3
A.3 IRQ Mapping Chart................................................A-4
A.4 DMA Channel Assignments...................................A-5
Appendix B Programming The Watchdog Timer
B.1 Programming .........................................................B-2
B.2 W83627HF Watchdog Timer Initial Program.........B-7

Half-size CPU Card HSB-835P
Chapter1GeneralInformation 1- 1
General
Information
Chapter
1

Half-size CPU Card HSB-835P
Chapter 1 General Information 1 - 2
1.1 Introduction
Introducing AAEON’s new HSB-835P, powered by Intel®
Pentium®4/Prescott processor, half-size form factor single board
computer (SBC) with an onboard VGA, 10/100/1000Mb LAN
optional and seven USB 2.0 ports.
HSB-835P successfully deployed Intel®most advanced 865GV
chipset, which supports high CPU frequency up to 3.2 GHz with
front side bus running at 400/533/800MHz. HSB-835P supports
Intel®Hyper-Threading Technology gives you the best overall
Pentium®4/Prescott processor performance available. HSB-835P
also provides high memory capacity up to 2 GB DDR DRAM (DDR
266/333/400) and support Dual channel DDR memory interface.
In addition to its powerful computing engine, the full functional
design of the board includes features such as integrated AGP 8X
2D/3D graphics engine, built-in USB 2.0 and on board
CompactFlash™Type I socket. HSB-835P delivers super graphic
performance and provides unique Intel®Extreme Graphics
architecture to maximize VGA performance capability.
Seven USB 2.0 ports provide an expandable, Plug and Play serial
interfaces that ensure a standard low-cost connection for peripheral

Half-size CPU Card HSB-835P
Chapter 1 General Information 1 - 3
devices. Industrial applications will benefit from the seven USB 2.0
by three pin headers and one Type A connector onboard, offering
480Mbps high-speed efficiency and value without compromising
performance.
Moreover, HSB-835P is also equipped with Intel®Ethernet
controllers. One of these provides superior 1 GB Mbps networking
access ability for high speed networking applications such as
gateway, VPN, Mini server and etc.
HSB-835P is a versatile Pentium®4/ Prescott compact board with
the best cost-performance for CTI, networking and mini-server
markets. For these diverse applications, HSB-835P definitely is
your best choice.

Half-size CPU Card HSB-835P
Chapter 1 General Information 1 - 4
1.2 Feature
• Supports Intel®Pentium®4 CPU up to 3.2GHz
(Prescott CPU)
• Supports DDR400 Memory up to 2GB
• Integrates AGP 8X 2D/3D Graphics Accelerator,
VGA support
• Integrates AC97 Codec Audio (Daughter Board
optional)
• Supports 10/100/1000Base-T Ethernet port x1
(10/100& GbE Optional)
• Supports Ultra ATA100 & SATA & CompactFlash™
Type I Storage
• Supports 7 USB 2.0 Ports
• Supports RS-232 x 1, RS-232/422/485 x 1 port
• Supports 1 parallel port
• Supports 1 IrDA port watchdog function 1~255 sec.

Half-size CPU Card HSB-835P
Chapter 1 General Information 1 - 5
1.3 Specification
System
 CPU: Supports Intel®Pentium®4
and Celeron®processors up
to 3.2 GHz (400/533/
800 MHz FSB)
 Chipset: Intel®865GV + Intel®
82801EB/ER (ICH5/ICH5R)
 Ethernet: 10/100Mb or
10/100/1000Mb LAN
optional, RJ-45 x 1, Intel®
82562EZ / 82547GI
controller
 System Memory: 184 pins 2.5V DDR DIMM
Socket x 2, total up to 2GB,
supports dual channel DDR
memory (DDR266/333/400)
 BIOS: Award Plug & Play
Firmware Hub BIOS –
4Mb ROM
 Watchdog Timer: 1~255 step, can be set with
software on Super I/O
 CompactFlash: Supports CFD Type I
Connector

