Aaeon AHP-1152 User manual

Touch Panel PC AHP-1152
AHP-1152
Onboard Intel®AtomD510
1.66 GHz Processor
Touch Panel PC
With 15” TFT LCD
AHP-1152 Manual 1st Ed.
November 2010

Touch Panel PC AHP-1152
i
Copyright Notice
This document is copyrighted, 2010. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Touch Panel PC AHP-1152
ii
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
•AMI is a trademark of American Megatrends Inc.
•Intel®, and Atom™ are trademarks of Intel®Corporation.
•Microsoft Windows®is a registered trademark of Microsoft
Corp.
•IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
All other product names or trademarks are properties of their
respective owners.

Touch Panel PC AHP-1152
iii
Packing List
Before you begin operating your PC, please make sure that the
following materials are enclosed:
zAHP-1152 Touch Panel PC
zPhoenix Terminal Block
zMounting brackets and screws
zCD-ROM for manual (in PDF format) and drivers
If any of these items should be missing or damaged, please contact
your distributor or sales representative immediately.

Touch Panel PC AHP-1152
iv
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Do
not use liquid or spray detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near
the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a firm surface during installation. Dropping
it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, only qualified
service personnel should open the equipment.
14. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.

Touch Panel PC AHP-1152
v
d. The equipment does not work well, or you cannot get it
to work according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
WHERE THE STORAGE TEMPERATURE IS BELOW -20°C
(-4°F) OR ABOVE 60°C (140°F). IT MAY DAMAGE THE
EQUIPMENT.
FCC
This device complies with Part 15 FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received including
interference that may cause undesired
operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer’s instructions and your local government’s recycling or
disposal directives.

Touch Panel PC AHP-1152
vi
Below Table for China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Panel PC/ Workstation
有毒有害物质或元素
部件名称 铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件 ×○○○○○
外部信号
连接器及线材 ×○○○○○
外壳 ×○○○○○
中央处理器
与内存 ×○○○○○
硬盘 ×○○○○○
液晶模块 ×○○○○○
光驱 ×○○○○○
触控模块 ×○○○○○
电源 ×○○○○○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、触控模块为选购品。

Touch Panel PC AHP-1152
vii
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Specification..............................................................1-3
1.3 Dimension .................................................................1-6
Chapter 2 Hardware Installation
2.1 Panelmount Installation.............................................2-2
2.2 COM 1/2 RS-232/422/485 Serial Port Connector.....2-4
2.3 CompactFlash™ Installation.....................................2-5
2.4 Hard Disk Drive Installation.......................................2-6
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization ...................................3-2
3.2 AMI BIOS Setup........................................................ 3-3
Chapter 4 Driver Installation
4.1 Introduction................................................................4-3

Touch Panel PC AHP-1152
Chapter 1 General Information 1- 1
General
Chapter
1
Information

Touch Panel PC AHP-1152
Chapter 1 General Information 1- 2
1.1 Introduction
The AHP-1152 operator panel is an Intel®Atom™ D510 1.66 GHz
processor computer that is designed to serve as a human machine
interface (HMI). It is a PC-based system with 15" color TFT LCD
display, onboard Ethernet controller, multi-COM port interfaces and
an audio controller. With a built-in CompactFlash socket, the
AHP-1152 is as compact and user friendly as a multi-function
computer. In addition, its "fit anywhere" design makes it very
flexible and able to be used in many different kinds of installations.
It can be VESA 75/100 wall mounted.
For system integrators, this simple, complete, compact and highly
integrated system let you easily build an operator panel into your
applications. Common industrial applications include factory
automation systems, precision machinery, and production process
control. It is also suitable for many non-industrial applications,
including vending machine, and car park automation. Our operator
panel is a reliable, cost-effective solution to your application’s
processing requirements.

