ABB XIO-08 User manual

ABB MEASUREMENT & ANALYTICS | USER MANUAL
Extendable IO (XIO)
XIO-08
Smart, extendable IO
Measurement made easy

2| XIO USER MANUAL | 2106424MNAA
—
Contents
Contents .....................................................................................................................................2
List of tables...............................................................................................................................7
Additional information................................................................................................................8
Cyber security ............................................................................................................................8
Malware Prevention ................................................................................................................. 8
Safety.........................................................................................................................................9
Safety symbol conventions ....................................................................................................... 9
Potential safety hazards ......................................................................................................... 10
Compliance...............................................................................................................................11
Waste Electrical and Electronic Equipment (WEEE) ..................................................................... 11
FCC RF Compliance ............................................................................................................... 11
1System Description .............................................................................................................. 12
1.1 Models........................................................................................................................ 12
1.2 Features Overview........................................................................................................ 12
2Physical Description............................................................................................................. 13
2.1 XIO Housing ................................................................................................................ 13
2.1.1 Enclosures...................................................................................................... 14
2.2 Electronic board ........................................................................................................... 16
2.2.1 Communication ports ....................................................................................... 16
2.2.2 TFIO expansion interfaces................................................................................. 19
2.2.3 Power port ..................................................................................................... 20
2.2.4 Security switch ............................................................................................... 21
2.2.5 Reset button................................................................................................... 22
2.2.6 COLD button................................................................................................... 22
2.2.7 Super capacitor ............................................................................................... 22
2.3 Embedded software and data ......................................................................................... 22
2.3.1 Operating system ............................................................................................ 23
2.3.2 Applications .................................................................................................... 23
2.3.3 Configuration files ........................................................................................... 24
2.3.4 Customer data collection files ............................................................................ 24
2.4 User interface .............................................................................................................. 24
2.5 Secure service access interface ...................................................................................... 24
3Installation .......................................................................................................................... 25
3.1 Site planning and requirements ...................................................................................... 25
3.1.1 Enclosure requirements .................................................................................... 25
3.1.2 External power supply requirements................................................................... 25
3.1.3 Location requirements...................................................................................... 25

XIO USER MANUAL | 2106424MNAA | 3
3.1.4 Mounting requirements .................................................................................... 26
3.1.5 Install antenna (for wireless functionality)........................................................... 26
3.2 Wiring requirements ..................................................................................................... 26
3.3 Unpack and inspect ...................................................................................................... 26
3.4 Basic hardware installation ............................................................................................ 26
3.4.1 Ground the controller ....................................................................................... 27
3.4.2 Standalone mounting ....................................................................................... 27
3.4.3 Mounting when using an enclosure..................................................................... 27
3.4.4 Wire serial communication ports ........................................................................ 28
3.4.5 Connect TFIO modules ..................................................................................... 31
3.5 Power the XIO ............................................................................................................. 32
3.5.1 Power-on sequence.......................................................................................... 33
3.5.2 Power with external power source...................................................................... 33
4Startup................................................................................................................................. 35
4.1 Download PCCU32 from the ABB global website ................................................................ 35
4.2 Install PCCU32 ............................................................................................................. 37
4.3 Establish local communication ........................................................................................ 37
4.3.1 Using the USB port .......................................................................................... 37
4.3.2 Using the Ethernet ports................................................................................... 39
4.4 Change PCCU to Expert view (required) ........................................................................... 42
4.5 Configure basic XIO parameters ..................................................................................... 43
4.6 Configure network communication (4-port switch mode) .................................................... 44
4.6.1 Sample connections ......................................................................................... 44
4.6.2 Configuration overview..................................................................................... 46
4.6.3Configure the XIO............................................................................................ 47
4.6.4 Configure the RMC........................................................................................... 49
4.7 Configure serial communication applications (COM ports) ................................................... 56
4.7.1 Configure COM port for communication with ABB devices ...................................... 57
4.7.2 Configure XIO application export ....................................................................... 69
4.7.3 Verify XIO application export on the RMC ............................................................ 70
4.7.4 Configure measurement applications to use XIO values......................................... 72
4.8 Configure Ethernet-Serial Passthrough ............................................................................ 73
4.8.1 Configure the XIO............................................................................................ 74
4.8.2 Configure the RMC........................................................................................... 82
4.8.3 Configure the peripheral ................................................................................... 86
4.8.4 Configure measurement applications to use XIO values......................................... 87
4.9 Configure the I/O Interface for TFIO module support ......................................................... 88
4.9.1 Connect the TFIO modules to the XIO................................................................. 88
4.9.2 Add and export the I/O Interface application ....................................................... 90
4.9.3 Verify TFIO module detection on XIO.................................................................. 91
4.9.4 Verify I/O interface application export on RMC ..................................................... 95

