ABB PST Manual

Installation
and maintenance manual
Softstarters
Type PST/PSTB
Low Voltage Products & Systems
Power on Protection
Fault
Power on Protection
Fault
Power on
Protection
Fault
Power on Protection
Fault
Power on
Protection
Fault
AC1006.9
1SFC132001M0202

This manual belongs to:

Low Voltage Products & Systems 3
ABB Inc. • 888-385-1221 • www.abb-control.com AC 1006.9 - 5/03
Installation and maintenance manual
PST30...PSTB1050
1 General
This is the Installation and maintenance manual for Softstarters
PST30...PSTB1050
Document number: 1SFC132001M0202 (AC1006.9)
Edition: 01
Revision: 01
Issue Date: May 15, 2003
Date subject to change without notice.
We reserve all rights to this document, even in the event that a patent is
issued and a different commercial proprietary right is registered. Improper
use, in particular reproduction and dissemination to third parties, is not
permitted.
This document has been carefully checked. If the user nevertheless detects
any errors, please notify us as soon as possible.
The data contained in this manual is intended solely for the product descrip-
tion and is not to be deemed to be a statement of guaranteed properties. In
the interests of our customers, we constantly seek to ensure that our
products are developed to the latest technological standards.
As a result, it is possible that there may be some differences between the
softstarter and the information in this manual.
Author’s address:
Low Voltage Products and Systems
ABB Inc.
1206 Hatton Road
Wichita Falls, TX 76302
Tel: [phone]
940.397.7000
Fax: [phone]
Web: www.abb-control.com

4Low Voltage Products & Systems
AC 1006.9 - 5/03 ABB Inc. • 888-385-1221 • www.abb-control.com
2 Safety
This section describes warning and information signs used in this manual.
The user should pay close attention to these signs.
The softstarter should be installed by authorized personnel only.
This manual is a part of the softstarter and should always be accessible to
personnel working with this product.
The manual should always be read before performing any installation or
commissioning tasks.
3 Safety signs
3:1 Use of Caution, Warning and Information
Caution!
Caution icon indicates the presence of a hazard which could result in
personal injury.
Warning!
Warning icon indicates the presence of a hazard which could result in
corruption of software or damage to equipment/property.
Information sign alerts the reader to pertinent facts and conditions.
Installation and maintenance manual
PST30...PSTB1050

Low Voltage Products & Systems 5
ABB Inc. •888-385-1221 •www.abb-control.com AC 1006.9 - 5/03
Chapter 1: Introduction ............................................................ 7
Chapter 2: Quickstart...............................................................13
Chapter 3: Description........................................................... 17
Chapter 4: Mounting ................................................................31
Chapter 5: Connection .............................................................37
Chapter 6: Human-Machine Interface (HMI)...........................49
Chapter 7: Settings and configuration ..................................61
Chapter 8: Fieldbus communication (option) .......................97
Chapter 9: Maintenance.........................................................113
Chapter 10: Functions ...........................................................117
Chapter 11: Trouble shotting ................................................157
Chapter 12: Diagrams ............................................................167
Chapter 13: Index ...................................................................171
Customer feedback report
Softstarters
Type PST/PSTB
Low voltage
Installation & maintenance manual

6Low Voltage Products & Systems
AC 1006.9 - 5/03 ABB Inc. •888-385-1221 •www.abb-control.com
Notes

Low Voltage Products & Systems 7
ABB Inc. •888-385-1221 •www.abb-control.com AC 1006.9 - 5/03
About the documentation for the softstarter ................................. 9
About the installation and commissioning manual ....................... 9
Intended audience ................................................................ 9
General ........................................................................ 9
Requirements ............................................................... 9
Chapters included .................................................................10
Revision notes ......................................................................10
Acronyms and abbreviations ................................................ 11
Softstarters
Type PST/PSTB
Chapter 1: Introduction

8Low Voltage Products & Systems
AC 1006.9 - 5/03 ABB Inc. •888-385-1221 •www.abb-control.com
Notes

Low Voltage Products & Systems 9
ABB Inc. •888-385-1221 •www.abb-control.com AC 1006.9 - 5/03
Chapter 1 - Introduction
1:1 About the documentation for the softstarter
For the softstarter, the following documents are available:
PST/PSTB Softstarters
Installation and commissioning manual
Document ID: 1SFC132001M0202 (AC1006.9)
Soft Starter Catalog
Document ID: AC1006
For other documents related to the PST Softstarters, see home page
www.abb-control.com/html/products/soft_strs.html
1:2 About the installation and commissioning
manual
This manual contains instructions on how to install and commission the
softstarter. The manual covers procedures for mechanical and electrical
installation and installation of communication devices. It also covers how to
energize, set, configure and verify settings.
For the quickest possible start, read Chapter 2 “ Quickstart” .
1:2.1 Intended audience
1:2.1.1 General
The installation and commissioning manual is intended for personnel
responsible for installing, commissioning and maintaining the softstarter.
1:2.1.2 Requirements
All personnel who interact with the softstarter must have a basic knowledge
in handling electric equipment. The commissioning and maintenance
personnel must be well experienced in using this kind of equipment.

