ABB ACS880-14 User manual

—
ABB INDUSTRIAL DRIVES
ACS880-14 drive modules (132…400 kW,
200…400 hp)
Hardware manual

ACS880-14 drive modules
(132…400 kW, 200…400 hp)
Hardware manual
Table of contents
1. Safety instructions
6. Mechanical installation
8. Electrical installation
13. Start-up
3AXD50000035160 Rev D
EN
Original instructions
EFFECTIVE: 2021-01-13

Table of contents
1 Safety instructions
15Contents of this chapter ...........................................................................
15Use of warnings and notes .......................................................................
16General safety in installation, start-up and maintenance ....................................
18Electrical safety in installation, start-up and maintenance ...................................
18Electrical safety precautions ..................................................................
20Additional instructions and notes .............................................................
20Optical components ........................................................................
20Printed circuit boards .......................................................................
21Grounding .......................................................................................
22General safety in operation .......................................................................
22Additional instructions for permanent magnet motor drives .................................
22Safety in installation, start-up, maintenance ................................................
23Safety in operation .............................................................................
2 Introduction to the manual
25Contents of this chapter ...........................................................................
25Applicability .........................................................................................
25Target audience ....................................................................................
25Purpose of the manual ............................................................................
25Categorization by frame size and option code .................................................
26Quick installation, commissioning and operating flowchart ..................................
27Terms and abbreviations ..........................................................................
28Related documents ................................................................................
3 Operation principle and hardware description
31Contents of this chapter ...........................................................................
31Operation principle .................................................................................
32Block diagram of the main circuit of the drive module ....................................
32Line-side converter .............................................................................
33AC voltage and current waveforms ......................................................
33Charging .....................................................................................
33Motor-side converter ...........................................................................
34Layout ...............................................................................................
34Standard drive module configuration ........................................................
35Drive module ....................................................................................
36LCL filter module ...............................................................................
37Drive module with full power cabling panels (option +H381) ............................
38
Drive module without full-size output cable connection terminals (option +0H371) and
IP20 shrouds (option +0B051) and with common mode filter (option +E208) .........
39Control panel ....................................................................................
40Overview of power and control connections ...................................................
41Type designation label ............................................................................
41Type designation key ..............................................................................
41Basic code .......................................................................................
Table of contents 5

42Option codes ....................................................................................
4 Generic cabinet planning instructions
45Contents of this chapter ...........................................................................
45Limitation of liability ................................................................................
45Cabinet construction ...............................................................................
45Disposition of the devices .....................................................................
46Grounding of mounting structures ...........................................................
46Busbar material and joints ....................................................................
46Shrouds ..........................................................................................
46Tightening torques .............................................................................
46Electrical connections ......................................................................
46Mechanical connections ...................................................................
47Insulation supports ..........................................................................
47Cable lugs ....................................................................................
47Cooling and degrees of protection ..............................................................
47Planning the cooling ...........................................................................
47Air inlets and outlets ...........................................................................
49Preventing the recirculation of hot air .......................................................
49EMC requirements .................................................................................
51Attaching the cabinet ..............................................................................
52Cabinet placement on a cable channel .........................................................
52Heaters ..............................................................................................
53Mounting the control panel on the cabinet door ...............................................
5 Guidelines for planning the mechanical installation
55Contents of this chapter ...........................................................................
55Installation positions of the drive module .......................................................
56Layout example, door closed .....................................................................
57Layout example, door open (standard drive module configuration) ........................
58Layout example, door open (option +0B051) ..................................................
59Cooling solutions ...................................................................................
60Preventing the recirculation of hot air ...........................................................
60Bookshelf mounting (standard drive module configuration) ..............................
61Bookshelf mounting (option +0B051) ........................................................
62Bookshelf mounting (option +H381) .........................................................
62Required free space ...............................................................................
62Free space at the top of the drive module ..................................................
63Free space around the drive module ........................................................
63ABB air inlet and outlet kits .......................................................................
6 Mechanical installation
65Contents of this chapter ...........................................................................
65Examining the installation site ...................................................................
65Moving and unpacking ............................................................................
66Package drawings ..............................................................................
66Drive module package without option +E202 ...........................................
67Package with option +E202 ...............................................................
68Boxes .........................................................................................
71LCL filter module package .................................................................
72Examining the delivery ............................................................................
6 Table of contents