4| XIO USER MANUAL | 2106424MNAA
5Calibration ........................................................................................................................... 97
6Basic troubleshooting .......................................................................................................... 98
6.1 RMC unable to detect or communicate with the XIO .......................................................... 98
6.1.1 Verify RMC-XIO connection (physical connection) ................................................. 99
6.1.2 Verify the IP parameter configuration (IP communication) ....................................101
6.2 XIO applications not displaying on the RMC .....................................................................104
6.3 RMC failure to receive data from XIO passthrough............................................................105
6.3.1 Missing or mismatched TCP port .......................................................................106
6.3.2 Missing or incorrect XIO serial port....................................................................107
6.3.3 Incorrect protocol selection ..............................................................................108
6.3.4 Mismatched serial communication parameters ....................................................109
6.4 Fail Safe Watchdog alarm does not clear.........................................................................111
7Additional procedures ........................................................................................................ 115
7.1 Enable SSH/SFTP ........................................................................................................115
7.2 Verify or add applications on the XIO .............................................................................115
8Configure security (recommended).................................................................................... 117
8.1 Access points..............................................................................................................117
8.2 Communication interfaces.............................................................................................117
8.2.1 User-enabled services .....................................................................................118
8.2.2Open Transmission Control Protocol (TCP) ports..................................................118
8.3 Denial of service (DOS) threshold rates ..........................................................................120
8.4 Security guidelines ......................................................................................................120
8.5 Configure bi-level security with security switch ................................................................121
8.5.1 Configure non-default XIO security code on the RMC ...........................................123
8.6 Configure Role-Based Access Control (RBAC)...................................................................123
8.6.1 Default access roles ........................................................................................124
8.6.2 Set up and create a new RBAC security control file ..............................................124
8.6.3 Edit the security file ........................................................................................126
8.6.4 Create a new user account...............................................................................126
8.6.5 Enable RBAC authentication on communication ports ...........................................130
8.7 Secure the SSH/SFTP service ........................................................................................133
8.7.1 Supported SSH/SFTP accounts .........................................................................133
8.7.2 SSH/SFTP authentication .................................................................................134
8.7.3 Update default SSH/SFTP keys .........................................................................134
9Service and maintenance ................................................................................................... 151
9.1 Preserve data and configuration ....................................................................................151
9.1.1 Collect data ...................................................................................................151
9.1.2 Save the device configuration...........................................................................154
9.2 Restore the device configuration....................................................................................159
9.3 Use the configuration from another XIO..........................................................................162
9.4 Update device software ................................................................................................163

XIO USER MANUAL | 2106424MNAA | 5
9.4.1 Security requirements before upgrade ...............................................................163
9.4.2 When to upgrade............................................................................................163
9.4.3 Software packages .........................................................................................164
9.4.4 Determine device software part number/version .................................................164
9.4.5 Update software .............................................................................................166
9.5 System restart ............................................................................................................167
9.5.1 Restart type overview .....................................................................................167
9.5.2 Warm restart with the RESET button .................................................................168
9.5.3 Warm restart from the device loader .................................................................169
9.5.4 Warm restart from PCCU Entry mode ................................................................170
9.5.5 Warm restart from terminal mode.....................................................................170
9.5.6 Cold restart from the device loader ...................................................................171
9.5.7 Cold restart from terminal mode .......................................................................172
9.5.8 Factory restart from the device loader ...............................................................173
9.6 Remove and restore power ...........................................................................................174
9.6.1 Remove power from the device ........................................................................174
9.6.2 Reconnect power to the device .........................................................................175
9.6.3 Remove the XIO from the DIN rail ....................................................................175
9.6.4 Return device for repair...................................................................................176
9.7 Maintain cleanliness of the XIO......................................................................................176
10 Ethernet connectivity scenarios ......................................................................................... 177
10.1 Connection types supported by XIO ...............................................................................177
10.1.1 Connection types............................................................................................177
10.1.2 Ethernet modes..............................................................................................178
10.2 IP parameter configuration ...........................................................................................179
10.2.1 IP Addressing per Ethernet mode......................................................................179
10.2.2 Dynamic and static addressing .........................................................................179
10.2.3 Private and public addressing ...........................................................................180
10.3 First-time local communication (4-port switch mode)........................................................181
10.3.1 Configuration .................................................................................................182
10.4 Network communication for switched mode.....................................................................183
10.4.1 Daisy-chain connection support by the RMC .......................................................183
10.4.2 Local access by host .......................................................................................184
10.4.3 Remote access by host....................................................................................186
10.4.4 Device-to-device communication ......................................................................189
10.5 Enterprise and industrial (3-network) support..................................................................190
10.5.1 Configuration .................................................................................................191
10.6 Separate 4-network support .........................................................................................191
11 Wi-Fi®connectivity scenarios............................................................................................. 192
11.1 Connections supported by Wi-Fi modes...........................................................................192
11.2 IP parameter configuration ...........................................................................................193