10 Low Voltage Products & Systems
AC 1006.9 - 5/03 ABB Inc. •888-385-1221 •www.abb-control.com
1:2.2 Chapters included
•Introduction introduces the reader to this manual.
•Quickstart contains information on how to install the softstarter and put it into
operation in the quickest and safest way. This chapter is intended for the
experienced user.
•Description describes the softstarter in general, its functions and specifica-
tions.
•Mounting contains information on receiving, unpacking and mounting the
softstarter.
•Connection contains instructions on how to make the electrical connections
as well as connections for communication devices.
•Human-Machine Interface describes the local Human-Machine Interface, how
it works and what it contains.
• Settings and configuration describes all possible settings and how to navigate
in the menu system.
• Fieldbus communication describes how to install and set up the fieldbus
communication.
• Maintenance describes what maintenance is required.
• Functions describes all functions included in the softstarter. This chapter also
describes parameter ranges and default values.
• Trouble shooting contains instructions on how to quickly find and correct the
most common faults.
• Diagrams contains a number of electrical diagrams for the softstarter itself. It
also contains some typical application diagrams.
1:2.3 Revision notes
Please check home page
www.abb-control.com/html/products/soft_strs.html
for latest information on revisions.
Chapter 1 - Introduction

Low Voltage Products & Systems 11
ABB Inc. •888-385-1221 •www.abb-control.com AC 1006.9 - 5/03
Chapter 1 - Introduction
Acronym/
abbreviation Description
LED Light Emitting Diode
LCD Liquid Crystal Display
SCR Silicon Controlled Rectifier
IT Information Technology
HMI Human-Machine Interface
FBP Fieldbusplug
PLC Programmable Logic Controller
PCB Printed Circuit Board
TOR Top Of Ramp (full voltage)
1.2.4 Acronyms and abbreviations
The following acronyms and abbreviations are used in this manual.

12 Low Voltage Products & Systems
AC 1006.9 - 5/03 ABB Inc. •888-385-1221 •www.abb-control.com
Notes

Low Voltage Products & Systems 13
ABB Inc. •888-385-1221 •www.abb-control.com AC 1006.9 - 5/03
Connection .........................................................................15
Configuration .........................................................................16
Start of the motor ........................................................................16
Softstarters
Type PST/PSTB
Chapter 2: Quickstart

14 Low Voltage Products & Systems
AC 1006.9 - 5/03 ABB Inc. •888-385-1221 •www.abb-control.com
Notes

Low Voltage Products & Systems 15
ABB Inc. • 888-385-1221 • www.abb-control.com AC 1006.9 - 5/03
Chapter 2 - Quickstart
This chapter is a short guide on how to connect, configure and start
the softstarter in the quickest and safest way.
Warning!
Mounting and installing the softstarter shall be done in accor-
dance with local laws and regulations and must be performed
by authorized personnel only.
Do not change any parameters in the Service Settings menu.
2:1 Connection
1. Mount the softstarter according to Chapter 4 “ Mounting” .
2. Be aware of the ambient temperature.
Derating is required above 40 °C (104 °F). See Chapter 3 for
more information.
3. Connect the main circuit: terminals 1L1 - 3L2 - 5L3 to the line
side and terminals 2T1 - 4T2 - 6T3 to the motor side.
4. Connect the control voltage: terminals 1 and 2
(100-250V 50/60Hz).
5. Connect the functional ground: terminal 3.
The wire shall be as short as possible, and be connected to the
mounting plate.The mounting plate should also be grounded.
6. Connect the start/stop circuits: terminal 4, 5, 8, 9 and 10 accord-
ing to Figure 2.
7. Verify that the main and control voltage corresponds to the
softstarter ratings.
8. Switch on the control voltage.
9. The green “Power on” LED should be lit and the LCD should
appear as shown in Figure 3.
U= 0% I=0.0A
Menu
Figure 1:
1 Status indication LEDs
2 LCD display
3 Selection keys for selecting, changing
and storing parameters
4 Navigation keys for navigating in the
menus
* Arrows shown in the display indicate
that the value/menu is possible to
change or scroll
Figure 2: Standard connection PST
Power on ProtectionFault
U = 0% I=0.0A
Menu
Figure 3: Top level

