Absen XD6 User manual

Leading LED Applications
XD6 /XD10
SMD HD OUTDOOR LED Display
HIGH
DEFINITION
FRONT & REAR
SERVICING
WIDE VIEWING
ANGLE
EASY
MAINTENANCE
NOISE
FREE
HIGH
IP RATING
ADVANCED TECHNOLOGY
SMART MONITORING

Leading LED Applications
// ADVANCED MONITORING
// WATERPROOF MODULE
RECEIVING
CARD
STATUS
MODULE
VOLTAGE
CABLE
MALFUNCT.
SENDING
CARD
STATUS
RUNNING
TIME
TEMPERATURE
Monitoring via multiple smart devices
MONITOR
•Without the need for traditional monitoring cards
and cale connections, the XD6 and XD10
make it possible to monitor modules and panels
in real-time.
•Monitor the panel temperature, module
temperature, module voltage, module running time,
module ID etc.
•Instant notication in case of loose module
connections plus pixel tracing.
•XD6/XD10 smart modules display the ID number,
order number, production date, running time,
module current, color coordinates, module voltage
and module temperature.
SMART MODULE
MODULE
ID
ORDER
INFO
PROD.
DATE
RUNNING
TIME
MODULE
CURRENT COLOR
COORD.
SUPPLY
VOLTAGE
MODEL
TEMP.
•A fully enclosed structure with rubber gaskets
and waterproof modules protects the
electronic components from moisture.
Module Front Module Rear

// LIGHT, THIN, CONVENIENT
// FRONT AND REAR MAINTENANCE
Loosen screws Push the module Disassemble the module
170 mm 106 mm
Normal P6 panel weight is over 40 kg/m2XD6 is only 34 kg/m2
•Front maintenance: Using a hex key, rst remove the xed screws
and then pull out the module.
•Rear maintenance: Remove screws, push the module out, hold the handle
and rotate it to pull it through the opening.
Insert hex key Loosen the screws Disassemble the module
•Panel thickness: 106mm,
Saving precious installation space.
•Panel weight: 21kg,
Making delivery and installation hassle free.

PARAMETERS
Specications above are only for your reference.
There‘s no further notication for any change. Please contact Absen for latest spec.
XD6 XD6C
// MODULE CONNECTION
•The module‘s data and power supply have
a parallel connection design, so that in case of
an individual module failure, others will not
be aected.
•External test button.
Parallel ConnectionTest Button
XD10 XD10C
6.66 mm
SMD 2727
6000 nits
1920 Hz
640x960x106 mm
96x144 pixel
21 kg
Aluminium Prole
300x300 mm
16 bit
10.000:1
1600/750
110 ～240 V
630/210 W/m2
-20 ～﹢50 ºC
10% ～ 90%
IP65/IP54
√
√
√
Aluminium Prole
TUV-CE, ETL, FCC, RoHS
Pixel Pitch
Pixel Conguration
Brightness
Refresh Rate
Panel Dimensions (WxHxD)
Pixel per Panel
Panel Weight
Panel Material
Module Dimensions (WxH)
Gray Scale
Contrast Ratio
Viewing Angle (horiz. / vert.)
Input Voltage (AC)
Power consumption (max./avg.)
Operating Temperature
Operating Humidity (RH)
IP Rating (Front/Rear)
Intelligent Monitor
F & R Maintenance
Power / Signal Plug
Power Box Cover Material
Certicate
6.66 mm
SMD 2727
6000 nits
1920 Hz
640x960x106 mm
96x144 pixel
21 kg
Aluminium Prole
300x300 mm
16 bit
10.000:1
1600/750
200 ～240 V
670/223 W/m2
-20 ～﹢50 ºC
10% ～ 90%
IP65/IP54
-
√
-
Aluminium
CCC
10 mm
SMD 2727
6000 nits
3840 Hz
640x960x106 mm
64x96 pixel
21 kg
Aluminium Prole
300x300 mm
16 bit
3000:1
1500/75
110 ～240 V
670/223 W/m2
-20 ～﹢50 ºC
10% ～ 90%
IP65/IP54
√
√
√
Aluminium Prole
TUV-CE, ETL, FCC, RoHS
10 mm
SMD 2727
6000 nits
3840 Hz
640x960x106 mm
64x96 pixel
21 kg
Aluminium Prole
300x300 mm
16 bit
13000:1
1500/75
200 ～240 V
670/223 W/m2
-20 ～﹢50 ºC
10% ～ 90%
IP65/IP54
-
√
-
Aluminium
CCC
// APPLICATIONS
The products are widely used for outdoor advertising in shopping malls, supermarkets, parks, stadiums and similar venues.
Comparable panels often weigh more than 40 kg/m2. XD6 only weighs 34 kg/m2.
Version July 2016 / Shenzen Absen Optoelectronic Co., Ltd reserves the right to modify product design, specications and parameters without further notice.
Photos are used for illustration purpose only as products may dier from these photos. All rights reserved by Shenzen Absen Optoelectronic Co., Ltd.
