ABB ACS880 Series User manual

—
ABB INDUSTRIAL DRIVES
User’s manual
ATEX-certified motor thermal protection
functions for cabinet-built ACS880 drives
(options +L513+Q971 and +L514+Q971)
00 ACS880 ATEX cabinet.book Page 1 Tuesday, May 28, 2019 10:25 AM

—
List of related manuals
You can find manuals and other product documents in PDF format on the Internet. See section
Document library on the Internet on the inside of the back cover. For manuals not available in the
Document library, contact your local ABB representative.
General drive manuals Code (English)
Safety instructions for ACS880 multidrive cabinets and modules 3AUA0000102301
Mechanical installation instructions for ACS880 multidrive
cabinets
3AUA0000101764
Electrical planning instructions for ACS880 multidrive cabinets
and modules
3AUA0000102324
Drive hardware manuals
ACS880-07 (45 to 630 kW, 50 to 700 hp) hardware manual 3AUA0000105718
ACS880-07 (560 to 2800 kW) hardware manual 3AUA0000143261
ACS880-17 drives hardware manual 3AXD50000020436
ACS880-37 drives hardware manual 3AXD50000020437
ACS880-107 inverter units hardware manual 3AUA0000102519
ACS880-07CLC drives hardware manual 3AXD50000131457
Drive firmware manuals
ACS880 primary control program firmware manual 3AUA0000085967
PC tool manuals
Start-up and maintenance PC tool Drive composer user’s manual 3AUA0000094606
Drive option manuals
ACS-AP-x Assistant control panels user’s manual 3AUA0000085685
Prevention of unexpected start-up (+Q950) for ACS880
multidrives user’s manual
3AUA0000145934
Prevention of unexpected start-up (+Q950) for
ACS880-07/17/37 drives user’s manual
3AUA0000145922
Safely-limited speed with the encoder interface (+Q965) for
ACS880-07/17/37 drives user’s manual
3AXD50000019727
Safely-limited speed with the encoder interface (+Q965) for
ACS880 multidrives user’s manual
3AXD50000019728
Safely-limited speed without the encoder interface (+Q966) for
ACS880 multidrives user’s manual
3AUA0000145935
Emergency stop, configurable stop category 0 or 1 (+Q978) for
ACS880-07/17/37 drives user’s manual
3AUA0000145920
Emergency stop, configurable stop category 0 or 1 (+Q979) for
ACS880 multidrives user’s manual
3AUA0000145933
Emergency stop, configurable stop category 0 or 1 (+Q979) for
ACS880-07/17/37 drives user’s manual
3AUA0000145921
FSO-12 safety functions module user’s manual 3AXD50000015612
FSO-21 safety functions module user’s manual 3AXD50000015614
FSE-31 pulse encoder interface module user’s manual 3AXD50000016597
Manuals and quick guides for I/O extension modules, fieldbus
adapters, etc.
General safety guides
Functional safety; Technical guide No. 10 3AUA0000048753
Safety and functional safety; A general guide 1SFC001008B0201
ABB Safety information and solutions www.abb.com/safety
Potentially explosive atmospheres. The basics you need to know
about motors and drives
3AUA0000037223
00 ACS880 ATEX cabinet.book Page 2 Tuesday, May 28, 2019 10:25 AM

User’s manual
ATEX-certified motor thermal protection functions for
cabinet-built ACS880 drives
(options +L513+Q971 and +L514+Q971)
3AXD50000014979 Rev C
EN
EFFECTIVE: 2019-05-22
2019 ABB Oy. All Rights Reserved.
Table of contents
00 ACS880 ATEX cabinet.book Page 3 Tuesday, May 28, 2019 10:25 AM