6| XIO USER MANUAL | 2106424MNAA
11.3 Wireless network communication ...................................................................................193
11.3.1 Local point-to-point wireless access to XIO (Wi-Fi AP) by host...............................193
11.3.2 Local wireless access to RMC by host.................................................................194
11.3.3 Local wireless access to XIO (Wi-Fi client) by host...............................................195
12 Product warranty ............................................................................................................... 196
Contact us ..........................................................................................................................197

XIO USER MANUAL | 2106424MNAA | 7
—
List of tables
Table 0-1: Related documents ....................................................................................................... 8
Table 1-1: XIO models ............................................................................................................... 12
Table 2-1: XCORE enclosures available ......................................................................................... 14
Table 2-2: Ethernet ports ........................................................................................................... 18
Table 2-3: Power connector specifications ..................................................................................... 20
Table 2-4: Applications available with XIO ..................................................................................... 23
Table 3-1: Power source requirements.......................................................................................... 25
Table 3-2: Serial communications specifications ............................................................................. 28
Table 3-3: Ferrule specifications .................................................................................................. 28
Table 3-4: TFIO modules ............................................................................................................ 31
Table 4-1: USB cabling............................................................................................................... 38
Table 4-2: Ethernet cabling ......................................................................................................... 40
Table 4-3: Required station setup ................................................................................................ 44
Table 8-1: Default communication ports on the XIO.......................................................................117
Table 8-2: Wireless interfaces in XIO ...........................................................................................118
Table 8-3: User-enabled services on the XIO ................................................................................118
Table 8-4: Open TCP ports on the XIO .........................................................................................118
Table 8-5: Denial of Service (DOS) threshold rates........................................................................120
Table 8-6: XIO security guidelines...............................................................................................120
Table 8-7: Per-port RBAC authentication options ...........................................................................130
Table 8-8: Security keys............................................................................................................134
Table 9-1: Restart types ............................................................................................................168
Table 10-1: XIO IP addressing per Ethernet mode .........................................................................179
Table 10-2: Reserved private address blocks ................................................................................180
Table 10-3: Configuration for first-time local communication...........................................................182
Table 10-4: Configuration for remote communication with networked XIO (ports A1 or A2) .................189
Table 10-5: Required connections for XIO – RMC communication.....................................................190
Table 10-6: Enterprise and industrial networks - configuration ........................................................190
Table 10-7: Separate 4-network support......................................................................................191
Table 11-1: Connections supported by Wi-Fi modes .......................................................................192
Table 11-2: IP parameter configuration........................................................................................193

