Aaeon PCM-4897 User manual

PCM-4897
All-in-One Media GXm CPU Card
with LCD, TV-Output, Audio, &
2 COMs

FCC STATEMENT
THISDEVICECOMPLIESWITHPART15FCCRULES.
OPERATIONISSUBJECTTO THEFOLLOWINGTWO
CONDITIONS:(1)THISDEVICEMAYNOTCAUSEHARM-
FULINTERFERENCE.(2)THISDEVICEMUSTACCEPTANY
INTERFERENCERECEIVEDINCLUDINGINTERFERENCE
THATMAYCAUSEUNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR A CLASS "A" DIGITAL
DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASON-
ABLE PROTECTION AGAINTST HARMFUL INTERFER-
ENCEWHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT
GENERATES,USES, AND CAN RADIATE RADIO FRE-
QUENCY ENERGYAND , IFNOTINSTATLLEDANDUSED
IN ACCORDANCEWITH THE INSTRUCTION MANUAL,
MAY CAUSE HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS.OPERATION OF THIS EQUIPMENT
IN A RESIDENTIALAREA IS LIKELY TO CAUSE HARM-
FUL INTERFERENCE IN WHICH CASE THE USER WILL
BE REQUIRED TOCORRECT THE INTERFERENCE AT HIS
OWN EXPENSE.

Copyright Notice
This document is copyrighted, 1999. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor for
any infringements upon the rights of third parties which may result
from its use.
Acknowledgements
AMI is a trademark of American Megatrends, Inc.
Award is a trademark of Award Software International, Inc.
Cyrixisa trademark ofCyrixCorporation.
IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
SMC is a trademark of Standard Microsystems Corporation.
UMC is a trademark of United Microelectronics Corporation.
NS is a trademark of National Semiconductor, Inc.
All other product names or trademarks are properties of their
respective owners.
PartNo. 2047489700 Manual PCM-4897 1st Edition
Prepared in Taiwan July 1999

A Message to the Customer
AAEON Customer Services
Each and every AAEON product is built to the most exacting
specifications to ensure reliable performance in the harsh and
demanding conditions typical of industrial environments. Whether
your new AAEON equipment is destined for the laboratory or the
factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name AAEON has
come to be known.
Your satisfaction is our primary concern. Here is a guide to
AAEON's customer services. To ensure you get the full benefit of
our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products.
So if you run into technical difficulties, we are here to help. For the
most frequently asked questions, you can easily find answers in
your product documentation. These answers are normally a lot
more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the
answer, gather all the information or questions that apply to your
problem, and with the product close at hand, call your dealer. Our
dealers are well trained and ready to give you the support you need
to get the most from your AAEON products. In fact, most problems
reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from AAEON
engineers every business day. We are always ready to give advice
on application requirements or specific information on the installa-
tion and operation of any of our products.

Product Warranty
AAEON warrants to you, the original purchaser, that each of its
products will be free from defects in materials and workmanship for
one year from the date of purchase.
This warranty does not apply to any products which have been
repaired or altered by persons other than repair personnel autho-
rized by AAEON, or which have been subject to misuse, abuse,
accident or improper installation. AAEON assumes no liability
under the terms of this warranty as a consequence of such events.
Because of AAEON's high quality-control standards and rigorous
testing, most of our customers never need to use our repair service.
If an AAEON product is defective, it will be repaired or replaced at
no charge during the warranty period. For out-of-warranty repairs,
you will be billed according to the cost of replacement materials,
service time, and freight. Please consult your dealer for more
details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU type and speed, AAEON products used, other
hardware and software used, etc.) Note anything abnormal and
list any on-screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your
manual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA
(return material authorization) number from your dealer. This
allows us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair
and Replacement Order Card and a photocopy proof of pur-
chase date (such as your sales receipt) in a shippable container.
A product returned without proof of the purchase date is not
eligible for warranty service.
5. Write the RMA number visibly on the outside of the package
and ship it prepaid to your dealer.