00 ACS880 ATEX cabinet.book Page 4 Tuesday, May 28, 2019 10:25 AM

5
Table of contents
1. Introduction to the manual
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Applicability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Example circuit diagrams of this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Commissioning the drive for a motor in a hazardous area . . . . . . . . . . . . . . . . . . . . . . . 11
Minimum switching frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Target audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Related documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Terms and abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Exclusion of liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2. ATEX-certified motor thermal protection function with PTC thermistor relays
(+L513+Q971)
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Operation principle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Without an FSO module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
With an FSO module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Resetting the ATEX-certified motor thermal protection function . . . . . . . . . . . . . . . . . . . 19
Indications of the ATEX-certified motor thermal protection function . . . . . . . . . . . . . . . . 19
PTC thermistor relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
ABB CM-MSS.41 thermistor motor protection relay . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Operation diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
DOLD MK 9163N.12/110-ATEX thermistor relay . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Operation diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
General wiring instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Wiring example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Start-up and acceptance test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Checks and settings with no voltage connected . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Settings with voltage connected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Acceptance test procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Fault tracing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Safety data and block diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Without an FSO module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
With an FSO module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3. ATEX-certified motor thermal protection function with Pt100 relays (+L514+Q971)
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
00 ACS880 ATEX cabinet.book Page 5 Tuesday, May 28, 2019 10:25 AM

6
Pt100 relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Operation principle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Without an FSO module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
With an FSO module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Resetting the ATEX-certified motor thermal protection function . . . . . . . . . . . . . . . . . . 34
Indications of the ATEX-certified motor thermal protection function . . . . . . . . . . . . . . . 34
Pt100 relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
GM International D1073S relay (programmable) . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
PRelectronics 9116B1 universal converter relay (programmable) . . . . . . . . . . . . . . 36
Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Pt100 relay programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
General wiring instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Wiring example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Start-up and acceptance test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Checks and settings with no voltage connected . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Settings with voltage connected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Acceptance test procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Fault tracing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Safety data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Without an FSO module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
With an FSO module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4. Parameter settings
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Drive / inverter unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Switching frequency limitation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Reset method and status indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
31.22 STO indication run/stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Motor overtemperature indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
31.11 Fault reset selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Other recommended settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
FSO module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
General parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Parameters for the STO function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Parameters for the SSE function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Parameters for the SS1 function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
SS1 ramp parameters in the drive/inverter unit . . . . . . . . . . . . . . . . . . . . . . . . . . 52
FSE module and safety pulse encoder parameters . . . . . . . . . . . . . . . . . . . . . . . . . 52
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Mechanical brake control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
5. Technical data
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
The ATEX-certified motor thermal protection functions . . . . . . . . . . . . . . . . . . . . . . . . . 55
PTC thermistor relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
ABB CM-MSS.41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Power supply A1-A2 (non-isolated) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Measuring circuit /Sensor circuit T1-T2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
00 ACS880 ATEX cabinet.book Page 6 Tuesday, May 28, 2019 10:25 AM

7
Control circuit S1-T2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Indication of operating states . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Operating controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Output circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Ambient temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Isolation data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
DOLD MK 9163N.12/110-ATEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Power supply A1-A2 (non-isolated) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Measuring circuit P1-P2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Reset circuit X1/X2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Output contacts (terminals 11-12/14, 21-22/24) . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Indication of operating states . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Ambient temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Pt100 relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
GM International D1073S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Power supply (terminals 3-4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Measuring circuit (terminals 13-16) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Current output (terminals 1-2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Output contacts (terminals 5-8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Isolation data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Indication of operating states . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Ambient temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Isolation data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
PRelectronics 9116B1 universal converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Power supply (terminals 32-31) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Status relay in safe area (terminals 33-34) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Measuring circuit/RTD input (terminals 41-44) . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
TC, linear resistance or potentiometer inputs (terminals 41-44) . . . . . . . . . . . . . . 62
Current output (terminals 12-11) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
2-wire 4...20 mA output (terminals 12-11) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Relay output (terminals 13-14) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Current and voltage inputs (terminals 51-54) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Indication of operating states . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Ambient temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Isolation data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
General rules, notes and definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Validation of the safety functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Validation procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Acceptance test reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
00 ACS880 ATEX cabinet.book Page 7 Tuesday, May 28, 2019 10:25 AM