72Lifting ................................................................................................
72Attaching the drive module and LCL filter module to a mounting plate or wall ...........
73Attaching the drive module to the LCL filter module ..........................................
73Attaching the drive module and the LCL filter module to the enclosure base .............
73Grounding the drive module and the LCL filter module ......................................
73Installing the drive in Rittal VX25 enclosure ...................................................
74Optional input power cable connection terminals and ground busbar assembly (+H370) .
74
Drive module without full-size output cable connection terminals (option +0H371) and
IP20 shrouds (option +0B051) ...................................................................
7 Guidelines for planning the electrical installation
75Contents of this chapter ...........................................................................
75Limitation of liability ................................................................................
75Selecting the main supply disconnecting device ..............................................
75European Union ................................................................................
76North America ...................................................................................
76Other regions ...................................................................................
76Selecting the main contactor .....................................................................
76North America ...................................................................................
76Other regions ...................................................................................
76Examining the compatibility of the motor and drive ...........................................
76Protecting the motor insulation and bearings ..............................................
77Requirements table ............................................................................
80Availability of du/dtfilter and common mode filter by drive type .....................
80Additional requirements for explosion-safe (EX) motors ..............................
80
Additional requirements for ABB motors of types other than M2_, M3_, M4_, HX_
and AM_ ......................................................................................
80Additional requirements for the regenerative and low harmonics drives ...........
80Additional requirements for ABB high-output and IP23 motors ......................
80Additional requirements for non-ABB high-output and IP23 motors .................
81Additional data for calculating the rise time and the peak line-to-line voltage .....
82Additional note for sine filters .............................................................
82Selecting the power cables .......................................................................
82General guidelines .............................................................................
83Typical power cable sizes .....................................................................
83Power cable types ..............................................................................
83Preferred power cable types ..............................................................
84Alternate power cable types ...............................................................
85Not allowed power cable types ...........................................................
85Additional guidelines, North America ........................................................
86Metal conduit ................................................................................
86Power cable shield .............................................................................
87Selecting the control cables ......................................................................
87Shielding .........................................................................................
87Signals in separate cables ....................................................................
87Signals that can be run in the same cable ..................................................
87Relay cable ......................................................................................
87Control panel to drive cable ...................................................................
88PC tool cable ....................................................................................
88Routing the cables .................................................................................
88General guidelines – IEC ......................................................................
88General guidelines – North America .........................................................
Table of contents 7