Packing list
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1PCM-4897 All-in-OneMediaGXm CPUCard
• 1Quick Installation Guide
• 1 Supporting CD-ROM contains the followings:
-- User's Manual (this manual in PDF file)
--VGA driversand utilities
-- Audio drivers and utilities
-- Latest BIOS (as of the CD-ROM was made)
• 1 hard disk drive (IDE) interface cable (44 pins)
• 1 floppy disk drive interface cable (34 pins)
• 1 6 pins mini-DIN dual outlet adapter for keyboard and PS/2
mouse
If any of these items are missing or damaged, contact your distribu-
tor or sales representative immediately.

http://www.aaeon.com
Notice
DearCustomer,
Thank you for purchasing the PCM-4897 board. This user's
manual is designed to help you to get the most out of the PCM-
4897, please read it thoroughly before you install and use the
board. The product that you have purchased comes with two year
limited warranty, but AAEON will not be responsible for misuse of
the product. Therefore, we strongly urge you to first read the
manual before using the product.
To receive the lastest version of the user manual, please visit our
Web site at:

Contents
Chapter 1: General Information ....................... 1
Introduction ........................................................................... 2
Features.................................................................................. 3
Specifications ......................................................................... 4
Board layout........................................................................... 7
Board dimensions ................................................................. 8
Chapter 2: Installation ....................................... 9
Jumpers and connectors.................................................... 10
Locating jumpers ................................................................ 12
Locating connectors ........................................................... 13
Setting jumpers ................................................................... 14
CPU installing and upgrading............................................ 15
Installing DRAM (DIMMs) .............................................. 16
CPU frequency ratio select (JBFA1) ............................... 17
CPU clock select (JCLK1)................................................ 18
ATX power connector (PW1) ............................................ 19
IrDA connector (JSIR1) .................................................... 20
Wake up on modem connector (JWOM1) ...................... 21
LCD Backlight power connector (J1).............................. 22
Composite video output connector (J2).......................... 23
S-Video connector (J3)....................................................... 24
Internal/external buzzer select (JP1)............................... 25
Hardware reset (JP2) ......................................................... 26
ATX Soft-Power Switch connector (JP3)......................... 27
Power on LED (JP4)........................................................... 28
Suspend switch & LED (JP5, JP6) .................................. 29
IDE LED connector (JP7) ................................................. 30
DOC address select (JP8)................................................. 31
CPU fan power connector (JP9) ....................................... 33
Wake On LAN connector (JP11)...................................... 34

Clear CMOS (JP13) ........................................................... 35
LCD backlight voltage select (JP14)............................... 36
Power LED and KB lock connector (JP15).................... 37
LCD driving voltage select (JP16) .................................. 38
IDE hard drive connector (CN1) ...................................... 39
Connecting the hard drive .......................................................40
IDE hard drive connector (CN1) ............................................41
Game/Joystick/MIDI connector (CN2)........................... 42
Floppy drive connector (CN3) .......................................... 43
Connecting the floppy drive.....................................................44
Floppy drive connector (CN3).................................................45
Display connector (CN8, CN4) ......................................... 46
LCD connector (CN4) ............................................................47
CD-ROM signal input connector (CN6) ......................... 48
Audio connector (for voice modem)(CN7)...................... 49
Parallel port connector (CN9) ........................................... 50
USB connector (CN10) ...................................................... 51
Audio singal input connector (CN11)............................... 52
MIC signal input connector (CN13) ................................ 53
Keyboard and PS/2 mouse connector (CN14) ................ 54
Serial ports (COM1/COM2, CN15/CN16) ..................... 55
COM 1-2 RS-232 serial ports (CN15/CN16) .........................55
DiskOnChip socket (U4) ................................................... 56
DiskOnChip (DOC) 2000 Installation ............................. 57
Chapter 3: Award BIOS Setup .......................... 59
Starting setup....................................................................... 60
Setup keys............................................................................ 61
Getting help ......................................................................... 62
In case of problem...................................................................62
Main setup menu ................................................................ 63
Standard CMOS setup ....................................................... 65

