AAT CR2303 Installation and operating instructions

www.aat-online.de
Ideen bewegen mehr
EN2021-03 (6.1)
Translation of the original user manual
picture shows accessory
'seat belt system including a hip belt‘

2
Spare parts
Repairs processing
Technical advice
Product seminars
Show room exhibition devices
Re-use
Complaints
Loaner devices
With our professional service concept
AAT proves once again its superior
quality standards and o󰀨ers its clients
an all-inclusive package.
We are there for you!
AAT service concept
Customer service at its best
AAT Alber Antriebstechnik GmbH
Ehestetter Weg 11 · D-72458 Albstadt
Phone: [phone]
Fax: [phone]
[email protected] · www.aat-online.de
Assembly team
Phone [phone]
Phone [phone]
Fax [phone]
E-Mail [email protected]
New devices
Phone [phone]
Phone [phone]
Fax [phone]
E-Mail [email protected]
Head o󰀩ce
Phone [phone]
E-Mail [email protected]
Web www.aat-online.de
Service and repairs
Phone [phone]
Phone [phone]
Fax [phone]
E-Mail [email protected]

3
The stair climber CR23 has been successfully tested by TÜV Süd Product Service GmbH in Hanover
according to ISO 7176-28.
The product is state of the art and complies with the associated technical safety requirements.
Nevertheless, a low level of residual risk cannot be ruled out. Please observe the safety instructions to
this end.
All serious incidents occurring in relation to the device must be reported to the manufacturer and to the
competent authority of the Member State where the user and/or occupant is established.
WARNING
Failure to observe this user manual, in particular the safety instructions, can lead to defects in the CR23,
endanger the operator and the occupant and impair function! There is an increased risk of injury! In the
event of an infringement, claims for warranty and liability are excluded!
People with visual and reading impairments or intellectual disabilities should print out the user manual
available on the website in enlarged letters or have this manual read to them, if necessary. You will also
nd all safety-relevant changes that have been made to the user manual on our homepage. All versions
with details of the production period of the product are available at:
www.aat-online.de/gb/um/CR2303

4
Table of contents
1 Symbols and safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2 Explanation of the symbols on the package . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3 Explanation of the symbols on the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
4 Description of the product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
4.1 Device overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
4.2 Type plate incl. serial number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.3 Intended purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.4 Intended patient population . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.5 Medical requirements and indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.6 Contraindications and restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.7 User group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
4.8 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.9 Dimensional sketch CR2303/CR2313 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
4.10 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.11 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5 Folding and unfolding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.1 Seat unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
5.2 Assemble the head rest (optional accessory) . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
5.3 Pull out the telescopic frame (optional accessory). . . . . . . . . . . . . . . . . . . . . . . . . .17
6 Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6.1 Adjust the handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
6.2 Insert the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
6.3 Turning on the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.4 Neutral position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.5 Checking the safety brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.6 Single step mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.7 ComfortStep . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.8 Check capacity of the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7.1 Position of the occupant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7.2 Drive on level ground / overcoming obstacles . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
7.3 Tilting the stair climbing system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
7.4 Operation on a slope. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
7.5 Climbing - upstairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
7.6 Climbing - downstairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.7 Laying the device down on the stairs / emergency stop function . . . . . . . . . . . . . . . . . . 28
7.8 Parking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
7.9 Transportation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8 Care and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8.1 Battery pack and charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.2 Check the lining of the brakes, climbing feet and gilding strips . . . . . . . . . . . . . . . . . . . 32
8.3 Cleaning and desinfection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8.4 Replacing fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8.5 Safety check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
8.6 Change of operator / re-use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8.7 Recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
8.8 Long-term storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