8
Competence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Ambient conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Reporting problems and failures related to safety functions . . . . . . . . . . . . . . . . . . . 65
Related standards and directives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Markings of the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
ATEX Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
6. Circuit diagrams
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
+2L513+Q971 (PTC monitoring with two relays) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
+2L513+Q971+Q973 (PTC monitoring with two relays and FSO module) – Sheet 60 . 74
+2L513+Q971+Q973 (PTC monitoring with two relays and FSO module) – Sheet 70 . 75
+5L514+Q971+Q973 (Pt100 monitoring with five relays and FSO module) – Sheet 60 76
+5L514+Q971+Q973 (Pt100 monitoring with five relays and FSO module) – Sheet 70 77
Further information
Product and service inquiries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Product training . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Providing feedback on ABB Drives manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Document library on the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
00 ACS880 ATEX cabinet.book Page 8 Tuesday, May 28, 2019 10:25 AM

Introduction to the manual 9
1
Introduction to the manual
Contents of this chapter
This chapter contains information on the manual, gives safety instructions and other
general information for the reader.
Applicability
The manual applies to cabinet-built ACS880 single drives and multidrives with the options:
•+L513+Q971 and +2L513+Q971
(+3L513+Q971 available as an application-engineered option)
•+3L514+Q971, +5L514+Q971 and +8L514+Q971.
The motor thermal protection functions described in this manual are certified, with an
EU-type examination certificate, as protective systems in accordance with the ATEX
Product Directive 2014/34/EU (previously 94/9/EC).
Safety instructions
Only qualified specialists are allowed to install, control and maintain the ATEX-certified
motor thermal protection functions (see EN/IEC 60079-14). Obey all safety regulations
required with application of Ex motors in Zone 1/21 (equipment category 2) or Zone 2/22
(equipment category 2 or 3).
WARNING! Read and obey all safety instructions given for the drive. If you ignore
them, injury or death, or damage to the equipment can occur.
This manual does not repeat the complete safety instructions of the drive but it only
includes the instructions related to the scope of this manual. The general instructions are
given in this section and the option-specific instructions in the appropriate chapter.
00 ACS880 ATEX cabinet.book Page 9 Tuesday, May 28, 2019 10:25 AM

10 Introduction to the manual
In addition to this manual,
•for ACS880 single drives, see the drive hardware manual
•for ACS880 air-cooled multidrives, see Safety instructions for ACS880 multidrive
cabinets and modules (3AUA0000102301 [English]).
The function described in this manual activates the Safe torque off (STO) function of the
drive/inverter unit. The STO function of the ACS880 drives is certified (SIL 3 according to
EN/IEC 61800-5-2 and IEC 61508). For a detailed description of the STO function, see the
hardware manual of your drive/inverter unit.
WARNING! The functions described in this manual do not disconnect the voltage
of the main and auxiliary circuits from the drive. Never work on the electrical parts
of the drive or the motor before you have also disconnected the drive system from
the electric supply, from rotating permanent magnet motors and from rotating motors
equipped with sine filters, and made sure by measuring that there is no dangerous voltage
present.
WARNING! The STO function of ACS880 drives cannot prevent the intermediate
DC current from flowing through, and heating up, the motor in case a short-circuit
occurs in the output stage of the drive. The supplier must take this into account
when planning the protection of the installation.
Note: When you connect the temperature sensor(s) of the Ex motor to the drive STO
terminals through a relay, ensure the availability of required reinforced (double) insulation
between the main circuit (motor) and the control unit. For example, the insulation of the
temperature sensor in the Ex motor and the insulation of the protection relay affect the
insulation of the whole circuit. All Ex motors manufactured by ABB have basic insulation
between the main circuit and the temperature sensor. Similarly, ABB protection relays
have basic insulation between the sensor circuit and relay output. This ensures double
insulation for the ATEX-certified motor thermal protection function between the main circuit
and the drive control unit.
Example circuit diagrams of this manual
The purpose of the example circuit diagrams is to help in understanding the operation of
the ATEX-certified motor thermal protection functions. The diagrams do not cover all
possible details and variants of the drives. The component designations do not necessarily
match each drive.
WARNING! Never connect, test or measure a drive based on the diagrams of this
manual. Each delivery is unique. Before you start the work on the electric circuits
of a drive, always refer to the delivery-specific circuit diagrams.
00 ACS880 ATEX cabinet.book Page 10 Tuesday, May 28, 2019 10:25 AM

