ABB GLA132 Series User manual

—
ABB MEASUREMENT & ANALYTICS | USER MANUAL
User Manual | OA-ICOSTM
GLA132 Series Ultraportable Analyzers
!
!
!
!
!
!

ABB GLA132 Series Ultraportable User Manual
2
Table of Contents
Disclaimer....................................................................................................................................... 4!
Cybersecurity ............................................................................................................................. 4!
Patent.............................................................................................................................................. 4!
Copyright........................................................................................................................................ 4!
Safety .............................................................................................................................................. 5!
Class of Laser Equipment........................................................................................................ 5!
Certification ............................................................................................................................... 5!
WEEE Directive........................................................................................................................... 5!
Labels........................................................................................................................................... 6!
Operator Safety ......................................................................................................................... 6!
Electrical Hazards...................................................................................................................... 6!
Laser Hazards ............................................................................................................................ 7!
Safety Provisions for a Chemical Spill................................................................................... 7!
Text Formats and Warning Icons........................................................................................... 8!
Transportation and Storage of Boxed Analyzers ................................................................... 9!
Warranty ....................................................................................................................................... 10!
Customer Support.......................................................................................................................11!
1!Analyzer Overview........................................................................................................................... 12!
Performance Specifications ..................................................................................................... 12!
Ambient Humidity ................................................................................................................... 12!
Operating Temperature......................................................................................................... 12!
Maximum Altitude................................................................................................................... 12!
Power Requirements .............................................................................................................. 12!
Fuse Ratings............................................................................................................................. 12!
Cable Plugs and Voltage for EC Countries ......................................................................... 12!
External Dimensions............................................................................................................... 13!
Weight ....................................................................................................................................... 13!
Cell Volume ............................................................................................................................... 13!
Standard Components .............................................................................................................. 14!
Optional Components ............................................................................................................... 14!
Power Connections .................................................................................................................... 16!
Emergency Shutdown Procedure ............................................................................................ 16!
Data Interface Connection Ports..............................................................................................17!
Plumbing Diagram...................................................................................................................... 18!
Inlet/Outlet Connections .......................................................................................................... 19!
Warning Labels and Descriptions............................................................................................20!
2!Analyzer Setup................................................................................................................................. 21!
Connect the Power Cords ......................................................................................................... 21!
Connect'the'Data'Interface'Connections......................................................................................... 21!
Connect'the'Inlet/Outlet'Plumbing'Connections............................................................................. 21!
3!Initialize and Run the Analyzer ..................................................................................................... 22!

ABB GLA132 Series Ultraportable User Manual
3
File System Integrity Check ...................................................................................................... 23!
Thermal Stabilization................................................................................................................. 23!
The Launch Service Screen........................................................................................................24!
The Auto Launch Screen............................................................................................................ 25!
Login to Access Menu Options ................................................................................................ 26!
Main Panel .................................................................................................................................... 27!
User Interface Control Bar.....................................................................................................28!
Main Panel Displays....................................................................................................................30!
Numeric Display.......................................................................................................................30!
Alarm Status Display .............................................................................................................. 31!
Spectrum Display ....................................................................................................................34!
TimeChart Display...................................................................................................................36!
Rate Control................................................................................................................................. 37!
File Transfer Menu ...................................................................................................................... 39!
Standard Data File ..................................................................................................................39!
Transfer Data Files..................................................................................................................40!
Types of directories in the local hard drive ...........................................................................42!
Daily Directory..........................................................................................................................42!
Archive Directory .....................................................................................................................43!
File Transfer Error Screen .........................................................................................................44!
Setup Menu ..................................................................................................................................45!
Time/Files Tab.........................................................................................................................46!
Calibration Tab ........................................................................................................................49!
Laser Adjust Tab...................................................................................................................... 51!
MIU Tab ..................................................................................................................................... 53!
Analog Output Tab..................................................................................................................54!
Water Vapor Isotope Standard Source Tab – WVISS Tab (Optional) ............................56!
Service Tab ............................................................................................................................... 57!
Shutting Down the Analyzer .....................................................................................................58!
4!Maintenance....................................................................................................................................59!
Daily Operation Checklist..........................................................................................................59!
Mirror Ring-Down Time and Maintenance.............................................................................59!
Replace the Fuse .........................................................................................................................60!
Appendix A:!Accessing Data Using the Ethernet ........................................................................63!
Additional Notes .........................................................................................................................64!
Appendix B:!Wireless Router Setup (Optional)............................................................................65!
Appendix C:!Set Up Devices for Remote Access Using VNC Software ...................................70!
Appendix D:!Calibration of WVIA and TWVIA analyzers .............................................................83!
Appendix E:!Spectrum Displays......................................................................................................88!
GLA431-CCIA2 Carbon Dioxide Isotopic Analyzer.............................................................88!
GLA132-GGA Greenhouse Gas Analyzer...............................................................................89!
GLA132-SOFX1 Soil Gas Analyzer ..........................................................................................90!
Appendix F:!Isotope Definitions ..................................................................................................... 91!
Appendix G:!Cables ...........................................................................................................................93!

