ABB LGR GLA351 Series User manual

—
ABB MEASUREMENT & ANALYTICS | USER MANUAL
User Manual | ICOS
GLA351 Enhanced Performance QC
Rackmount Analyzers

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
2
Table of Contents
Disclaimer...................................................................................................................................5
Cyber Security.........................................................................................................................5
Patent..........................................................................................................................................5
Copyright....................................................................................................................................5
Safety...........................................................................................................................................6
Class of Laser Equipment.....................................................................................................6
Certification............................................................................................................................6
WEEE Directive........................................................................................................................6
Labels.......................................................................................................................................7
Operator Safety......................................................................................................................7
Electrical Hazards...................................................................................................................7
Laser Hazards .........................................................................................................................8
SafetyProvisions for a Chemical Spill.................................................................................8
Text Formats and Warning Icons.........................................................................................9
Transportation and Storage of BoxedAnalyzers ...............................................................10
Positioning theanalyzer.........................................................................................................10
Warranty.....................................................................................................................................11
Customer Support................................................................................................................... 12
1Analyzer Overview........................................................................................................................13
Performance Specifications...................................................................................................13
Ambient Humidity................................................................................................................13
Operating Temperature...................................................................................................... 13
Maximum Altitude................................................................................................................13
Power Requirements............................................................................................................13
Power Requirements with ExternalPump........................................................................13
Fuse Ratings..........................................................................................................................13
Cable Plugs and Voltage for EC Countries....................................................................... 13
Standard Components............................................................................................................14
Optional Components.............................................................................................................14
Power Connections ................................................................................................................. 17
Data Interface ConnectionPorts...........................................................................................18
Plumbing Diagram...................................................................................................................19
Standard Plumbing..............................................................................................................19
Optional Fast Flow Mode....................................................................................................20
Fast and SlowFlow Pump Options.................................................................................... 21
Plumbing Diagram with a Pretreatment Box...................................................................22
Gas Inlet/Outlet Connections................................................................................................23
Warning Labels and Descriptions .........................................................................................25
2Mount the Analyzer......................................................................................................................26
Mounting Specifications ........................................................................................................26
External Dimensions:...........................................................................................................26
Weight:...................................................................................................................................26

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
3
Rack-Mount Installation..........................................................................................................27
Rack Mounting Ventilationand Power Requirements....................................................27
Emergency ShutdownProcedure..........................................................................................27
3Analyzer Setup.............................................................................................................................28
Connect the Power Cords.......................................................................................................28
Connect the Data Interface Connections ............................................................................28
Connect the Inlet/Outlet Plumbing Connections...............................................................28
Connect theGLA351-CCIA3analyzer tothe pretreatment box........................................29
Attachand Tighten the Swagelok Connectors...................................................................30
ThePretreatment Box for the GLA351-CCIA3......................................................................31
4Initialize and Run the Analyzer ..................................................................................................32
File System Integrity Check....................................................................................................33
Thermal Stabilization..............................................................................................................33
The Launch Service Screen.....................................................................................................34
The Auto Launch Screen.........................................................................................................35
Login to Access MenuOptions..............................................................................................36
MainPanel.................................................................................................................................37
UserInterface Control Bar..................................................................................................38
Main Panel Displays................................................................................................................ 40
Numeric Display................................................................................................................... 40
Alarm Status Display............................................................................................................41
Spectrum Display.................................................................................................................45
TimeChart Display................................................................................................................47
Rate Control..............................................................................................................................48
File Transfer Menu...................................................................................................................50
Standard Data File................................................................................................................50
Transfer Data Files...............................................................................................................51
Types of directories in the local hard drive.........................................................................53
Daily Directory.......................................................................................................................53
Archive Directory..................................................................................................................54
File Transfer Error Screen.......................................................................................................55
Setup Menu...............................................................................................................................56
Time/Files Tab......................................................................................................................58
Calibration Tab.....................................................................................................................61
Laser Adjust Tab...................................................................................................................63
MIU tab...................................................................................................................................65
Analog Output Tab...............................................................................................................68
DCS Tab..................................................................................................................................69
Servicetab.............................................................................................................................70
Shutting Down the Analyzer................................................................................................... 71
5Maintenance.................................................................................................................................72
DailyOperation Checklist.......................................................................................................72

