Abestorm Guardian SNS100 User manual

User’s Manual
C
Guardian SNS100
Ab est or m
Add: 8605 SANTA MONlCA BLVD#79525
WEST HOLLYWOOD,California,90069 USA
E-mail: [email protected]
Note: as we keep upgrading our product, we reserve the right to modify the product without notice in advance.

1

2

3
Capacity @ 80°F/60%RH: 100 Pints Per Day
Capacity @ 73°F/60%RH: 78 PPD
Airflow : 250 CFM
Operating Temp. Range: 33.8-104°F
Operating Relative Humidity Range: 35%-90%
COP: 2.7 L/kWh
Refrigerant: R410A
Amperage Usage: 6.82 Amps
Power Supply: 115V/60Hz/Single Phase
Outlet Requirement: 15 Amp, 3 prong, GFCI
Sound Level: 60 dBa
Dimensions LxWxH: 23.82x13.98x15.94
ETL Listed: Yes
· The area where the dehumidifier is located should be sealed with a vapor barrier.
• If the unit is installed in a crawl space, all vents should be sealed.
• For proper ventilation, neither the inlet or discharge should be positioned against a wall.
• The inlet needs a minimum of 12” clearance and the discharge requires a minimum of 36”
clearance.
• For the best air diffusion, install the unit so that a side panel faces the wall.
• Abestorm dehumidifiers are only intended for operation when the unit is upright and level
with the feet on the ground.

4

·� The continuous light will illuminate green and the display will show “CO”.
·� To switch back to normal humidistat operation, use the arrow keys to
move the setpoint above 36%.
4. Manual Drain Button
·� If you need to store or move your dehumidifier, press the “Drain” button to remove water
from the integral pump’s reservoir.

· The Abestorm Guardian SNS100 has an integrated condensate pump. During normal operation,
the Guardian SNS100 will automatically drain as required.
· If you would like to store or move your unit, press the drain button to drain water from
the pump reservoir. The drain will operate for 15 seconds each time the button is pushed.
It may be necessary to push the button more than once.