ABB GLA132 Series Ultraportable User Manual
4
Disclaimer
This document contains product specifications and performance statements that may be
in conflict with other ABB published literature, such as product flyers and product catalogs.
All specifications, product characteristics, and performance statements included in this
document are suggested specifications only. In case of conflict between product
characteristics in this document and specifications in the official ABB product catalogs, the
latter takes precedence.
ABB reserves the right to make changes to the specifications of all equipment and
software, and to the contents of this document, without obligation to notify any person or
organization of such changes. Every effort has been made to ensure that the information
contained in this document is current and accurate. Please contact ABB-LGR if you find any
error in this document, so we can make appropriate corrections.
Cybersecurity
This product is designed to be connected to and to communicate information and data via
a network interface. It is your sole responsibility to provide and continuously ensure a
secure connection between the product and your network or any other network (as the
case may be). You shall establish and maintain any appropriate measures (such as, but not
limited to, the installation of firewalls, application of authentication measures, encryption
of data, etc.) to protect the product, the network, its system and the interface against any
kind of security breaches, unauthorized access, interference, intrusion, leakage and/or
theft of data or information. ABB and its affiliates are not liable for damages and/or losses
related to such security breaches, any unauthorized access, interference, intrusion, leakage
and/or theft of data or information.
Patent
The analyzer technology is protected by patents:
•7,468,797
•6,839,140
•6,795,190
•6,694,067
Copyright
© 2023 ABB Inc. All rights reserved. No information contained in this document may be
reproduced in any form, in full or in part, without prior written consent from ABB.
!

ABB GLA132 Series Ultraportable User Manual
5
Safety
The following pages provide important safety precautions.
Class of Laser Equipment
The analyzer is a Class 1 laser instrument when the case cover is closed for normal
operation, and the lock is installed.
Certification
The analyzer certifications are listed in Table 1.
Table 1: Safety Certifications
Symbols
Standards Tested and Met
2004/108/EU (EMC), EN61326-1
Title 21 Code of Federal Regulations, chapter 1, sub-chapter J
WEEE Directive
The analyzer is not subject to WEEE Directive 2002/96/EC (Waste Electrical and Electronic
Equipment) or relevant national laws (e.g. ElektroG in Germany).
The product must be disposed of at a specialized recycling facility. Do not use municipal
garbage collection points. According to the WEEE Directive 2002/96/EC, only products
used in private applications may be disposed of at municipal garbage facilities.

ABB GLA132 Series Ultraportable User Manual
6
Labels
The following labels are at specific locations on or in the analyzer to identify
hazardous areas. (Figure 1)
Figure 1: Radiation Labels
These labels are located on the enclosure covering the OA-ICOSTM cell. The fiber
laser is visible only when the insulated enclosure is removed from the OA-ICOSTM
cell.
Operator Safety
When the case cover is closed and locked into position, the analyzer runs safely, without
risk to the operator. Modifying the analyzer to operate with the case cover open can injure
personnel.
Bypassing the analyzer interlock switch to open the case cover during
analyzer operations can cause serious bodily injury. Even though the
analyzer provides a second layer of protection, such as a laser cover to
prevent the user from the invisible laser beam or any secondary reflection
from the laser on a reflective surface, it is not recommended to modify the
analyzer to operate in an unsafe condition.
Electrical Hazards
The analyzer poses no electrical hazards. The analyzer components operate at ≤6.8 V DC.

