FEA-01 user’s manual 3
FEA-01 user’s manual
Safety instructions
Overview
The chapter contains the safety instructions that you must follow
when installing and operating the FEA-01 F-series Extension
Adapter. Read the safety instructions before you work on the unit.
In addition to the safety instructions given below, read the
complete safety instructions of the specific drive you are working
on.
General safety instructions
WARNING! Ignoring the following instructions can cause
physical injury or death, or damage to the equipment.
•Only qualified electricians are allowed to install and maintain
the drive.
•The drive and adjoining equipment must be properly earthed.
•Do not work on a powered drive. After switching off the input
power, always allow the intermediate circuit capacitors 5
minutes to discharge before working on the drive, the motor or
the motor cable. Always ensure by measuring with a
multimeter (impedance at least 1 Mohm) that the drive is
discharged before beginning work.
•The motor cable terminals of the drive are at a dangerously
high voltage when input power is applied, regardless of motor
operation.
•There can be dangerous voltages inside the drive from
external control circuits even when the drive input power is
shut off. Exercise appropriate care when working on the unit.
A6 manual template.book Page 3 Friday, January 8, 2010 3:39 PM

4 FEA-01 user’s manual
FEA-01 F-series Extension Adapter
Overview
The FEA-01 F-series Extension Adapter is an extension unit for the
mounting of FIO I/O extension modules and FEN encoder modules
outside the drive unit. The FEA-01 is connected to the drive via a
DDCS-protocol fiber-optic link. One I/O extension module can be
mounted on one FEA-01 adapter. Several FEA-01 adapters can be
connected in a ring topology using fibre optic cable.
Optical component types
The FEA-01 has a 10 MBd fiber-optic link. The drive must also
have a 10 MBd DDCS fiber-optic connection. The following optical
cable types can be used:
Note: The optical components (transmitter and receiver) on a fibre
optic link must be of the same type.
•Plastic optical fibre (POF) cables (max. length 30 m) and
•Hard Clad Silica (HCS®) cables (max. length 200 m).
HCS cables allow longer connection distances because of their
lower attenuation. HCS®is a registered trademark of SpecTran
Corporation.
The optical component types used in ABB drive equipment are
presented in Settings and connections.
A6 manual template.book Page 4 Friday, January 8, 2010 3:39 PM

FEA-01 user’s manual 5
Settings and connections
Layout
The following figure shows the layout and dimensions of the
FEA-01, indicating the F-series module connector and front
components such as the diagnostic LED, fiber-optic transmitter
(V1), receiver (V2) and power supply connector.
Power supply
The FEA-01 requires a supply voltage of 24 V DC ±10%.
10 MBd
channel
68 mm [2.7 in]
V1 V2
Power supply
connector (24 V)
DIN rail mounting
Diagnostic LED
(POWER OK)
+24 V DC
GND
120 mm [4.7 in]
67 mm [2.6 in]
F-series module
connector
A6 manual template.book Page 5 Friday, January 8, 2010 3:39 PM

6 FEA-01 user’s manual
Diagnostic LED
The green diagnostic LED on the circuit board of the FEA-01 unit
can be viewed on the front of the metal housing.
The LED is lit when the FEA-01 is powered. If the LED is off when
power is applied, there is a fault.
Fiber-optic link connection
Connect the FEA-01 V1 (TXD) connector to the drive RXD
connector. Connect the FEA-01 V2 (RXD) connector to the drive
TXD connector as shown below.
Multiple FEA-01 F-series Extension Adapters are connected
together in a ring topology as shown below.
For more information on the fiber-optic link connection, see the
relevant firmware manual.
Drive
FEA-01 FEA-01 FEA-01
V2V1 V2V1 V2V1
RXD TXD
Drive
RXD TXD
V2V1
FEA-01
A6 manual template.book Page 6 Friday, January 8, 2010 3:39 PM

FEA-01 user’s manual 7
Mechanical installation
The housing of the FEA-01 unit has two spring-loaded fasteners
for vertical or horizontal 35 × 7.5 mm DIN rail mounting. The
mounting rail must be earthed to a noiseless earth. If the rail is not
mounted on a properly earthed base, a separate earthing
conductor must be used. The conductor must be as short as
possible and its cross-sectional area must be 6 mm2at least.
Note: No solid copper conductor may be used (stranded wire
allowed only).
The unit should be mounted so that air can freely pass through the
ventilation holes in the housing. Mounting directly above heat-
generating equipment should be avoided.
Mounting an I/O extension module
To mount an I/O extension module, insert the plastic retaining clips
of the module (a) into the slots in the FEA-01 and fasten the screw
(b). Correct installation of the screw is essential for fulfilling the
EMC requirements and for proper operation of the module. For
more information, see the relevant user’s manual.
a
b
A6 manual template.book Page 7 Friday, January 8, 2010 3:39 PM

8 FEA-01 user’s manual
Technical data
Housing: Painted and zinc-plated sheet steel
Dimensions: 67 × 120 × 68 mm
Mounting: Onto 35 × 7.5 mm DIN rail
Power supply connection
•Voltage: 24 V DC ±10%
•Current consumption: Refer to I/O extension module’s
User’s Manual.
Connectors
•Fiber-optic link connection: Avago Versatile Link (10 MBd)
•Power supply connection: Detachable screw terminal block
(Phoenix Contact MSTBA 2.5/2-G-5.08)
LED: Diagnostic LED labeled ‘POWER OK’.
Ambient conditions: The applicable ambient conditions specified
for the drive in its hardware manual are in effect.
Degree of protection: IP20
Standards: Complies with the safety standard IEC 61800-5-1 and
EMC standard IEC 61800-3.
A6 manual template.book Page 8 Friday, January 8, 2010 3:39 PM

Further information
Product and service inquiries
Address any inquiries about the product to your local ABB
representative, quoting the type designation and serial number of
the unit in question. A listing of ABB sales, support and service
contacts can be found by navigating to www.abb.com/drives and
selecting Sales, Support and Service network.
Product training
For information on ABB product training, navigate to
www.abb.com/drives and select Training courses.
Providing feedback on ABB Drives manuals
Your comments on our manuals are welcome. Go to
www.abb.com/drives and select Document Library – Manuals
feedback form (LV AC drives).
Document library on the Internet
You can find manuals and other product documents in PDF format
on the Internet. Go to www.abb.com/drives and select Document
Library. You can browse the library or enter selection criteria, for
example a document code, in the search field.