5
1 Symbols and safety instructions
DANGER – Immediately imminent DANGER
If not avoided, this will result in death or severe physical injuries!
WARNING – Possible imminent DANGER
If not avoided, this may result in death or severe physical injuries!
CAUTION – Possible imminent danger or harmful situation
If not avoided, this may result in minor bodily injuries or damage to property!
iNOTE – Manufacturer’s information
General safety instructions
iNOTE
In the event of debility of sight, this user manual can be downloaded at:
www.aat-online.de/gb/um/CR2303
Read the user manual prior to start-up and observe the warning notices and safety instructions.
In the event of reading di󰀩culties, training contents must be broadened verbally.
The user manual must be kept in a safe place after reading.
Contains some ammable materials. Keep the CR23 away from sources of ignition.
CR23 can interfere with highly sensitive electromagnetic elds of other electronic devices
(e.g. anti-theft devices).
Stability tests were performed under laboratory conditions. CR23 can behave di󰀨erently under
real conditions compared to laboratory tests.
Training courses may only be done by the manufacturer or authorized personnel.
CAUTION
External heat sources may cause the surface temperature to rise (e.g. sunlight)!
In such case, surfaces may inict burns - do not touch!
9 Malfunction and trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
10 Warranty and liability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
11 Corrective actions / product recall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

6
Symbol Explanation
Handle with care!
The packaging including the product must be handled with special care.
Protect from moisture!
Protect the packaging including the product from excessively high air humidity.
Cover during storage. Carefully cover with a tarpaulin, if necessary.
Caution fragile!
Handle the packaging including the product carefully and never allow it to fall.
This way up!
The packaging must be stored and transported in such a way that the arrows
point upwards at all times. Any failure to comply with this rule, such as rolling
or tilting the package, must be avoided.
2 Explanation of the symbols on the package
WARNING
Never touch rotating or moving parts to avoid crushing of ngers and hands!
DANGER
CR23 must not be operated in the case of severe visual impairment and/or blindness!
Do not exceed the approved total weight and the maximum person weight, as this may lead to
defects or overloading of the CR23!
Do not use in rain, wet, snow or ice as the restricted braking capacity may cause slipping!
Do not use on travelators or escalators as doing so may risk physical injury and/or material damage as
a result of crashing or the occupant falling out of the seat.
The operational capability of CR23 can be inuenced by electromagnetic elds
(e.g. by mobile phones, electric generators or high-voltage sources)!
Do not store near medical devices, for example with a life support function, and diagnostic devices,
as these may malfunction!

7
3 Explanation of the symbols on the device
Symbol Erklärung
CE marking
Location: type plate
The product complies with the relevant provisions of the EC Regulation
EC 2017/745 (MDR)
20XX
Date of manufacture
Location: type plate
Indicates the year the medical device was manufactured.
Manufacturer
Location: type plate
Shows the manufacturer of the medical device (AAT Alber Antriebstechnik GmbH)
SN
SN
Location: type plate
Serial number of the product e.g. CR2303XXXXXX / CR2313XXXXXX
Medical Device
Location: type plate
Observe the user manual!
Location: type plate
The user manual must be observed! (www.aat-online.de)
Attention!
Location: type plate
Refers to the need for the user to review the user manual and
important safety-related information.
Barcode
Location: type plate
Contains the AAT serial number
Technical safety test badge
(refer to chapter Technical safety test)
Location: drive unit, left side
Informs about the due date of the next technical safety test
TÜV-Süd marking
Location: drive unit, above keypad
Indicates that the product has been successfully tested at TÜV Süd Product Service
GmbH according to the standards DIN EN 12182, DIN EN 12184 and the applicable
parts of ISO 7176.
Lable with notes
Location: Battery pack
Observe the user manual!
DANGER - Parts in motion!
Operation only by one trained person!
Activate safety brakes on the stairs and check them before each use!
Observe max. load!

