ABB CoriolisMaster FCHB400 User manual

—
ABB MEASUREMENT & ANALYTICS |
COMMISSIONING INSTRUCTION | CI/FCB400/FCH400-EN REV. G
CoriolisMaster FCB400, FCH400
Coriolis mass flowmeter
—
ABB Measurement & Analytics
For your local ABB contact, visit:
www.abb.com/contacts
For more product information, visit:
www.abb.com/flow
Devices Firmware version: 01.07.00
Measurement made easy
CI/FCB400/FCH400
-EN Rev. G 04.2021
—
CoriolisMaster FCB430 / 450
CoriolisMaster FCH430 / 450
Introduction
With no up or downstream piping requirements
the compact Coriolis flowmeters can be installed
in the tightest spaces, enabling applications not
possible before.
CoriolisMaster FCB400
The compact Coriolis mass flowmeters from the
CoriolisMaster FCB400 seri
es offer low pressure
drop, high capacity, an intuitive ABB display
featuring a standardized design and cross
-
product compatibility, five modular inputs and
outputs as well as HART communication.
CoriolisMaster FCH400
The compact Coriolis mass flowmeters
for
hygienic applications from the CoriolisMaster
FCH400 series additionally offer EHEDG certified
cleanability; all wetted materials are polished.
Additional Information
Additional documentation on
CoriolisMaster
FCB400, FCH400
is available for download free of
charge at www.abb.com/
flow.
Alternatively simply scan this code:
—
We reserve the right to make technical changes or
modify the contents of this document
without prior
notice. With regard to purchase orders, the agreed particulars shall prevail.
ABB does not accept any
responsibility whatsoever for potential errors or possible lack of
information in this document.
We reserve all rights in this document and in the
subject matter and illustrations contained
therein.
Any reproduction, disclosure to th ird parties or util ization of its contents – in whole
or in parts
– is forbidden without prior written consent of ABB.
© ABB 2021 3KXF411010R4401

2 CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G
Table of contents
1Safety ........................................................................4
General information and instructions ............................... 4
Warnings............................................................................... 4
Intended use......................................................................... 5
Improper use ........................................................................ 5
Notes on data safety ........................................................... 5
Warranty provisions............................................................. 5
Manufacturer’s address ...................................................... 5
2Use in potentially explosive atmospheres .............6
Device overview.................................................................... 6
ATEX / IECEx.................................................................... 6
cFMus ................................................................................7
Ex marking............................................................................ 8
Description of model numbers ...................................... 8
ATEX / IECEx................................................................... 11
cFMus .............................................................................. 12
Temperature data...............................................................13
Temperature resistance for the connecting cable......13
Environmental and process conditions for model
FCx4xx…..........................................................................13
Measuring medium temperature for sensors in
integral mount design with dual-compartment
housing............................................................................14
Measuring medium temperature for sensors in
integral mount design with single-compartment
housing............................................................................15
Measuring medium temperature for sensors in remote
mount design..................................................................16
Electrical data...................................................................... 17
Overview.......................................................................... 17
Zone 2, 21 and Division 2 – Model: FCx4xx-A2, FCx4xx-
F2 .....................................................................................18
Zone 1 ,21 und Division 1 – Model: FCx4xx-A1, FCx4xx-
F1......................................................................................19
Special connection conditions..................................... 20
Installation instructions..................................................... 21
ATEX / IECEx................................................................... 21
cFMus .............................................................................. 21
Use in areas exposed to combustible dust..................21
Opening and closing the housing ................................. 21
Cable entries in accordance with ATEX / IECEx ..........22
Cable entries in accordance with cFMus......................22
Electrical connections....................................................23
Process sealing...............................................................23
Operating instructions...................................................... 24
Protection against electrostatic discharges .............. 24
Repair.............................................................................. 24
Changing the type of protection ................................. 24
3Product identification............................................25
Name plate ..........................................................................25
4Transport and storage...........................................26
Inspection............................................................................26
Transporting the device.....................................................26
Storing the device...............................................................27
Ambient conditions........................................................27
Returning devices ...............................................................27
5Installation .............................................................. 27
General installation conditions .........................................27
Installation location and assembly...............................27
Liquid measuring media ................................................28
Gaseous measuring media............................................29
Turn-off devices for the zero point adjustment......... 30
Sensor insulation........................................................... 30
Installation in EHEDG-compliant installations........... 30
Devices for legal metrology in accordance with
MID / OIML R117 ............................................................. 31
Process conditions ............................................................. 31
Temperature limits °C (°F)............................................. 31
Pressure ratings ............................................................. 31
Housing as a protective device (optional)................... 31
Material load for process connections .............................32
Material load curves for flange devices........................32
Installing the sensor ...........................................................33
Installing the transmitter in the remote mount design..33
Opening and closing the housing .....................................35
Dual- compartment housing.........................................35
Single-compartment housing .......................................36
Adjusting the transmitter position...................................36
Installing the plug-in cards ................................................38
Optional plug-in cards ...................................................38
Dual-compartment housing......................................... 40
Single-compartment housing .......................................41
Ethernet card..................................................................42
6Electrical connections............................................43
Safety instructions .............................................................43
Power supply.......................................................................43
Installing the connection cables....................................... 44
Recommended cables................................................... 44
Terminal assignment......................................................... 45
Electrical data for inputs and outputs............................. 46
Power supply L / N, 1+ / 2− .......................................... 46
Current output 32 / Uco, 31 / 32 (basic device).......... 46
Current output Uco / 32 as loop power supply for
digital output 41 / 42 or 51 / 52....................................47
Digital output 41 / 42, 51 / 52 (basic device).............. 48
Current output V1 / V2, V3 / V4 (plug-in module) ...... 48
Digital output V1 / V2, V3 / V4 (plug-in module)........ 49
Digital input V1 / V2, V3 / V4 (plug-in module)........... 49
24 V DC loop power supply (plug-in module) ............. 50
Modbus® / PROFIBUS DP® interface V1 / V2 (plug-in
card) ............................................................................... 50
Connection examples ................................................... 50
Connection to integral mount design...............................53
Connection to remote mount design ...............................55

CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G 3
Transmitter.................................................................... 55
Flowmeter sensor...........................................................57
Digital communication...................................................... 58
HART® Communication................................................. 58
Modbus® communication............................................. 58
Cable specification........................................................ 59
PROFIBUS DP® communication ................................... 59
EtherNet/IP™ communication..................................... 60
7Commissioning .......................................................68
Safety instructions ............................................................ 68
Hardware settings............................................................. 68
Dual- compartment housing ........................................ 68
Single-compartment housing ...................................... 69
Configuration of digital outputs V1 / V2 or V3 / V4... 69
Checks prior to commissioning........................................ 70
Switching on the power supply ........................................ 70
Parameterization of the device ........................................ 70
Installation of ABB AssetVision Basic and ABB Field
Information Manager (FIM).......................................... 70
Parameterization via the infrared service port adapter
..........................................................................................72
Parameterization via HART®..........................................73
Basic Setup......................................................................... 74
Menu: Easy Setup .......................................................... 74
8Operation ................................................................ 77
Safety instructions .............................................................77
Menu navigation..................................................................77
Menu levels ..........................................................................78
Selecting and changing parameters.................................79
Entry from table .............................................................79
Error messages on the LCD display ................................. 80
9Maintenance / Repair .............................................81
Safety instructions .............................................................81
10 Dismounting and disposal.....................................81
Dismounting........................................................................81
Disposal .............................................................................. 82
11 Specification ...........................................................82
12 Additional documents............................................82
13 Appendix .................................................................83
Return form ........................................................................ 83

4 CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G
1Safety
General information and instructions
These instructions are an important part of the product and
must be retained for future reference.
Installation, commissioning, and maintenance of the product
may only be performed by trained specialist personnel who have
been authorized by the plant operator accordingly. The specialist
personnel must have read and understood the manual and must
comply with its instructions.
For additional information or if specific problems occur that are
not discussed in these instructions, contact the manufacturer.
The content of these instructions is neither part of nor an
amendment to any previous or existing agreement, promise or
legal relationship.
Modifications and repairs to the product may only be performed
if expressly permitted by these instructions.
Information and symbols on the product must be observed.
These may not be removed and must be fully legible at all times.
The operating company must strictly observe the applicable
national regulations relating to the installation, function testing,
repair and maintenance of electrical products.
Warnings
The warnings in these instructions are structured as follows:
DANGER
The signal word ‘DANGER’ indicates an imminent danger.
Failure to observe this information will result in death or
severe injury.
WARNING
The signal word ‘WARNING’ indicates an imminent danger.
Failure to observe this information may result in death or
severe injury.
CAUTION
The signal word ‘CAUTION’ indicates an imminent danger.
Failure to observe this information may result in minor or
moderate injury.
NOTICE
The signal word ‘NOTICE’ indicates possible material damage.
Note
‘Note’ indicates useful or important information about the
product.

CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G 5
Intended use
This device is intended for the following uses:
• To convey liquids and gases (including unstable measuring
media).
• To meter mass flow directly.
• To meter volumetric flow (indirectly via mass flow and
density).
• To measure the density of the measuring medium.
• To measure the temperature of the measuring medium.
The device has been designed for use exclusively within the
technical limit values indicated on the identification plate and in
the data sheets.
When using measuring media, the following points must be
observed:
• Measuring media may only be used if, based on the state
of the art or the operating experience of the user, it can
be assured that the chemical and physical properties
necessary for operational security of the materials of the
wetted parts of the flowmeter sensor will not be
adversely affected during the operating time.
• Media containing chloride in particular can cause
corrosion damage to stainless steels which, although not
visible externally, can damage wetted parts beyond repair
and lead to the measuring medium escaping. It is the
operator's responsibility to check the suitability of these
materials for the respective application.
• Measuring media with unknown properties or abrasive
measuring media may only be used if the operator is able
to perform regular and suitable tests to ensure the safe
condition of the device
Improper use
The following are considered to be instances of especially
improper use of the device:
• Operation as a flexible compensating adapter in piping,
for example for compensating pipe offsets, pipe
vibrations, pipe expansions, etc.
• For use as a climbing aid, for example for mounting
purposes.
• For use as a bracket for external loads, for example as a
support for piping, etc.
• Material application, for example by painting over the
housing, name plate or welding/soldering on parts.
• Material removal, for example by spot drilling the
housing.
Notes on data safety
This product is designed to be connected to and to
communicate information and data via a network interface.
It is operator’s sole responsibility to provide and continuously
ensure a secure connection between the product and your
network or any other network (as the case may be).
Operator shall establish and maintain any appropriate measures
(such as but not limited to the installation of firewalls,
application of authentication measures, encryption of data,
installation of anti-virus programs, etc.) to protect the product,
the network, its system and the interface against any kind of
security breaches, unauthorized access, interference, intrusion,
leakage and / or theft of data or information.
ABB Automation Products GmbH and its affiliates are not liable
for damages and / or losses related to such security breaches,
any unauthorized access, interference, intrusion, leakage and /
or theft of data or information.
Warranty provisions
Using the device in a manner that does not fall within the scope
of its intended use, disregarding this manual, using
underqualified personnel, or making unauthorized alterations
releases the manufacturer from liability for any resulting
damage. This renders the manufacturer's warranty null and void.
Manufacturer’s address
ABB Automation Products GmbH
Measurement & Analytics
Schillerstr. 72
32425 Minden
Germany
Tel: [phone]
Fax: [phone]
Customer service center
Tel: [phone]
Email: [e-mail]