BIOS features setup ........................................................... 71
CHIPSET features setup ................................................... 75
Power management setup.................................................. 77
PNP/PCI congfiguration setup .......................................... 80
Load BIOS defaults/Load setup defaults ........................ 82
Integrated peripherals setup............................................. 83
Supervisor/User password setting ................................... 84
IDE HDD auto detection ................................................... 88
Save & exit setup................................................................ 89
Exit without saving ............................................................. 90
Chapter 4: C&T 69000 Flat Panel/CRT controller
Display Drivers and Utilities ......... 91
Software drives .................................................................... 92
Hardware configuration ..........................................................92
Necessary prerequisites ..........................................................93
Before you begin .....................................................................93
Windows 95 .......................................................................... 94
Driverinstallation ....................................................................94
Windows 3.1.......................................................................102
Driverinstallation ..................................................................102
OS/2.....................................................................................103
Windows NT 3.51..............................................................105
Driverinstallation ..................................................................105
Windows NT 4.0 ................................................................106
Driverinstallation ..................................................................106
Chapter 5: Audio setup .................................. 107
Introduction .......................................................................108
Setting up in windows 95..................................................108
Installing the drivers under Window 95 .................................109

Chapter 1 General Information 1
1
General
Information
This chapter gives background informa-
tion on the mainboard.
Sections include:
• Board specifications
• Layout and dimensions
CHAPTER

2PCM-4897 User Manual
Introduction
ThePCM-4897isanall-in-onemulti-media Cyrix MediaGX MMX
(abbreviated as GXm) processor based single board computer
(SBC) with an integrated audio and video controller, a PCI Flat
Panel controller, and one PISA expansion slot. With ture Pentium
MMX capability, the PCM-4897 achieves outstanding performance
that surpasses other SBC in its class. In addition, the onboard SSD
interface supports M-Systems DiskOnChip 2000 series, memory
capacityfrom 2MB to 144 MB. This compact(only 6.378"x 7.87")
unit offers all the functions of a single board industrial computer.
Onboard features include two serial ports, one multi-mode parallel
(ECP/EPP/SPP)port, connectorfor two USB (Universal SerialBus)
connector, a floppy drive controller, and a keyboard/PS/2 mouse
interface. The built-in high speed PCI IDE controller supports Ultra
DMA/33 mode. Up to two IDE devices can be connected, including
large hard disks, CD-ROM drives, and tape backup drives, etc.
ThePCM-4897 alsofeatures power management to minimizepower
consumption. It complies with the ACPI standard and supports two
types of power saving features: Doze mode, Standby mode. In
addition, the board's watchdog timer can automatically reset the
system or generate an interrupt in case the system stops due to a
program bug or EMI.
Highly integrated multi-media SBC
ThePCM-4897 isa highly integrated multi-media SBCthat com-
bines audio, video, and TV-Output functions on a CD-ROM drive
size single computer board. It provides, 16-bit full-duplex, integrat-
ed 3D audio and up to 1024 x 768 resolution @ 64K colors. Major
onboard devices adopt PCI technology to achieve outstanding
computing performance.

Chapter 1 General Information 3
Features
• SupportsCyrixMediaGXMMXCPU200~300 MHz
•DiskOnChip(SSD) up to144MB
•18-bit PCI-bus SVGA/LCDcontroller supports LCD& CRT display
• AC-97 2.0 audio interface, Sound Blaster compatible
• Supports Bus Master and Ultra DMA/33 IDE devices
•Two RS-232serial ports
•USB interface& PISAslot forflexible expansion capabilities