Half-size CPU Card HSB-835P
Chapter 1 General Information 1 - 6
 Expansion Interface: PICMG/ PCI interface
 Power Supply Request: +12V ATX, other supply
from Backplane
 VGA Controller: Integrated on Intel®865G,
AGP 8X, Core frequency up
to 266MHz
 Audio (Daughter board):Realtek ALC655 AC97
(Optional) Codec, MIC-in/Line-in
/Line-out/CD-in
 IDE Interface: ATA-100 x 1 channel
(Supports two ATAPI
devices); SATA-150 x 2
(Supports two SATA devices,
Raid function optional)
 Universal Serial Bus: USB 2.0 Port x 7,
dual 5 x 2 pin headers for
internal, Type-A connector
onboard x 3
 IR Interface: Supports IrDA header x 1
 RTC: Internal RTC
 Operation Temp: 0°C~60°C (32°F~140°F)
I/O
 FDD Interface: Standard Floppy Disk Drive
port x 1 (supports up to 2

Half-size CPU Card HSB-835P
Chapter 1 General Information 1 - 7
floppy devices)
 Serial Ports: Two COM ports: (Internal
pin header, external D-sub x
2)
COM 1: RS-232
COM 2: RS-232/422/485
 Parallel Port: Supports SPP/EPP/ECP
mode
 K/B & Mouse connector:Mini-DIN for PS/2 keyboard
and mouse connector x 1,
Internal keyboard pin
header x 1
 IrDA: IrDA Tx/Rx header x 1
 USB Dual 5 x 2 pin headers for
internal, supports 7 USB 2.0
ports

Half-size CPU Card HSB-835P
Chapter 2 Quick InstallationGuide 2 -1
Quick
Installation
Guide
Chapter
2
Part No. 2007835P10Printed in Taiwan Mar. 2005
Notice:
The Quick Installation Guide is derived
from
Chapter 2 of user manual. For other
chapters and
further installation
instructions
, please refer to the user
manual CD-ROM that ca
me with the
product.

Half-size CPU Card HSB-835P
Chapter 2 Quick Installation Guide 2 -2
2.1 Safety Precaution
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

Half-size CPU Card HSB-835P
Chapter 2 Quick Installation Guide 2 -3
2.2Location of Connectors and Jumpers
Component Side
Solder Side

Half-size CPU Card HSB-835P
Chapter 2 Quick Installation Guide 2 -4
2.3 Mechanical Drawing
Component Side
Solder Side

Half-size CPU Card HSB-835P
Chapter 2 Quick Installation Guide 2 -5
2.4List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Jumpers
Label Function
JP1
Clear CMOS

Half-size CPU Card HSB-835P
Chapter 2 Quick Installation Guide 2 -6
2.5List of Connectors
The board has a number of connectors that allow you to configure
your system to suit your application. The table below shows the
function of each board's connectors:
Label Function
FP1 Front PanelConnector 1
FP2 Front PanelConnector 2
ATX1 ATX Power +12V Connector
VGA1VGA Display Connector
FDD1 Floppy Connector
IDE1 EIDE Connector
CFD1CompactFlash Slot
COM1RS-232 Serial Port Connector
COM2RS-232/422/485 Serial Port Connector
IR1 IrDA Connector
LPT1LPT Port Connector
USB3~5 USB Connector
USB1~2 USB Connector
LAN110/100 or 100/1000 Base-Tx Ethernet
Connector
DIMM1~2 DIMM Slot
FAN1 Fan Connector
CN1 ATX Power Control Connector
CN3AC97Connector
CN4PS2 Keyboard/Mouse Connector
CN5Internal Keyboard Connector
CN2LAN 1 Active LED Connector
SATA1 ~ 2 SATA connector

Half-size CPU Card HSB-835P
Chapter 2 Quick Installation Guide 2 -7
2.6Setting Jumpers
You configure your card to match the needs of your application by
setting jumpers. A jumper is the simplest kind of electric switch. It
consists of two metal pins and a small metal clip (often protected by
a plastic cover) that slides over the pins to connect them. To “close”
a jumper you connect the pins with the clip.
To“open” a jumper you remove the clip. Sometimes a jumper will
have three pins, labeled 1, 2 and 3. In this case you would connect
either pins 1 and 2 or 2 and 3.
12
3
Open Closed Closed 2-3
A pair of needle-nose pliers may be helpful when working with
jumpers.
If you have any doubts about the best hardware configuration for
your application, contact your local distributor or sales
representative before you make any change.
Generally, you simply need a standard cable to make most
connections.