6 CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G
2Use in potentially explosive atmospheres
Note
Further information on the Ex-Approval of devices can be found in the type examination certificates or the relevant certificates at
www.abb.com/flow .
Device overview
ATEX / IECEx
Standard / No explosion protection
Zone 2, 21, 22
Zone 1, 21 (Zone 0)
Model number
FCx4xx Y0
FCx4xx A2
FCx4xx A1
Integral mount design
•
Standard
•
Zone 2, 21, 22
•
Zone 1, 21
•
Zone 0
Model number
FCT4xx Y0 FCx4xx Y0 FCT4xx A2 FCx4xx A2 FCT4xx A1 FCx4xx A1
Remote mount design
Transmitter and
flowmeter sensor
•
Standard
•
Zone 2, 21, 22
•
Zone 1, 21
•
Zone 0
Model number
FCT4xx Y0
FCT4xx A2
FCx4xx A1
Remote mount design
Transmitter
•
Standard
•
Zone 2, 21, 22
Sensor
•
Zone 1, 21
• Zone 0
Model number
—
FCT4xx A2
FCx4xx A1
Remote moun
t design
Transmitter
•
Zone 2, 21, 22
Sensor
•
Zone 1, 21
—
1
Single-compartment housing
2
Dual-compartment housing
3
Zone 0 within the meter tube

CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G 7
cFMus
Standard / No explosion protection
Class I Div. 2 / Zone 2
Class I Div. 1 / Zone 1 (Zone 0)
Model number
FCx4xx Y0
FCx4xx F2
FCx4xx F1
Integral mount design
•
Standard
•
Div. 2 / Zone 2
•
Div. 1 / Zone 1
(Zone 0)
Model number
FCT4xx Y0 FCx4xx Y0 FCT4xx F2 FCx4xx F2 FCT4xx F1 FCx4xx F1
Remote mount design
Transmitter and
flowmeter sensor
•
Div. 2 / Zone 2
•
Div. 1 / Zone 1
(Zone 0)
Model number
FCT4xx Y0 FCT4xx F2 FCx4xx F1
Remote mount design
Transmitter
•
Standard
Sensor
•
Div. 2 / Zone 2
•
Div. 1 / Zone 1
(Zone 0)
Model number
—
FCT4xx F2
FCx4xx F1
Remote mount design
Transmitter
•
Div. 2 / Zone 2
Sensor
•
Div. 1 / Zone 1
(Zone 0)
—
1
Single-compartment housing
2
Dual-compartment housing
3
Zone 0 within the meter tube

8 CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G
… 2 Use in potentially explosive atmospheres
Ex marking
Description of model numbers
Each device design has a specific model number. The parts of the model number relating to explosion protection are listed in the
following table. The complete key to model numbers is described in the device data sheet.
Basic model
FCa4c d m f g h i j k l m
Explosion protection
Without
Y0
ATEX / IECEx (Zone 2 / 22)
A2
ATEX / IECEx (Zone 1 / 21)
A1
cFMus version, Class 1, Div. 2 (Zone 2 / 21)
F2
cFMus version, Class 1, Div. 1 (Zone 1 / 21)
F1
NEPSI (Zone 2 / 22)
S2
NEPSI (Zone 1 / 21)
S1
Design / terminal box material / cable glands
Integral mount
- see transmitter housing Y0
Remote mount / aluminum / 1
× M20 × 1.5
U1
Remote
mount / aluminum / 1 × NPT ½ in U2
Remote mount / stainless steel / 1
× M20 × 1.5
A1
Remote mount / stainless steel / 1
× NPT ½ in A2
Nominal diameter / nominal connection diameter
xxxxx
Process
connection xx
Material for wetted parts
Stainless steel
A1
Polished stainless steel
H1
Nickel alloy
C1
Flow rate calibration
x
Density calibration
x

CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G 9
Basic model
FCa4c
d m f g h i j
k
l
m
Design / transmitter housing / transmitter housing material / cable gland
Integral mount / dual
-compartment housing / aluminum / 3 × M20 × 1.5 D1
Integral mount / dual-compartment housing / aluminum / 3 × NPT ½ in
D2
Integral mount / dual
-compartment housing / aluminum / 3 × M20 × 1.5 (Ex d / XP) D5
Integral mount / dual-compartment housing / aluminum / 3 × NPT ½ in (Ex d / XP)
D6
Integral mount / dual
-compartment housing / stainless steel / 3 × M20 × 1.5 D3
Integral mount / dual
-compartment housing / stainless steel / 3 × NPT ½ in D4
Integral mount / dual
-compartment housing / stainless steel / 3 × M20 × 1.5 (Ex d / XP) D7
Integral mount / dual
-compartment housing / stainless steel / 3 × NPT ½ in (Ex d / XP) D8
Integral mount / single-compartment housing / aluminum / 3 × M20 × 1.5
S1
Integral mount / single
-compartment housing / aluminum / 3 × NPT ½ in S2
Remote mount / dual-compartment housing / aluminum / 3 × M20 × 1.5
R1
Remote mount / dual
-compartment housing / aluminum / 3 × NPT ½ in R2
Remote mount / dual-compartment housing / aluminum / 3 × M20 × 1.5 (Ex d / XP)
R5
Remote mount / dual
-compartment housing / aluminum / 3 × NPT ½ in (Ex d / XP) R6
Remote mount / dual-compartment housing / stainless steel / 3 × M20 × 1.5
R3
Remote mount / dual-compartment housing / stainless steel / 3 × NPT ½ in
R4
Remote mount / dual
-compartment housing / stainless steel / 3 × M20 × 1.5 (Ex d / XP) R7
Remote mount / dual
-compartment housing / stainless steel / 3 × NPT ½ in (Ex d / XP) R8
Remote mount / single
-compartment housing, wall mounting / aluminum / 4 × M20 × 1.5 W1
Remote mount /
single-compartment housing, wall mounting / aluminum / 4 × NPT ½ in W2
Remote mount / not specified
Y0
Outputs
Current output 1 (active or passive), digital output 1 & 2 (passive),
HART®, PROFIBUS DP®
D1
Current output 1 (active), digital output 1 & 2 (passive), HART®, Modbus®
M1*
Current output
1 (active / passive), digital output 1 & 2 (passive), HART® G0
Current output 1 (active or passive), digital output 1 & 2 (passive), HART
®,
1 Port Ethernet
E2**
Current output 1 (active or passive), digital output 1 & 2 (passive), HART
®,
2 Port Ethernet
E3**
Current output 1 (active or passive), digital output 1 & 2 (passive), HART
®,
1 PortEthernet + POE
E4**
Current output 1 (active / passive), digital output 1 & 2 (passive),
24 V DC transmitter loop power supply, HART®
G1
Current output 1 (active / passive), digital output 1 & 2 (passive),
current output 2 (passive), HART®
G2
Current output 1 (active / passive), digital output 1 & 2 (passive),
current
output 2 (passive), current output 3 (passive), HART® G3
Current output 1 (active / passive), digital output 1 & 2 (passive),
current output 2 (passive), 24 V DC transmitter loop power supply, HART®
G4
Without
Y0
Power supply
100 to 230 V AC
A
11 to 30 V DC
C
Without
Y
* The M1 design is identical in construction to the M5 design, as it can also be called in other locations
** Available with single compartment housing only, Non-Ex or Zone 2, Div. 2 only

