ABSCO SHEDS CG56552N2 Installation guide

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 1
AU: 1800 029 701
NZ: 0800 466 444
[email protected]
www.abscosheds.com.au
For construction in non-cyclonic areas
Wind rating: N2 as per AS4055-2012.
If you require a higher wind rating please contact
us: [email protected] or 1800 029 701
*The frame must be secured to a concrete slab
or footings, details of which are noted on the
attached engineering drawings. Brackets for
securing the frame to either a concrete slab or
footings are included in this kit. Anchors are not
included.
Local authority approval must be obtained prior
to construction. Once you have selected your
site, draw a site plan and lodge your application
together with a copy of the engineering plans
located at the back of these instructions.
Opening width: 4400mm
Opening height: 2210mm
Internal wall height: 2170mm
Download the Absco
Sheds Assembly App
for instructional videos
MANUFACTURED
IN AUSTRALIA
SNAPTiTE
Assembly
5.64 x 5.49 m x 2.64

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 2
Tools Required
Tools Recommended
Safety Notes
• Some parts and assemblies have sharp edges and/ or sharp corners.
• The use of gloves and safety shoes is highly recommended.
• Pay attention to where these parts can be handled most safely, and plan the handling of these
parts and assemblies prior to working with them.
• The assembly of this product requires drilling into sheet metal which produces small metal
shavings.
• Clearing of these shavings throughout the assembly process is highly recommended.
The assembly of this product requires some lifting of heavy assemblies
BUILDERS’
STRING

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 3
Steps To Construct Your Garage
Identification of parts ...................................................................... 4
Concrete slab/ footing details ....................................................... 9
Rear frame assembly ...................................................................... 11
Center frame assembly .................................................................. 13
Front frame assembly ..................................................................... 15
Frame layout ................................................................................... 17
Frame construction ......................................................................... 18
Fit roof purlins ................................................................................. 20
Fit sheeting ...................................................................................... 21
Assemble & fit barn doors ............................................................. 24
Fit gutters & trim ............................................................................ 28
Engineering drawings...................................................................... 30
1. Part numbers
As noted on page one, part numbers have been printed on most 80 x 40 channel sections and
sheeting. All other components have not been marked with part numbers, but can be identified by
their description, size and sketches provided on pages three, four and five of this instruction.
2. Personal Access Door (P.A. Door)
If you have selected the optional Personal Access Door, P.A. Door, There is an additional
instruction manual that is to be used in conjunction with this document.
3. All components pre-cut to size
Do not cut any components to a different size, unless it is clearly noted in this instruction to do
so. Dimensions in this assembly instruction are exact, where as dimensions noted on the engineering
plans are approximate. Double check that you have the correct component for the correct location.
4. Self drilling screws
Helpful Hints
10 x 16 Hex head tek screw for general use.
Phillips head tek screw - use on outside
of front framework to maintain a smooth
surface to surface to secure sheeting to.
The structure is assembled using these self drilling tek screws. All roof and wall sheets are pan
fixed. ie screw through the flat pan of the sheet into the framework.
Screw driver bits are included for use in your drill. Refer to the attached engineering drawings
for the quantity of screws required per connection.
10 x 16 Hex head tek screw with neoprene
washer for securing roof sheets to
framework.

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 4
5. Missing parts
To prevent damage in transit, some items are packed inside others. eg. some flashings may be
inside channel sections, other items may be packed inside gutters, some roof sheets packed on top,
some on the bottom etc. be very thorough when checking and locating all components.
6. Anchor sets not supplied (Hold down brackets are included)
Anchor sets are not supplied with this garage, but can be obtained from most hardware out-
lets. Anchors required for this garage are as follows;
11 Chemsets M10130 (10mm x 130mm Long)
2 M10 X 75 Dynabolts for P’ Door if applicable.
Note: M10 x 125 long dynabolts can be substituted for chemsets
Frame Section Identification Guide
There are several types of frame section, each featuring a different combination of notches and/or
holes. Frame sections are coded with a letter representing the type of frame section, followed by the
length of the frame section in millimeters.
EG: C2960 = Straight cut both ends with overall length of 2960mm
C-TYPE - Straight cut at both ends M-TYPE - 45mm lip notch at both ends
J-TYPE - Straight cut at one end: 20mm tab notch with
holes at other end
K-TYPE - 20mm tab notch with holes at both ends
L-TYPE - Straight cut at one end: 45mm lip notch at other
end.
N-TYPE - Straight cut at one end: 45mm lip notch/20mm
tab notch with holes at other end
P-TYPE - 45mm lip notch/20mm tab notch with holes at
both ends.
R-TYPE - 45mm lip notch/20mm tab notch with holes at
one end: 90mm lip notch at other end.
S-TYPE - Variable notching and/or holes nominated in parts checklist