ABB GLA132 Series Ultraportable User Manual
7
Laser Hazards
The analyzer is a Class 1 laser product that complies with:
•21 CFR 1040.10 and 1040.11
•EN 60825-1:2014
The laser is classified as a Class IIIb when exposed.
Only trained service personnel are authorized to open the housing or
service the laser.
Using this analyzer in a manner not specified by ABB-LGR may result in
damage to the analyzer and render it unsafe to operate.
Only authorized persons may open the analyzer cover or perform internal
maintenance. Contact ABB-LGR for maintenance instructions and
maintenance kits. Make sure the analyzer is unplugged before working
with the internal components. Failure to do so may result in damage to
the analyzer and electric shock.
Safety Provisions for a Chemical Spill
Follow these precautions when dealing with all chemicals:
•Keep all chemical containers away from heat, sparks, and open flames.
•Use only on grounded equipment and with non-sparking tools.
•Store in a cool, dry, and well-ventilated place, away from incompatible materials.
If a spill occurs:
•Make sure all handling equipment is electrically grounded.
•Mop or wipe up, and then place all chemical-soaked items in containers approved
by the US Department of Transportation (DOT) or the appropriate local regulatory
agency.

ABB GLA132 Series Ultraportable User Manual
8
Text Formats and Warning Icons
Text Formats
This section describes the text formats and warning icons used in this manual.
• Italicized text is used for emphasis in text and also to emphasize the names
of screens or text fields.
•Bold text is used to show text that you type in fields and also button
choices that you enter.
Warning Icons
Table 2 shows and describes the warning icons used in this manual.
Table 2: Warning Icon Descriptions
Icon
Meaning
NOTE or
IMPORTANT!
Emphasizes facts and conditions important to analyzer operation.
WARNING!
General Warning Icon: gives general safety information that must be
followed to avoid hazardous conditions.
WARNING!
Electrical Warning Icon: warns of potential electrical shock hazard.
WARNING!
Laser Warning Icon: warns of potential laser hazard.

ABB GLA132 Series Ultraportable User Manual
9
Transportation and Storage of Boxed
Analyzers
When transporting and storing boxed analyzers:
•Analyzers may be shipped in non-pressurized aircraft.
•Analyzers are fragile: Do not drop or smash boxed analyzers.
•Do not store analyzers outside in wet weather.
•Do not stack boxes more than five high.
•Analyzers may be safely stored at temperatures between -20oC and +60oC.
Save the original shipping materials to use when returning the analyzer to
ABB-LGR if factory service or repair is needed.
Table 3 lists and describes the safety icons on ABB-LGR shipping boxes. Follow these
instructions when transporting and storing boxed analyzers.
Table 3: Transportation and Storage Icon Descriptions
Icon
Meaning
Store your analyzer in a sheltered, dry area. Do not let the box get
wet.
Transport and store the analyzer box with the arrows on the box
pointing up.
The analyzer is fragile. Transport carefully. Do not drop the box.

ABB GLA132 Series Ultraportable User Manual
10
Warranty
Each ABB-LGR analyzer is warranted by ABB-LGR to be free from defects in material and
workmanship. However, our sole obligation under this warranty shall be to repair or
replace any part of the analyzer, which our examination discloses to have been defective in
material or workmanship without charge and only under the following conditions:
1. The defects are called to the attention of ABB-LGR in writing within one year after
the shipping date of the analyzer.
2. The analyzer has not been maintained, repaired or altered by anyone who was not
approved by ABB-LGR.
3. The analyzer was used in the normal, proper, and ordinary manner and has not been
abused, altered, misused, neglected, involved in an accident or damaged by an act
of God or other casualty.
4. The purchaser (whether a distributor or direct customer of ABB-LGR, or a
distributor’s customer), packs and ships or delivers the analyzer to ABB-LGR’s main
office within 30 days after ABB-LGR has received written notice of the defect.
Unless other arrangements have been made in writing, transportation to ABB-LGR
is at customer’s expense.
5. No-charge repair parts may be sent at ABB-LGR’s sole discretion to the purchaser
for installation by purchaser.
6. ABB-LGR’s liability is limited to repair or replace any part of the analyzer free of
charge if ABB-LGR’s examination discloses the part to be defective.
The laws of some locations may not allow the exclusion or limitation on implied warranties
or on incidental or consequential damages, so the limitations herein may not apply directly.
This warranty gives you specific legal rights, and you may already have other rights, which
vary from location to location. All warranties that apply, whether included by this contract
or by law, are limited to the time period of this warranty, which is a twelve-month period
commencing from the analyzer customer ship date or eighteen months from the date of
shipment to an ABB-LGR authorized distributor, whichever is earlier.
Further information concerning this warranty may be obtained by writing or telephoning
the Warranty Manager at ABB-LGR Customer Service.
ABB-LGR provides direct assistance in the use and application of all of its analyzers through
email, telephone, and if necessary, in person.
Please contact icos.suppor[email protected]m and your local sales representative for more
details.

