Abb Relion 615 series User manual

Relion® 615 series

Voltage Protection and Control

REU615

DNP3 Point List Manual

Document ID: 1MRS757056

Issued: 2010-06-11

Revision: A

Product version: 3.0

This document and parts thereof must not be reproduced or copied without written

permission from ABB, and the contents thereof must not be imparted to a third

party, nor used for any unauthorized purpose.

The software or hardware described in this document is furnished under a license

and may be used, copied, or disclosed only in accordance with the terms of such

license.

Trademarks

ABB and Relion are registered trademarks of ABB Group. All other brand or

product names mentioned in this document may be trademarks or registered

trademarks of their respective holders.

Warranty

Please inquire about the terms of warranty from your nearest ABB representative.

ABB Oy

Distribution Automation

P.O. Box 699

FI-65101 Vaasa, Finland

Telephone: +358 10 2211

Facsimile: +358 10 22 41094

http://www.abb.com/substationautomation

Disclaimer

The data, examples and diagrams in this manual are included solely for the concept

or product description and are not to be deemed as a statement of guaranteed

properties. All persons responsible for applying the equipment addressed in this

manual must satisfy themselves that each intended application is suitable and

acceptable, including that any applicable safety or other operational requirements

are complied with. In particular, any risks in applications where a system failure and/

or product failure would create a risk for harm to property or persons (including but

not limited to personal injuries or death) shall be the sole responsibility of the

person or entity applying the equipment, and those so responsible are hereby

requested to ensure that all measures are taken to exclude or mitigate such risks.

This document has been carefully checked by ABB but deviations cannot be

completely ruled out. In case any errors are detected, the reader is kindly requested

to notify the manufacturer. Other than under explicit contractual commitments, in

no event shall ABB be responsible or liable for any loss or damage resulting from

the use of this manual or the application of the equipment.

Conformity

This product complies with the directive of the Council of the European

Communities on the approximation of the laws of the Member States relating to

electromagnetic compatibility (EMC Directive 2004/108/EC) and concerning

electrical equipment for use within specified voltage limits (Low-voltage directive

2006/95/EC). This conformity is the result of tests conducted by ABB in

accordance with the product standards EN 50263 and EN 60255-26 for the EMC

directive, and with the product standards EN 60255-1 and EN 60255-27 for the low

voltage directive. The IED is designed in accordance with the international

standards of the IEC 60255 series.

Table of contents

Section 1 Introduction.......................................................................3

This manual........................................................................................3

Intended audience..............................................................................3

Product documentation.......................................................................4

Product documentation set............................................................4

Document revision history.............................................................5

Related documentation..................................................................6

Symbols and conventions...................................................................6

Safety indication symbols..............................................................6

Manual conventions.......................................................................6

Functions, codes and symbols......................................................7

Section 2 DNP3 data mappings.....................................................11

Overview...........................................................................................11

Point list for REU615 Ver.3.0 UE01-02............................................12

Section 3 DNP3 protocol implementation.......................................25

DNP3 device profile..........................................................................25

DNP3 implementation table..............................................................27

Section 4 Glossary.........................................................................31

Table of contents

REU615 1

Point List Manual

Section 1 Introduction

1.1 This manual

The point list manual describes the outlook and properties of the data points

specific to the IED. The manual should be used in conjunction with the

corresponding communication protocol manual.

1.2 Intended audience

This manual addresses the communication system engineer or system integrator

responsible for pre-engineering and engineering for communication setup in a

substation from an IED perspective.

The system engineer or system integrator must have a basic knowledge of

communication in protection and control systems and thorough knowledge of the

specific communication protocol.