8
Label UP / DOWN
Location: UP / DOWN switch on control unit
Indicates the driving direction
(see chapter „Climbing upstairs and downstairs“)
Label notice - No handle
Location: C-part, below seat, rear of the drive unit.
DANGER
Parts in motion

9
4 Description of the product
4.1 Device overview
9
Control unit
Handle, adjustable
Main wheel
Lever with chain drive
Climbers and climbing feet
Safety brake
Battery display
Single step switch
ComfortStep
Battery pack
Safety interlock of the battery pack (release button)
LED to display the error codes
Helix cable
Tightening screw for the handle

10
Speed control
Safety chip
ON/OFF switch
UP/DOWN switch
Back rest
LED for safe operation in lowlight situations
C-part (with seat unit)
Foot rest with feet belt
Release button for the C-part with seat unit
Steering rollers
Hip belt
Type label with serial number
i
Manufacturer‘s information:
For a simplied assignment of
the individual components, the
numbers listed here are cited
in full for the rst time in the
following chapters.

11
4.2 Type plate incl. serial number
Product / Model
Max. Load
Battery
Charging Voltage
Operating Voltage
Rated Power
Barcode (see chapter 3)
Serial number (see chapter 3)
Symbols (see chapter 3)
Manufacturer‘s address
4.3 Intended purpose
The stair climbers are guided manually and are operated by an operator.
They make it possible to transport a single person with reduced mobility safely over stairs, upwards
and downwards. The products have been designed for indoor and outdoor use, and moving on spiral
stairs and slopes is possible, too.
4.4 Intended patient population
The intended patient population includes all persons who are able to sit independently and have a
maximum body weight corresponding to the technical specication of the respective model and variant
(max. 230 kg).

12
4.5 Medical requirements and indication
The patients must be able to sit independently. Secure persons, who cannot sit on their own, with belts
(see Accessories). This keeps the occupant from falling out!
The manually guided stair climber assists the accompanying person while transporting the patient over
stairs or slopes, upwards and downwards. The use of the stair climber is intended for patients who
are not able to move by themselves and accompanying persons who do not have su󰀩cient physical
endurance and strength to move the patient over stairs or slopes.
The CR23 is used to transport patients with a weight of more than 140 kg (maximum patient weight:
230 kg).
4.6 Contraindications and restrictions
The stair climbers must not be used if:
- the operator has obtained no training/instruction for the product!
- the operator is below the age of 16!
- there is no supervision for minors of at least 16 years of age!
- the operator is not physically and mentally able to operate the stair climber safely!
- more than one person shall be transported simultaneously!
- the person to be transported cannot sit upright unaided!
- the operator does not have adequate eyesight!
- the braking e󰀨ect is reduced due to rain, wet conditions, snow or black ice!
- the one-side and/or two-side braking e󰀨ect of stair climber does not set in!
- escalators or travelators shall be overcome!
- medical devices with e.g. a life support function, and diagnostic devices are in the proximity!
- it is not used according to the intended use!
4.7 User group
The stair climbers are intended for the use by:
- medical sta󰀨,
- healthcare professionals,
- driving services, and laymen
Users are trained in the use of the device by means of a training course.