89
Continuous motor cable shield/conduit or enclosure for equipment on the motor
cable ..............................................................................................
89Separate control cable ducts .................................................................
90Implementing motor and motor cable short-circuit and thermal overload protection .....
90Protecting the motor and motor cable in short-circuits ....................................
90Protecting the motor cables against thermal overload ....................................
90Protecting the motor against thermal overload .............................................
90Protecting the motor against overload without thermal model or temperature sensors .
91Protecting the drive and the input power cable in short-circuits .............................
91Protecting the drive against thermal overload .................................................
91Protecting the input power cable against thermal overload ..................................
91Implementing a motor temperature sensor connection ......................................
92Connecting motor temperature sensor to the drive via an option module .............
93Protecting the drive against ground faults ......................................................
93Residual current device compatibility ........................................................
93Implementing the Emergency stop function ....................................................
93Implementing the Safe torque off function .....................................................
93Implementing the undervoltage control (Power-loss ride-through) .........................
94Implementing the functions provided by the FSO-xx safety functions module ............
94Using power factor compensation capacitors with the drive .................................
94Using a safety switch between the drive and the motor ......................................
94Implementing an ATEX-certified motor thermal protection ...................................
95Controlling a contactor between drive and motor .............................................
95Implementing a bypass connection .............................................................
96Example bypass connection ..................................................................
96Switching the motor power supply from drive to direct-on-line .......................
97Switching the motor power supply from direct-on-line to drive .......................
97Protecting the contacts of relay outputs ........................................................
8 Electrical installation
99Contents of this chapter ...........................................................................
99Safety ................................................................................................
99Grounding the motor cable shield at the motor end ..........................................
100Measuring the insulation ..........................................................................
100Measuring the insulation of the drive ........................................................
100Measuring the insulation of the input power cable ........................................
100Measuring the insulation of the motor and motor cable ..................................
100Grounding system compatibility check ..........................................................
101Installing the EMC filter (option +E202) .........................................................
101Connecting the power cables ....................................................................
102Power cable connection diagram ............................................................
104Preparing the cable ends and making 360-degree grounding at the cable entry .....
105Power cable connection procedure ..........................................................
106Removing the control panel holder from the external control unit ..........................
106Attaching the control cable clamp plate ........................................................
107Connecting the external control unit to the drive module ....................................
107External control unit connection cables .....................................................
108Routing the external control unit cables into the drive module ..........................
108Connecting control cables to the drive module ............................................
108Connecting control cables to the control unit ...............................................
109Attaching the external control unit ...............................................................
110Attaching the external control unit to a mounting plate or wall ...........................
8 Table of contents

110Attaching the external control unit vertically on a DIN rail ................................
111Attaching the external control unit horizontally on a DIN rail .............................
112Connecting the control cables to the terminals of the external control unit ................
112Connecting a control panel .......................................................................
113Panel bus (Control of several units from one control panel) .................................
116Panel bus wiring with FDPI-02 – single drive ..............................................
117Panel bus wiring with FDPI-02 and ZDPI-01 – several drives ...........................
117Panel bus wiring with FDPI-02 – several drives ...........................................
118Connecting a PC ...................................................................................
118Installing option modules .........................................................................
118Installing the FSO-xx safety functions module .............................................
119Installing I/O extension, fieldbus adapter and pulse encoder interface modules .....
120Wiring the option modules ....................................................................
9 External control unit
121Contents of this chapter ...........................................................................
122ZCU-14 layout ......................................................................................
123Default I/O diagram of the drive control unit (ZCU-1x) .......................................
125Additional information on the connections .....................................................
125External power supply for the control unit (XPOW) .......................................
125DI6 as a PTC sensor input ....................................................................
125AI1 or AI2 as a Pt100, Pt1000, PTC or KTY84 sensor input .............................
126DIIL input ........................................................................................
126The XD2D connector ..........................................................................
127Safe torque off (XSTO) ........................................................................
127FSO-xx safety functions module connection (X12) ........................................
128Connector data .....................................................................................
130ZCU-1x ground isolation diagram ............................................................
10 Installation example of the standard drive module configuration in Rittal VX25
enclosure
131Contents of this chapter ...........................................................................
131Limitation of liability ................................................................................
131Safety ................................................................................................
132Required parts ......................................................................................
132Required tools ......................................................................................
132Overall flowchart of the installation process ...................................................
133Installing the drive module and LCL filter module into an enclosure .......................
134Connecting the motor cables and installing the shrouds .....................................
135Connecting the input cables and installing the shrouds ......................................
136Installing the air baffles ............................................................................
137Installing the roof and door (Rittal parts) .......................................................
138Removing the protective covering from the drive module and LCL filter module air outlet .
11 Installation example with full cabling panels (option +H381)
139Contents of this chapter ...........................................................................
139Limitation of liability ................................................................................
139Safety ................................................................................................
140Required parts ......................................................................................
140Required tools ......................................................................................
141Overall flowchart of the installation process ...................................................
Table of contents 9