8| XIO USER MANUAL | 2106424MNAA
—
Additional information
Additional free publications for the device are available for download at www.abb.com/upstream or by
scanning this code:
XIO Product page
Table 0-1: Related documents
Document
Document number
XIO Data sheet
DS_2102774-EN
XIO Quick Start Guide (tri-fold leaflet)
2106425
XIO Startup Guide
2106605
XIO Interface Application Guide
2107011
Ethernet to Serial Passthrough Application Guide
2107010
Network Communication Application Guide
2107013
I/O Interface Application Guide
2107012
RMC User Manual
2105552
TFIO Module User Manual
2101226
Wi-Fi Antenna Kit
2106123
Cyber security
This product is designed to be connected, and communicate information and data, via a network interface.
All Totalflow products should be connected to a secure network. It is the customer's sole responsibility to
provide and continuously ensure a secure connection between the product and the customer network or
any other network (as the case may be). The customer shall establish and maintain appropriate measures
(such as, but not limited to, the installation of firewalls, application of authentication measures, encryption
of data, or installation of antivirus programs) to protect this product, the network, its system and
interfaces against any kind of security breaches, unauthorized access, interference, intrusion, leakage
and/or theft of data or information. ABB Inc. and its affiliates are not liable for damages and/or losses
related to such security breaches, any unauthorized access, interference, intrusion, leakage and/or theft
of data or information.
Although ABB provides functionality testing on the products and updates that it releases, the customer
should institute its own testing program for any product updates or other major system updates (to
include, but not limited to, code changes, configuration file changes, third party software updates or
patches, hardware change out) to ensure that the security measures that the customer has implemented
have not been compromised and that system functionality in the customer's environment is as expected.
Malware Prevention
Recommendation: As with any downloaded software, scan ABB embedded software packages using a
malware prevention solution.

XIO USER MANUAL | 2106424MNAA | 9
—
Safety
Read these instructions carefully before installation and commissioning. These instructions do not contain
all details on all types of product and do not explain all assembly, operating, or maintenance scenarios.
Ask the manufacturer for further information.
The content of these instructions is neither part of nor provided for changing a previous or existing
agreement, promise, or legal relationship. All obligations of ABB result from the respective sales contract,
which also contains the full and solely valid warranty clauses. These are neither limited nor extended by
the content of these instructions.
Observe warning signs on packaging and on the device.
Assign only qualified and authorized specialists for the assembly, electrical connection, commissioning,
and maintenance of the equipment. Specialist qualifications include:
–Training or instruction and/or authorization to operate and maintain devices or systems according to
safety engineering standards for electrical circuits, high pressures, and aggressive media
–Training or instruction in accordance with safety engineering standards regarding maintenance and
use of adequate safety systems
WARNING:
According to EN 60 900, use only sufficiently insulated tools for the electrical
conn
ection.
Also consider the following regulations:
–The applicable standards and safety regulations concerning the construction and operation of
electrical installations
–The regulation on technical working materials (safety guidelines for tools)
–The regulations and recommendations relating to explosion protection
–The recommendations for safe working in the case of installation in a Safety Integrity Level (SIL)
loop.
–The regulations that apply in the country of use
Safety symbol conventions
The following conventions appear throughout this document:
DANGER and WARNING hazards relate to personal injury and NOTICE hazards are associated with
equipment or property damage. However, under certain operating conditions, operating damaged
equipment can result in a degraded system or process performance leading to serious or life-threatening
injuries. Therefore, compliance with all DANGER, WARNING and NOTICE hazards is required at all times.
DANGER
–Serious damage to health / risk to life. These symbols, and the signal word
"DANGER"
,
indicate imminent danger or electrical hazard. Failure to observe this safety information
result
s in death or severe injury. The text describes the hazard, how to avoid the hazard, and the
result if not followed. The lightnin
g bolt is for electrical danger; the exclamation point is for general
dangers.
DANGER – Serious damage to health / risk to life. This symbol, and the signal word
"DANGER", indicates imminent danger or explosive hazard. Failure to observe this safety
information results in death or severe injury. The text states the hazard, how to avoid the hazard,
and the result if not followed.
!

10 | XIO USER MANUAL | 2106424MNAA
WARNING
– Bodily injury. These symbols, and the signal word "WARNING", indicate a
potentially dangerous situation. Failure to observe this safety information could result in death or
severe injury. The text may state the hazard, how to avoid the hazard, and the result if not
followed. The bolt is for electrical warnings; the
exclamation point is for general warnings.
NOTICE
– Equipment damage, cybersecurity risk, or loss of data. This symbol indicates a
potential for equipment damage, loss
of data or another unintended outcome. Failure to observe
this information may result in damage to or destruction of the product and / or other system
components.
IMPORTANT NOTE:
This symbol indicates operator tips, particularly useful information, or
important
information about the product or its further uses.
Potential safety hazards
The XIO uses voltages in the range of 12 - 24 Vdc plus some percent of tolerance. There are no hazardous
voltages present in the device. However, some optional power sources might convert power from Vac to -
Vdc.
Pressurized natural gas is present in the measurement pipeline. Natural gas can escape from the pipeline
during installation, calibration, or following damage to the pipeline. Only properly trained and authorized
personnel should work in hazardous locations.
WARNING – Bodily injury. Apply power only after the procedures are complete. Technicians
must perform the procedures in order: plan, install, wire, verify the power-on sequence, and
configure.
WARNING – Bodily injury. The device can be operated at high levels of pressure and with
aggressive media. Serious injury and/or considerable material damage can be caused if this
device is handled incorrectly.
WARNING – Bodily injury. Read and follow instructions contained in this guide before and
during equipment installation. Failure to do so could result in bodily injury or equipment damage.
WARNING – Bodily injury. Ensure there is no hazardous atmosphere present when performing
maintenance on the unit. Do not separate components when energized. This applies to all
connectors and connections, cabling and wiring.
NOTICE
– Equipment damage or loss of data. Potential electrostatic charging hazard: clean
only with a damp cloth.
!
!