10 CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G
… 2 Use in potentially explosive atmospheres
… Ex marking
Additional ordering information
FCa4cdefghijklm
XXX XXX XX
Additional Output 1
2 port
Ethernet (various protocols) DR6*
Additional Output 2
Modul Power over Ethernet / Modbus (for Single Comp Hsg)
DS8*
Connector type
Without
U0
1
× M 12 Plug for Ethernet 1 Port (4 signal leads) UE*
2
× M 12 Plug for Ethernet 2 Port (4 signal leads) UF*
1
× M 12 Plug for Ethernet 1 Port (8 signal leads) UG*
1
× RJ45 connector with 5 m (15 ft) cable length fitted (4 signal leads) U5*
2
× RJ45 connector with 5 m (15 ft) cable length fitted (4 signal leads) UB*
1
× RJ45 connector with 5 m (15 ft) cable lenth fitted (8 signal leads) UC*
1
× RJ45 connector with 10 m (30 ft) cable length fitted (4 signal leads) U6*
2 × RJ45 connector with 10 m (30 ft) cable length fitted (4 signal leads)
DU*
1
× RJ45 connector with 10 m 30 ft cable lenth fitted (8 signal leads) UH*
1
× RJ45 connector with 15 m (49 ft) cable length fitted (4 signal leads) U7*
2
× RJ45 connector with 15 m (49 ft) cable length fitted (4 signal leads) UJ*
1
× RJ45 connector with 15 m 49 ft cable lenth fitted (8 signal leads) UK*
1
× RJ45 connector with 2O m (66 ft) cable length fitted (4 signal leads) U8*
2
× RJ45 connector with 2O m (66 ft) cable length fitted (4 signal leads) UN*
1
× RJ45 connector with 2O m (66 ft) cable length fitted (8 signal leads) UP*
* Available with single compartment housing, Ethernet Card, Non-Ex or ATEX Zone 2

CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G 11
ATEX / IECEx
Note
• A specific marking applies, depending on the design.
• ABB reserves the right to modify the Ex-marking. Refer to the name plate for the exact marking.
Model number for use in Zone 2, 21
Ex marking
Certificate
FCa4c
– A2Y0fghijD
Integral mount design with dual
-compartment
housing
II3G Ex ec IIC T6...T1 Gc
II2D Ex tb IIIC T80°C...Tmedium Db
ATEX:
FM15ATEX0014X, FM15ATEX0016X
IECEx:
IECEx FME 15.0005X
FCa4c
– A2efghijY
Sensor in remote mount design with dual
-
compartment housing
FCT4c
– A2R
Transmitter in remote mount design with dual
-
compartment housing
II3G Ex ec IIC T6 Gc
II2D Ex tb IIIC T80°C Db
Model number for use in Zone 1, 21
Ex marking
Certificate
FCa4c
– A1Y0fghijDx (x = 1 to 4)
Integral mount design with dual
-compartment
housing
II 1/2 (1) G Ex db eb ia mb [ia Ga] IIC T6…T1 Gb
II 2 (1) D Ex ia tb [ia Da] IIIC T80°C Db
ATEX:
FM15ATEX0015X
IECEx:
IECEx FME 15.0005X
FCa4c
– A1Y0fghijDx (x = 5 to 8)
Integral mount design with
dual-compartment
housing (flameproof enclosure ‘Ex d’)
II 1/2 (1) G Ex db ia mb [ia Ga] IIB+H2 T6...T1 Gb
II 2 (1) D Ex ia tb [ia Da] IIIC T80°C Db
FCa4c
– A1efghijY
Sensor in remote mount design with dual
-
compartment housing
II 1/2 G Ex eb ia mb
IIB+H2 T6…T1 Ga/Gb
II 2 D Ex ia tb IIIC T80°C Db
FCT4c
– A1R (x = 1 to 4)
Transmitter in remote mount design with dual
-
compartment housing
II 2 (1) G Ex db e ia mb [ia Ga] IIC T6…T1 Gb
II 2 (1) D Ex ia mb tb [ia Da] IIIC T80°C Db
FCT4c
– A1R (x = 5 to 8)
Transmitter in remote mount design with dual
-
compartment housing
(flameproof enclosure ‘Ex d’)
II 2 (1) G Ex db ia mb [ia Ga] IIB+H2 T6…T1 Gb
II 2 (1) D Ex ia tb [ia Da] IIIC T80°C Db