4PCM-4897 User Manual
Specifications
Standard SBC Functions
•CPU:CyrixMediaGXMMX200~300MHz
•CPUsocket:Socket 7
•BIOS:Award256KB Flash BIOS
•Chipset:CyrixMediaGXMMX/Cx5530
•I/OChipset:NS97317
• Memory: Onboard one 168 pins DIMM socket supports up to
128Mbytes SDRAM
•Enhanced IDE: Support up to two IDE devices. Supports Ultra DMA/
33 mode with data transfer rate up to 33MB/sec.
•FDD interface: Supports up to two floppy disk drives, 5.25" (360KB
and 1.2MB) and/or 3.5" (720KB,1.44MB, and 2.88MB)
•Parallel port: One bi-directional parallel port. Supports SPP, ECP and
EPP modes
•Serial ports: Two RS-232 serial ports. Ports can be configured as COM1,
COM2,COM3, COM4, or disabledindividually. (16C550 equivalent)
•IRinterface: Supportsone IrDA Tx/Rx header
•Keyboard/mouseconnector:6 pins mini-Dinconnector supports PC/AT
keyboard and PS/2 mouse
•USB connectors: Two USB ports onbard
•Battery: Lithium battery for data retention
•DMA:7 DMAchannels (8237 equivalent)
•Interrupt:15 interrupt levels(8259equivalent)
•Power management: Supports ATX power supply. Supports PC97,
LAN wake up, and modem ring-in functions. I/O peripheral devices
support power saving and doze/standby/suspend modes. APM 1.2
compliant

Chapter 1 General Information 5
Flat Panel/CRT Interface
•Chipset:CyrixCx5530
•Displaymemory: UMA
• Displaytype: Supports non-interlaced CRT and LCD (TFT) displays. Can
display both CRT and Flat Panel simultaneously
•Resolution: Up to 1024x768@64K colors
Sound Interface
•Chipset:CyrixCx5530
•3D audio: Supports for Microsoft DirectSound and DirectSound 3D
audio technology in two-speaker mode (requires Microsoft Direct
Sound 3D supported software titles)
•16-bit stereodigital audio: Full-duplex support enables simultaneous
record and playback for Internet communications software
TV-Output
• Chipset: Chrontel 7003 supports both PAL and NTSC system
SSD Interface
One 32-pin DIP socket supports M-systems DiskOnChip 2000 Series up
to 144MB
ExpansionSlots
• PISA slot: One PISA slot onboard for expansion

6PCM-4897 User Manual
Mechanical and environmental
•Powersupplyvoltage:+5V(4.75Vto5.25V),
+12V (11.4V to 12.6V)
•Powerrequirement:[email protected](CyrixGXm200MHz)
•Operating temperature:32to140o F (0 to60oC)
•Boardsize:8"(L)x5.75"(W)(203mmx146mm)
•Weight:1.2lb.(0.5Kg)

Chapter 1 General Information 7
Board layout
Cyrix CX5530
NS97317
CHRONTEL
CH7003

8PCM-4897 User Manual
Board dimensions

Chapter 2 Installation 9
2
Installation
This chapter describes how to set up the
main board hardware, including instruc-
tions on setting jumpers and connecting
peripherals, switches, and indicators. Be
sure to read all the safety precautions
before you begin the installation proce-
dure.
CHAPTER

10 PCM-4897 User Manual
Jumpers and connectors
Connectors on the board link it to external devices such as hard
disk drives, a keyboard, or floppy drives. In addition, the board
has a number of jumpers that allow you to configure your system
to suit your application.
The following tables list the function of each of the board's
jumpers and connectors.
Jumpers
Label Function
JCLK1 CPU clock select
JBFA1 CPU frequency ratio select
PW1 ATX power connector
JSIR1 IrDA connector
JWOM1 Wake up on modem connector
J1 Backlight power connector
J2 Composite video connector
J3 S-Video connector
JP1 Internal/external buzzer select
JP2 Hardware reset connector
JP3 ATX soft-power switch connector
JP4 Power on LED connector
JP5 Suspend Switch (Green mode)
JP6 Suspend LED connector
JP7 HDD LED connector
JP8 DOC address select
JP9 CPU fan power connector
JP11 Wake on LAN connector
JP13 Clear CMOS
JP14 LCD backlight voltage select
JP15 Power LED & KB lock connector
JP16 LCD driving voltage select