1MRS757056 A Section 1

Introduction

REU615 3

Point List Manual

1.3 Product documentation

1.3.1 Product documentation set

Planning & purchase

Engineering

Installing

Commissioning

Operation

Maintenance

Decommissioning

deinstalling & disposal

Application manual

Operation manual

Installation manual

Service manual

Engineering manual

Commissioning manual

Communication protocol

manual

Technical manual

Planning & purchase

Engineering

Installing

Commissioning

Operation

Maintenance

Decommissioning

deinstalling & disposal

Planning & purchase

Engineering

Installing

Commissioning

Operation

Maintenance

Decommissioning

deinstalling & disposal

Application manualApplication manual

Operation manualOperation manual

Installation manualInstallation manual

Service manualService manual

Engineering manualEngineering manual

Commissioning manualCommissioning manual

Communication protocol

manual

Communication protocol

manual

Technical manualTechnical manual

en07000220.vsd

IEC07000220 V1 EN

Figure 1: The intended use of manuals in different lifecycles

The engineering manual contains instructions on how to engineer the IEDs using

the different tools in PCM600. The manual provides instructions on how to set up a

PCM600 project and insert IEDs to the project structure. The manual also

recommends a sequence for engineering of protection and control functions, LHMI

functions as well as communication engineering for IEC 61850 and other

supported protocols.

The installation manual contains instructions on how to install the IED. The

manual provides procedures for mechanical and electrical installation. The chapters

are organized in chronological order in which the IED should be installed.

The commissioning manual contains instructions on how to commission the IED.

The manual can also be used by system engineers and maintenance personnel for

assistance during the testing phase. The manual provides procedures for checking

of external circuitry and energizing the IED, parameter setting and configuration as

Section 1 1MRS757056 A

Introduction

4REU615

Point List Manual

well as verifying settings by secondary injection. The manual describes the process

of testing an IED in a substation which is not in service. The chapters are organized

in chronological order in which the IED should be commissioned.

The operation manual contains instructions on how to operate the IED once it has

been commissioned. The manual provides instructions for monitoring, controlling

and setting the IED. The manual also describes how to identify disturbances and

how to view calculated and measured power grid data to determine the cause of a

fault.

The service manual contains instructions on how to service and maintain the IED.

The manual also provides procedures for de-energizing, de-commissioning and

disposal of the IED.

The application manual contains application descriptions and setting guidelines

sorted per function. The manual can be used to find out when and for what purpose

a typical protection function can be used. The manual can also be used when

calculating settings.

The technical manual contains application and functionality descriptions and lists

function blocks, logic diagrams, input and output signals, setting parameters and

technical data sorted per function. The manual can be used as a technical reference

during the engineering phase, installation and commissioning phase, and during

normal service.

The communication protocol manual describes a communication protocol

supported by the IED. The manual concentrates on vendor-specific implementations.

The point list manual describes the outlook and properties of the data points

specific to the IED. The manual should be used in conjunction with the

corresponding communication protocol manual.

Some of the manuals are not available yet.

1.3.2 Document revision history

Document revision/date Product version History

A/2010-06-11 3.0 First release

Download the latest documents from the ABB web site http://

www.abb.com/substationautomation.

1MRS757056 A Section 1

Introduction

REU615 5

Point List Manual

1.3.3 Related documentation

Name of the document Document ID

DNP3 Communication Protocol Manual 1MRS756709

1.4 Symbols and conventions

1.4.1 Safety indication symbols

The caution icon indicates important information or warning related

to the concept discussed in the text. It might indicate the presence

of a hazard which could result in corruption of software or damage

to equipment or property.

The information icon alerts the reader to important facts and

conditions.

The tip icon indicates advice on, for example, how to design your

project or how to use a certain function.

Although warning hazards are related to personal injury, it should be understood

that operation of damaged equipment could, under certain operational conditions,

result in degraded process performance leading to personal injury or death.

Therefore, comply fully with all warning and caution notices.

1.4.2 Manual conventions

Conventions used in IED manuals. A particular convention may not be used in this

manual.

• Abbreviations and acronyms in this manual are spelled out in the glossary. The

glossary also contains definitions of important terms.

• Push button navigation in the LHMI menu structure is presented by using the

push button icons, for example:

To navigate between the options, use and .

• HMI menu paths are presented in bold, for example:

Select Main menu/Settings.