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 5
SINGLE SECTION TWO SECTIONS
BOXED TOGETHER
8800
3388
4400
PPAACCKKTTYYPPEEQQTTYYPPAARRTTNNOO..CCHHEECCKK
QQTTYYPPAACCKKTTYYPPEEQQTTYYPPAARRTTNNOO..CCHHEECCKK QQTTYY
FRONT
FRAME
REAR
FRAME
CENTRE
FRAME
SIDE
WALLS
ROOF
PURLINS
BARN
DOORS
8
8
12
C2069
C2832
K1780
18 K1780
8
6
4
C2177
K2142
P2360
One leg of the channel section is 2mm shorter thatn the other leg to allow two channel sections to be
boxed together. Most framing requires only single sections of channel, with boxed sections located
only where noted in this instruction.
80mm x 40mm Galvanized Channel Framing Sections
Part Details (Sheet 2 of 6)
2
2
2
3
2
1
4
2
2
C2150
S2833
C2199
C1466
R0877
J0403
K0525
R1100
K0144
C2150
N2380
C2335
C2633
M2833
K1392
2
2
2
2
2
8

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 6
GUTTER
40
40
60 ROOF
SHEET
EDGE
TRIM
'L' ANGLE
FLASHING
BARN DOOR
FLASHING
RIDGE
CAPPING
SHEET PACK
QTY COMPONENT
DESCRIPTION
PART
No. CHK QTY COMPONENT DESCRIPTION
PART
No. CHK
1
STEEL SHEET
2676 x 773mm
REAR
CLB1 1
STEEL SHEET
2676 x 773mm
REAR
CRB1
1
STEEL SHEET
2546 x 773mm
REAR
CLB2 1
STEEL SHEET
2546 x 773mm
REAR
CRB2
1
STEEL SHEET
2416 x 773mm
REAR
CLA1 1
STEEL SHEET
2416 x 773mm
REAR
CRA1
2
STEEL SHEET
2286 x 773mm
CORNER
CLA2 2
STEEL SHEET
2286 x 773mm
CORNER
CRA2
1
STEEL SHEET
435 x 773mm
FRONT
087L 1
STEEL SHEET
435 x 773mm
FRONT
087R
1
*STEEL SHEET
305 x 773mm
FRONT
070-1 1
*STEEL SHEET
305 x 773mm
FRONT
070-2
1
*STEEL SHEET
175 x 773mm
FRONT
070-3 1
*STEEL SHEET
175 x 773mm
FRONT
070-4
16
STEEL SHEET
2860 x 773mm
ROOF
286 14
STEEL SHEET
2180 x 773mm
SIDE WALL
218
2
*STEEL SHEET
2175 x 695mm
DOOR
217-A 4
STEEL SHEET
2175 x 773mm
DOOR
217
* Part number not printed as above. Conrm part by dimensions and/or angle of cut.

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 7
2
4
4
2
4
2
RIDGE CAPPING TR08
BARGE CAPPING TR34
GUTTERS TR22
BARN DOOR FLASHING TR21
'L ANGLE FLASHING TR19
50mm PVC DOWNPIPES RWG14
3030
3000
3030
3000
3000
1880
EXTERNAL TRIM
QTY TYPE LENGTH CHECK
BRACKETS, PLATES AND ACCESSORIES
QTY DESCRIPTION CHECK QTY DESCRIPTION CHECK
2
8
4
1
200
900
2
3
14
2
9
4
1
100
2
6
TYPE 'H' CHANNEL 2233mm LONG
H2233
CENTER FRAME KNEE PLATES
ZACO193
CENTER FRAME APEX PLATES
ZACO194
SET OF INSTRUCTIONS
SELF DRILLING SCREWS
Fast 200
HEX HEAD TEK SCREWS
Fast014
SIX HOLE DOOR STRAPS
FAST040
PADBOLTS & HASPS
FAST006
GUTTER BRACKETS
RWG06
ROLLS CYCLONE STRAPPING
FAST040
80 x 40 CHANNEL 100mm LONG
C0100
PURLIN CONNECTION PLATES
ZACO200
SCREWDRIVER BIT
FAST038
POP RIVETS 3mm
FAST009
DOWNPIPE SPOUTS 50mm DIA.
RWG17
84mm BUTT HINGES
FAST028
Part Details (Sheet 5 of 6)

