Abus TVCC34000 User manual

13
Mini dome camera
Version 03/2012
Original operating instructions in English. Retain for future reference!
TVCC34000
TVCC34500

14
Ŝ
Introduction
Dear customer,
Thank you for purchasing this product.
This product complies with current domestic and European regulations. Conformity has
been proven, and all related certifications are available from the manufacturer on request
(www.abus-sc.com).
To maintain this status and to guarantee safe operation, it is your obligation to observe these
operating instructions!
Read the entire operating instructions carefully before putting the product into operation and pay
attention to all operating and safety information!
All company names and product descriptions are trademarks of the corresponding owner.
All rights reserved.
In the event of questions, please contact your local maintenance specialist or dealer.
Disclaimer
These operating instructions have been produced with the greatest care. Should you discover any
missing information or inaccuracies, please let us know about them.
ABUS Security-Center GmbH assumes no liability for technical and typographical errors, and
reserves the right to make changes to the product and operating instructions at any time and
without prior notice.
ABUS Security-Center GmbH is not liable or responsible for direct or indirect damages resulting
from how this product is equipped, how it performs, and how it is used. No forms of guarantee are
accepted for the contents of this document.

15
Important safety information
All guarantee claims are invalid in case of damage caused by non-compliance with
these operating instructions. We cannot be held liable for resulting damages.
In case of material or personal damage caused by improper operation or non-
compliance with the safety notes, we cannot be held liable. All guarantee claims are
invalid in such cases.
The following safety information and hazard notes are not only intended to protect your health, but
also to protect the device from damage. Please read the following points carefully:
xThere are no components inside the product that require servicing. Opening or dismantling the
product invalidates the CE certification and guarantee claims/warranty.
xThe product can be damaged if it is dropped, even from a low height.
xThis device is designed for indoor use.
xInstall the device so that the image sensor is not subjected to direct sunlight. Pay attention to the
installation instructions in the corresponding chapter of these operating instructions.
Avoid the following adverse conditions during operation:
xHumidity that is too high
xExtreme heat or cold
xDirect sunlight
xDust or flammable gases, vapors, or solvents
xStrong vibrations
xStrong magnetic fields (e.g. next to machines or loudspeakers)
xThe camera must not be installed on unstable surfaces
General safety information:
xDo not leave packaging material lying around. Plastic bags, sheeting, polystyrene packaging, etc.,
can pose a danger to children if played with.
xThe surveillance camera contains small parts which could be swallowed, and should be kept out of
reach of children for safety reasons.
xDo not insert any objects into the device through the openings.
xOnly use replacement devices and accessories that are approved by the manufacturer. Do not
connect any non-compatible products.
xPlease pay attention to the safety information and operating instructions for the other connected
devices.
xCheck the device for damage before commissioning. Do not put the device into operation if you detect
any damage.
xAdhere to the operating voltage limits specified in the technical data. Higher voltages could destroy
the device or the IR LEDs, or pose a health risk (electric shock).
When installing the device in an existing video surveillance system, ensure that all devices are
disconnected from the power supply and low-voltage circuit.
If in doubt, have a specialist technician carry out assembly, installation, and connection of the
device. Improper or unprofessional work on the power supply system or domestic installation
puts both you and other persons at risk.
Connect the installations so that the power supply circuit and low-voltage circuit always run
separately from each other. They should not be connected at any point or be able to become
connected as a result of a malfunction.

16
Contents
1. Intended use ............................................................................................................17
2. Explanation of symbols ..........................................................................................17
3. Scope of delivery.....................................................................................................17
4. Features and functions...........................................................................................17
5. Device description...................................................................................................18
5.1 Overview – Model numbers..............................................................................18
5.2 Unpacking the device.......................................................................................18
6. Installation................................................................................................................18
6.1 Installing the camera........................................................................................18
6.2 Power supply....................................................................................................19
6.3 Installing the video cable..................................................................................19
6.4 Aligning the camera .........................................................................................19
7. Maintenance and cleaning......................................................................................20
7.1 Test of function.................................................................................................20
7.2 Cleaning...........................................................................................................20
8. Disposal ...................................................................................................................20
9. Technical data..........................................................................................................21

17
1. Intended use
The mini dome camera is equipped with a high-quality image sensor. It is used for video
surveillance in conjunction with a recording device or surveillance monitor.
For a detailed description of functions, refer to Section 4, “Features and functions”.
Use of this product for other than the described purpose may lead to damage to the
product and other hazards. All other uses are not as intended and will result in the
invalidation of the product guarantee and warranty. No liability can be accepted as a
result. This also applies to any alterations or modifications made to the product.
Read the entire operating manual carefully before putting the product into operation.
The operating manual contains important information on installation and operation.
2. Explanation of symbols
The triangular high voltage symbol is used to warn of the risk of injury or health
hazards (e.g. caused by electric shock).
The triangular warning symbol indicates important notes in these operating instructions
which must be observed.
This symbol indicates special tips and notes on the operation of the unit.
3. Scope of delivery
xMini dome camera
xOperating instructions
xInstallation material (screws, wall plugs)
4. Features and functions
xCompact design for inconspicuous installation
xIntegrated 3.6 mm miniature lens
xHigh resolution of 650 TVL (TVCC34500)
xNoise suppression function and soft WDR function (TVCC34500)
xIR LEDs for night vision (TVCC34500)
xTriaxial camera module