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
4
Mirror Ring-Down Time and Maintenance...........................................................................72
Replace the Power Inlet Fuse.................................................................................................73
Appendix A: About Gas Analyzers and Laser Absorption Spectroscopy...............................74
Conventional Laser Absorption Spectroscopy...................................................................74
ABB-LGR’sOff-Axis Integrated-Cavity Output Spectroscopy (Off-Axis ICOS)..............76
Appendix B: Accessing Data Using the Ethernet.......................................................................77
Appendix C: Wireless Router Setup (Optional)..........................................................................79
Appendix D: Set UpDevices for Remote Access Using VNC Software ..................................84
Appendix E: Multi-Port Inlet Unit (Optional)..............................................................................97
Appendix F: External Dynamic Dilution System (Optional) ...................................................102
Appendix G: Fast-Flow Operation for the GLA351-N2OCM andGLA351-N2OM1................107
Appendix H: Batch Mode Operation...........................................................................................112
Appendix I: Spectrum Displays....................................................................................................121
GLA351-CCIA3 EnhancedPerformance QC Rackmount Carbon DioxideIsotopic
Analyzer.................................................................................................................................121
GLA351-N2OCM Enhanced Performance QC Rackmount Nitrous Oxide/Carbon
Monoxide Analyzer.............................................................................................................122
GLA351-N2OM1EnhancedPerformance QC Rackmount Methane / NitrousOxide
Analyzer................................................................................................................................123
Appendix J: Isotope Definitions.................................................................................................124
Appendix K: Cables.......................................................................................................................126

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
5
Disclaimer
This document contains product specifications and performance statements that may be
in conflict with other ABB published literature, such as product flyers and product catalogs.
All specifications, productcharacteristics, and performance statements includedin this
document are suggested specifications only. In case of conflict between product
characteristics in this document and specifications in the official ABB product catalogs, the
latter takes precedence.
ABB reserves theright to make changes to thespecifications of all equipment and
software, andto thecontents of this document, without obligation to notifyany person or
organization of such changes. Every effort has been made to ensurethat the information
contained inthis document is currentandaccurate. Please contact ABB-LGRif you find any
error in this document, so we canmake appropriate corrections.
Cyber Security
This product is designedto be connected to and to communicate informationand data via
a network interface. It is your soleresponsibility to provideand continuously ensure a
secure connection between the product and yournetwork or any other network (as the
case may be). You shall establish andmaintain any appropriate measures (such as, but not
limited to, the installation of firewalls, application of authentication measures, encryption
of data, etc.) to protect the product,the network, its system and the interface against any
kind of security breaches, unauthorized access, interference, intrusion, leakageand/or
theft of data or information.ABB and itsaffiliates are not liable for damagesand/or losses
related to such security breaches, any unauthorizedaccess,interference, intrusion, leakage
and/or theftof data orinformation.
Patent
The analyzertechnology is protected by patents:
7,468,797
6,839,140
6,795,190
6,694,067
Copyright
© 2020 ABB Inc. All rights reserved. No informationcontained inthis document may be
reproducedin any form, in full orin part, without prior written consent fromABB.

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
6
Safety
The followingpages provideimportant safety precautions.
Class of Laser Equipment
The analyzeris a Class 1 laser instrument whenthecase cover is closed for normal
operation, and the lock is installed.
Certification
The analyzercertifications are listed in Table 1.
Table 1: Safety Certifications
Symbols
Standards Tested and Met
2004/108/EU (EMC), EN61326-1
Title 21 Code of Federal Regulations,chapter 1, sub-chapter J
WEEE Directive
The analyzeris not subject to WEEE Directive 2002/96/EC (Waste Electricaland Electronic
Equipment) orrelevant national laws (e.g. ElektroGin Germany).
The product must be disposed of at a specialized recycling facility. Do notusemunicipal
garbage collection points. According to the WEEEDirective 2002/96/EC,only products
used in private applications may be disposed of at municipal garbage facilities.

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
7
Labels
The followinglabels are at specific locations on or in the analyzerto identify hazardous
areas. (Figure 1)
Figure 1: Radiation Labels
These labelsare located on the enclosure covering the ICOS cell. The fiber laser is visible
only when the insulated enclosure is removed fromthe ICOS cell.
Operator Safety
When the case cover is closedand locked into position, the analyzerruns safely, without
risk to the operator. Modifying theanalyzer to operatewith thecase cover opencan injure
personnel.
Bypassing the analyzer interlock switch to open the case cover during
analyzer operations can cause seriousbodily injury. Even though the
analyzer provides a second layer of protection, such as a laser cover to
prevent the user from the invisible laser beam or any secondary reflection
from the laser on a reflective surface, it is not recommended to modify the
analyzer to operate in an unsafe condition.
Electrical Hazards
The analyzer poses no electrical hazards. Theanalyzer components operateat ≤6.8 V DC.