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 8
47
80
47
TYPE 'H'
BRACKETS, PLATES AND ACCESSORIES (CONT.)
QTY DESCRIPTION CHECK QTY DESCRIPTION CHECK
Part Details (Sheet 6 of 6)
GUTTER STOP ENDS
TR25
4
1
400
SET OF ENGINEERS
SPECIFICATIONS
HEX HEAD TEK WITH
NEO WASHERS
FAST035
MPB MULTI-PURPOSE
BRACKETS
BKT17
2
1
13
84mm BUTT HINGES
Fast028
130mm LONG SHAFT
DOOR LOCK
OT010
PADBOLT FAST006
HASP
DOOR STRAP ZAC012A
PURLIN
CONNECTION
PLATE
ZAC0200
KNEE
PLATE
ZA193
APEX
PLATE
ZA194
80 x 80 x 80 Channel
FRONT FRAME H2233
MPB
MULTIPURPOSE
BRACKET (DIFFERENT
HOLES USED
FOR DIFFERENT
APPLICATIONS)
BKT117
DOWNPIPE
SPOUT
RWG17

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 9
CONCRETE SLAB AND FRAME LAYOUT DETAILS
The garage has been designed
so the slab and the external
frame size are the same. The wall
sheeting then overlaps the slab
by a depth of 30mm to form a
water proof joint.
1747
40
1727
40
1747
80 80
5460
40 40 1352 40
7827
5608
605
4398
605
EXTERNAL FRAME SIZE:
3388 x 5460
SLAB SIZE:
3388 x 5460 x 100mm THICK
DIAGONAL DIMENSION
FRONT ENTRY
650 650
100
4308
.
72
135240 13521352
Note: Refer to the attached Engineering drawings for footing sizes in lieu of a slab

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 10
Guide for Connecting Frame Sections
Absco sheds’ frame assemblies are supplied with
10-16x16 self drilling wafer head phillips drive tek
screws
The wafer head minimises distortion to the sheet
cladding once it is fitted to the frame
Ensure that driver bits used to fasten these screws
is phillips drive, as similar alternatives (EG. Pozi
drive) increases the risk of stripping the head of
these screws.
Some holes are pre-punched in Absco sheds’ frame
sections, however the wide range of positions that
most fasteners are required for means that the
remainder have to be drilled as per the connection
being made
A 3mm drill bit is supplied for pre-drilling holes
where self drilling screws may be more difficult to
establish holes with (EG. Fitment of purlin brackets).
Absco sheds’ frame sections are manufactured
from light gauge steel, enabling for the notched
ends or lengths of one frame section to be spread
over the sides of another frame section, boxed
frame section or H-section.
Absco sheds’ frame sections are designed to nest
into one another to create boxed frame sections
Boxed frame sections are only required in some
parts of the entire frame assembly
Boxed frame sections are fastened together using
the fast014 tek screws supplied at 300mm centres
(unless otherwise stated) along the length of each
boxed frame section.
Some connections are designed to fasten more than two parts together. Connections may also not
feature a defined alignment or physical stop.
For these reasons, focus on arranging all parts of a frame assembly or subassembly together (to
the overall sizes and check measurements nominated) using minimal screws. This allows for easier
adjustment to various connections which may be necessary to achieve the overall dimensions and
check measurements that are nominated.
Fit the remaining screws once the frame assembly or subassembly is assembled as per the overall
dimensions and check measurements that are nominated
Boxing Frame Sections
A
A
B
B
HIGH SIDE A
HIGH SIDE B
LOW SIDE B
LOW SIDE A FAST014
FAST014
HIGH SIDE HIGH SIDE
(PRINT) (PRINT)
LOW SIDE LOW SIDE

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 11
Rear Frame
Parts required: 80 x 40 Frame section.
M2833
K1392
C2150
All are single frame
section except
center and midwall
studs
Rear Leg
Rear girt
100mm Bracket
connector
(one on each corner
upright)
2x M2833 Top chord
2x C2150 Corner upright
2x C2633 Centre stud - to box
2x C2335 Midwall stud - to box
2x N2380 Midwall stud - to box
8x K1392 Girt
2x C0100 Bracket connector
2x ZACO200 Purlin connection plate
Box these sections together
1 OFF: C2633 + C2633 Centre stud
2 OFF: C2335 + N2380 Midwall stud
• See the next page for detailed dimensions
• Refer to the engineering drawings for the quantity of screws required at connection points
Secure channels together
with one purlin connection
plate each side.
Tabs to top
C2335
+
N2380
Boxed
C2633
+
C2633
Boxed

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 12
FRAME DIMENSIONS
1412 1392 1392 1412
**5608
**2150
**1150
**140
**2644
FRAME DIMENSIONS - Lay the parts out on your slab or level area as shown. - Check diagonals for squareness, then join all components together with self drilling screws. - Re-check the dimensions, then mark around the outside of the frame with chalk so that you have a template for the remaining frames. - Using the 100mm bracket connectors, box the bottom of the two corner legs as shown on the previous page. - Carefully turn the frame over and fasten with screws on the opposite side.
Note: **Highlighted dimensions identical for rear, center and front frames