Introduction to the manual 11
Commissioning the drive for a motor in a hazardous area
Commission the drive according to the requirements and limitations set by the application,
the motor manufacturer’s instructions, drive firmware manual, local laws and regulations
and this manual.
Minimum switching frequency
The certificate of the Ex motor typically requires that you set a minimum limit for the output
switching frequency of the drive. Make sure that the Ex motor is operated above the
minimum output switching frequency specified by the motor manufacturer. See chapter
Parameter settings for instructions on how to make the setting.
Target audience
The manual is intended for people who install, start-up, use and service the ATEX-certified
motor thermal protection functions of the drive. Read the manual before working on the
drive. You are expected to know the fundamentals of electricity, wiring, electrical
components, electrical schematic symbols and ATEX/Ex regulations.
Contents
This manual contains information on implementing the ATEX-certified motor thermal
protection functions in the ACS880 cabinet-built drives, as well as the ATEX certification
documents.
This manual consists of the following chapters:
•Introduction to the manual introduces this manual, gives safety instructions and other
general information for the reader.
•ATEX-certified motor thermal protection function with PTC thermistor relays
(+L513+Q971) describes how the function is used for protecting the motor with PTC
thermistor relays, and provides the related safety data.
•ATEX-certified motor thermal protection function with Pt100 relays (+L514+Q971)
describes how the function is used for protecting the motor with Pt100 relays, and
provides the related safety data.
•Parameter settings lists the parameters that you have the set for the safety functions.
•Technical data contains the technical specifications of the relays, applicable
standards, ATEX compliance markings and certificates.
•Circuit diagrams contains example circuit diagrams illustrating the operation and
wiring of the functions.
Related documents
•Product manuals (see the inside of the front cover)
•Circuit diagrams delivered with the drive
•Part lists delivered with the drive
00 ACS880 ATEX cabinet.book Page 11 Tuesday, May 28, 2019 10:25 AM

12 Introduction to the manual
Terms and abbreviations
The abbreviations used in this manual are listed below.
Term /
abbreviation
Description Reference
ATEX Directives 2014/34/EU (94/9/EC) and 1999/92/EC are
commonly referred to as the ATEX directives (from
“Atmosphères Explosibles”)
-
BCU Type of drive control unit used in ACS880 drives -
CM-MSS.41 ABB thermistor motor protection relay -
Ex An IEC term used in the context of explosive atmospheres IEC 60079 series
Ex d Type of protection, flameproof enclosures EN/IEC 60079-1
Ex e Type of protection, increased safety, to be replaced with
Ex eb
EN 60079-7:2007 and
IEC 60079-7:2006
Ex eb, Ex ec Types of protection, increased safety IEC 60079-7:2015
Ex i Intrinsically safe EN 60079-11:2012 and
IEC 60079-11:2011
Ex motors Motors used in explosive atmospheres -
Ex nA Type of protection, non-sparking enclosures, to be replaced
with Ex ec
EN/IEC 60079-15:2010
Frame (size) Relates to the construction type of the drive in question. For
example, several drive types with different power ratings can
have the same basic construction, and a frame size is used in
reference to all those drive types.
With the ACS880-07 (smaller), the frame size marking of the
drive indicates the physical size of the drive, eg, R6.
With the ACS880-07 (larger), the frame size marking of the
drive indicates the quantity and frame size of the diode supply
modules plus the quantity and frame size of the inverter
modules, eg, “2×D8T +3×R8i”.
With the ACS880-17 and ACS880-37, the frame size marking
of the drive indicates the quantity and frame size of the IGBT
supply modules plus the quantity and frame size of the
inverter modules, eg, “2×R8i +3×R8i”.
-
FSE-31 Pulse encoder interface module which can be used in safety
applications
-
FSO Safety functions module (FSO-12 or FSO-21) -
FSO-12 Safety functions module which does not support the use of
safety encoders
-
FSO-21 Safety functions module which supports the FSE-31 module
and the use of safety encoders
-
FIT Failure in time: 1E-9 hours IEC 61508
HFT Hardware fault tolerance IEC 61508
PFD Probability of dangerous failures on demand IEC 61508
PLC Programmable logic controller -
00 ACS880 ATEX cabinet.book Page 12 Tuesday, May 28, 2019 10:25 AM