• LHMI messages are shown in Courier font, for example:

To save the changes in non-volatile memory, select Yes and press .

• Parameter names are shown in italics, for example:

The function can be enabled and disabled with the Operation setting.

• Parameter values are indicated with quotation marks, for example:

Section 1 1MRS757056 A

Introduction

6REU615

Point List Manual

The corresponding parameter values are "On" and "Off".

• IED input/output messages and monitored data names are shown in Courier

font, for example:

When the function starts, the START output is set to TRUE.

1.4.3 Functions, codes and symbols

Table 1: REU615 Functions, codes and symbols

Function IEC 61850 IEC 60617 IEC-ANSI

Protection

Three-phase non-directional

overcurrent protection, low stage,

instance 1

PHLPTOC1 3I> (1) 51P-1 (1)

Three-phase non-directional

overcurrent protection, high stage,

instance 1

PHHPTOC1 3I>> (1) 51P-2 (1)

Three-phase non-directional

overcurrent protection,

instantaneous stage, instance 1

PHIPTOC1 3I>>> (1) 50P/51P (1)

Residual overvoltage protection,

instance 1 ROVPTOV1 Uo> (1) 59G (1)

Residual overvoltage protection,

instance 2 ROVPTOV2 Uo> (2) 59G (2)

Residual overvoltage protection,

instance 3 ROVPTOV3 Uo> (3) 59G (3)

Three-phase undervoltage

protection, instance 1 PHPTUV1 3U< (1) 27 (1)

Three-phase undervoltage

protection, instance 2 PHPTUV2 3U< (2) 27 (2)

Three-phase undervoltage

protection, instance 3 PHPTUV3 3U< (3) 27 (3)

Three-phase overvoltage

protection, instance 1 PHPTOV1 3U> (1) 59 (1)

Three-phase overvoltage

protection, instance 2 PHPTOV2 3U> (2) 59 (2)

Three-phase overvoltage

protection, instance 3 PHPTOV3 3U> (3) 59 (3)

Positive-sequence undervoltage

protection, instance 1 PSPTUV1 U1< (1) 47U+ (1)

Positive-sequence undervoltage

protection, instance 2 PSPTUV2 U1< (2) 47U+ (2)

Negative-sequence overvoltage

protection, instance 1 NSPTOV1 U2> (1) 47O- (1)

Negative-sequence overvoltage

protection, instance 2 NSPTOV2 U2> (2) 47O- (2)

Frequency protection, instance 1 FRPFRQ1 f>/f<,df/dt (1) 81 (1)

Frequency protection, instance 2 FRPFRQ2 f>/f<,df/dt (2) 81 (2)

Frequency protection, instance 3 FRPFRQ3 f>/f<,df/dt (3) 81 (3)

Table continues on next page

1MRS757056 A Section 1

Introduction

REU615 7

Point List Manual

Function IEC 61850 IEC 60617 IEC-ANSI

Frequency protection, instance 4 FRPFRQ4 f>/f<,df/dt (4) 81 (4)

Frequency protection, instance 5 FRPFRQ5 f>/f<,df/dt (5) 81 (5)

Frequency protection, instance 6 FRPFRQ6 f>/f<,df/dt (6) 81 (6)

Three-phase thermal overload

protection for power transformers,

two time constants

T2PTTR1 3Ith>T 49T

Master trip, instance 1 TRPPTRC1 Master Trip (1) 94/86 (1)

Master trip, instance 2 TRPPTRC2 Master Trip (2) 94/86 (2)

Arc protection, instance 1 ARCSARC1 ARC (1) 50L/50NL (1)

Arc protection, instance 2 ARCSARC2 ARC (2) 50L/50NL (2)

Arc protection, instance 3 ARCSARC3 ARC (3) 50L/50NL (3)

Multi-purpose protection, instance

11) MAPGAPC1 MAP (1) MAP (1)

Multi-purpose protection, instance

21) MAPGAPC2 MAP (2) MAP (2)

Multi-purpose protection, instance

31) MAPGAPC3 MAP (3) MAP (3)