141Installing the mechanical accessories into a enclosure ......................................
143Connecting the power cables ....................................................................
143Connection diagram ............................................................................
144Power cable connection procedure ..........................................................
146Installing the drive module into the enclosure .................................................
147Installation procedure ..........................................................................
148Assembly drawing of connecting the drive module to the cabling panels ..........
149Installing air baffles (non-ABB parts) ............................................................
149Miscellaneous ......................................................................................
149Installing the rubber grommet ................................................................
12 Installation checklist
151Contents of this chapter ...........................................................................
151Checklist .............................................................................................
13 Start-up
153Contents of this chapter ...........................................................................
153Start-up procedure .................................................................................
14 Fault tracing
155Contents of this chapter ...........................................................................
155LEDs .................................................................................................
155Warning and fault messages .....................................................................
15 Maintenance
157Contents of this chapter ...........................................................................
157Maintenance intervals .............................................................................
157Descriptions of symbols .......................................................................
157Recommended annual maintenance actions by the user ................................
158Recommended maintenance intervals after start-up ......................................
158Recommended functional safety actions ...................................................
158Cleaning the interior of the cabinet ..............................................................
159Cleaning the interior of the heatsink ............................................................
160Cleaning the interior of the LCL filter ............................................................
160Fans ..................................................................................................
160Replacing the auxiliary cooling fans of the drive module .................................
161Replacing the drive module main cooling fans .............................................
162Replacing the LCL filter module cooling fan ................................................
163Replacing the standard drive module ...........................................................
166Replacing the LCL filter module .................................................................
166Replacing the drive module with option +H381 ................................................
168Replacing the LCL filter module with option +H381 ..........................................
169Capacitors ...........................................................................................
169Reforming the capacitors ......................................................................
169Control panel .......................................................................................
169Cleaning the control panel ....................................................................
169Replacing the battery ..........................................................................
170Replacing the ZCU-14 control unit battery .....................................................
171Replacing the ZCU-12 control unit battery .....................................................
171Memory unit .........................................................................................
171Replacing the memory unit of ZCU-14 ......................................................
10 Table of contents

171Replacing the memory unit of the line-side converter control unit (ZCU-12) ..........
172Functional safety components ...................................................................
16 Ordering information
173Contents of this chapter ...........................................................................
173ACS-AP-W and ACS-AP-I control panel .......................................................
173Control panel mounting platforms ...............................................................
174Output (du/dt) filters ...............................................................................
174Sine filters ...........................................................................................
174EMC filter ARFI-10 .................................................................................
174Cabinet ventilation .................................................................................
174Air inlet kits ......................................................................................
176Air outlet kits ....................................................................................
177Cooling fans ........................................................................................
178FSO accessories kit ...............................................................................
178Control panel mounting platforms ...............................................................
178Retrofit accessory kits .............................................................................
17 Technical data
179Contents of this chapter ...........................................................................
179Ratings ..............................................................................................
181When is derating necessary ..................................................................
181Surrounding air temperature derating .......................................................
182Altitude derating ................................................................................
182Deratings for special settings in the drive control program ...............................
184High speed mode ...........................................................................
185Derating for output voltage boosting .........................................................
185400 V and 500 V drive types ..............................................................
185575 V and 690 V drives ....................................................................
187Fuses (IEC) .........................................................................................
188Fuses (UL) ..........................................................................................
189Circuit breakers (UL) ..............................................................................
189Dimensions, weights and free space requirements ...........................................
190Losses, cooling data and noise ..................................................................
190Typical power cable sizes .........................................................................
191Terminal and entry data for the power cables .................................................
192Units with optional cabling panels (+H381) .................................................
192
Units without full-size output cable connection terminals (+0H371) and with a common
mode filter (+E208) .............................................................................
192Terminal data for the control cables .............................................................
192Electrical power network specification ..........................................................
193Motor connection data ............................................................................
194DC connection data ................................................................................
194Control panel type .................................................................................
195Efficiency ............................................................................................
195Protection classes for module ....................................................................
195Ambient conditions ................................................................................
196Materials .............................................................................................
197Applicable standards ..............................................................................
197Markings .............................................................................................
Table of contents 11