Touch Panel PC AHP-1152
Chapter 1 General Information 1-3
1.2 Specification
System
zCPU Onboard Intel®Atom™ D510 1.66 GHz
Processor
zSystem Memory DDR2 SODIMM x 1, Max. 2 GB
zLCD / CRT Controller Integrated in Processor, shared memory
up to 224 MB
zEthernet 10/100/1000Base-TX, RJ-45 x 2
zI/O Port USB2.0 x 4
RS-232 x 2
RS-232/422/485 x 1
LAN x 2
VGA x 1
zStorage Disk Drive CompactFlash™ slot x 1 (Internal);
2.5” SATA Hard Disk Drive x 1
zExpansion PCI-Express Mini Card x 2
zOS Support Windows® CE 6.0, Windows® XP
Embedded, Windows® XP, Windows®
7, Windows® Embedded Standard 7,
Linux Fedora
Mechanical
zConstruction IP-65 certified plastic front bezel and
back panel

Touch Panel PC AHP-1152
Chapter 1 General Information 1- 4
zColor PMS 5425C + Gray
zMounting VESA 75/100
zDimension 16” (W) x 12.2” (H) x 2.6” (D) (407mm x
310.5mm x 65mm)
zCarton Dimension 20.67” (W) x 18.31” (H) x 9.1” (D)
(525mm x 465mm x 230mm)
zNet Weight 9.7 lb (4.4 kg)
zGross Weight 11.9 lb (5.4 kg)
Environmental
zOperating Temperature 32oF~122oF (0oC~50oC)
zStorage Temperature -4oF~140oF (-20oC~60oC)
zOperating Humidity 5 to 90%@ 40oC, non-condensing
zVibration 3 g rms/ 5-500Hz/ Operation—With
Hard Disk Drive
zShock 20 G peak acceleration (11 msec.
duration)
zEMC CE/FCC Class A
zPower Supply DC 12V
LCD
Model AHP-1152HTT AHP-1152STT
zDisplay Type 15” TFT LCD
zMax. Resolution 1024x768
zMax. Colors 262K

Touch Panel PC AHP-1152
Chapter 1 General Information 1-5
zLuminance (cd/m2)250 cd/m2800 cd/m2
zViewing Angle 170o(H),160o(V) 160o(H),140o(V)
zBacklight CCFL LED
zBacklight MTBF (Hours) 30,000 60,000
Touch Screen
zType 5-wire analog resistive
zResolution 2048x2048
zLight Transmission > 80%
zLifetime 35 million activations

Touch Panel PC AHP-1152
Chapter 1 General Information 1- 6
1.3 Dimension
Cutout Size:394mm x 297.5mm

Touch Panel PC AHP-1152
Chapter 2 Quick Installation Guide 2-1
Hardware
Installation
Chapter
2

Touch Panel PC AHP-1152
Chapter 2 Quick Installation Guide 2 - 2
2.1 Panelmount Installation
The display panel can be mounted into the wall. You will need the
screws along with the mounting brackets, which be packed in the
accessory box. Follow the steps below:
Before you start to follow the instructions, please place the
display panel into the wall. See the following illustration on the
left.
Step 1: Place the mounting brackets and plug the screw.
Step 2: Aim the mounting set at the hole on the monitor.
Step 3: Move the mounting set to the narrow gauge and fix it with
screws.
Step 4: You’ve completed the preliminary when the mounting set
is tightened. Next, repeat the steps and tighten all mounting set
around the monitor until the monitor is firmly mounting on the
wall.
1
2
3
4

Touch Panel PC AHP-1152
Chapter 2 Quick Installation Guide
2 - 3
Complete Illustration

Touch Panel PC AHP-1152
Chapter 2 Quick Installation Guide 2 - 4
2.2 COM1/2 RS-232/422/485 Serial Port Connector
COM1 (D-sub 9 male)
5
4
2
1
9
8
6
7
Pin Signal Pin Signal
1 DCD 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI
COM2 RS-232/422/485 (D-sub 9 male)
5
4
2
1
9
8
67
Pin Signal Pin Signal
1 DCD
(422TXD-/485DATA-) 2 RXD (422RXD+)
3 TXD
(422TXD+/485DATA+) 4 DTR (422RXD-)
5 GND 6 DSR
7 RTS 8 CTS
9 RI/+5Volt/+12Volt

Touch Panel PC AHP-1152
Chapter 2 Quick Installation Guide
2 - 5
2.3 CompactFlashInstallation
Step 1: Loose the screws on the rear cover
Step 2: Insert the CompactFlash™ Card to the CompactFlash™ slot

Touch Panel PC AHP-1152
Chapter 2 Quick Installation Guide 2 - 6
2.4 Hard Disk Drive Installation
Step 1: Loose the screws on the rear cover
Step 2: Unfasten the HDD bracket