13
4.8 Technical data
WARNING - The approved total weight may not be exceeded because it can lead to
malfunction or cause an overload of the CR23!
iNOTE - Observe the technical data.
Technology CR2303 / CR2313
Measurements See chapter „dimensional drawing“
Weight Climbing unit = 34.9 kg, Handle unit = 2.3 kg, Battery pack = 4.3 kg
Total weight without battery pack = 37.2 kg
Total weight approved 271 kg
Max. weight of the person (max. load) 230 kg
Climbing speed1) 8 - 21 steps / minute, continually adjustable
Range with one charge of the batteries -
with an average load of 75 kg1) approx. 25 oors (corresponds to approx. 375 steps)
Range with one charge of the batteries -
with a maximum load1) approx. 5 oors (corresponds to approx. 75 steps)
Maximum height of step 210 | 225 mm (extended climbing height)
Minimum depth of step2) 140 mm
Necessary step width (straight stairs) Width CR23 + 100 mm
Minimum platform size (U-shaped stairs) 1350 x 1350 mm
Minimum radius of spiral staircases 1350 mm
Minimum depth of step (spiral staircases)2) 140 mm
Maximum gradient of the stairs 60.3°
Tilt stability In driving direction 3.7° / against driving direction 2.7 °
Batteries 2 x 12 V / 5 Ah (gas-proof)
Direct current motor 24 V / 275 W
Operating force UP/DOWN-switch 3-8 N
Direct operating force max. 350 N whilst climbing downstairs (chapter 7.6)
Noise level < 70 dB
Storing/operating temperature, device -40° C to +65° C / -25° C to +50° C
Storing/operating temperature, batteries -20° C to +65° C(3) / -25° C to +50° C(3)
Charging temperature, device 0° C to +40° C
Height operating range
(NHN, normal height null) < 3.000 m above sea level
Vibration information The weighted RMS value of acceleration the upper body is exposed to
lies typically below 2.5 m/s².
Type label serial number Left on the power unit and the rear side of the user manual
IP-Protection class PX4 protection class: Protection against splash water from all sides
Classication according to ISO 7176-28:2012 Type C (table 1 of annex A)
1) The climbing speed as well as the range with one charge of the batteries is reduced if the ComfortStep is activated.
2) Never use the stair climber to climb stairs with too little depth because it is no longer possible for the main wheels to touch the steps safely.
3) Temperatures below 0°C will reduce the performance of the battery pack, therefore we recommend a storage temperature of at least 0°C.

14
4.9 Dimensional sketch CR2303/CR2313
m
l
k
RoHS & REACH Compliant
Für diese technische Unterlage behalten wir uns alle Rechte nac h DIN 34 vor.
Ers. für
>315-1000
>120-315
>30-120
>6-30
Zust.
>0,5-6
NameÄnderung Datum
±0,8
±0,5
±0,3
±0,2
±0,1
bearb.
gepr.
Werkstoff
Datum Name
Toleranzen
Zeichnungsnummer
Baugruppe
Benennung
BL.
Oberfläche
Werkstück-
kanten DIN ISO 1 3715
-0,3
+0,3 Maßstab
Revision
Status
AATAlber Antriebstechnik GmbH
Artikelnummer
Reihe 3
16.12.2016 Kramer
CR2303
1:5
2/2
www.aat-online.de
Fax:[phone]
Tel.:[phone]
D-72458Albstadt
EhestetterWeg 11
DIN ISO 2768-1-m / DIN ISO 2768-2-m
DIN ISO 1302
1
InBearbeitung
c-max U2 Reha 230Kg
CR2303
039086
Rauheit Normen im Zeichnungsfeld vorr angig
min. 1287
h2
a
e
b
h1
max. 1631
g
f
n
d
Maße nach ISO 7176-15
a Winkel der Sitzfläche 9°
b effektive Sitztiefe 398mm
c effektive Sitzbreite 340mm
d Höhe der Sitzfläche an der vorderen Kante 520mm
e Rückenlehnenwinkel 19°
f Rückenlehnenhöhe 615mm
g Abstand der Fußstütze zur Sitzfläche 436mm
h1 Gesamtlänge m. Fußstütze min. 1095mm
h2 Gesamtlänge m. Fußstütze max. 1212mm
i Gesamtbreite 496mm
k Länge zusammengeklappt 451mm
l Breite zusammengeklappt 496mm
m Höhe zusammengeklappt 1335mm
n Winkel Fußstütze zu Sitzfläche 6°
minimaler Wenderadius ca. 1150mm
c-max U2 Reha 230Kg
RoHS & REACH Compliant
Für diese technische Unterlage behalten wir uns alle Rechte nac h DIN 34 vor.
Ers. für
>315-1000
>120-315
>30-120
>6-30
Zust.
>0,5-6
NameÄnderung Datum
±0,8
±0,5
±0,3
±0,2
±0,1
bearb.
gepr.
Werkstoff
Datum Name
Toleranzen
Zeichnungsnummer
Baugruppe
Benennung
BL.
Oberfläche
Werkstück-
kanten DIN ISO 1371 5
-0,3
+0,3 Maßstab
Revision
Status
039086
Artikelnummer
AATAlber Antriebstechnik GmbH
Reihe 3
16.12.2016 Kramer
1:2
1/3
www.aat-online.de
Fax:[phone]
Tel.:[phone]
D-72458Albstadt
EhestetterWeg 11
CR2303
DIN ISO 2768-1-m / DIN ISO 2768-2-m
DIN ISO 1302
1
InBearbeitung
CR2303
Rauheit Normen im Zeichnungsfeld vorrangig
i
446
c
CR2303
039086
Artikelnummer
RoHS& REACH Compliant
Fürdiese t echnische Unterlage behalten wir uns alle Rechte nach DIN 34 vor.
Ers.für
>315-1000
>120-315
>30-120
>6-30
Zust.
>0,5-6
NameÄnderung Datum
±0,8
±0,5
±0,3
±0,2
±0,1
bearb.
gepr.
Werkstoff
Datum Name
Toleranzen
Zeichnungsnummer
Baugruppe
Benennung
BL.
Oberfläche
Werkstück-
kanten DIN ISO 13715
-0,3
+0,3 Maßstab
c-max U2 Reha 230Kg
Revision
Status
AATAlber Antriebstechnik GmbH
Reihe 3
16.12.2016 Kramer
CR2303
1:5
1/2www.aat-online.de
Fax:[phone]
Tel.:[phone]
D-72458Albstadt
Ehestetter Weg 11
A0
DINI SO 2768-1-m / DIN ISO 2768-2-m
DIN ISO 1302
1
In Bearbeitung
Rauheit Normen im Zeichnungsfeld vorrangig
Dimensions according to ISO 7176-15
a Angle of the seat 9°
bE󰀨ective seat depth 398 mm
cE󰀨ective seat width 340 mm
d Height of the seat, frontal edge 520 mm
e Angle of the back rest 19°
f Height of the back rest 615 mm
g Distance between foot rest and seat 436 mm
h1 Total length with foot rest min. 1095 mm
h2 Total length with foot rest max. 1212 mm
i Total width 496 mm
k Length, folded 451 mm
l Width, folded 496 mm
m Height, folded 1335 mm
nAngle from food rest to seat 6°
Min. turning radius ca. 1150 mm