12 CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G
… 2 Use in potentially explosive atmospheres
… Ex marking
cFMus
Note
• A specific marking applies, depending on the design.
• ABB reserves the right to modify the Ex-marking. Refer to the name plate for the exact marking.
Model number for use in Division 2
Ex marking
FCa4c
– F2Y0fghijD
Integral mount design with dual
-compartment housing
Certificate: FM18US0160X
NI: CL I,II,III Div 2, GPS ABCDEFG, T6…T1
CL I, ZN 2, AEx ec IIC T6…T1
CL I, ZN 2, Ex ec IIC T6...T1
See handbook for temperature class
information
Certificate:
FM18CA0073X
DIP: CL II,III, Div 1, GPS EFG, T6
ZN 21, AEx ia tb
IIIC T80°C
ZN21,Ex ia tb IIIC T80°C
FCa4c
– F2efghijY
Sensor in remote mount design with dual-compartment housing
Design in accordance with
ANSI / ISA 12.27.01 as ‘Single Seal Device’
or as ‘
Dual Seal Device’ (option TE2)
FCT4c
– F2R
Transmitter in remote mount design with dual-compartment housing
FCT4c
– F2W
Transmitter in remote mount design with single
-compartment
housing
Model number for use in Division 1
Ex marking
Certificate
FCa4c
– F1Y0fghijDx (x = 1 to 4)
Integral mount design with dual-compartment housing
XP
-IS: CL I, Div 1, GPS ABCD,T6…T1 (USA)
XP
-IS: CL I, Div 1, GPS BCD,T6…T1 (CAN)
DIP: CL II,III, Div 1, GPS EFG,T6
CL I, ZN 1, AEx db ia IIB+H2 T6…T1 (USA)
ZN21, AEx ia tb IIIC T80°C (USA)
CL I, ZN
1, Ex db ia IIB+H2 T6…T1 (CAN)
ZN21, Ex ia tb IIIC T80°C (CAN)
See handbook for temperature class information and installation
drawing 3KXF000028G0009
cFMus:
3050239
FCa4c
– F1Y0fghijDx (x = 5 to 8)
Integral mount design with dual
-compartment housing
(
Explosionproof ‘XP’).
Design in accordance with
ANSI / ISA 12.27.01 as ‘Single Seal Device’
or as ‘
Dual Seal Device’ (option TE2)
FCa4c
– F1efghijY
Sensor in remote mount design with dual
-compartment housing
XP
-IS: CL I, Div 1, GPS BCD T6…T1 (USA)
DIP: CL II,III, Div 1, GPS EFG,T6
CL I, ZN 1, AEx db ia IIB+H2 T6…T1 (USA)
ZN 21, AEx ia tb IIIC T80°C (USA)
CL I, ZN 1, Ex db ia IIB+H2 T6…T1 (CAN)
ZN21,
Ex ia tb IIIC T80°C (CAN)
See handbook for temperature class information and installation
drawing 3KXF000028G0009
Design in accordance with
ANSI / ISA 12.27.01 as ‘Single Seal Device’
or as ‘
Dual Seal Device’ (option TE2)
FCT4c
– F1Rx (x = 1 to 4)
Transmitter in remote mount design with dual-compartment housing
XP
-IS: CL I, Div 1, GPS BCD,T6…T1 (USA) XP-IS: CL I, Div 1, GPS
BCD,T6…T1 (CAN)
DIP: CL II,III, Div 1, GPS EFG, T6
CL I, ZN 1, AEx db ia IIB+H2 T6…T1 (USA)
ZN 21, AEx ia tb IIIC T80°
C (USA)
CL I, ZN 1, Ex db ia IIB+H2 T6…T1 (CAN)
ZN21,Ex ia tb IIIC T80°C (CAN)
See handbook for temperature class information and installation
drawing 3KXF000028G0009
FCT4c
– F1Rx (x = 5 to 8)
Sensor in remote mount design with dual
-compartment housing
(
Explosionproof ‘XP’).

CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G 13
Temperature data
Temperature resistance for the connecting cable
The temperature at the cable entries of the device depends on
the design, the measuring medium temperature Tmedium and the
ambient temperature Tamb..
For the electric connection of the device, use only cables with
sufficient temperature resistance in accordance with the
following table.
Devices in integral mount design with dual-compartment
housing
Tamb.
Temperature resistance
≤
50 °C (≤ 122 °F) ≥70 °C (≥ 158
°F)
≤
60 °C (≤ 140 °F) ≥80 °C (≥ 176
°F)
≤
70 °C (≤ 158 °F) ≥90 °C (≥ 194
°F)
Devices in integral mount design with single-compartment
housing
Tamb.
Temperature resistance
≤50 °C (≤ 122 °F)
≥75 °C (≥ 167 °F)
≤
60 °C (≤ 140 °F) ≥85 °C (≥ 185
°F)
≤
70 °C (≤ 158 °F) ≥95 °C (≥ 203
°F)
Sensor in remote mount design
Tamb.
Temperature resistance
≤50 °C (≤ 122 °F)
≥105 °C (≥ 221 °F)
≤
60 °C (≤ 140 °F) ≥110 °C (≥ 230
°F)
≤70 °C (≤ 158 °F)
≥120 °C (≥ 248 °F)
For sensors in remote mount design, the wires in the connection
box must be additionally insulated with the enclosed silicone
hoses starting from ambient temperatures of Tamb. ≥60 °C
(≥ 140 °F).
Environmental and process conditions for model
FCx4xx…
Am
bient temperature Tamb. -20 to 70
°C
(-4 to 158 °F)
-40 to 70
°C*
(-40 to 158
°F)*
Measuring medium temperature
Tmedium
-40 to 205
°C
(-40 to 400 °F)
IP rating / NEMA rating
IP 65, IP
67 /
NEMA 4X,Type
4X
* Optional, with order code ‘Ambient temperature range – TA9’