198EMC compliance (IEC/EN 61800-3:2004) .....................................................
198Definitions .......................................................................................
198Category C2 .....................................................................................
199Category C3 .....................................................................................
200Category C4 .....................................................................................
200UL and CSA checklist .............................................................................
201EU Declaration of Conformity (Machinery Directive) .........................................
201Disclaimers .........................................................................................
201Generic disclaimer .............................................................................
202Cybersecurity disclaimer ......................................................................
18 Dimension drawings
203Contents of this chapter ...........................................................................
204Standard configuration ............................................................................
205Location of power cable connection terminals with options +H370, +H356 ...............
206Drive module with options +0B051+H356+0H371 ............................................
207Configuration with option +H381 ................................................................
208LCL filter module ...................................................................................
209Bottom plate ........................................................................................
210Air baffles ............................................................................................
210Material of the air baffles ......................................................................
211Air baffles for option +H381 in 800 mm wide Rittal VX25 enclosure .......................
212External control unit ...............................................................................
19 Example circuit diagrams
213Contents of this chapter ...........................................................................
213Example circuit diagram ..........................................................................
20 The Safe torque off function
215Contents of this chapter ...........................................................................
215Description ..........................................................................................
216Compliance with the European Machinery Directive ......................................
217Wiring ................................................................................................
217Activation switch ................................................................................
217Cable types and lengths .......................................................................
217Grounding of protective shields ..............................................................
218Single drive (internal power supply) .........................................................
218Dual-channel connection ..................................................................
219Single-channel connection ................................................................
220Multiple drives ...................................................................................
220Internal power supply ......................................................................
221External power supply ......................................................................
222Operation principle .................................................................................
223Start-up including validation test .................................................................
223Competence .....................................................................................
223Validation test reports ..........................................................................
223Validation test procedure ......................................................................
225Use ...................................................................................................
226Maintenance ........................................................................................
226Competence .....................................................................................
227Fault tracing .........................................................................................
12 Table of contents

228Safety data ..........................................................................................
228Abbreviations ...................................................................................
229TÜV certificate ..................................................................................
230Declaration of conformity ......................................................................
21 Filters
231Contents of this chapter ...........................................................................
231du/dtfilters ..........................................................................................
231When is a du/dtfilter necessary? ............................................................
231Selection table ..................................................................................
231Ordering codes .................................................................................
232Description, installation and technical data of the FOCH filters .........................
232Sine filters ...........................................................................................
232When is a sine filter necessary? .............................................................
232Selection table ..................................................................................
232ABB ordering codes ............................................................................
232Derating ..........................................................................................
232Description, installation and technical data of the sine filters ............................
22 Step-by-step drawings for an installation example of standard drive
configuration in Rittal VX25 800 mm wide enclosure
233Handling the drive module, power cable connection diagram ...............................
235Installing the drive module and LCL filter module into a Rittal VX25 enclosure ..........
240Connecting the motor cables and installing the shrouds .....................................
243Connecting the input power cables and installing the shrouds ..............................
244Installing the air baffles and removing the cardboard covers ................................
Further information
Table of contents 13

14

Safety instructions
Contents of this chapter
This chapter contains the safety instructions which you must obey when you install, start
up, operate and do maintenance work on the drive. If you ignore the safety instructions,
injury, death or damage can occur.
Use of warnings and notes
Warnings tell you about conditions which can cause injury or death, or damage to the
equipment. They also tell you how to prevent the danger. Notes draw attention to a particular
condition or fact, or give information on a subject.
The manual uses these warning symbols:
WARNING!
Electricity warning tells about hazards from electricity which can cause injury or
death, or damage to the equipment.
WARNING!
General warning tells about conditions, other than those caused by electricity,
which can cause injury or death, or damage to the equipment.
WARNING!
Electrostatic sensitive devices warning tells you about the risk of electrostatic
discharge which can cause damage to the equipment.
1
Safety instructions 15