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 13
Internal Frame
(2x required)
SINGLE SECTION
80
38
40
Galvanised Channel Part No. Qty Length Pre-Assembly
C2069 8 2069 = 4x Box sections
C2832 8 2832 = 4x Box sections
4x Apex plates
8x Knee plates
Fit the channels which form the
boxed sections together with the
smaller edge neatly inside the
larger edge. Fasten with screws at
300mm spacings where possible.
16mm Self drilling tek screw
use only to form boxed sections.
JOIN PART NUMBERS
C2069 & C2832
PARTS C2069
BOXED TOGETHER
PARTS C2832
BOXED TOGETHER
80
80
2644
2150
6006
5608
• Lay out the boxed sections to the above configuration.
• Use the same layout pattern as the rear frame. Check that both diagonal measurements are equal
to ensure that the frame is square.

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 14
Internal Frame (continued)
(2x required)
Secure apex plates and knee plates to each side of the frame as shown. Use
self drilling screws at every pre-punched location in both knee and apex plates.
Carefully turn frame over, re-check dimensions and diagonals, then fasten plates
in the same manner as the previous page.
Underneath View
Join plates
together with
three screws
Underneath View
Join plates together with three
screws

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 15
Front Frame
Parts required: 80 x 40 Channel
2x M2833
2x C2150
2x R0877
2x R1100
4x K0525
1x J0403
2x K0144
4x 100mm Long Bracket connectors (80x40 channel)
3x C1466 Boxed all five sections together
2x C2199 to form one 4398mm Head Beam
2x Type 'H' Channel 2233mm for Door Mullions
2x Purlin connection plates
Top chords
Corner uprights
Top chord braces
Side diagonal braces
Horizontal girts
Top center vertical strut
Top vertical outer struts
80x80 Channel
Take care to ensure that the
section does not twist during
this procedure.
3) PART C1466
2) PART C2199
R1100
K0525
C2150
K0144
J0403
R0877
S2833
1412
605 4398 605
2209
Keep the first screw 150mm
in from each end.
300mm Lip notch in
515mm from this end in
S2833
Door Mullion
Head Beam
Bracket connector
1x Purlin connection plate each side
(For Purlin
Connection)
Refer to the next page for further details.
• Lay the components as shown above, using the same dimensions as used for the rear frame, and
fasten with screws in the same manner.
• The top chords have special lip notches to allow the insertion of other components as shown on
the following page.

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 16
Front Frame (continued)
others, including some pieces with different notching patterns.

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 17
Frame Configuration
EDGE OF CONCRETE SLAB
Fasten the MPB Brackets to the frames as shown below, while the frames are still laying on the ground
.
6600mmmm
Note: Accuracy is important as any misalignments will stop the side wall girts from fitting properly in
later steps.
Secure brackets to frame uprights with six
self-drilling screws each.
When securing the brackets to the slab, use
the brackets hole that is furthest away from
the slab edge, to prevent the possibility of
the concrete cracking near the slab.
Mark the frame positions out on the slab.
(Refer to page 6 for details)

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 18
Frame Construction
1. Rear Frame
To secure each frame to the slab, move the frame to its marked position. Whilst one
other person holds the frame in position. Mark the hole position of each upright, move
the frame away enough to drill the slab for each anchor, move the frame back and secure
in position.
Rear frame can be supported with
ropes and pegs, or roof purlins
used as braces during this stage.
2. Center Frame Connection
Bend the inside tab at
right angles to secure to
the rear wall girt.
Side
wall
girt
Secure the first center frame to slab. Fit eight side wall girts K1780 at the same height as the rear wall
girts. Secure every connection with two tek screws.
K1780

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 19
Frame Construction
Secure Front Frame
Secure the front frame and side wall girts.
4 OFF: K1780.
Fit the sidewall girts in the same manner as the
rear frame, bending the inner tab 90 degrees.
Secure every connection with two tek screws.
K1780

Absco Industries Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG56552N2
5.64m W x 5.49m D x 2.64m H
Model: CG56552N2 16/10/19 20
Secure Roof Purlins
885566
779966
PURLIN
REAR
FRAME
PURLIN
REAR
FRAME PURLIN
CENTRE
FRAME
PURLIN
PURLIN
CENTRE
FRAME
Fit the roof purlins between each frame as shown, so the top
Secure each roof purlin with two tek screws through each
purlin end tab. (8x tek screws per roof purlin) bend purlin
end tabs as shown.
tek screws may have to be removed, then replaced to
achieve this.