14 CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G
… 2 Use in potentially explosive atmospheres
… Temperature data
Measuring medium temperature for sensors in integral mount design with dual-compartment housing
Model FCx4xx-A1… and FCx4xx-F1… in Zone 1, Division 1
The table shows the maximum permissible measuring medium temperature as a function of ambient temperature and temperature
class.
Temperature class
Ambient temperature Tamb.
T1
T2
T3
T4
T5
T6
≤
30 °C (≤ 86 °F)
205 °C (400 °F)*
130 °C (266 °F)
205 °C (400 °F)*
130 °C (266 °F)
195 °C (383 °F)*
130 °C (266 °F)
130 °C (266 °F)
95 °C (203 °F)
80 °C (176 °F)
≤
40 °C (≤ 104 °F)
205 °C (400 °F)*
130 °C (266 °F)
205 °C (400 °F)*
130 °C (266 °F)
195 °C (383 °F)*
130 °C (266 °F)
130 °C (266 °F)
95 °C (203 °F)
80 °C (176 °F)
≤
50 °C (≤ 122 °F)
205 °C (400 °F)*
130 °C (266 °F)
205 °C (400 °F)*
130 °C (266 °F)
195 °C (383 °F)*
130 °C (266 °F)
130 °C (266 °F)
95 °C
(203 °F)
80 °C (176 °F)
≤
60 °C (≤ 140 °F)
205 °C (400 °F)*
130 °C (266 °F)
205 °C (400 °F)*
130 °C (266 °F)
195 °C (383 °F)*
130 °C (266 °F)
130 °C (266 °F)
95 °C (203 °F)
80 °C (176 °F)
≤
70 °C (≤ 158 °F)
205 °C (400 °F)*
130 °C (266 °F)
205 °C
(400 °F)*
130 °C (266 °F)
195 °C (383 °F)*
130 °C (266 °F)
130 °C (266 °F)
95 °C (203 °F)
80 °C (176 °F)
* Only with the ‘Extended tower length – TE1, TE2 or TE3’ order option
Model FCx4xx-A2… and FCx4xx-F2… in Zone 2, Division 2
The table shows the maximum permissible measuring medium temperature as a function of ambient temperature and temperature
class.
Temperature class
Ambient temperature Tamb.
T1
T2
T3
T4
T5
T6
≤
30 °C (≤ 86 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383 °F)*
130 °C
(266 °F)
130 °C (266 °F)
95 °C (203 °F)
80 °C (176 °F)*
60 °C (140
°F)
≤
40 °C (≤ 104 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383 °F)*
130 °C (266 °F)
130 °C (266 °F)
95 °C (203 °F)
—
≤
50 °C (≤ 122 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383
°F)*
130 °C (266 °F)
130 °C (266 °F)
—
—
≤
60 °C (≤ 140 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383 °F)*
130 °C (266 °F)
130 °C (266 °F)
—
—
≤
70 °C (≤ 158 °F)
205 °C (400 °F)*
130 °C (266 °F)
205 °C (400 °F)*
130 °C (266 °F)
195 °C (383 °F)*
130
°C (266 °F)
130 °C (266 °F)
—
—
* Only with the ‘Extended tower length – TE1, TE2 or TE3’ order option

CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G 15
Measuring medium temperature for sensors in integral mount design with single-compartment housing
Model FCx4xx-A2… and FCx4xx-F2… in Zone 2, Division 2
The table shows the maximum permissible measuring medium temperature as a function of ambient temperature and temperature
class.
Temperature class
Ambient temperature Tamb.
T1
T2
T3
T4
T5
T6
≤
30 °C (≤ 86 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383 °F)
130 °C (266 °F)
95 °C (203 °F)
80 °C (176 °F)
≤
40 °C (≤ 104 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383 °F)
130 °C (266 °F)
95 °C (203 °F)
—
≤
50 °C (≤ 122 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383 °F)
130 °C (266 °F)
95 °C (203 °F)
—
≤
60 °C (≤ 140 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383 °F)
130 °C (266 °F)
—
—
≤
70 °C (≤ 158 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383 °F)
130 °C (266 °F)
—
—
* Only with the ‘Extended tower length – TE1, TE2 or TE3’ order option

16 CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G
… 2 Use in potentially explosive atmospheres
… Temperature data
Measuring medium temperature for sensors in remote mount design
Model FCx4xx-A1…, FCx4xx-F1… in Zone 1
The table shows the maximum permissible measuring medium temperature as a function of ambient temperature and temperature
class.
Temperature class
Ambient temperature Tamb.
T1
T2
T3
T4
T5
T6
≤30 °C (≤ 86 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383 °F)
130 °C (266 °F)
95 °C (203 °F)
80 °C (176 °F)
≤
40 °C (≤ 104 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383 °F)
130 °C (266 °F)
95 °C (203 °F)
80 °C (176 °F)
≤
50 °C (≤ 122 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383 °F)
130 °C (266 °F)
95 °C (203 °F)
80 °C (176 °F)
≤
60 °C (≤ 140 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383 °F)
130 °C (266 °F)
95 °C (203 °F)
80 °C (176 °F)
≤70 °C (≤ 158 °F)
205 °C (400 °F)
205 °C (400 °F)
195 °C (383 °F)
130 °C (266 °F)
95 °C (203 °F)
80 °C (176 °F)
Model FCx4xx-A2… and FCx4xx-F2… in Zone 2, Division 2
The table shows the maximum permissible measuring medium temperature as a function of ambient temperature and temperature
class.
Temperature class
Ambient temperature Tamb.
T1
T2
T3
T4
T5
T6
≤
30 °C (≤ 86 °F)
205 °C (400 °F)*
195 °C (383 °F)
205 °C (400 °F)*
195 °C (383 °F)
195 °C (383 °F)*
130 °C (266 °F)
130 °C (266 °F)*
95 °C (203 °F)
95 °C (203 °F)*
80 °C (176 °F)
80 °C (176 °F)
≤
40 °C (≤ 104 °F)
205 °C (400 °F)*
180 °C (356 °F)
205 °C (400 °F)*
180 °C (356 °F)
195 °C (383 °F)*
130 °C (266 °F)
130 °C (266 °F)*
95 °C (203 °F)
95 °C (203 °F)*
80 °C (176 °F)
—
≤
50 °C (≤ 122 °F)
205 °C (400 °F)*
140 °C (284 °F)
205 °C (400 °F)*
140 °C (284 °F)
130 °C (266 °F)*
130 °C (266 °F)
130 °C (266 °F)*
95 °C (203 °F)
80 °C (176 °F)*
60 °C (140 °F)
—
≤
60 °C (≤ 140 °F)
205 °C (400 °F)*
120 °C (248
°F)
205 °C (400 °F)*
120 °C (248
°F)
130 °C (266 °F)*
120 °C (248
°F)
130 °C (266 °F)*
95 °C
(203 °F)
—
—
≤
70 °C (≤ 158 °F)
180 °C (356 °F)*
80 °C (176 °F)
180 °C (356 °F)*
80 °C (176 °F)
130 °C (266 °F)*
80 °C (176 °F)
130 °C (266 °F)*
80 °C (176 °F)
—
—
* Only with the ‘Extended tower length – TE1, TE2 or TE3’ order option

CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G 17
Electrical data
Overview
Standard / No explosion protection
Zone 2, 21
Zone 1, 21 (Zone 0)
Division 2 and Zone 2, 21
Division 2 and Zone 1, 21
ATEX:
–
IECEx:
–
ATEX:
II 3 G & II 2 D
IECEx:
Gc & Db
ATEX:
II 1/2 (1) G & II 2 (1) D
II 1/2 G &
II 2 D
II 2 (1) G & II 2 (1) D
IECEx:
(Ga) Gb & (Da) Db
Ga/Gb & Db
(Ga) Gb & (Da) Db
USA:
–
Canada:
–
USA:
NI & DIP
AEx ec & AEx tb
Canada:
Non
-Incendive & Dust Ignition Proof
Ex ec & Ex tb
USA:
XP
-IS & DIP
AEx db ia & AEx ia tb
Canada:
XP
-IS & DIP
Ex db ia & Ex ia tb
A
Power supply
B
Inputs / outputs, communication
C
Signal cable (remote mount design only)
•
Type of protection ATEX / IECEx: Increased safety
‘Ex e’
•
Type of protection USA / Canada: ‘non IS’
•
Maximum 250 Vrms
•
Terminals: 1+, 2-, L, N,
•
Type of protection ATEX / IECEx: Either increased
safety ‘Ex e’ or intrinsically safe ‘Ex ia’
•
Type of protection USA / Canada: Either ‘non IS’ or
‘intrinsically safe IS’.
•
When installing in ‘Ex ia’ or ‘IS’, suitable
intrinsically safe isolation amplifiers must be used
for the connection.
•
Terminals: 31, 32, Uco, V1, V2, V3, V4, 41, 42, 51, 52
•
Terminals: A, B, UFE, GRN
•
Type of protection ATEX / IECEx: Increased safety
‘Ex e’
•
Type of protection USA / Canada: ‘non IS’
Note
When installing in ‘Ex ia’ or ‘IS’ type of protection, the type of protection is determined by the type of electrical connection. The
information in Changing the type of protection on page 24 must be observed when changing the type of protection!

18 CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G
… 2 Use in potentially explosive atmospheres
… Electrical data
Zone 2, 21 and Division 2 – Model: FCx4xx-A2, FCx4xx-F2
Outputs on basic device
Operating values (general)
Type of protection –
‘nA’ / ‘NI’
U
N
I
N
U
N
I
N
Current
/ HART output 31 / UCO, active
Terminals 31
/ U
CO
30
V
30
mA
30
V
30
mA
Current
/ HART output 31 / 32, passive
Terminals 31 / 32
30
V
30
mA
30
V
30
mA
Digital output 41
/ 42, active*
Terminals 41
/ 42 and V1 / V2*
30
V
30
mA
30
V
30
mA
Digital output 41
/ 42, active**
Terminals 41 / 42 and UCO / 32**
30
V
30
mA
30
V
30
mA
Digital output 41
/ 42, passive
Terminals 41 / 42
30
V
25
mA
30
V
25 mA
Digital output 51
/ 52, active*
Terminals 51 / 52 and V1 / V2*
30
V
30
mA
30
V
30
mA
Digital output 51
/ 52, passive
Terminals 51
/ 52
30
V
30
mA
30
V
30
mA
All
outputs are electrically isolated from each other and from the power supply.
Digital outputs 41 / 42 and 51 / 52 are not electrically isolated from each other.
Terminals 42 / 52 have the same potential.
* Only in conjunction with additional ‘24 V DC loop power supply (blue)’ plug-in card in slot OC1.
** Only in conjunction with current output UCO / 32 in ‘Powermode’, see Current output Uco / 32 as loop power supply for digital output 41 / 42 or 51 / 52 on
page 47.
Inputs and outputs with optional plug
-in cards
Operating values (general)
Type of protection – ‘nA’ / ‘NI’
UN
IN
UN
IN
Current output V3 / V4, active*
Terminals V3 / V4 and V1 / V2*
30
V
30
mA
30
V
30 mA
Current output V1 / V2, passive**
Current output V3 / V4, passive**
Terminals V1 / V2** or V3 / V4**
30
V
30
mA
30
V
30 mA
Digital output V3 / V4, active*
Terminals V3 / V4 and V1 / V2*
30
V
25
mA
30
V
25 mA
Digital output V1 / V2, passive**
Digital output V3 / V4, passive**
Terminals V1 / V2** or V3 / V4**
30
V
30
mA
30
V
30 mA
Digital input V3 / V4,
active*
Terminals V3 / V4 and V1 / V2
30
V
3.45
mA
30
V
3.45 mA
Digital input V1 / V2, passive*
Digital input V3 / V4, passive*
Terminals V1
/ V2** or V3 / V4**
30
V
3.45
mA
30
V
3.45 mA
Modbus® / PROFIBUS
DP®
Terminals V1 / V2
30
V
30
mA
30
V
30 mA
Ethernet card
Ethernet (various protocols)
Port 1 / Port 2
57
V
417
mA
57 V 417 mA
Ethernet card in conjunction with Power over Ethernet (POE Card)
Ethernet (various protocols)
Port 1 / Port 2
57
V
417
mA
57 V 417 mA
* Only in conjunction with additional ‘24 V DC loop power supply (blue)’ plug-in card in slot OC1.
** The terminal assignment depends on the model number or the slot assignments. For connection examples, see Connection examples on page 50.

CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G 19
Zone 1 ,21 und Division 1 – Model: FCx4xx-A1, FCx4xx-F1
Type of protection
‘e’ / ‘XP’
‘ia’ / ‘IS’
Outputs on basic device
U
M
[V]
I
M
[A]
U
O
[V]
U
I
[V]
I
O
[mA]
I
I
[mA]
P
O
[mW]
P
I
[mW]
C
O
[nF]
C
I
[nF]
C
OPA
[nF]
C
IPA
[nF]
L
O
[mH]
L
I
[mH]
Current
/ HART output 31 / UCO, active
Terminals 31 / UCO
30
0.2
30
30
115
115
815
815
10 10
5
5
0.08
0.08
Current
/ HART output 31 / 32, passive
Terminals 31
/ 32
30
0.2
—
30
—
115
—
815
—
27
—
5
0.08
0.08
Digital output 41
/ 42, active*
Terminals 41 / 42 and V1 / V2*
30
0.1
27.8
30
119
30
826
225
20
20
29
29
0.22
0.22
Digital output 41
/ 42, active**
Terminals 41
/ 42 and U
CO
/ 32**
30
0.1
30
30
115
115
826
225
16 16
10
10
0.08
0.08
Digital output 41
/ 42, passive
Terminals 41 / 42
30
0.1
—
30
—
30
—
225
—
27
—
5
—
0.08
Digital output 51
/ 52, active*
Terminals 51
/ 52 and V1 / V2*
30
0.1
27.8
30
119
30
826
225
20
20
29
29
0.22
0.22
Digital output 51
/ 52, passive
Terminals 51 / 52
30
0.1
—
30
—
30
—
225
—
27
—
5
—
0.08
All outputs are electrically isolated from each other and from the power supply.
Digital outputs 41 / 42 and 51 / 52 are not electrically isolated from each other. Terminals 42 / 52 have the same potential.
* Only in conjunction with additional ‘24 V DC loop power supply (blue)’ plug-in card in slot OC1.
** Only in conjunction with current output UCO / 32 in ‘power mode’, see Current output Uco / 32 as loop power supply for digital output 41 / 42 or 51 / 52 on
page 47.
Type of protection
‘e’ / ‘XP’
‘ia’ / ‘IS’
Inputs and outputs with optiona
l plug-in cards U
M
[V]
I
M
[A]
U
O
[V]
U
I
[V]
I
O
[mA]
I
I
[mA]
P
O
[mW]
P
I
[mW]
C
O
[nF]
C
I
[nF]
C
OPA
[nF]
CIPA
[nF]
L
O
[mH]
L
I
[mH]
Current output V3 / V4, active*
Terminals V3 / V4 and V1 / V2*
30
0.1
27.8
30
119
30
826
225
29
29
117
117
0.4
0.4
Current output V1 / V2, passive**
Current output V3 / V4, passive**
Terminals V1 / V2** or V3 / V4**
30
0.1
—
30
—
68
—
510
—
45
—
59
—
0.27
Digital output V3 / V4, active*
Terminals V3 / V4 and V1 / V2*
30
0.1
27.8
30
119
68
826
225
17
17
31
31
0.4
0.4
Digital output V1 / V2, passive**
Digital output V3 / V4, passive**
Terminals V1 / V2** or V3 / V4**
30
0.1
—
30
—
30
—
225
—
13
—
16
—
0.27
Digital input V3 / V4, active*
Terminals V3 / V4 and V1 / V2
30
0.1
27.8
30
119
3.45
826
25.8
17
17
31
31
0.4
0.4
Digital input V1 / V2, passive*
Digital input V3 / V4, passive*
Terminals V1 / V2** or V3 / V4**
30
0.1
—
30
—
3.45
—
25.8
—
13
—
16
—
0.27
Modbus® / PROFIBUS
DP®
Terminals V1
/ V2
30
0.1
4.2
4.2
150
150
150
150
1.5
1.5
6
6
0.14
0.14
* Only in conjunction with additional ‘24 V DC loop power supply (blue)’ plug-in card in slot OC1.
** The terminal assignment depends on the model number or the slot assignments. For connection examples, see Connection examples on page 50.

20 CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. G
… 2 Use in potentially explosive atmospheres
… Electrical data
Special connection conditions
Note
The AS plug-in card (24 V DC loop power supply) may only be
used to power the internal inputs and outputs on the device.
It must not be used to power external circuits!
Note
If the protective earth (PE) is connected in the flowmeter's
terminal box, you must ensure that no dangerous potential
difference can arise between the protective earth (PE) and the
potential equalization (PA) in areas with explosion risk.
Note
• For devices with a power supply of 11 to 30 V DC, on-site
external overvoltage protection must be provided.
• You must make sure that the overvoltage is limited to
140 % (= 42 V DC) of the maximum operating voltage.
The output circuits are designed so that they can be connected
to both intrinsically-safe and non-intrinsically-safe circuits.
• Combining intrinsically safe and non-intrinsically safe circuits
is not permitted.
• On intrinsically safe circuits, potential equalization should be
established along the entire length of the cable used for the
signal outputs.
• The rated voltage of the non-intrinsically safe circuits is
UM= 30 V.
• Intrinsic safety is preserved If the rated voltage UM= 30 V is
not up-scaled when connections are established to non-
intrinsically safe external circuits.
• The information in Changing the type of protection on
page 24 must be observed when changing the type of
protection.
Devices connected to the relevant equipment must not be
operated at over 250 Vrms AC or 250 V DC to ground.
Installation in accordance with ATEX or IECEx must comply with
the applicable national and international standards and
directives.
Installation in the USA or Canada must comply with ANSI / ISA
RP 12.6, ‘Installation of intrinsically safe systems for hazardous
(classified) locations’, the ‘National Electrical Code (ANSI / NFPA
70), sections 504, 505’ and the ‘Canadian electrical code (C22.1-
02)’.
Apparatus connected to the flowmeter must have appropriate
explosion protection approval in accordance with the Entity
concept.
The apparatus must have intrinsically safe circuits.
The apparatus must be installed and connected in accordance
with the relevant manufacturer documentation.
The electrical specifications in Electrical data on page 17 must
be observed.
Ethernet communication
DANGER
Explosion hazard due to improper installation!
Ethernet Option Cards are designed only for use in hazardous
applications Zone 2 / Division 2.
The output circuits are designed so that different topologies
such as daisy chain or point to point can be connected. See
Installation diagram for detailed information.
• It is not permitted to combine both topologies.
• Ethernet communication is only available for installations in
Zone 2/Division 2.
• The rated voltage of these non-intrinsically safe circuits are
UM = 57 V.