General safety in installation, start-up and maintenance
These instructions are for all personnel who do work on the drive.
WARNING!
Obey these instructions. If you ignore them, injury or death, or damage to the
equipment can occur.
•Keep the drive in its package until you install it. After unpacking, protect the drive from
dust, debris and moisture.
•Use the required personal protective equipment: safety shoes with metal toe cap, safety
glasses, protective gloves and long sleeves, etc. Some parts have sharp edges.
•Lift a heavy drive with a lifting device. Use the designated lifting points. See the dimension
drawings.
•Incorrect lifting can cause danger or damage. Obey the local laws and regulations
applicable to lifting, such as requirements for planning the lift, for capacity and condition
of lifting equipment, and for training of personnel.
•Attach the drive cabinet to the floor to prevent it from toppling over. The cabinet has a
high center of gravity. When you pull out heavy components or power modules, there is
a risk of overturning. Attach the cabinet also to the wall when necessary.
•Do not use the module extraction/installation ramp with plinth heights which exceeds the
maximum allowed height.
•Attach the module extraction/installation ramp carefully.
16 Safety instructions
3

•Make sure that the module does not topple over when you move it on the floor: To open
the support legs, press each leg a little down and turn it aside (1, 2). Whenever possible
attach the module also with chains. Do not tilt the drive module. It is heavy and its center
of gravity is high. The module overturns from a sideways tilt of 5 degrees. Do not leave
the module unattended on a sloping floor.
1
2
3
•To prevent the drive module from falling, attach its top lifting lugs with chains to the
cabinet (1) before you push the module into the cabinet and pull it from the cabinet. Push
the module into the cabinet and pull it from the cabinet carefully preferably with help from
another person. Keep a constant pressure with one foot on the base of the module (2)
to prevent the module from falling on its back.
1
2
1
2
Safety instructions 17

•Beware of hot surfaces. Some parts, such as heatsinks of power semiconductors, and
brake resistors, remain hot for a while after disconnection of the electrical supply.
•Vacuum clean the area around the drive before the start-up to prevent the drive cooling
fan from drawing the dust inside the drive.
•Make sure that debris from drilling, cutting and grinding does not enter the drive during
the installation. Electrically conductive debris inside the drive may cause damage or
malfunction.
•Make sure that there is sufficient cooling. See the technical data.
•Keep the cabinet doors closed when the drive is powered. With the doors open, a risk
of a potentially fatal electric shock, arc flash or high-energy arc blast exists. If you cannot
avoid working on a powered drive, obey the local laws and regulations on live working
(including – but not limited to – electric shock and arc protection).
•Before you adjust the drive operation limits, make sure that the motor and all driven
equipment can operate throughout the set operation limits.
•Before you activate the automatic fault reset or automatic restart functions of the drive
control program, make sure that no dangerous situations can occur. These functions
reset the drive automatically and continue operation after a fault or supply break. If these
functions are activated, the installation must be clearly marked as defined in
IEC/EN 61800-5-1, subclause 6.5.3, for example, "THIS MACHINE STARTS
AUTOMATICALLY".
•The maximum drive power cycles is five times in ten minutes. Power cycling the drive
too often can damage the charging circuit of the DC capacitors.
•If you have connected safety circuits to the drive (for example, Safe torque off or
emergency stop), validate them at start-up. See separate instructions for the safety
circuits.
• Beware of hot air exiting from the air outlets.
• Do not cover the air inlet or outlet when the drive is running.
Note:
• If you select an external source for the start command and it is on, the drive will start
immediately after fault reset unless you configure the drive for pulse start. See the firmware
manual.
• If the drive is in remote control mode, you cannot stop or start the drive with the control
panel.
• Only authorized persons are allowed to repair a malfunctioning drive.
Electrical safety in installation, start-up and maintenance
￭Electrical safety precautions
These electrical safety precautions are for all personnel who do work on the drive, motor
cable or motor.
18 Safety instructions
3