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
8
Laser Hazards
The analyzeris a Class 1 laser product that complies with:
21 CFR 1040.10 and 1040.11
EN 60825-1:2014
The laser is classified as a Class IIIb when exposed.
Only trained service personnel are authorized to open the housing or
service the laser.
Using this analyzer in a manner not specified by ABB-LGR may result in
damage to the analyzer and render it unsafe to operate.
Only authorized persons may open the analyzer cover or perform internal
maintenance. Contact ABB-LGR for maintenanceinstructions and
maintenance kits. Make sure the analyzer is unplugged before working
with the internal components. Failure to do so may result in damage to
the analyzer and electric shock.
Safety Provisions for a Chemical Spill
Follow these precautions when dealing withall chemicals:
Keep allchemicalcontainers away from heat, sparks, and open flames.
Use onlyon groundedequipment and with non-sparkingtools.
Store in a cool, dry, and well-ventilatedplace, away from incompatible materials.
If a spill occurs:
Make sure all handling equipment is electrically grounded.
Mop or wipe up, andthen place all chemical-soaked items in containers approved
by the US Department of Transportation (DOT) or the appropriate localregulatory
agency.

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
9
Text Formats and Warning Icons
Text Formats
This section describestext formats and warning icons used in this manual.

Italicized text is usedfor emphasis in text and also to emphasize the names
of screens or text fields.
Bold text is used toshow text that you type in fieldsand also button
choices that you enter.
Warning Icons
Table 2shows and describes the warning icons used in this manual.
Table 2: Warning Icon Descriptions
Icon Meaning
Emphasizes facts and conditions important to analyzer operation.
WARNING!
General Warning Icon: gives general safety information thatmust be
followed toavoid hazardous conditions.
WARNING! Electrical Warning Icon: warns ofpotential electrical shockhazard.
WARNING!
Laser Warning Icon: warns of potential laser hazard.

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
10
Transportation and Storage of Boxed
Analyzers
When transporting and storing boxed analyzers:
Analyzers may be shipped in non-pressurizedaircraft.
Analyzers are fragile: Do not drop or smash boxed analyzers.
Do not storeanalyzers outside in wetweather.
Do not stack boxesmore than five high.
Analyzers may be safely stored at temperatures between -20oCand +60oC.
Save the original shipping materials to use when returning the analyzer to
ABB-LGR if factory service or repair is needed.
Table 3 lists and describes thesafety icons on ABB-LGR shipping boxes. Follow these
instructions when transporting and storing boxedanalyzers.
Table 3: Transportation and Storage Icon Descriptions
Icon
Meaning
Store your analyzer ina sheltered, dry area. Do not let the box get
wet.
Transport and storetheanalyzer box with thearrows on the box
pointing up.
The analyzeris fragile. Transport carefully. Donot drop the box.
Positioning the analyzer
Positioningthe analyzer isa two-person task. Withone person on each side, lift the
analyzer out of the box andonto a flat surface. Leave four inches of freespace on each side
of the analyzer for proper ventilation.

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
11
Warranty
Each ABB-LGRanalyzer iswarranted byABB-LGR to be free from defects in material and
workmanship. However, our sole obligation underthis warrantyshall be to repair or
replace any part of the analyzer, which our examination discloses to have been defective in
material orworkmanshipwithout charge and only under the following conditions:
1. The defects are called to the attention of ABB-LGRin writing within one year after
the shipping date of the analyzer.
2. The analyzerhas not beenmaintained,repaired oraltered by anyonewho was not
approved by ABB-LGR.
3. The analyzerwas used inthe normal, proper, and ordinarymanner and has not been
abused, altered,misused, neglected,involvedin anaccident or damagedby an act
of God or other casualty.
4. The purchaser (whethera distributor or direct customer of ABB-LGR, or a
distributor’scustomer), packs andships or delivers theanalyzer to ABB-LGR’smain
office within 30 days after ABB-LGR has receivedwritten notice of the defect.
Unless otherarrangements have beenmade inwriting, transportation to ABB-LGR
is at customer’s expense.
5. No-charge repair parts may be sent at ABB-LGR’s sole discretion to the purchaser
for installation by purchaser.
6. ABB-LGR’s liability is limitedto repair or replace anypart of theanalyzer freeof
charge if ABB-LGR’s examination disclosesthe part to be defective.
The laws of some locations may not allow the exclusion or limitation on impliedwarranties
or on incidental or consequential damages, so the limitations herein may not apply directly.
This warranty gives you specific legalrights, and you may already have otherrights, which
vary from location to location. All warranties that apply, whether includedby this contract
or by law,are limited to thetime period of this warranty, which isa twelve-month period
commencing from the analyzer customer shipdate or eighteen months from thedate of
shipment to an ABB-LGR authorized distributor, whichever is earlier.
Further information concerning this warranty may be obtained by writing or telephoning
the Warranty Managerat ABB-LGR Customer Service.
ABB-LGR provides direct assistance in theuse and application of all of its analyzers through
email, telephone, and if necessary, in person.
Please contact [e-mail] and your local salesrepresentative for more
details.