ABB GLA132 Series Ultraportable User Manual
11
Warranty Returns
If your product is defective, you may return it during its designated warranty period for a
prompt exchange or repair. To return a product, please contact your local sales
representative and ABB service support to request a Return Material Authorization (RMA)
number. Requests for refunds and exchanges cannot be processed without a valid RMA
number.
Please have the following information available when requesting an RMA number:
•Part Number
•Serial Number (Located on the side panel of the analyzer)
•Description of the Problem
The company-issued RMA number must be prominently displayed on the return package.
No returns will be accepted collect or C.O.D. On all warranty returns, ABB-LGR will pay the
shipping charges on the return of the merchandise to the customer.
Customer Support
ABB provides product support services worldwide. To receive product support, either in or
out of warranty, contact the ABB office that serves your geographical area, or the office
indicated below:
ABB Inc. Measurement & Analytics
3400, rue Pierre-Ardouin
Quebec, (Quebec) G1P 0B2 Canada
Tel: [phone] (North America)
Tel: [phone] (Worldwide)
Fax: [phone]
Technical Support: Icos.[email protected]
Please contact icos.[email protected] and your local sales representative for more
details.
Please provide the serial number or sales order number of the analyzer.

ABB GLA132 Series Ultraportable User Manual
12
1 Analyzer Overview
The ABB-LGR GLA132 Series are Ultra-Portable Analyzers that measure concentrations of
gas in parts per million (ppm) and parts per billion (ppb).
This analyzer is a Class 1 laser product.
Performance Specifications
Ambient Humidity
•<99% relative humidity non-condensing
Operating Temperature
•5 - 45oC
Maximum Altitude
•6,000 Feet
Power Requirements
•60 Watts (typical) – 11-30 VDC (battery power)
•66 Watts (typical) – 15-230 VAC, 50/60hz (AC adaptor)
•120 Watts maximum
Fuse Ratings
•32 VAC
•10 Amps
•Fast-blow fuse
Cable Plugs and Voltage for EC Countries
•See page 93.
Always use the power supply cord provided by ABB-LGR. See page 93 for a
description of power cords for a specific country.

ABB GLA132 Series Ultraportable User Manual
13
External Dimensions
•18.5” W x 14” D x 7” H
Weight
•16.9 kg
Cell Volume
•345 cc cavity
•10 cc tubing
•Total volume = 355 cc

ABB GLA132 Series Ultraportable User Manual
14
Standard Components
This section describes the analyzer components. Verify that each of the system
components has arrived before installation.
The standard components include:
•GLA132 Series analyzer
•Analyzer power cord
•AC/DC power supply
•External in-line filter (push-connect)
•Null modem type serial data cable
•USB flash drive
•User Guide (this document)
•Certificate of compliance
Optional Components
Available on select analyzers.
•Multiport Inlet Unit, eight or sixteen channels (MIU-8, MIU-16)
oPower cable
o25-pin control signal cable
o64GB solid state hard drive
•Water Vapor Isotope Standard Source – Standard range (WVISS)
oWVISS hand pad
oControl signal cable
oBNC cable
This analyzer has been CE certified using data cables three meters long or
less. Connecting the analyzer using longer data-cables is not
recommended.
The wireless user interface will not work if:
•The analyzer has a system failure
•The hard drive fails or is corrupted
•Battery power to the analyzer is interrupted
If any of these failures occur, you will need a mouse, keyboard and monitor
to restart the analyzer. A back up hard drive is recommended.
If you have not received all of these components, contact ABB-LGR at
icos.sup[email protected]bb.com.