Introduction to the manual 13
Exclusion of liability
ABB is not responsible for the implementation, verification and validation of the overall
safety system. It is the responsibility of the end user (or other party) who is responsible for
the overall system, system safety and compliance with ATEX/Ex regulations.
The end user (or other responsible party) must make sure that the entire implementation
complies with all relevant standards, directives and local electrical code, and that the
system is tested, verified and validated correctly.
PTC Positive temperature coefficient; PTC thermistor, PTC resistor
temperature sensor.
-
Pt100 A platinum temperature sensor with a resistance of 100 ohm
at 0 °C (32 °F)
-
RTD Resistance temperature detector -
SAR Safe acceleration range. In the FSO module, there are two
sets of SAR parameters (SAR0 and SAR1) that are used to
define and/or monitor the deceleration ramp in safety
functions. SAR0 parameters are used in the SSE function.
SAR1 parameters are used in the SS1 function.
-
SBC Safe brake control. A safety function in the FSO module. -
SIL Safety integrity level IEC 61508
SS1 Safe stop 1. A safety function in the FSO module. EN/IEC 61800-5-2
SSE Safe stop emergency. A safety function in the FSO module. -
STO Safe torque off. In this manual, this term is used in two
different contexts:
• the STO circuit in the drive (the drive STO function)
• the STO safety function in the FSO module.
Safety functions in the FSO module (eg, STO, SSE and SS1)
activate the drive STO function, that is, open the drive STO
circuit. In addition, some safety functions can activate the
STO safety function in the FSO module, which in turn opens
the drive STO circuit.
EN/IEC 61800-5-2
Stop category 0 Uncontrolled stop EN/IEC 60204-1
Stop category 1 Controlled stop EN/IEC 60204-1
T1 Proof test interval IEC 61508
ZCU Type of drive control unit used in ACS880 drives. -
Zone An IEC term for hazardous areas. Hazardous areas are
divided into zones, according to the degree of hazard. The
degree of hazard is defined according to the probability of the
occurrence of explosive atmospheres.
EN/IEC 60079 series
Term /
abbreviation
Description Reference
00 ACS880 ATEX cabinet.book Page 13 Tuesday, May 28, 2019 10:25 AM

14 Introduction to the manual
00 ACS880 ATEX cabinet.book Page 14 Tuesday, May 28, 2019 10:25 AM

ATEX-certified motor thermal protection function with PTC thermistor relays (+L513+Q971) 15
2
ATEX-certified motor thermal
protection function with PTC
thermistor relays (+L513+Q971)
Contents of this chapter
This chapter describes the ATEX-certified motor thermal protection function
(option +L513+Q971) and gives instructions on how to wire, install and start up the
function. It also describes the PTC thermistor relays available for the option and gives fault
tracing and maintenance instructions. The safety data is also given.
00 ACS880 ATEX cabinet.book Page 15 Tuesday, May 28, 2019 10:25 AM