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
12
Warranty Returns
If your product is defective, you may returnit during its designated warranty period for a
prompt exchangeor repair. To returna product, please contact your localsales
representativeandABB service support to request a Return Material Authorization (RMA)
number. Requests for refunds and exchanges cannot be processed without a valid RMA
number.
Please have the following information available when requestingan RMA number:
Part Number
Serial Number (Located on the back panel of the analyzer)
Description of the Problem
The company-issued RMA numbermust be prominently displayed onthereturn package.
No returns will be accepted collect or C.O.D. On all warranty returns, ABB-LGR will paythe
shipping charges on the return of the merchandiseto the customer.
Customer Support
ABB provides productsupport services worldwide. To receive product support, either in or
out of warranty, contact the ABB officethat serves your geographical area, or the office
indicated below:
ABB Inc. Measurement & Analytics
3400, rue Pierre-Ardouin
Quebec, (Quebec)G1P 0B2 Canada
Tel: [phone] (North America)
Tel: [phone] (Worldwide)
Fax: [phone]
Technical Support: [e-mail]
Please contact [e-mail] and your local salesrepresentative for more
details.
Please provide the serial number or sales order number of the analyzer.

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
13
1 Analyzer Overview
The ABB-LGR GLA351 series are EnhancedPerformanceQC Rackmount Analyzers that
measure concentrations of gas in parts per billion (ppb) and parts per million (ppm).
Isotoperatios are shownin parts per thousand (‰).
This analyzer is a Class 1 laser product.
Performance Specifications
Ambient Humidity
<99% relative humiditynon-condensing
Operating Temperature
0 - 45oC
Maximum Altitude
6,000 Feet
Power Requirements
115/230 VAC, 50/60hz
300 W (steady state)
420 Watts with theACC DP3H external pump (steady state)– Applicable for the
GLA351-CCIA3 analyzer
Power Requirements with External Pump
420 W with the optional ACC DP3H external pump
Fuse Ratings
250 VAC
10 Amps
Cable Plugs and Voltage for EC Countries
See page 126
Always use the power supply cord provided by ABB-LGR. See page 126 for
a description of power cords for a specific country.

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
14
Standard Components
This section describesthe analyzer components. Verify that each ofthe system
components has arrivedbefore installation.
Basic free-flow system:
GLA351 Series analyzer
Analyzer power cord
User Guide (this document)
USB flash drive
Serial port connection cable (null modem type)
Exhaust muffler
Applicable for the GLA351-CCIA3
External Pump System
oExternal pump (ACC-DP3H)
oPump power cord
Pretreatment box with five Teflon connecting tubes:
oTwo 6’ x 1/4”
oTwo 6’ x 3/8”
oOne 3’ x 1/4”
Optional Components
Available on select analyzers.
External Pump System (includesconnection kitandpower cord); Options include:
o3-head diaphragm vacuum pump (ACC-DP3H)
o4-head diaphragm vacuum pump (ACC-DP4H)
o3-head diaphragm vacuum pump- Europe only (ACC-DP20)
oDry Scroll Vacuum Pump (ACC-DS10)
Multiport Inlet Unit (MIU-16or MIU-8)
oPower cable
o25-pinconnection cable for control signal
Batch Injection System (OPT-BATCH-INJECTION)
oInjection port to provide capability for discretesample measurements via
syringe injection. Accessoriesinclude:
Syringe injection port
140 mL syringe
Centering needle
Septa (box of 50)
Septum puller
External Dynamic Dilution System (EDDS)
oPower cable
oBNC Control Cable
o¼” x 6’ Teflonconnectiontube with Swagelok teeconnector

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
15
This analyzer has been CE certified using data cables three meters long or
less. Connecting the analyzer using longer data-cables is not
recommended.
If you have not receivedall of these components,contact ABB-LGR at
icos.suppo[email protected].com.