ABB GLA132 Series Ultraportable User Manual
15
Figure 2 shows the left side of the analyzer.
Figure 2: Left Panel
Figure 3 shows the right side of the analyzer.
Figure 3: Right Panel

ABB GLA132 Series Ultraportable User Manual
16
Power Connections
The power connector is on the left side panel of the analyzer. (Figure 4)
The analyzer can be powered two ways:
•Using the AC/DC power supply to the DC power inlet
•Using the battery hook-up kit (Optional)
The battery voltage must be in the range of 11-30 volts DC . It has a continuous discharge
rate to power 80 watts (or higher).
Figure 4 shows the power entry connector and the power switch.
Figure 4: Power Connections and AC Voltage Selection Switch
The analyzer is equipped with a three-prong power plug. The third prong
of the facility electrical outlets must be grounded. Failure to ground the
third prong may result in electrical damage to the analyzer and electrical
shock to the operator.
Emergency Shutdown Procedure
If the analyzer malfunctions and requires emergency shutdown:
1. Turn off the analyzer using the left side panel on/off switch. (Figure 2)
2. Unplug the power cord from the analyzer. (Figure 4)
3. Notify trained service personnel that the analyzer needs repair or servicing.

ABB GLA132 Series Ultraportable User Manual
17
Data Interface Connection Ports
This section describes the data interface connections as shown in Figure 5. These
connections may vary from analyzer to analyzer depending on the ordered configuration.
•USB ports – Used for transferring data to a USB memory device, or to connect a
USB keyboard and mouse.
•Ethernet port – Connects the analyzer to a local area network (LAN) and allows
access to the data directory using an external computer.
•Serial port (9 pin D-sub) – For real-time digital measurement output.
•Video port (15 pin D-sub) – Connects an external monitor to the analyzer.
•Analog out ports – Provides a DC voltage proportional to the measured gas
concentration. If this output is connected to an external device, it must be
terminated into a moderate to high impedance (>1 kOhm).
•MIU port (25-pin data port) – For connecting to a Multiport Inlet Unit (optional).
•WVISS- Only applicable for the GLA132-WVIA
Figure 5: Data Interface Connection Ports
!

ABB GLA132 Series Ultraportable User Manual
18
Plumbing Diagram
The plumbing diagram measures the internal flow of gas through the analyzers.
Standard Plumbing
Figure 6 shows an example of the internal flow of gas in an ultraportable analyzer.
Plumbing configurations will vary depending on the analyzer type.
Figure 6: Plumbing Diagram for a GLA132-GGA analyzer
The internal pump draws gas through the SAMPLE INLET on the left side panel of the
analyzer. The gas is filtered through a screen filter before entering the pressure controller,
which regulates the pressure to maintain a specific set point. The gas travels through the
optical cell and out through the WASTE port.
Figure 7 shows the plumbing diagram for a GLA132-CCIA2
Figure 7: Plumbing diagram for a GLA132-CCIA2

ABB GLA132 Series Ultraportable User Manual
19
Inlet/Outlet Connections
The inlet and outlet ports are located on the left side panel of the analyzer. (Figure 8)
•Gas to be measured is connected to the ¼” push-connect INLET port.
•An External In-Line Filter (Figure 10) is provided and can be attached to the INLET
port.
During normal operation, the pump draws the sample through the analyzer inlet, and
exhausts the sample through the waste port.
The ¼” push-connect WASTE port may be:
•Routed to the facility ventilation system, or
•Remain open, expelling non-hazardous gas into the room air.
Figure 8: Inlet/Outlet ports
!

ABB GLA132 Series Ultraportable User Manual
20
Warning Labels and Descriptions
This section describes the warning labels shown on the analyzer.
•Table 4 gives a description of the warning labels.
•Figure 9 shows the location of the labels on the analyzer.
Table 4: Warning Labels and Descriptions
Label
Description
The laser is rated Class 3 (invisible laser radiation) when the
housing is open.
Only trained maintenance personnel may open the analyzer
housing.
General laser warning label.
Figure 9: Warning Label Locations
!