18
5. Device description
5.1 Overview – Model numbers
Item number TVCC34000 TVCC34500
Resolution 540 TVL 650 TVL
Lens 3.6 mm 3.6 mm
IR -

IR swivel filter
(ICR) - 
Operating voltage 12 V DC 12 V DC
5.2 Unpacking the device
Handle the device with extreme care when unpacking it.
If the original packaging has been damaged, inspect the device. If the device shows signs
of damage, then return it in the original packaging and contact the delivery service.
6. Installation
6.1 Installing the camera
IMPORTANT!
The camera must be disconnected from the power supply during installation.
Before you remove the dome, it may be
necessary to remove the screw on the side.
The dome can then be unscrewed
counterclockwise with the dome ring.
Hold the camera at the intended installation
location, mark the mounting holes on the
surface, and drill the holes with a suitable drill.
Use the screws and wall plugs provided to
fasten the camera in place.
After you have mounted the camera and
aligned the camera module, the dome can be
screwed back on. Then refasten the dome with
the screw.

19
6.2 Power supply
Before starting installation, ensure that the power supply system voltage and the rated voltage on
the camera are identical.
(1) Video signal (BNC)
(2) Power supply
12 V DC (5.5 x 2.1 mm)
The cameras have a 12 V DC power supply. Ensure correct polarity when connecting it. A plug-in
power supply unit (round plug, 5.5 mm x 2.1 mm) is provided for the connection.
6.3 Installing the video cable
In order to transmit the video signal to a converter, monitor, or recorder, a coaxial cable of type
RG59 with BNC plug (male) must be connected to the “Video OUT” connection. The cable length to
the next device may not exceed 150 meters. To increase the range, you can install suitable signal
repeaters.
6.4 Aligning the camera
The camera can now be aligned in 3 axes.
Pan (1st axis)
Tilt (2nd axis) Rotation (3rd axis)
(Illustration: TVCC34500)
1
2

20
7. Maintenance and cleaning
7.1 Test of function
Regularly check the technical safety of the product, e.g. check the housing for damage.
If safe operation is no longer possible, cease operating the product and safeguard it against
accidental operation.
Safe operation is no longer possible in the following circumstances:
xThe device shows visible damage.
xThe device no longer works correctly.
xThe device has been stored in adverse conditions for a long period of time.
xThe device has been subjected to stress during transportation.
Please note:
This product is maintenance-free for you. There are no components to service or
anything inside the product to check. Never open it.
7.2 Cleaning
Clean the device with a clean, dry cloth. The cloth can be dampened with lukewarm water if it gets
dirty.
Ensure that liquid does not penetrate the device, as this will cause damage. Do not use
any chemical cleaning products, as they could damage the surface of the housing.
8. Disposal
Devices displaying this symbol may not be disposed of as domestic waste. At the
end of its service life, dispose of the product according to the applicable legal
requirements.
Please contact your dealer or dispose of the products at the local collection point
for electronic waste.

21
9. Technical data
Model number TVCC34000 TVCC34500
Image sensor 1/3'' Sharp CCD 1/3" Sony Exview HAD II
CCD
DSP Nextchip Sony Effio-E
Camera type Mini dome camera
Resolution 540 TVL 650 TVL
Pixels (total) 795(H) x 596(V) 1020(H) x 596(V)
Pixels (effective) 752(H) x 582(V) 976(H) x 582(V)
Lens 3,6 mm, fixed lens
Horizontal angle of view 78°
Lens control AES
Day/night switching - IR swivel filter (ICR),
color/B&W
Minimum illumination (color) 0,3 lux @ F2.0 0,1 lux @ F2.0
Minimum illumination (IR) - 0 lux @ F2.0
Noise suppression - 2D DNR
Electronic shutter 1/50 sec – 1/100.000 sec
White balance AWB, 2700 - 9500 K ATW, 1800 - 10500 K
Gain control Auto
Backlight compensation BLC Soft WDR
Dynamic range (WDR) - 46 dB
Video system PAL
Synchronization Internal
IR LEDs - 12 IR LEDs
IR range - 5 meters
Connections 1 x BNC (FBAS, 1Vp-p, 75 ohm),
1 x DC (5,5 x 2,1 mm)
Power supply 12 V DC
Power consumption 75 mA 170 mA
Operating temperature 0 °C ~ +50 °C
Humidity 0 ~ 85% (non-condensing)
Protection class IP34
Dimensions (H x D) 75 x 105 mm
Weight 210 g
Certifications CE, RoHS, REACH