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
16
Figure 2 shows the front panel of theGLA351 Series.
Figure 2: Front Panel
Figure 3 shows the back of the GLA351 Series analyzers with connections. Port locations
may vary for different analyzer types.
Figure 3: Back Panel (GLA351-N2OM1)

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
17
Power Connections
Figure 4 shows the power connections on the backpanel, and Table 4describesthe
connections.
Figure 4: Power Connections
Table 4: Power Connections and AC Voltage Selection Switch Description
Connector
D
escription
AC Power In Connects the analyzer to the power supply
AC Voltage Selection Toggles the input voltage to theanalyzer’s power supply
between 115 VAC and 230 VAC, determined bythe countrywhere
the analyzer is used.
Settingan incorrect voltage may damage the analyzer. When
changing the supply voltageverify that both the:
Analyzer is powered offor notconnected to power.
AC voltage selection on theanalyzer matches the AC
voltage being supplied from your powersupply.
EXT. Pump Power Provides power to an external pump when operating the
analyzer.
If you require a different power source, please contact ABB-LGR.

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
18
Data Interface Connection Ports
This section describes the data interface connections for the GLA351-N2OCM and the
GLA351-N2OM1. These connections vary from analyzer to analyzer depending on the
ordered configuration.
Analog ports– Provides a DC voltage proportional to the measured gas
concentration. Ifthese outputs are connectedto an external device, it must be
terminated into a moderate to high impedance (>1kOhm).
USB ports – Used for transferring data to a USB memory device, or to connecta
USB keyboard andmouse.
Ethernet port – Connects the analyzer to a localarea network (LAN)andallows
access tothe data directory using an externalcomputer.
Serial port (9 pin D-sub) – For real-time digitalmeasurement output.
Video port (15 pin D-sub) – Connectsan external monitor to the analyzer.
TO MIU port (25-pin data port) – For connecting toa Multiport Inlet Unit (optional).
DCS port (BNCmale port) – Used to control the optional External Dynamic Dilution
System (EDDS). (Applicable for theGLA351-CCIA3)
Figure 5 showsan example ofthe
Data Interface Connection Ports ofa GLA351-N2OCM.
Figure 5: Data Interface Connection Ports (GLA351-N2OCM)

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
19
Plumbing Diagram
The plumbing diagram measurestheinternal flow of gas through the analyzers.
Standard Plumbing
Figure 6 shows an exampleof the internal flow of gasin standard plumbing analyzers.
Configurations will vary depending on the analyzer typeand may not includean external
pump.
For standard operation, the internal pump draws gas throughthe
Sample Inlet Swagelok
port on the back panel of the analyzer. The gas is filtered through a filter before entering
the pressurecontroller, which determines the analyzer flow rate. The gas thentravels
through the optical cell andis exhaustedthrough the Internal Pump Exhaust port. The
acceptable inlet gas pressure range is 1 to 5 psig.
Figure 6: Standard Plumbing Diagram for a GLA351-N2OCM

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
20
Optional Fast Flow Mode
Analyzers with fast flowcapabilities (external pumpon/internal pump off) measure data at
a higher flow rate. Fast analyzers are equipped with an external throttle valve (Figure7) to
tune the pressure ofthe systemso the pressure in the gas cavity remains within the
pressure control range ofthe internal pressure controller during measurement. Details on
how to adjust the throttle valveare located inAppendix F: Fast Flow Operation on page
107.
The gas exiting thecell flows through the external pump pathway during fast flow. Both
the internal pump and external pump outlet flow paths are isolated by check valves to
prevent leakage fromthe flow path that is not in use.
Cap the
Internal Pump Exhaust port with the provided ¼” Swagelok cap
during Fast-Flow operation.
Figure 7 shows the optional external high-flow throttle valve.
Figure 7: High-Flow Throttle Valve
The optional external pump draws gas through the Sample Inlet Swagelok port on the back
panel of the analyzer, andthe waste is exhausted through the
To External Pump Swagelok
port when set to Fast Flow Mode.