16 ATEX-certified motor thermal protection function with PTC thermistor relays (+L513+Q971)
Description
This protection function monitors the temperature of a motor with PTC resistor sensors
(PTC thermistors) in a potentially explosive atmosphere. It is possible to
•monitor either the motor’s bearings or windings (+L513+Q971) or
•monitor both the motor’s bearings and windings (+2L513+Q971 or +3L513+Q971).
The function is activated when the PTC sensor resistance exceeds the overtemperature
limit. The function activates the Safe torque off (STO) function of the drive. This disables
the control voltage of the power semiconductors of the drive output stage. This prevents
the inverter from generating the torque required to rotate the motor. The motor coasts to a
stop.
ACS880-07/17/37 drives with the option +Q978: Also the main contactor/breaker is
opened.
ACS880-07 drives, frames nxDXT + nxR8i with a main contactor/breaker (option +F250/
+F255) and ACS880-17/37 drives, frames nxR8i + nxR8i: When the STO function is
activated in the inverter unit, the main contactor/breaker is opened after user-defined delay
(defined with parameter 94.11, the default value is 600 s). See hardware and firmware
manuals for more information.
Other safety functions in the drive can also use the STO function. In addition, the FSO
module can be included in the activation sequence of the ATEX-certified motor thermal
protection function. See the circuit diagrams delivered with the drive for the actual safety
circuitry.
The FSO safety functions module (FSO-12 or FSO-21) is an optional device used with the
ACS880 drives to implement safety functions. When installed, it reserves the standard
STO connection of the drive. In this case, the FSO module activates the STO function of
the drive (that is, opens the drive STO circuit) either immediately or after a deceleration
ramp.
You can implement the motor thermal protection function with or without an FSO safety
functions module:
•Without an FSO module, the opening contacts of the PTC relay(s) open the STO
circuit of the drive (see section Without an FSO module on page17).
•With an FSO module, the opening contacts of the PTC relay(s) activate the STO or
Safe stop 1 (SS1) function of the FSO module and the FSO module opens the STO
circuit of the drive (see section With an FSO module on page 18). For more
information on the safety functions of the FSO module, see FSO-12 safety functions
module user’s manual (3AXD50000015612 [English]) or FSO-21 safety functions
module user’s manual (3AXD50000015614 [English]).
Always consider which stop category (0 = immediate STO or 1 = delayed STO after SS1)
is more appropriate for the motor in overtemperature situations.
The protection function circuit is motor specific, also in multidrives where several motors
are connected. The function stops only the motor where overtemperature is detected.
It is possible to get information on the status of the protection function by means of a
normally-open contact. The information can be obtained separately from the bearing and
stator thermistors. The contact can be wired to a digital input on the drive control unit or to
an external control system. For instructions, see section Wiring on page 23.
The temperature measurement circuit of ABB Ex motors has basic insulation. For
information on the insulation of the thermistor relays, see its data starting on page 56.
00 ACS880 ATEX cabinet.book Page 16 Tuesday, May 28, 2019 10:25 AM

ATEX-certified motor thermal protection function with PTC thermistor relays (+L513+Q971) 17
Operation principle
Without an FSO module
1. When the motor temperature rises to the thermistor wake-up level, the resistance of
the thermistor increases sharply.
2. The PTC thermistor relay detects the change and indicates motor overtemperature
through its output contacts.
3. The opening contacts of the PTC relay(s) open the STO circuit of the drive. This
prevents the drive from generating the torque required to rotate the motor.
4. The drive generates an STO indication (parameter 31.22, see page 44).
5. If the auxiliary contacts of the PTC relays are wired to a digital input, the loss of the
signal triggers a motor overtemperature indication in the drive (see page 44).
6. After the motor temperature has decreased to normal, the user resets the PTC relay(s)
using remote reset buttons (or the buttons on the PTC relays themselves). See the
circuit diagrams of the delivery.
7. Optional: The user resets the drive faults either from the reset source defined by the
user (parameter 31.11, see page 45) or locally with the drive control panel:
•the STO fault in the drive (if configured with drive parameter 31.22, see page 44)
•the motor overtemperature fault in the drive (if configured, see page 44).
WARNING! We recommend that you do not use the autoreset setting (that is,
short-circuit the reset switch terminals of the PTC relay) with a safety device
protecting an Ex motor.
00 ACS880 ATEX cabinet.book Page 17 Tuesday, May 28, 2019 10:25 AM