15
4.10 Scope of delivery
Charger incl. user manual and splash protection
Battery pack with charging electronics and safety interlock
CR2303/CR2313, incl. hip belt
4.11 Accessories
Head rest, adjustable in height and depth
Charging cable for your vehicle
Widening of the seat
Arm rests (adjustable in width)
Seat belt system, incl. hip belt
NOTE – Only use AAT Alber Antriebstechnik GmbH accessories.
ii
Dimensions according to ISO 7176-15
a Angle of the seat 9°
bE󰀨ective seat depth 398 mm
cE󰀨ective seat width 340 mm
d Height of the seat, frontal edge 520 mm
e Angle of the back rest 19°
f Height of the back rest 615 mm
g Distance between foot rest and seat 436 mm
h1 Total length with foot rest min. 1095 mm
h2 Total length with foot rest max. 1212 mm
i Total width 496 mm
k Length, folded 451 mm
l Width, folded 496 mm
m Height, folded 1335 mm
nAngle from food rest to seat 6°
Min. turning radius ca. 1150 mm

16
5 Folding and unfolding
5.1 Seat unit
DANGER - Lock the seat unit safely, otherwise parts may move involuntarily!
WARNING - Special care must be taken to avoid crushing or pinching of body parts while
folding or unfolding!
First, unlock the folding
mechanism.
» Push down the release
knob and simultaneously
pull down the C-part .
Fold out the foot rest .
Push down the C-part until
the mechanism is entirely
unfolded.
» The steering rollers
have to touch the oor.
Folding up.
To fold up the CR23, rst, ip up the foot rest.
Then fold the C-part with seat unit upwards until the folding mechanism locks automatically.
5.2 Assemble the head rest (optional accessory)
CAUTION - To ensure head stability, we recommend placing the head rest at the back of the
occupant‘s head.
Place the bracket of the head
rest above the marks.
» Mount the head rest on the
back rest using the screws.
Adjust the height of the
head rest to the head of the
occupant.
» Secure with the locking
screw.