16 Low Voltage Products & Systems
AC 1006.9 - 5/03 ABB Inc. •888-385-1221 •www.abb-control.com
2:2 Configuration
1. Enter the Application Setting by pressing the left selection key twice.
Press Select using the left selection key.
2. Select the appropriate type of load by using the navigation keys.
3. Press Store Set and Nex t to continue or Back to previous parameter
using the selection keys.
4. Set Ie (motor FLA) using the navigation keys.
In Line connected = rated motor current
Inside Delta connected = 58% of the rated motor current. For
example, if the soft starter is connected in line with a 100A motor, Ie =
100A. If the softstarter is connected inside the delta of a 100A motor, Ie
= 58A.
5. Press Store and Next to continue or press Back to access the previous
parameter.
6. Set the required overload class using the navigation keys.
7. Press Store and Next to continue or press Back to access the previous
parameter.
8. If an external by-pass contactor is used set Ext ByPass to Yes using the
navigation keys. (PST30...300 only).
9. Press Store and Next to continue or Back to previous parameter using
the selection keys.
10.Select Yes if ready or Tune Set if ramp times, initial voltage, current
limit etc. need to be adjusted.
2:3 Start of the motor
1. Switch on the main voltage.
2. Give a start command to the softstarter.
(To start the softstarter from the keypad, enter the LOCAL CONTROL
menu, select Start/Stop and press Start . The motor must be stopped
before leaving this menu.)
Chapter 2 - Quickstart
Figure 4: Application setting
menu
Figure 5: Centrifugal pump
Figure 6: Centrifugal pump
stored
Figure 7: Setting Ie
Figure 8: Setting Ie stored
Figure 9: OL Class
Figure 10: OL Class stored
Figure 11: External Bypass
Figure 12: External Bypass
stored
Figure 13: Ready / Tune Set
OL Class 10
Next Back
Application Setting
Select Back
Centrifugal Pump
Store Set Back
Centrifugal Pump
Next Back
Setting Ie 99.0A
Store
Setting Ie 99.0A
Next Back
OL Class 10
Store
Ext ByPass No
Store
Ext ByPass No
Next Back
Ready?
Yes Tune Set
(1/( 3))

Low Voltage Products & Systems 17
ABB Inc. •888-385-1221 •www.abb-control.com AC 1006.9 - 5/03
Overview ................................................................................... 19
Functions .............................................................................. 20
Markings and connections .................................................... 22
Type designation .................................................................. 23
Industrial IT .......................................................................... 23
Environmental influence ....................................................... 24
Specifications ....................................................................... 24
Technical data ...................................................................... 25
General................................................................................. 25
Softstarter types ................................................................... 26
Weights ................................................................................ 27
PSTB AC3 (Across the line) Contactor Ratings .................... 27
Dimensions........................................................................... 28
Softstarters
Type PST/PSTB
Chapter 3: Description

18 Low Voltage Products & Systems
AC 1006.9 - 5/03 ABB Inc. • 888-385-1221 • www.abb-control.com
Notes

Low Voltage Products & Systems 19
ABB Inc. • 888-385-1221 • www.abb-control.com AC 1006.9 - 5/03
Chapter 3 - Description
This chapter describes the softstarter in general, specifications and available
accessories and spare parts.
3:1 Overview
The PST softstarter is a microprocessor-based softstarter designed with the
latest technology for the soft start and soft stop of squirrel cage motors. The
softstarter has several advanced motor protection features as standard.
The softstarter is designed to be used with or without a by-pass contactor except
for the larger sizes, PSTB370...1050 where the bypass contactor is integrated. In
an emergency, it is possible to start the motor across the line with the integrated
bypass contactor. See Section 3:8.4 for AC3 ratings.
The keypad on the front is designed to be as user-friendly as possible, with a
clear text display. It is possible to choose between ten different languages
(default is English).
The softstarter can be controlled in three ways:
• Hardware inputs
• Keypad control (local)
• Fieldbus communication interface
The integrated fans for cooling are operated only during ramping (start/stop) and
when the temperature of the heat sink is too high. The temperature is monitored
by a thermistor.
Only one type of control method can be enabled simultaneously.
Default selection is hardware inputs.
Keypad control has the highest priority and overrides all other control methods.

20 Low Voltage Products & Systems
AC 1006.9 - 5/03 ABB Inc. • 888-385-1221 • www.abb-control.com
3:2 Functions
The PST softstarter has several integrated protection and warning functions.
Almost any type of fault can be detected and displayed.
All available protections, warnings and fault indications are listed below.
Start/Stop functions
• Start ramp
• Stop ramp (also called soft stop or decel)
• Initial voltage
• Step down voltage
• Current limit
• Kick Start
• Extended start range
• Extended stop range
• Sequence start
Protection functions
• Motor overload protection
• Locked rotor protection
• Motor underload protection
• High current protection
• Phase imbalance protection
• Phase reversal protection
• SCR overload protection
• PTC input for motor protection
Warning functions
• Warning high current
• Warning low current
• Warning motor overload
• Warning SCR overload
Chapter 3 - Description