WARNING!
Obey these instructions. If you ignore them, injury or death, or damage to the
equipment can occur.
If you are not a qualified electrical professional, do not do installation or
maintenance work.
Go through these steps before you begin any installation or maintenance work.
1. Clearly identify the work location and equipment.
2. Disconnect all possible voltage sources. Make sure that re-connection is not possible.
Lock out and tag out.
•Open the main disconnecting device of the drive.
•Open the charging switch if present.
•Open the disconnector of the supply transformer. (The main disconnecting device in
the drive cabinet does not disconnect the voltage from the AC input power busbars
of the drive cabinet.)
•Open the auxiliary voltage switch-disconnector (if present), and all other possible
disconnecting devices that isolate the drive from dangerous voltage sources.
•If you have a permanent magnet motor connected to the drive, disconnect the motor
from the drive with a safety switch or by other means.
•Disconnect all dangerous external voltages from the control circuits.
•After you disconnect power from the drive, always wait 5 minutes to let the intermediate
circuit capacitors discharge before you continue.
3. Protect any other energized parts in the work location against contact.
4. Take special precautions when close to bare conductors.
5. Measure that the installation is de-energized. If the measurement requires removal or
disassembly of shrouding or other cabinet structures, obey the local laws and regulations
applicable to live working (including – but not limited to – electric shock and arc
protection).
•Before and after measuring the installation, verify the operation of the voltage tester
on a known voltage source.
•Make sure that the voltage between the drive input power terminals (L1, L2, L3) and
the grounding (PE) busbar is zero.
•Make sure that the voltage between the drive output terminals (T1/U, T2/V, T3/W)
and the grounding (PE) busbar is zero.
•Make sure that the voltage between the drive DC terminals (UDC+ and UDC-) and
the grounding (PE) terminal is zero.
6. Install temporary grounding as required by the local regulations.
7. Ask the person in control of the electrical installation work for a permit to work.
Safety instructions 19

￭Additional instructions and notes
WARNING!
Obey these instructions. If you ignore them, injury or death, or damage to the
equipment can occur.
If you are not a qualified electrical professional, do not do installation or
maintenance work.
•Keep the cabinet doors closed when the drive is powered. With the doors open, a risk
of a potentially fatal electric shock, arc flash or high-energy arc blast exists.
•Make sure that the electrical power network, motor/generator, and environmental
conditions agree with the drive data.
•Do not do insulation or voltage withstand tests on the drive.
•If you have a cardiac pacemaker or other electronic medical device, keep away from the
area near motor, drive, and the drive power cabling when the drive is in operation. There
are electromagnetic fields present which can interfere with the function of such devices.
This can cause a health hazard.
•Remove the code labels attached to mechanical parts such as busbars, shrouds and
sheet metal parts before installation. They may cause bad electrical connections, or,
after peeling off and collecting dust in time, cause arcing or block the cooling air flow.
Note:
•The motor cable terminals of the drive are at a dangerous voltage when the input power
is on, regardless of whether the motor is running or not.
•When the input power is on, the drive DC bus is at a dangerous voltage.
•External wiring can supply dangerous voltages to the relay outputs of the control units
of the drive.
•The Safe torque off function does not remove the voltage from the main and auxiliary
circuits. The function is not effective against deliberate sabotage or misuse.
Optical components
WARNING!
Obey these instructions. If you ignore them, damage to the equipment can occur.
•Handle the fiber optic cables with care.
•When you unplug the fiber optic cables, always hold the connector, not the cable itself.
•Do not touch the ends of the fibers with bare hands as the ends are extremely sensitive
to dirt.
•Do not bend the fiber optic cables too tightly. The minimum allowed bend radius is 35 mm
(1.4 in).
Printed circuit boards
WARNING!
Use a grounding wrist band when you handle printed circuit boards. Do not touch
the boards unnecessarily. The boards contain components sensitive to electrostatic
discharge.
20 Safety instructions
3