17
6 Start-up
iNOTE - Store CR23 in a frost-free environment at least one hour prior to start-up to avoid
malfunctions.
iNOTE - Wait a few seconds after turning on the CR23 before you press the UP/DOWN
switch.
5.3 Pull out the telescopic frame (optional accessory)
WARNING - Do not use the telescopic frame as a carrying handle, as it is not designed for
carrying!
CAUTION - Special care must be taken at the pinch point whilst pulling the telescopic
frame in or out!
The stair climber is designed for operation by just one person. This person must be physically and
mentally capable of safely operating the CR23. Minors of at least 16 years may only operate the CR23
under the constant supervision and instruction of an adult.
Push out the telescopic frame.
» It is secured by means of
the locking bolt.
Push in the telescopic frame.
The telescopic frame can
simly be inserted again, if it is
not needed.
The telescopic frame provides an accompanying person the
opportunity to attend the climbing process of the CR23.
In case the telescopic frame was not included when the new
stair climber was ordered, there is a shaft for the foot rest
instead of the telecoping frame.
i

18
6.1 Adjust the handles
WARNING – Always tighten the locking screws, as otherwise parts can suddenly become loose!
CAUTION - To avoid injury, beware of pinch points at the notch opening!
Release the locking screws
of the handles counter
clockwise.
Adjust the height of the
handles approx. to the
level of the operator‘s shoulder.
Tighten the locking screws.
6.2 Insert the battery pack
WARNING - The battery pack has to be locked safely, otherwise it may move involuntarily!
Attach the battery pack.
Push the battery pack into
its xture by means of the
guiding pins on the top of the
housing.
» This locks the release button
automatically.
Detach.
Unlock the battery pack
by pressing the release
button on top of the battery
pack until it engages.

19
6.3 Turning on the device
Insert safety chip for the
engine immobiliser.
» Safety chip must latch!
Turn on the CR23
by pressing the ON/OFF
switch .
6.4 Neutral position
Bring climbers into the
neutral position by pressing
the UP/DOWN switch.
»If single step mode
(see chapter 6.6) is
activated, climbers will stop
automatically in the neutral
position.
Wrong.

20
6.5 Checking the safety brakes
DANGER - Do not use the CR23, if the required braking e󰀨ect (on one side or both sides) is
not guaranteed because a reduced braking e󰀨ect can lead to falling down the stairs! Contact
the manufacturer or your authorized dealer!
WARNING - Check safety brakes without an occupant!
There are safety brakes
located on the climbing frame
on both sides. Activate them
for checking the braking
e󰀨ect.
» Check the safety brakes
each time before using the
CR23.
Pull in the climbers to their
upmost position and tilt the
CR23 backwards.
Test: CR23 cannot be
pushed forward, only
backwards = safety brakes
activated!
6.6 Single step mode
Single step mode
Activate / deactivate
LED glows = single step
mode is activated!
Should you choose to turn
o󰀨 the single step mode you
can do so by pressing the
appropriate button.
» LED does not glow = single
step mode is deactivated!
i
Manufacturer‘s
recommendation
Only deactivate the
single step mode, if the
operator is able to use
the CR23 safely.
DANGER - If the single step mode is deactivated, make sure to operate the CR23 correctly
and safely! Otherwise it can lead to falling down the stairs!
i
Manufacturer‘s
recommendation
Put your foot on the
housing and tilt the CR23
slightly towards you until
you feel that it is balanced.
See detailed description in
chapter 7.3