18 ATEX-certified motor thermal protection function with PTC thermistor relays (+L513+Q971)
With an FSO module
1. When the motor temperature rises to the thermistor wake-up level, the resistance of
the thermistor increases sharply.
2. The PTC thermistor relay detects the change and indicates motor overtemperature
through its output contacts.
3. The opening contacts of the PTC relay(s) switch off the voltage to terminal X113:4 of
the FSO module (this is configured as the input of the STO [or SS1] function in the
FSO module).
4. The FSO module opens the STO circuit of the drive either immediately (STO function)
or after a deceleration ramp (SS1 function). This prevents the drive from generating
the torque required to rotate the motor.
5. The drive generates an STO indication (parameter 31.22, see page 44).
6. The FSO module generates an STO indication (parameter FSOGEN.61, see
page 47).
7. If the auxiliary contacts of the PTC relay(s) are wired to a digital input, the loss of the
signal triggers a motor overtemperature indication (see page 44).
8. After the motor temperature has decreased to normal, the user resets the PTC relay(s)
using remote reset buttons (or the buttons on the PTC relays themselves). See the
circuit diagrams of the delivery.
9. Optional: The user resets the drive faults either from the reset source defined by the
user (parameter 31.11, see page 45) or locally with the drive control panel:
•the STO fault in the drive (if configured with drive parameter 31.22, see page 44)
•the motor overtemperature fault in the drive (if configured, see page 44),
10. Optional: The user resets the safety function in the FSO module with the reset button
(if a reset circuit is wired and configured, see page 46 and the next section).
00 ACS880 ATEX cabinet.book Page 18 Tuesday, May 28, 2019 10:25 AM

ATEX-certified motor thermal protection function with PTC thermistor relays (+L513+Q971) 19
WARNING! We recommend that you do not use the autoreset setting (that is,
short-circuit the reset switch terminals of the PTC relay) with a safety device
protecting an Ex motor.
Resetting the ATEX-certified motor thermal protection
function
A manual reset is mandatory in the temperature protection function, if it is required for
ensuring the compliance of the system with Ex/ATEX regulations.The manual reset is set
in the ATEX-certified PTC thermistor relay at the factory. This makes sure that the ATEX
requirement on manual reset is fulfilled and you do not have to configure any faults in the
drive (or FSO) parameters.
If you change the manual reset setting in the PTC thermistor relay, make sure that the user
cannot restart the drive without a manual reset.
You can configure the manual reset either in:
•the drive with the motor overtemperature or STO indication parameters (see
page 44)
•the FSO module by connecting a reset circuit to the FSO module (see page 46).
ACS880-07/17/37 drives with the option +Q978 or +Q979 (Emergency stop): In these
safety functions, a reset circuit is connected to the FSO module and the user must reset
the safety function with the emergency stop reset button. In this case, the user must reset
also the ATEX-certified motor thermal protection function with the emergency stop reset
button. Do not change this setting.
Indications of the ATEX-certified motor thermal
protection function
An indication of the safety function can come from several sources:
•the motor overtemperature indication in the drive
•the STO indication in the drive
•the STO indication in the FSO module.
If you want to avoid parallel indications in overtemperature situations, you can set one or
several of the indication parameters value to No indication (or None) or Event:
•the motor overtemperature indication with drive parameters 31.01...31.02 or
35.11...35.12 (see page 44),
•the STO indication in the drive with drive parameter 31.22 STO indication run/stop
(see page 44),
•the STO indication in the FSO module with FSO parameter FSOGEN.61 STO
indication ext request (see page 47).
Note: If the PTC thermistor relay is not in the manual reset mode, make sure that at least
one of these indications generates a fault.
00 ACS880 ATEX cabinet.book Page 19 Tuesday, May 28, 2019 10:25 AM

20 ATEX-certified motor thermal protection function with PTC thermistor relays (+L513+Q971)
PTC thermistor relays
The ATEX-certified motor thermal protection function contains one (+L513) or two
(+2L513) ABB CM-MSS.41 thermistor relays by default. Three ABB CM-MSS.41
thermistor relays (+3L513) are available as an application-engineered option.
DOLD MK 9163N.12/110-ATEX thermistor relay(s) are available by request.
00 ACS880 ATEX cabinet.book Page 20 Tuesday, May 28, 2019 10:25 AM