XIO USER MANUAL | 2106424MNAA | 11
—
Compliance
Waste Electrical and Electronic Equipment (WEEE)
EU Directive 2012/19/EU
ABB Industrial Automation, Measurement and Analytics is committed to actively protecting the
environment. Do not dispose of WEEE as unsorted municipal waste. Collect WEEE separately. WEEE
management participation is critical to the success of WEEE collection.
Do not mix electrical and electronic equipment with general household waste if it displays the
crossed-out wheeled bin symbol. Dispose of it correctly at a recycling facility to save valuable
resources and prevent potential negative effects on health and the environment. These steps
ensure compliance with the Waste Electrical and Electronic Equipment (WEEE) Directive.
Treat waste electrical and electronic equipment (WEEE) separately. Use the national collection framework
available to customers for the return, recycling, and treatment of WEEE.
FCC RF Compliance

12 | XIO USER MANUAL | 2106424MNAA
—
1System Description
The ABB XIO is a microprocessor-based device with built-in, pre-engineered applications for expanding
communication and IO over Ethernet to a host controller. The devices are extendable, supporting
hardware expansion using TFIO modules.
XIO may be placed remotely from the controller (RTU) using Ethernet. Configuration of the device may be
performed using USB, Wi-Fi, Bluetooth, or an Ethernet connection. It has extendable IOs, using TFIO
modules and up to 8 onboard COM serial ports to communicate with measurement transmitters, additional
automation or control equipment, flow computers, etc.
1.1 Models
The table below lists XIO models and the number of COM ports available. They are engineered to be
flexible, enable increased productivity, and improve asset use.
Table 1-1: XIO models
Model
Description
XIO-08
4 Ethernet ports, plus 8 COM ports
XIO-04
4 Ethernet ports, plus 4 COM ports (this is a product for future release)
XIO-00
4 Ethernet ports (this is a product for future release)
1.2 Features Overview
The XIO provides backward-compatible functionality based on ABB Totalflow software, communications,
and IO technologies.
The XIO supports:
–IO and serial communication expansion
–A single, backward-compatible TFIO bus, with the IO module capacity up to 22 modules
IMPORTANT NOTE:
For general specifications, refer to the Data sheet on the Remote modular
controller XIO
product page.

XIO USER MANUAL | 2106424MNAA | 13
—
2Physical Description
2.1 XIO Housing
A DIN rail mountable plastic housing packages the XIO electronic boards and components.
IMPORTANT NOTE:
The XIO must be installed on an interior wall, or in an enclosure that meets
the environmental ratings
for the location. See section 2.1.1 Enclosures for information about ABB
enclosures
. See section 3.1.1 Enclosure requirements for information about third-party enclosures.
The housing is an interlocked top cover and a base.
The following figures illustrate the XIO components and interfaces (ports).
Figure 2-1: XIO housing cover
Legend:XIO housing cover
ID
Description
ID
Description
External power supply input (12 or 24 Vdc)
Micro SD holder
Wi-Fi antenna connector
Cold button (paperclip actuated)
Security switch
A Network Ethernet ports 1 and 2
System status LEDs
B Network Ethernet ports 1 and 2
TFIO Module interface (male)
COM 1 – Com 8 Serial communication ports
Reset button (paperclip actuated)
TFIO Module interface (female)
USB mini port
Communication card status LEDs
The electronic boards are inserted into a backplane at the base and the mounting clips are accessible on
the exterior. Figure 2-2 illustrates the exterior of the housing base.

