ABSTRACTA Plenty Pod User manual

2(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Including the following screws and fasteners for
Plenty Pod medium mobile module
Pos
Art.nr
Pcs
Description
1
543 421 40
6
Screw 5,0 x 90
2
543 424 34
14
Screw 5,0 x 50
3
575 046 04
45
4,2 x 25 screw with drill bit
4
575 045 04
14
4,2 x 14 screw with drill bit
5
543 101 41
15
Wood plug
6
543 410 10
4
Magnet
7
543 410 65
4
Washer for magnet
8
575 020 04
8
Screw for magnets and washer
9
377 001 01
6
UP-bracket (pairs, right-left)
10
1
Carpet set

3(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Required tools
•Spirit-level
•Screwdriver
•Ratchet
•Bit set, Ph, Torx, Insex
•Rubber hammer

4(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24

5(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Mounting.
Start with evening out the floor module which you want to
set up your pod on.
(An uneven floor can especially complicate mounting the glaswalls
and fitting in the door)

6(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Start by placing the floor module on the floor.
Mount the magnet (543 410 10) and washer (543 410 65) on
the MDF parts with screw (575 020 04).

7(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Insert the wood plugs (543 101 41) into the MDF
floor board with a rubber hammer, not a hard
hammer!
Place the floor board on the MDF parts with the
wood plugs.

8(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24

9(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Fix the board with screws (543 424 34). Note, only in
the holes marked below.

10(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Adjust the support legs
Adjust the support legs by screwing them vertically. The adjustment
is performed from above. Make sure that the floor is straight and flat,
the floor should not be able to wobble.
Place the wall module with the electrical socket
first. Fix with screws (543 421 34).

11(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Place the bottom frame profiles.
543 421 40

12(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Place the bottom frame profiles.
Place the frame profile form on the of the vertical profile and make
sure that the hammerhead bolt is fitted into the middle track of the
vertical profile (Fig A). When the hammerhead bolt is inserted into the
track, push the frame profile down to the floor (Fig B). Then tighten the
set screw until the profile is fixed to the vertical frame (Fig D). The edge
of the profile should align with the outer edge of the floor. Repeat
with the profile on the opposite side.
Fig A Fig B
Fig C Fig D

13(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Mount the two separate vertical profile.

14(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Pull the frame out of the floor and screw in the screw from below.

15(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Mount the top horizontal profile between the
vertical profile.
Place the threshold L-profile bracket into the
threshold before placing it into the track of the
vertical profile.

16(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Place the threshold between the two vertical
profiles and squeeze them together so that there
is no gap between them and the threshold.
Drag it down to the floor.

17(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Drill a hole through the L profile.
Screw the threshold and L-profile down to the
floor.
Fixate the L-profile in the vertical profiles.

18(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Fasten the bottom horizontal profile to the floor
with screw (543 421 40)
Mount the last horizontal profile between the
vertical profiles.

19(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Placement of profiles
Socket
Left top and bottom
horizontal profile
Right top and bottom
horizontal profile
Front horizontal
profile
Central pillar
Central pillar
Seperate vertical
profils
Threshold

20(37)
Abstracta AB Mounting Instruction Plenty Pod Medium Mobile 2021-05-24
Fabric wall mounting
Find out which walls are going to have fabric, respectively glasses. For fabric
walls, mount the vertical and horizontal L-profile profiles as shown below.
L-profile
2 pcs 2038 mm
2 pcs 970 mm
L-profile is mounted with screw
(575 045 04, 4,2x14).
Start with the vertical L-profiles,
then the horizontal.