14 | XIO USER MANUAL | 2106424MNAA
Figure 2-2: XIO housing base
Legend: XIO housing base
ID
Description
ID
Description
Male TFIO interface
DIN rail channel
DIN rail clip
Female TFIO interface
IMPORTANT NOTE:
The XIO has grounding clips attached to the bottom of the electronic board.
The grounding clips fit through the base grounding slots to contact the DIN rail when mounted. Be
sure to ground the DIN rail.
2.1.1 Enclosures
The XIO can be purchased installed in an enclosure. ABB offers the XCORE enclosures described in Ta b l e
2-1. For more information and complete specifications see www.abb.com/upstream.
Table 2-1: XCORE enclosures available
Part number
Size
Weight
2424
24 x 24 x 12 inches (61 x 61 x 30 cm)
45 pounds maximum (fully loaded system)
3630
36 x 30 x 12 inches (91 x 76 x 30 cm)
75 pounds maximum (fully loaded system)

XIO USER MANUAL | 2106424MNAA | 15
Figure 2-3: XCORE 3630 medium size enclosure (front view)
Figure 2-4: XCORE 2424 small size enclosure (internal view displays installed XIO)

16 | XIO USER MANUAL | 2106424MNAA
2.2 Electronic board
The electronic board component specifications are listed in this section.
DANGER – Serious damage to health / risk to life. Explosion Hazard: Do not connect or
disconnect connectors or their terminations while energized unless the area is known to be non-
hazardous.
IMPORTANT NOTE:
For general specifications, refer to the Data sheet listed under Additional
information
.
2.2.1 Communication ports
Communication ports provide communication between the XIO and host systems or external devices.
Factory preconfigured ports support typical communication scenarios. The ports support several available
communication protocols.
Ports configured for local communication (direct connection) support either local access from a host
system, or connection to external devices or peripherals including:
–Measurement transmitters
–Additional automation or control equipment
–Flow computers
–Analyzers
The XIO has several communication ports. Figure 2-5 illustrates the ports and communication expansion
interfaces.
Figure 2-5: Communication ports
Legend: Communication ports (data speed and use)
ID
Port
name
Connector
type
Data transfer rate
(port speed)
Use (connections)
Wi-Fi
/Bluetooth
None, Wireless
Antenna
54 Mbps over Wi-Fi maximum
Local communication with Wi-Fi
Access Point or Client and
Bluetooth

XIO USER MANUAL | 2106424MNAA | 17
ID
Port
name
Connector
type
Data transfer rate
(port speed)
Use (connections)
3 Mbps over Bluetooth Actual
throughput-rate will be less
depending on number of device
connected, distance and
obstacles between device
antenna.
USB
USB Type Mini B
Supports USB 2.0 full speed
mode and high-speed mode
Local communication (high-speed
serial local operator interface)
Ethernet
A Network (1,
2)
RJ-45
10/100 Mbps Full Duplex (auto-
negotiable, not user
configurable)
Two ports: A1 and A2.
Connection to the corporate
network for data collection and
local connection
Ethernet
B Network
(1,
2)
RJ-45
100 Mbps Full Duplex
Two ports: B1 and B2.
Realtime data communication
between XIO and RMC
Serial
c
ommunicatio
n (COM 1 -
COM 8)
Removable
Terminal
connector (8
POS), spring-
cage termination
Baud Rate: 2,400 to 115,200
bps
(Manually configurable from the
user interface)
Remote or local serial
communication configurable for
either RS-232, RS-422 or RS-485
Serial communication ports
COM 1 to COM 8 are software-configurable for serial (RS-232, RS-485, or RS-422) communication
between the XIO and external measurement equipment such as pressure or temperature transmitters.
DANGER – Serious damage to health / risk to life. Explosion Hazard: Do not connect or
disconnect connectors or their terminations while energized unless the area is known to be non-
hazardous.
The configured interface type and the distance between the XIO and the connected external device
determine maximum serial communication speed. The supported port speed ranges from 2,400 bps to
115,200 bps.
XIO COM LEDs
There are two kinds of COM LED on the front of the XIO device.
–COM LEDs
–STATUS LEDs
Figure 2-6: COM LEDs
Legend: COM LEDs
LED
ON
OFF
1
Port Enabled
Port Disabled
2
Port Power Output ON
Port Power Output OFF
3
Port TXD Activity

18 | XIO USER MANUAL | 2106424MNAA
LED
ON
OFF
4
Port RXD Activity
Communications Port Group STATUS LEDs
During normal operation LEDs 1-3 should be ON, LED 4 should be OFF.
Figure 2-7: STATUS LEDs
Legend: Status LEDs for all COMS
LED
ON
OFF
1
Port Group Power On
Port Group Power OFF (LED is OFF no other LEDs should be ON)
2
Port Group Enabled
Port Group Disabled (LED is OFF no Port LEDs should be ON)
3
Port Group Normal operation
Port Group Suspend Mode
4
Port Group Suspend Mode
Port Group Normal Operation
USB port
The USB type mini B port provides high-speed serial communications between the XIO and equipment,
host systems or computers with USB interfaces. The port supports local operator access through PCCU32.
The USB port has two speed modes: full speed and high speed. The XIO automatically negotiates data
transmission rates with the host system.
Ethernet ports
The XIO has two types of Ethernet ports (A Network and B Network). The A Network ports are Enterprise
Network ports and B Network ports are Industrial Network Ports. Ta b l e 2 -2 shows the uses of the Ethernet
ports.
Table 2-2: Ethernet ports
Port
name
Data transfer rate (port speed)
Use
A Network (1,
2)
10/100 Mbps Full Duplex (supports auto-
negotiation and uses standard or straight-
through
Ethernet cable)
Two ports: A1 and A2.
Connection to the corporate network for
data collection and local connection.

XIO USER MANUAL | 2106424MNAA | 19
Port
name
Data transfer rate (port speed)
Use
B Network (1,
2)
10/100 Mbps Full Duplex (supports auto-
negotiation and uses standard or straight-
through
Ethernet cable)
Two ports: B1 and B2.
Realtime data communication between
XIO and RMC.
IMPORTANT NOTE:
For additional details on Ethernet connections, refer to section 10 Ethernet
connectivity scenarios
, or click Help on the Networking tab when connected to the device with the
user interface (PCCU32).
2.2.2 TFIO expansion interfaces
The XIO provides two ports to add modular I/Os. The XIO supports up to 22 TFIO modules.
The XIO uses an independent bus to communicate with the modules. Totalflow has an I/O protocol to
exchange information between the modules and the XIO. The bus operates in a master/slave mode, with
the main board acting as master.
The TFIO modules are DIN rail mountable and employ contact technology for field wiring. The modules
interconnect to each other to provide the necessary power and interface signals along the bus.
The TFIO modules are hot-pluggable and can be inserted, replaced or removed during the normal
operation of the device with no restart required. The system will detect any changes to the modules on
the TFIO bus and the module states can be verified with PCCU.
DANGER – Serious damage to health / risk to life. Explosion Hazard: Do not connect or
disconnect TFIO modules, connectors or their terminations while energized unless the area is
known to be non-hazardous.
IMPORTANT NOTE:
Power compatibility for TFIO modules depends on module type:
−Older green modules must only use 12 Vdc.
−M2 modules and newer grey modules can use 24 Vdc.
−A combination of green modules, and M2 modules or grey modules, must only use 12 Vdc.
Figure 2-8: TFIO module connections to XIO
All modules have four LED lights, a manual reset button, and a selectable address from zero through
seven (Figure 2-9). The faceplate of each module shows:
–Type of module

20 | XIO USER MANUAL | 2106424MNAA
–LED light panel
–Reset button
–Module address selector
For additional information, refer to the TFIO Module User Manual. See Additional information for a link to
the online manual.
Figure 2-9: TFIO module
Legend: TFIO module
ID
Description
ID
Description
1
4 pin terminals
6
TFIO front face
2
Bus address rotary switch
7
TFIO top view
3
Bus interface (male)
8
TFIO side face
4
Activity LEDs
9
Bus interface (female)
5
4 pin terminals
2.2.3 Power port
The XIO has a single port for connection to an external power source. The port supports reverse polarity
protection.
Table 2-3: Power connector specifications
Port
Terminal type
Power
Removable terminal connector (4 POS), spring cage termination. Wire gauge 12 AWG to 22 AWG
IMPORTANT NOTE:
Select wire gauges based on the voltage and current requirements of the
circuitry
and the expected length of the wires. The gauge differs for each application.
The external power supply is the sole source of power to the XIO. The power supply may be one of several
different devices, represented as a rectangle in the following drawing.
